Sharding and Scaling Your Database

Determining a data storage solution as your web application scales can be the most difficult part of web development, and takes time away from developing application features. MongoDB, Redis, Postgres, Riak, Cassandra, Voldemort, NoSQL, MySQL, NewSQL — the options are overwhelming, and all claim to be elastic, fault-tolerant, durable, and give great performance for both reads and writes. This talk will describe these different storage solutions and explain what is really important when choosing a datastore — your application data schema and feature requirements. You’ll learn how to think about scaling, consistency, sharding, and fault-tolerance, and most importantly, you’ll be able to start building your web application with confidence knowing that you can scale when the time comes.

Presented at Future Insights Live, Las Vegas, NV

Transcript

1. Sharding  and  Scaling
   Your  Database
   Neha  Narula
   @neha
   May  1,  2013


   View Slide

2. What  to  Think  About  When
   Building  Your  ApplicaCon
   Neha  Narula
   @neha
   May  1,  2013


   View Slide

3. @neha
   Froogle
   Blobstore
   NaCve  Client


   View Slide

4. In  This  Talk
   What  to  think  about  when
   choosing  a  datastore  for  a  web
   applicaCon


   View Slide

5. Every  so  oKen…
   Friends  ask  me  for  advice  when
   they  are  building  a  new
   applicaCon


   View Slide

6. Friend


   View Slide

7. “Hi  Neha!    I  am  making  a  new
   applicaCon.


   View Slide

8. I  have  heard  MySQL  sucks  and  I
   should  use  NoSQL.


   View Slide

9. I  am  going  to  be  iteraCng  on  my  app
   I  don’t  have  any  customers  yet
   And  my  current  dataset  is  Cny
   But…


   View Slide

10.  Can  you  tell  me  which  NoSQL
    database  I  should  use
    And  how  to  shard  it?”


    View Slide

11. Me


    View Slide

12. hWp://knowyourmeme.com/memes/facepalm


    View Slide

13. View Slide

14. View Slide

15. Hype


    View Slide

16. What  to  think  about  when
    choosing  a  datastore  for  a  web
    applicaCon
    Hint:  Not  Scaling


    View Slide

17. Outline
    SQL,  NoSQL,  and  sharding
    Stages  of  development
    Sharding  myths


    View Slide

18. Outline
    SQL,  NoSQL,  and  sharding
    Stages  of  development
    Sharding  myths


    View Slide

19. SQL
    •  SQL:    Query  language
    •  Features:    ACID

    SELECT  descripCon  FROM  conferences
    WHERE  name  =  “Future  Insights  Live”;


    View Slide

20. SQL/NoSQL


    View Slide

21. NoSQL
    •  Key/Value  store
    •  Document  stores
    •  Simple,  less  restricCve

    GET  “filive_descripCon”


    View Slide

22. Sharding
    •  Split  data  between  mulCple  servers
    •  One  way  of  gecng  beWer  performance

    sh.shardCollection(“records.conferences”,
    {“name”:1 })



    View Slide

23. Database
    Example  Sharded
    Database
    Database
    Database
    Database


    View Slide

24. Outline
    SQL,  NoSQL,  and  sharding
    Stages  of  development
    Sharding  myths


    View Slide

25. Prototype   Launch   Scale


    View Slide

26. Prototype


    View Slide

27. First  five  minutes  –
    what’s  it  like?
    Idea  credit:  Adam  Marcus,  The  NoSQL  Ecosystem,  HPTS  2011

    via  JusCn  Sheehy  from  Basho


    View Slide

28. First  Five  Minutes:  Redis
    hWp://simonwillison.net/2009/Oct/22/redis/


    View Slide

29. First  Five  Minutes:  MySQL


    View Slide

30. Developing
    •  MulCple  people  working  on  the  same  code
    •  TesCng  new  features  =>  new  access  paWerns
    •  New  person  comes  along…


    View Slide

31. Redis
    Time  to  go  get
    lunch


    View Slide

32. MySQL


    View Slide

33. Launch


    View Slide

34. QuesCons
    •  What  is  your  mix  of  reads  and  writes?
    •  How  much  data  do  you  have?
    •  Do  you  need  transacCons?
    •  What  are  your  access  paWerns?
    •  What  will  grow  and  change?
    •  What  do  you  already  know?


    View Slide

35. Reads  and  Writes
    •  Write  opCmized  vs.  Read  opCmized
    •  MongoDB  used  to  have  a  global  write  lock
    – Now  a  lock  per  database  (version  2.2)
    •  No  concurrent  writes!


    View Slide

36. Size  of  Data
    •  Does  it  fit  in  memory?
    •  Do  you  have  another  persistent  store?
    •  Worst  case,  Redis  needs  2X  the  memory  of
    your  data!


    View Slide

37. •  Performance
    Latency  tolerance
    •  Durability
    Data  loss  tolerance
    •  Consistency
    Weird  result  tolerance
    •  Availability
    DownCme  tolerance


    View Slide

38. Performance
    •  RelaConal  databases  are  considered  slow
    •  But  they  are  doing  a  lot  of  work!
    •  SomeCmes  you  need  that  work,  someCmes
    you  don’t.


    View Slide

39. Flexibility  vs.  Performance
    •  We  might  want  to  pay  the  overhead  for  query
    flexibility
    •  In  a  primary  key  datastore,  we  can  only  ask
    queries  on  primary  key,  but  they  are  generally
    faster
    •  SQL  gives  us  flexibility  to  change  our  queries,
    but  might  be  slow


    View Slide

40. Safeness  vs.  Performance
    •  Being  safe  is  slow
    •  TransacCons
    •  WriCng  to  disk


    View Slide

41. •  Performance
    Latency  tolerance
    •  Durability
    Data  loss  tolerance
    •  Consistency
    Weird  result  tolerance
    •  Availability
    DownCme  tolerance


    View Slide

42. Durability
    •  Really  persistent  datastores
    •  No  data  loss  or  corrupCon


    View Slide

43. Durability
    1.  Client:    write
    2.  Server:  flush  to  disk
    3.  Server:  Send  done
    4.  Server  CRASH
    5.  Server  recover
    6.  Client:  see  the  write


    View Slide

44. No  Durability
    App   Datastore
    Buy
    shoes
    Ship
    Neha
    Shoes
    Charge
    $100
    Write


    View Slide

45. Bad  Defaults

    By  default,  MongoDB  does  not  fsync()  before
    returning  to  client  on  write
    – Need  j:true

    By  default,  MySQL  uses  MyISAM  instead  of
    InnoDB


    View Slide

46. DeleCon
    •  Know  your  laws!
    •  Purge  backups  and  copies


    View Slide

47. •  Performance
    Latency  tolerance
    •  Durability
    Data  loss  tolerance
    •  Consistency
    Weird  result  tolerance
    •  Availability
    DownCme  tolerance


    View Slide

48. How  Messed  Up  Can  Things  Get?


    View Slide

49. Consistency
    •  ApplicaCon  business  logic
    •  Ask  yourself:  How  bad  can  things  get?    What’s
    ok  to  show  the  user?
    •  Compromise  for  performance


    View Slide

50. •  Performance
    Latency  tolerance
    •  Durability
    Data  loss  tolerance
    •  Consistency
    Weird  result  tolerance
    •  Availability
    DownCme  tolerance


    View Slide

51. Availability
    •  Expect  failures
    •  What  happens  when  a  datacenter  goes  down?


    View Slide

52. Scale


    View Slide

53. SpecializaCon
    •  You  know  your
    – query  access  paWerns  and  traffic
    – consistency  requirements
    •  Design  specialized  lookups
    – TransacConal  datastore  for  consistent  data
    – Memcached  for  staCc,  mostly  unchanging  content
    – Redis  for  a  data  processing  pipeline
    •  Know  what  tradeoffs  to  make


    View Slide

54. Ways  to  Scale
    •  Reads
    – Cache
    – Replicate
    – Shard
    •  Writes
    – Shard  data  amongst  mulCple  servers



    View Slide

55. Cache
    Database
    Cache
    App


    View Slide

56. Replicate
    Database
    App
    Database
    App


    View Slide

57. Outline
    SQL,  NoSQL,  and  sharding
    Stages  of  development
    Sharding  myths


    View Slide

58. Lots  of  Folklore


    View Slide

59. Myth
    NoSQL  scales  beWer  than  a
    relaConal  database


    View Slide

60. Tell  These  Guys


    View Slide

61. Post  Page
    SELECT * "
    FROM comments"
    WHERE post_id = 100"
    "

    zrange comments:100 0 -1"



    View Slide

62. Example  Sharded
    Database
    Database
    Database
    Database
    comments table
    post_id"
    100-199"
    0-99"
    200-199"
    Webservers


    View Slide

63. MySQL
    MySQL
    MySQL
    Query  Goes  to  One
    Shard
    MySQL
    MySQL
    MySQL
    Comments
    on  post  100
    100-199"
    0-99"
    200-299"


    View Slide

64. MySQL
    MySQL
    MySQL
    Many  Concurrent
    Queries
    MySQL
    MySQL
    MySQL
    Comments
    on  post  100
    100-199"
    0-99"
    200-299"
    Comments
    on  post  52
    Comments
    on  post  289


    View Slide

65. Complex  Queries
    SELECT * "
    FROM friends, statuses"
    WHERE friends.f1 = “neha”"
    AND statuses.user = friends.f2"
    "
    "
    GET neha_friends
    for each friend in friends
    GET friend_status


    View Slide

66. MySQL
    MySQL
    MySQL
    Complex  Queries
    MySQL
    MySQL
    MySQL
    JOIN  Query


    View Slide

67. MySQL
    MySQL
    MySQL
    Concurrent  Complex
    Queries
    MySQL
    MySQL
    MySQL
    JOIN  Query
    JOIN  Query
    JOIN  Query


    View Slide

68. NoSQL  App  JOIN
    Several  GET
    queries
    NoSQL  key/
    value  stores


    View Slide

69. Concurrent  NoSQL
    App  Joins
    Several  GET
    queries
    Several  GET
    queries
    Several  GET
    queries


    View Slide

70. Lessons  Learned
    •  Don’t  worry  at  the  beginning:  Use  what  you
    know
    •  Know  your  applicaCon,  make  the  right
    tradeoffs
    •  Not  about  SQL  vs.  NoSQL  systems  –  about
    simple  vs.  complex  applicaCon  queries


    View Slide

71. Thanks!
    @neha
    narula@mit.edu
