Using Vagrant, Docker, & Terraform for environments

Nikhil Vaze
September 28, 2015

Using Vagrant, Docker, & Terraform for environments

Talk given at HashiConf 2015 on 9/28/2015 in Portland, Oregon.

This was a 50 minute talk centered around how Electric Cloud identified certain problems, came up with requirements and found solutions.

There was a focus on how to gather consensus within an organization and how I would explain these technologies to others.

Nikhil Vaze

September 28, 2015
Tweet

More Decks by Nikhil Vaze

Other Decks in Technology

Transcript

  1. © Electric Cloud | electric-cloud.com
    Nikhil Vaze | @therealnikhil | HashiConf 2015
    USING VAGRANT, DOCKER AND TERRAFORM
    TO STREAMLINE YOUR DEV AND DEMO
    ENVIRONMENTS

    View Slide

  2. © Electric Cloud | electric-cloud.com
    Introductions
    Nikhil Vaze
    https://github.com/nikhilv
    @therealnikhil
    Senior Software Engineer at Electric Cloud
    Full stack engineer and loves to hack on things.
    Johns Hopkins University Alum

    View Slide

  3. © Electric Cloud | electric-cloud.com
    I love tools that make my life easier!
    Vagrant
    Docker
    Terraform

    View Slide

  4. © Electric Cloud | electric-cloud.com
    DEV
    OPS
    Electric Cloud: Powering Continuous Delivery
    ElectricFlow
    Deploy
    Pipeline Management and Visibility
    ElectricAccelerator
    Build & Test Acceleration
    DevOps Automation Platform (ElectricFlow)
    Build
    DELIVERY
    Plugs right in to
    your existing tools
    CONTINUOUS
    Build Test

    View Slide

  5. © Electric Cloud | electric-cloud.com
    I spend my time on integrations
    Source Control, Defect Tracking, Databases,
    Clouds, Testing tools , Application Servers….

    View Slide

  6. © Electric Cloud | electric-cloud.com
    The dark days before
    Vagrant...
    2010-2013

    View Slide

  7. © Electric Cloud | electric-cloud.com
    Our situation in 2010
    • One engineering site (Sunnyvale, CA)
    • All engineers were in one room, on the
    same schedule.
    • Code reviews were done informally by
    calling someone over to your desk.
    • Engineers documented setup on wiki.
    Other employees expected to follow.

    View Slide

  8. © Electric Cloud | electric-cloud.com
    Show of hands
    Who has been
    burned following a
    wiki document?

    View Slide

  9. © Electric Cloud | electric-cloud.com
    How to start a code review in 2010?

    View Slide

  10. © Electric Cloud | electric-cloud.com
    The company grows - 2012
    • We were lucky enough
    to grow.
    • Added three new sites in
    three different time
    zones.
    • New employees? Read
    this wiki!

    View Slide

  11. © Electric Cloud | electric-cloud.com
    “I tried reading the wiki…”
    • Information out of date
    • Incomplete information
    • Couldn’t find it
    • Person who can answer
    the question to unblock
    you is asleep.

    View Slide

  12. © Electric Cloud | electric-cloud.com
    No Problem! I’ll just update the wiki

    View Slide

  13. © Electric Cloud | electric-cloud.com
    How to install our product on AWS EC2?

    View Slide

  14. © Electric Cloud | electric-cloud.com
    “I tried reading the wiki…”
    • Information out of date
    • Incomplete information
    • Couldn’t find it
    • Person who can answer
    the question to unblock
    you is asleep.

    View Slide

  15. © Electric Cloud | electric-cloud.com
    What were the problems?
    • Wiki was out of date.
    • Our software was getting harder to
    setup.
     For example: we introduced support
    for clustering
    • Found ourselves spending more time
    troubleshooting individual environments
    instead of product issues.

    View Slide

  16. © Electric Cloud | electric-cloud.com
    After spending a day on a configuration issue

    View Slide

  17. © Electric Cloud | electric-cloud.com
    There has to be a better way ~ 2013
    How do we create development
    environments such that they can
    be:
    • reconstructed
    • shared
    • local to each tester
    • deployed into an automated test
    environment

    View Slide

  18. © Electric Cloud | electric-cloud.com
    Side note: Cultural Observation
    • What worked well and got you this far
    may not be the thing to get you the
    next level.
     It’s hard because the people suffering
    may be new to the organization
     It’s very natural to think “But it has
    worked for us so well!”

    View Slide

  19. © Electric Cloud | electric-cloud.com
    Partly Cloudy Days: Adopting better
    tooling ~2013

    View Slide

  20. © Electric Cloud | electric-cloud.com
    “If it hurts, do it more
    frequently, and bring
    the pain forward.”
    Jez Humble

    View Slide

  21. © Electric Cloud | electric-cloud.com
    Bringing the pain forward:
    • It hurts to construct these
    environments so….let’s do it more
    often!
    • How can we run through the
    process regularly?
    • How can we have documentation
    that is always up to date?

    View Slide

  22. © Electric Cloud | electric-cloud.com
    Introducing Vagrant
     https://www.vagrantup.com/
     Open Source
     Made by HashiCorp
    $ vagrant up (start or create the VM)
    $ vagrant ssh (ssh to the VM)
    $ vagrant halt (stop the VM)
    $ vagrant destroy (destroy the VM)
    $ vagrant package (snapshot the VM)

    View Slide

  23. © Electric Cloud | electric-cloud.com
    Vagrant up

    View Slide

  24. © Electric Cloud | electric-cloud.com
    Vagrant ssh

    View Slide

  25. © Electric Cloud | electric-cloud.com
    Vagrant status

    View Slide

  26. © Electric Cloud | electric-cloud.com
    Vagrant destroy

    View Slide

  27. © Electric Cloud | electric-cloud.com
    So…. I know what you’re all thinking
    “Big deal. You just
    described VMs”

    View Slide

  28. © Electric Cloud | electric-cloud.com
    Step 1: Vanilla Vagrantfile
    $ vagrant up

    View Slide

  29. © Electric Cloud | electric-cloud.com
    Step 1.5: Vanilla Vagrantfile
    $ vagrant up

    View Slide

  30. © Electric Cloud | electric-cloud.com
    Step 2: Install software within Vagrantfile

    View Slide

  31. © Electric Cloud | electric-cloud.com
    Step 2: Install software within Vagrantfile

    View Slide

  32. © Electric Cloud | electric-cloud.com
    What problems did Vagrant solve?
    • Simple commands to instantiate and destroy
    • Documentation via code inside Vagrantfile (or shell script invoked
    by Vagrantfile)
    • Check in Vagrantfile. Now available to all developers
    • Each developer can run Vagrant on their laptop
    • Same process can be used in automated testing

    View Slide

  33. © Electric Cloud | electric-cloud.com
    How do I get Vagrant and what do I need to use it?
    • Install Vagrant on each machine where vagrant will be used.
    • Install virtualization provider (VirtualBox).
    • Supported Host Operating Systems:
     Mac OSX
     Windows
     Linux (Debian, RedHat)
    • Vagrant
     http://downloads.vagrantup.com/
    • Oracle VirtualBox
     https://www.virtualbox.org/wiki/Downloads

    View Slide

  34. © Electric Cloud | electric-cloud.com
    Vagrant Tips
    • Your relationship with VirtualBox will be love/hate
    • At a high level, Vagrant uses Ruby to wrap VBoxManage. So if you
    are running into any issues you can open up the VirtualBox UI or
    instrument the ruby code (add puts/print statements)
    • As with all Open Source: read the source, check out the open
    issues. https://github.com/mitchellh/vagrant/
    • Stackoverflow also helpful

    View Slide

  35. © Electric Cloud | electric-cloud.com
    Side note: Cultural Observation
    • When trying to gather consensus or persuade an
    organization to adopt change:
     Identify a problem, formulate a hypothesis and then
    look for a tool/solution.
    • Avoid
     “Oooh shiny technology!”
     “All the cool kids are doing it”
    • Even if you have followed the problem solving steps
    people may still feel like you’re just chasing technology.

    View Slide

  36. © Electric Cloud | electric-cloud.com
    Real emails showing Vagrant adoption

    View Slide

  37. © Electric Cloud | electric-cloud.com
    Next use case: Multi App Server,
    Multi Host Deployments

    View Slide

  38. © Electric Cloud | electric-cloud.com
    Use case : Creating a demo environment
     Jboss/Wildfly
     Domain mode, 3 machines
     Business on the line! Fast fast
    fast!

    View Slide

  39. © Electric Cloud | electric-cloud.com
    Diagram

    View Slide

  40. © Electric Cloud | electric-cloud.com
    Requirements for environment creation
     Definition based
     Reproducible
     Shareable
     Each invocation must be unique to
    an individual

    View Slide

  41. © Electric Cloud | electric-cloud.com
    Cue Terraform

    View Slide

  42. © Electric Cloud | electric-cloud.com
    Introducing Terraform
     https://terraform.io/
     Open Source
     Made by HashiCorp
    $ terraform plan
    $ terraform apply
    $ terraform destroy

    View Slide

  43. © Electric Cloud | electric-cloud.com
    Let’s read some code!
    https://gist.github.com/nikhilv/74a107af7e44866e3f14
    Note: these days terraform’s doc
    have improved. A lot of this is
    available in the aws-two-tier
    example
    https://github.com/hashicorp/terraf
    orm/tree/master/examples/aws-two-
    tier

    View Slide

  44. © Electric Cloud | electric-cloud.com
    Plan
    $ terraform plan -var 'name=nikhilDemo' -var 'key_name=' –var 'key_path='

    View Slide

  45. © Electric Cloud | electric-cloud.com
    Terraform Graph
    $ terraform graph | dot –Tpng > graph.png

    View Slide

  46. © Electric Cloud | electric-cloud.com
    Apply
    $ terraform apply -var 'name=nikhilDemo' -var 'key_name=' –var 'key_path='

    View Slide

  47. © Electric Cloud | electric-cloud.com
    Apply
    $ terraform apply -var 'name=nikhilDemo' -var 'key_name=' –var 'key_path='

    View Slide

  48. © Electric Cloud | electric-cloud.com
    Destroy
    $ terraform destroy -var 'name=nikhilDemo' -var 'key_name=' –var 'key_path='

    View Slide

  49. © Electric Cloud | electric-cloud.com
    Review: Requirements for environment creation
     Definition based
    .tf files
     Reproducible
    Plan -> Apply – Destroy.
     Shareable
    Check into source control
     Each invocation must be unique to
    an individual
    Parametrized scripts

    View Slide

  50. © Electric Cloud | electric-cloud.com
    What problems did Terraform solve?
    • Simple commands to instantiate and destroy cloud VMs
    • Documentation via code inside Terraform files
    • Check in Terraform files. Now available to all developers
    • Each developer can run Terraform on their laptop
    • Save those UI clicks! Write it once in Terraform and build on it
    later

    View Slide

  51. © Electric Cloud | electric-cloud.com
    Terraform Tips
    • Super easy to install and upgrade (directory of executables)
    • Caution: Using Terraform will cost you money with your cloud
    provider!
    • Some syntax is not intuitive. But the documentation has improved.
    • Parameterize and use the graph
    • IMO: Good for demo and short term work. But I wouldn’t use it
    alone to deploy to production

    View Slide

  52. © Electric Cloud | electric-cloud.com
    Next use case: Integrated Software
    Delivery Scenario

    View Slide

  53. © Electric Cloud | electric-cloud.com
    Integrated Software Delivery Scenario

    View Slide

  54. © Electric Cloud | electric-cloud.com
    Delivery Pipeline
    Commit Pipelines

    View Slide

  55. © Electric Cloud | electric-cloud.com
    Interlude: Docker overview

    View Slide

  56. © Electric Cloud | electric-cloud.com
    Docker
    • https://docker.io/
    • Open Source
    • Used to wrap LXC, now has its own container implementation
    • Really, really fast. Start measuring in milliseconds

    View Slide

  57. © Electric Cloud | electric-cloud.com
    Docker 102 – Different drivers

    View Slide

  58. © Electric Cloud | electric-cloud.com
    Docker 102 containers vs. VMs

    View Slide

  59. © Electric Cloud | electric-cloud.com
    Back to the use case

    View Slide

  60. © Electric Cloud | electric-cloud.com
    Use case : Simulating ‘Big Data Software Team’
     Pieces
     Front End
     Dashing Dashboard
     Database
     Redis
     Backend
     Ratpack Server

    View Slide

  61. © Electric Cloud | electric-cloud.com
    Use case : Simulating ‘Big Data Software Team’
    Communication paths
     ELB-> instance(s)
     Backend -> DB
     Frontend -> Backend
     IoT -> ELB / Backend
     Mobile Device -> ELB /
    Backend

    View Slide

  62. © Electric Cloud | electric-cloud.com
    Use case : Simulating ‘Big Data Software Team’
     How does the Front end know
    the IP the backend gets
    spawned at?
     How does the Back end know
    the IP the database gets
    spawned at?
     How does the ELB know about
    the two availability zones?
    What is the criteria for the
    health check?

    View Slide

  63. © Electric Cloud | electric-cloud.com
    Technologies used
     Didn’t use Terraform
     Regretted it. All my setup is now bespoke and won’t be easy to re-use
     Lost: ELB (Health Check, Port forward and instances), VPC, Subnets, EC2
    instance data
     Decided Docker would be the way to go from “dev” to “production”
     Easy to simulate pieces locally on dev laptop and then run same thing in
    AWS.
     Was easy to share with others working on the same demo
     Feel confident that I could go back to the source for a future demo

    View Slide

  64. © Electric Cloud | electric-cloud.com
    “Demo”

    View Slide

  65. © Electric Cloud | electric-cloud.com
    Pictures because I didn’t want to bring this on a plane

    View Slide

  66. © Electric Cloud | electric-cloud.com
    Docker Tips
    • Where do you save, version and test your containers?
    • Your disk usage will skyrocket. One reason Docker is fast is
    because it caches intermediate layers.
    • As with all Open Source: read the source, check out the open
    issues. https://github.com/docker/docker
    • Check out Greg Osuri’s guide on Guide to automating a multi-
    tiered application securely on AWS with Docker and Terraform
    https://www.airpair.com/aws/posts/ntiered-aws-docker-terraform-guide

    View Slide

  67. © Electric Cloud | electric-cloud.com
    Wrap up

    View Slide

  68. © Electric Cloud | electric-cloud.com
    Vagrant, Terraform, Docker FTW!
    • It’s an exciting time to be in software
    • Warning bells should go off if you keep
    clicking on a UI.
    • Organization and structure increase
    velocity and confidence
    • Drift is minimized if the ‘documentation’
    is exercised regularly
    • You will find bugs or areas where
    documentation could be improved

    View Slide

  69. © Electric Cloud | electric-cloud.com
    Thank you
    Networking
    Other Systems
    ISV, Internet
    & Entertainment
    Heavy Industry
    Financial
    Services
    Automotive Medical Devices
    Semiconductor
    Aerospace /
    Defense
    Mobile Devices
    Q&A

    View Slide
