1. Keep your users
   up-to-date in real-time
   with WebSockets!
   Ondřej Mirtes
   phpDay, May 14th 2016


   View Slide

2. ...is boring!
   There's a much broader set of technologies you can use to your advantage, your users' comfort
   and to lower your monthly hosting bill. Just don't be afraid to try them out.


   View Slide

3. I love using modern technologies that fit the solved problem better.


   View Slide

4. Inspected webpage is doing the same AJAX request over and over again checking if there's
   something new to show to the user.


   View Slide

5. Periodical updates
   Event occurs User is notified about it
   time


   View Slide

6. ½ interval delay

   on average!
   User waits a really long time to see the update. This approach also causes unnecessary server
   strain - building and checking state from clean slate in every request.


   View Slide

7. Event occurs
   Sending to server
   Server processing
   Sending event to client
   User is notified about it
   Push
   time
   With push principle, we leave waiting completely out of the picture, everything happens
   instantly. User is notified immediately. This whole timeline usually happens in tens of ms.


   View Slide

8. WebSockets
   TCP/IP connection, not HTTP (Connection upgrade handshake at the beginning)
   Not request-response, but a two-way stream of messages
   I encourage adopting optimistic UI


   View Slide

9. youtu.be/XrvleVBa6aE
   WebSockets is not only a web technology, you can use it in native mobile apps too.
   Video of a prototype I made shows communication between web and a native app, React.PHP
   server forwards messages behind the scenes.


   View Slide

10. Booking theater seats
    I'd like to show a few cool things I made with WebSockets.


    View Slide

11. Papertrail iOS app & React.PHP backend


    View Slide

12. Notifications about other users editing a page


    View Slide

13. WebSockets in PHP
    Long-running process

    listening on a port


    View Slide

14. PHP is ready for long-running processes. Memory leaks do not happen because of language's
    fault anymore. But it certainly requires more discipline and thinking about memory allocation.


    View Slide

15. WebSockets in PHP
    Asynchronous processing
    PHP is single-threaded, but still capable of asynchronous processing. Waiting happens in the OS.
    Suitable for HTTP requests, SQL queries, filesystem access…


    View Slide

16. WebSockets in PHP
    Event loop
    Handling Events
    Waiting

    for Events
    Core of async programming. Possible with vanilla PHP using stream_select function.

    Use abstraction libraries like React.PHP for nicer code.


    View Slide

17. WebSockets in PHP
    Beware of blocking functions!
    Request 1
    R1 - blocking the thread
    Request 2 Request 3
    R2 R3
    Responses


    View Slide

18. WebSockets in PHP
    Non-blocking – start processing ASAP
    Request 1 Request 2 Request 3
    Event loop controls the flow. PHP process does something useful at all times and does not block.


    View Slide

19. How asynchronous code looks
    $db
    ->query('SELECT url FROM foo')
    ->then(function ($result) {

    return $httpClient->get($result['url']);
    })
    ->then(function ($response) {
    $webSocketClient->send($response->body);
    });
    echo "processing...\n";
    Using promises. The echo is run first because the callbacks are called in the next loop run (tick)
    at the earliest.


    View Slide

20. WebSockets in PHP
    composer require cboden/ratchet


    View Slide

21. Initial setup
    $loop = React\EventLoop\Factory::create();
    $server = new \React\Socket\Server($loop);

    $server->listen(8080, '0.0.0.0');
    new \Ratchet\Server\IoServer(

    new \Ratchet\Http\HttpServer(

    new \Ratchet\WebSocket\WsServer($app)

    ),

    $server

    );

    $loop->run();
    Outside your main app's MVC and router, usually inside Symfony Console.
    $loop->run() blocks – nothing after it gets executed until $loop->stop() is called.


    View Slide

22. $app – \Ratchet\MessageComponentInterface
    function onOpen(ConnectionInterface $conn);
    function onClose(ConnectionInterface $conn);
    function onError(
    ConnectionInterface $conn,
    \Exception $e
    );
    function onMessage(ConnectionInterface $from, $msg);
    Entrypoint to the WebSockets app. Something like a controller – don't make a fat one.
    When client connects, I don't know anything about him, what is he interested in etc.
    The first message should usually be about what the client subscribes to.


    View Slide

23. Simple chat app
    private $clients;
    function __construct() {
    $this->clients = new \SplObjectStorage();
    }
    function onOpen(ConnectionInterface $conn) {
    $this->clients->attach($conn);
    }
    function onClose(ConnectionInterface $conn) {
    $this->clients->detach($conn);
    }


    View Slide

24. Simple chat app
    function onMessage(
    ConnectionInterface $from,
    $msg
    ) {
    foreach ($this->clients as $client) {
    if ($client !== $from) {
    $client->send($msg);
    }
    }
    }
    Avoid sending the message back to the original author.


    View Slide

25. Everything should be asynchronous
    function onMessage(
    ConnectionInterface $from,
    $msg
    ) {
    $this->db->query('...')->then(
    function ($result) use ($from) {
    $from->send($result['foo']);
    }
    );
    }
    Stuff dependent on incoming messages should be async in order not to block the server.
    Async is more complex – anything can happen between the request is sent and the response is
    received. The client could have already been disconnected.


    View Slide

26. Debugging
    /** \Monolog\Logger */
    private $logger;
    function onOpen(ConnectionInterface $conn) {
    $ua = $connection
    ->WebSocket
    ->request
    ->getHeader('User-Agent');
    $this->logger->addDebug('Connected: ' . $ua);
    }
    Use Monolog even for debug output – easy to switch to logging somewhere else

    just by configuration.


    View Slide

27. Timers
    $timer = $loop->addTimer(5, function () {
    echo "5 seconds passed!\n";
    });
    $loop->cancelTimer($timer);
    $loop->addPeriodicTimer(5, function () {
    echo "Every 5 seconds\n";
    });
    Non-blocking alternative to sleep(). Useful in WebSockets for expiration or tracking inactivity.
    Can occur a little bit later – after "waiting for events" loop phase.


    View Slide

28. One process to rule them all
    $_SESSION
    One process handling all requests – global variables like $_SESSION not usable


    View Slide

29. One process to rule them all
    Client Browser
    WebSockets Server HTTP Web Server
    Session Storage
    You need to abstract session storage, session data are connection-specific
    Solved by Ratchet SessionProvider connected to a Symfony session handler


    View Slide

30. One process to rule them all
    Stateless API approach
    Or do not use sessions at all and authorize user via a token in an HTTP header


    View Slide

31. Inter-process commucation
    PHP-FPM
    CLI
    WebSockets Server
    Client Browsers
    When something happens in the classic big web app and you need to notify the WebSockets
    clients about it, you can do it through a message queue.


    View Slide

32. Deployment
    Use Supervisord to keep the process alive
    Restart the process when deploying a new version
    Implement pcntl_signal to handle kill signals


    View Slide

33. Nginx as a proxy
    Client Browser
    HTTP or HTTPS
    80 or 443
    HTTP
    any port
    Ratchet
    Exotic ports are blocked in corporate environments, you want to provide access to the WS server
    through 80 or 443. Ratchet does not support HTTPS, can be solved with Nginx proxy.


    View Slide

34. Nginx as a proxy
    upstream websockets_ratchet {
    server localhost:8080;
    }
    Name of the upstream will be used in proxy configuration.


    View Slide

35. Nginx as a proxy
    location /heartbeat-websocket {
    proxy_pass http://websockets_ratchet;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_set_header Host $host;
    proxy_read_timeout 86400;
    proxy_redirect off;
    proxy_buffering off;
    }
    It's important to turn the buffering off otherwise it doesn't work as well.


    View Slide

36. Ratchet 1 Ratchet 2 Ratchet 3 Ratchet 4
    Loadbalancer
    Client Browser
    Horizontal scaling by adding Ratchet servers. They have to communicate between each other.


    View Slide

37. caniuse.com/#feat=websockets


    View Slide

38. Client-side support detection
    'WebSocket' in window
    It's better to detect certain features like this instead of a browser vendor and version, too
    difficult to maintain the matrix of supporting browsers.


    View Slide

39. WebSockets JavaScript API


    var ws = new WebSocket('ws://localhost:8080');

    var ws = new WebSocket('wss://localhost:8080');
    Constructor causes the client to connect. You can connect to any server, no cross-origin
    restriction forced by the browser. wss is secure variant, on HTTPS you can connect to wss only.


    View Slide

40. WebSockets JavaScript API
    ws.onopen = function () {}
    ws.onerror = function (error) {}
    ws.onclose = function () {}
    ws.onmessage = function (event) {
    alert(event.data);
    }
    ws.send(JSON.stringify({'foo': 'bar'}));


    View Slide

41. Reconnecting
    var openConnection = function () {
    var ws = new WebSocket(...);
    ws.onclose = function () {
    setTimeout(function () {
    openConnection();
    }, 2000);
    };
    };
    User can go offline and come back online at any time. Improve this implementation

    by presenting that the connection is offline and prolonging the interval between attempts.


    View Slide

42. Content Security Policy
    connect-src ws://example.com
    CSP is used to harden the security of your app – essentially whitelisting what the browser

    can do. self does not work because it matches the scheme of the website - ws is not http.


    View Slide

43. WebSockets PHP Client

    wat?
    Until now we've talked about the web browser as the WebSockets client.
    But PHP can be a client too!


    View Slide

44. WebSockets PHP client
    composer require ratchet/pawl


    View Slide

45. WebSockets PHP client
    Functional tests
    Verify end-to-end that your WebSockets server works in PHPUnit


    View Slide

46. WebSockets PHP client
    Server monitoring
    Use it to provide HTTP endpoint for services like Pingdom or Uptime Robot that do not support
    WebSockets directly. Return HTTP 200 if you can connect to the server, 500 if the server is down.


    View Slide

47. WebSockets PHP client
    Ratchet
    WebSockets
    AJAX
    Long-polling server
    WebSockets
    If you need to support older browsers, you can write another React.PHP server to provide

    AJAX longpolling to your WebSockets app. This server will persist WebSockets connections
    across HTTP requests.


    View Slide

48. Future where the reload button

    does not exist



    Looking foward to what

    you build with it!


    View Slide
