Rapid development of enterprise web apps with Netzke

RubyKaigi 2013, Tokyo: http://rubykaigi.org/2013/talk/S34

Transcript

1. Rapid development of enterprise
   web apps with Netzke
   Max Gorin (@uptomax)


   View Slide

2. Max Gorin
   author and maintainer of Netzke
   on Rails since 2007
   nomad since 2008
   Dvorak, vim, geekery, speaking, mountains


   View Slide

3. Today's talk
   is about building web apps


   View Slide

4. Not apps that look like this


   View Slide

5. ... but rather like this


   View Slide

6. ... or like this


   View Slide

7. eval
   ?


   View Slide

8. View Slide

9. Enterprise apps
   complex data
   complex workflows
   complex GUI


   View Slide

10. Challenges
    hundreds of data models
    very comlpex views
    monstrous monolitic client side
    decoupled client and server code
    lack of best practices


    View Slide

11. Few of us deal with those
    but those who do - are in pain


    View Slide

12. I'm here to ease the pain


    View Slide

13. Let's have a closer look


    View Slide

14. Repeated GUI elements


    View Slide

15. Repeated GUI elements


    View Slide

16. Repeated GUI elements


    View Slide

17. ... and most probably more


    View Slide

18. Devide and conquer!


    View Slide

19. Modular GUI development
    old proven concept
    used for building complex apps
    does Rails cooperate?
    and Cells
    lack of consistent front-end
    lack of pre-built components


    View Slide

20. Netzke
    client-server GUI components for web


    View Slide

21. Netzke component


    View Slide

22. Sencha Ext JS


    View Slide

23. Why Ext JS
    consistent, themable look
    tons of feature-rich components
    programmable views


    View Slide

24. Our arms
    reusability
    extensibility (OOP)
    modular development
    debugging and testing
    composability
    dynamic loading


    View Slide

25. Our score?
    MAINTAINABLE CODE


    View Slide

26. Floralogic app


    View Slide

27. Cargologic


    View Slide

28. Order flow


    View Slide

29. Roles


    View Slide

30. Models and associations


    View Slide

31. Let's see how Netzke can help


    View Slide

32. Everest Region, Nepal, ~5300m


    View Slide

33. Reusability


    View Slide

34. Models


    View Slide

35. Contacts
    class Contacts < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "Contact"
    end
    end


    View Slide

36. Netzke::Basepack::Grid
    CRUD
    pagination
    sorting
    filtering
    association support
    on-the-fly column configuration
    and more


    View Slide

37. A component is worth nothing
    ...unless it is configurable and extendable


    View Slide

38. Setting data model
    class Contacts < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "Contact"
    end
    end
    •◦◦


    View Slide

39. Setting data model
    class Carriers < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "Carrier"
    end
    end
    ◦•◦


    View Slide

40. Setting data model
    class PackingTypes < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "PackingType"
    end
    end
    ◦◦•


    View Slide

41. Netzke::Basepack::Grid configuration
    model
    columns
    permissions
    scope
    strong attributes
    and more


    View Slide

42. Our arms
    reusability ✓
    extensibility (OOP)
    modular development
    composability
    dynamic loading


    View Slide

43. Extensibility


    View Slide

44. Netzke component is Ruby class


    View Slide

45. Duplication
    class Contacts < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "Contact"
    end
    end
    class Carriers < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "Carrier"
    end
    end
    class PackingTypes < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = "PackingType"
    end
    end


    View Slide

46. Better
    class GridBase < Netzke::Basepack::Grid
    def configure(c)
    super
    c.model = self.class.name.singularize
    end
    end
    # Now:
    class Contacts < GridBase
    end
    class Carriers < GridBase
    end
    class PackingTypes < GridBase
    end
    # etc


    View Slide

47. Shared changes
    class GridBase < Netzke::Basepack::Grid
    # hide the created_at and updated_at columns
    column :created_at do |c|
    c.excluded = true
    end
    column :updated_at do |c|
    c.excluded = true
    end
    def configure(c)
    super
    c.model = self.class.name.singularize
    end
    end


    View Slide

48. Nothing new to you
    you are Ruby developers!
    what about the client side?


    View Slide

49. Shipments


    View Slide

50. Shipments


    View Slide

51. Code structure
    floralogic/
    app/
    components/
    shipments/
    grid.rb  


    View Slide

52. Code structure
    floralogic/
    app/
    components/
    shipments/
    grid.rb grid/
    javascripts/
    grid.js

    View Slide

53. grid.js
    {
    initComponent: function(){
    this.features = this.features || [];
    this.features.push({ ftype: 'grouping' });
    this.callParent();
    }
    }


    View Slide

54. What goes to JS
    overrides
    event handlers
    any client-side logic
    more on this in a few minutes


    View Slide

55. Extending with Ruby mixins
    attachment management for orders and shipments


    View Slide

56. class Shipments::Grid < GridBase
    include Floralogic::Netzke::Attachments
    # ...
    end


    View Slide

57. class Shipments::Grid < GridBase
    include Floralogic::Netzke::Attachments
    # ...
    end


    View Slide

58. class Shipments::Grid < GridBase
    include Floralogic::Netzke::Attachments
    # ...
    end


    View Slide

59. class Shipments::Grid < GridBase
    include Floralogic::Netzke::Attachments
    # ...
    end


    View Slide

60. Our arms
    reusability ✓
    extensibility (OOP) ✓
    modular development
    composability
    dynamic loading


    View Slide

61. View Slide

62. View Slide

63. Modular development


    View Slide

64. Floralogic app


    View Slide

65. Floralogic app


    View Slide

66. Filters in Orders::Grid


    View Slide

67. Tests first!


    View Slide

68. Testing code structure
    floralogic/
    spec/
    mocha/
    fixtures/
    orders/
    grid.rb orders/
    grid.js.coffee support/
    ... mocha_spec.rb

    View Slide

69. Fixtures
    seller1 = FactoryGirl.create :seller, short_name: 'One'
    seller2 = FactoryGirl.create :seller, short_name: 'Two'
    cargo1 = FactoryGirl.create :cargo_type, name: 'CARGO ONE'
    cargo2 = FactoryGirl.create :cargo_type, name: 'CARGO TWO'
    FactoryGirl.create :order,
    seller: seller1, cargo_type: cargo1
    FactoryGirl.create :order,
    seller: seller1, cargo_type: cargo2
    FactoryGirl.create :order,
    seller: seller2, cargo_type: cargo1
    # ...


    View Slide

70. Mocha specs
    describe 'Orders::Grid', ->
    it 'searches by seller', (done) ->
    wait ->
    expect(gridCount('Orders')).to.eql 5
    select 'One', from: combo('seller_id')
    wait ->
    expect(gridCount('Orders')).to.eql 3
    select 'Two', from: combo('seller_id')
    wait ->
    expect(gridCount('Orders')).to.eql 2
    done()


    View Slide

71. Running specs


    View Slide

72. Our arms
    reusability ✓
    extensibility (OOP) ✓
    modular development ✓
    composability
    dynamic loading


    View Slide

73. Composability


    View Slide

74. We've seen how to split things apart


    View Slide

75. Now let's see how to put them together


    View Slide

76. Composability in Floralogic


    View Slide

77. Orders::Grid nested in...


    View Slide

78. ShipmentsAndOrders nested in...


    View Slide

79. Workspace nested in...


    View Slide

80. Application


    View Slide

81. ShipmentsAndOrders


    View Slide

82. ShipmentsAndOrders component
    one-to-many relationship


    View Slide

83. ShipmentsAndOrders component


    View Slide

84. ShipmentsAndOrders: nesting
    class ShipmentsAndOrders < Netzke::Base
    js_configure do |c|
    c.layout = :border
    end
    component :shipments do |c|
    c.klass = Shipments::Grid
    c.region = :center
    end
    component :orders do |c|
    c.klass = Orders::Grid
    c.region = :south
    c.height = 300
    end
    def configure(c)
    super
    c.items = [:shipments, :orders]
    end
    end


    View Slide

85. Client-side code
    initComponent: function(){
    this.callParent();
    var shipments = this.netzkeGetComponent('shipments'),
    orders = this.netzkeGetComponent('orders');
    shipments.on('itemclick', function(view, record){
    // call endpoint
    this.serverSelectShipment(record.get('id'));
    orders.getStore().load();
    }, this);
    }


    View Slide

86. Select shipment at server
    class ShipmentsAndOrders < Netzke::Base
    endpoint :server_select_shipment do |id, this|
    # dept: authorization
    component_session[:selected_shipment_id] = id
    end
    component :orders do |c|
    c.klass = Orders::Grid
    c.shipment_id = component_session[:selected_shipment_id]
    c.region = :south
    c.height = 300
    end
    # ...
    end


    View Slide

87. Orders::Grid
    module Orders
    class Grid < GridBase
    def configure(c)
    super
    c.model = "Order"
    if c.shipment_id
    c.scope = {
    shipment_id: c.shipment_id
    }
    c.strong_default_attrs = {
    shipment_id: c.shipment_id
    }
    end
    end
    # ...
    end
    end


    View Slide

88. Notes on composability
    nesting components is easy
    by doing it we get new components
    nested doesn't always mean visible
    we can show components on demand
    however...


    View Slide

89. "Complex" app


    View Slide

90. An enterprise app can have hundreds of models
    and even a bigger number of components


    View Slide

91. Loading them all in one go can be costly


    View Slide

92. Our arms
    reusability ✓
    extensibility (OOP) ✓
    modular development ✓
    composability ✓
    dynamic loading


    View Slide

93. Dynamic loading


    View Slide

94. class Shipments::Grid < GridBase
    include Floralogic::Netzke::Attachments
    # ...
    end


    View Slide

95. Dynamic loading
    server side
    class Shipments::Grid < GridBase
    component :attachment_window do |c|
    c.klass = Attachment::Window
    end
    # ...
    end


    View Slide

96. Dynamic loading
    client side
    onManageAttachments: function(){
    var row = this.getSelectionModel().selected.first();
    if (row) {
    this.netzkeLoadComponent('attachment_window', {
    clientConfig: { id: row.get('id') },
    callback: function(w){ w.show(); }
    });
    }
    }


    View Slide

97. Conclusion


    View Slide

98. Powerful techniques
    reusability ✓
    extensibility (OOP) ✓
    modular development ✓
    composability ✓
    dynamic loading ✓
    JS encapsulation


    View Slide

99. Final notes
    Netzke component != data grid
    use Netkze Core to build any reusable GUI element
    that needs to talk to the server
    forms, trees, dynamic layouts with persistence, photo
    galeries, charts, etc


    View Slide

100. I love building things with Netzke


     View Slide

101. "If I had to develop a webapp like that,
     I would try your framework."
     -- Matz


     View Slide

102. Thanks!
     @uptomax @netzke


     View Slide

103. View Slide
