Auto-scaling containers with KEDA

Slide deck of the presentation done at Ground Labs demonstrating KEDA capabilities. The talk focused on different options ofr scaling in Kubernetes cluster. The demo covered the auto scaling options based on events using KEDA project.


Nilesh Gule

September 27, 2019

More Decks by Nilesh Gule

Other Decks in Programming


  1. Auto-Scaling containers with Nilesh Gule @nileshgule | www.HandsOnArchitect.com

  2. $whoami { “name” : “Nilesh Gule”, “website” : “https://www.HandsOnArchitect.com", “github”

    : “https://github.com/NileshGule" “twitter” : “@nileshgule”, “linkedin” : “https://www.linkedin.com/in/nileshgule”, “email” : “nileshgule@gmail.com", “likes” : “Technical Evangelism, Cricket” }
  3. None
  4. None
  5. None
  6. Pros Cons Scale k8s objects: Kubectl scale –replicas=3 processor-deployment.yml Kubectl

    scale –replicas=3 deployment/rabbitmq-consumer Scale AKS cluster: az aks scale --resource-group myResourceGroup \ --name myAKSCluster \ --node-count 5 \ --nodepool-name <your node pool name>
  7. Pros Cons kubectl autoscale deployment php-apache \ --cpu-percent=50 \ --min=1

    \ --max=10
  8. None
  9. Pros Cons

  10. Pros Cons

  11. Kubernetes-based Event Driven Autoscaling

  12. None
  13. None
  14. Azure Event Hub Azure Service Bus Queues and Topics Azure

    Storage Queues Kafka Prometheus RabbitMQ Redis Lists Liiklus AWS CloudWatch AWS Simple Queue Service GCP PubSub Integrates with Azure functions
  15. Demo Autoscaling Storage Queue consumer with ACI

  16. 5000 messages

  17. apiVersion: keda.k8s.io/v1alpha1 kind: ScaledObject metadata: name: hello-keda namespace: default labels:

    deploymentName: hello-keda spec: scaleTargetRef: deploymentName: hello-keda pollingInterval: 5 # Optional. Default: 30 seconds maxReplicaCount: 15 # Optional. Default: 100 triggers: - type: azure-queue metadata: name: myQueueItem type: queueTrigger direction: in queueName: js-queue-items connection: AzureWebJobsStorage
  18. Demo Autoscaling RabbitMQ

  19. https://github.com/NileshGule/AKS-learning-series

  20. 1000 messages Batch of 10 messages

  21. apiVersion: keda.k8s.io/v1alpha1 kind: ScaledObject metadata: name: rabbitmq-consumer namespace: default labels:

    deploymentName: rabbitmq-consumer spec: scaleTargetRef: deploymentName: rabbitmq-consumer pollingInterval: 5 # Optional. Default: 30 seconds cooldownPeriod: 30 # Optional. Default: 300 seconds minReplicaCount: 1 # Optional. Default: 0 maxReplicaCount: 30 # Optional. Default: 100 triggers: - type: rabbitmq metadata: queueName: hello host: 'amqp://user:PASSWORD@rabbitmq.default.svc.cluster.local:5672’ queueLength : '5'
  22. AKS cluster-autoscalar Virtual Node Horizontal pod autoscale virtual kubelet KEDA

    Azure Function with Queue
  23. None
  24. None
  25. Thank you very much Code with Passion and Strive for

    Excellence https://github.com/NileshGule/AKS-learning-series https://github.com/NileshGule/pd-tech-fest-2019 https://github.com/NileshGule/sample-dotnet-core-rabbitmq-keda https://www.slideshare.net/nileshgule/presentations https://speakerdeck.com/nileshgule/
  26. Q&A
