ONOS Summit: ONOS talk by NEC (Vendor Perspective)

ONOS Project
December 09, 2014

ONOS Summit: ONOS talk by NEC (Vendor Perspective)

ONOS talk by NEC at ONOS Summit on Dec 9th, 2014
Presented by: Shinya Nakamura, NEC

ONOS Project

December 09, 2014
Tweet

More Decks by ONOS Project

Other Decks in Technology

Transcript

  1. ONOS Summit Expectations to ONOS 9th December, 2014 Shinya Nakamura

    NEC Corporation 【NEC Group Internal Use Only】
  2. Page 2 © NEC Corporation 2014 ▌ NEC SDN activities

    l OpenFlow networking solutions ~ Programmable Flow l Transport SDN for carriers’ WAN l NFV references ▌ ONOS expectations l Transport SDN requirements and ONOS ▌ Conclusion
  3. Page 3 © NEC Corporation 2014 ▌ Many contributions and

    leading position at various SDN/NFV standardization and research activities 2010 2009 2008 2011 2012 2013 Reliability WG and Management WG Attending from the beginning and lead Reliability WG and Management WG R&D for OpenFlow controller and OpenFlow Switch R&D for OpenFlow controller and OpenFlow Switch NFV ISG Joined (Jan/2008) Joined Stanford Univ. Clean Slate Program (Jan/2008) Open Network Consorthium Open Network Consorthium Open Networking Foundation Open Networking Research Center member Attending as one of founding member Product launched as the world first OpenFlow SDN switch and controller Developed NEC’s unique Programmable Flow technology Open Daylight Gold member Global SDN Standardization activities of NEC ONOS 2014 Contributing carrier grade SDN controller development
  4. Page 4 © NEC Corporation 2014 ProgrammableFlow For all industrial

    vertical network Int’l Reserch Ofelia, Esnet, .. Logistics Nippon Express Healthcare Kanazawa University Hospital Broadcasting TV Asahi Telecommunication NTT Communications Transportation Railroad, Highway Campus Stanford Univ, Geogia tech, … Campus Stanford Univ, Geogia tech, …
  5. Page 5 © NEC Corporation 2014 ▌ NEC SDN activities

    l OpenFlow networking solutions ~ Programmable Flow l Transport SDN for carriers’ WAN l NFV references ▌ ONOS expectations l Transport SDN requirements and ONOS ▌ Conclusion
  6. Page 6 © NEC Corporation 2014 Most comprehensive SDN-NFV offering

    in the market Aggregation Switches WDM Packet Transport Home Fiber Office Packet Transport Mobile PC Smartphone Aggregation Switches eNB OLT OLT eNB Core/Metro/ Access EPC, IMS, MVNO-GW, etc. Edge BRAS, SBC, CDN, Security-GW, etc. Microwave Data Centers (1) Data Center SDN Data Center/ Networks IaaS Platforms (2) Network Functions Virtualization vEPC vBRAS vCPE vIMS (3) Transport Packet /Optical SDN Wireless SDN SDN controller E2E Orchestration OSS/BSS
  7. Page 7 © NEC Corporation 2014 Datacenter-Transport Convergence & Virtualization

    Vendor -B (OF 1.3+) Vendor -D (Non-OF) 10G links 10G links Datacenter Site 1 NEC Transport Network Coordinator Service orchestration Datacenter Site 2 Vendor-C Vendor-A Transport network PF 6800 OF controller PF 6800 OF controller PF 5240 OF switch PF 5240 OF switch NEC VTN web API OIF NBI service/topology API Video client Video server OF 1.3 OF 1.3 ▌ ONF-OIF Transport SDN Interop-2014 5 Carriers, 9 Vendors. ▌ Objectives: Open SDN-interconnect of distributed datacenter sites & multiple transport network WAN domains l Automation, orchestration, virtualization of multi-vendor, multi-layer networks Web client
  8. Page 8 © NEC Corporation 2014 Open Approach to Transport

    SDN ▌ Multi-protocol southbound iterface capability - OpenFlow and non-OpenFlow NEC Transport NW Cordinator Controller 1 (Vendor B) Controller 2 (Vendor C) Controller 3 (Vendor A) OF 1.3+ Domain 1 1.A 1.Z Domain 2 2.A 2.Z Domain 3 3.A 3.Z Non-OF Non-OF OIF NBI Controller 4 (Vendor B) Domain 4 4.A 4.Z OF 1.3+ Cordinater: Coordinates multiple domains to provide inter-domain service Controller 1/2/3/4: Controls each domain, provide intra-domain connections NBI: OIF NBI (Service/Topology API) for inter-transport-domain connectivity
  9. Page 9 © NEC Corporation 2014 NFV References ▌ NEC

    is actively helping Telecommunications Providers in the network virtualization transformation ….
  10. Page 10 © NEC Corporation 2014 ▌ NEC SDN activities

    l OpenFlow networking solutions ~ Programmable Flow l Transport SDN for carriers’ WAN l NFV references ▌ ONOS expectations l Transport SDN requirements and ONOS ▌ Conclusion
  11. Page 11 © NEC Corporation 2014 Changes in requirements for

    transport network l Conventional transport requirements • Important to provide high-integrity connections with pre-assigned routes and bandwidths • Basically no major network configuration changes assumed • IP service layer provides services thru transmission layer being "unaware of transmission" • "Static" operation provided by transport to IP services l Future transport requirements and issues "High-integrity" connection remains important as network infrastructure 1. Automation of network design, provisioning and operation to increase revenue 2. Multi-layer, multi-domain and multi vendor network optimization for OPEX reduction 3. Secure higher reliability and provide flexible availability menu with WAN scalability
  12. Page 12 © NEC Corporation 2014 Practical operational issues in

    transport network ü Increase revenue by reduction of TAT and flexible/efficient service delivery time ü Minimize network facility cost by “total” network optimization to absorb peak time traffic ü Increase revenue by flexibly accommodating diversified inter-DC traffic ü Accomplish prompt and automated network recovery in case of cable cut or major disaster Transport SDN Flexible and automated network operation 1 Issues and new requirements “Multi Layer/Domain/Vender Network Design" Ensure network robustness 2 “Flexible Node Technologies and Software Defined Optics” Network optimization in cooperation with services requirements "Network Virtualization and Programming“ 3
  13. Page 13 © NEC Corporation 2014 ▌ NEC SDN activities

    l OpenFlow networking solutions ~ Programmable Flow l Transport SDN for carriers’ WAN l NFV references ▌ ONOS expectations l Transport SDN requirements and ONOS ▌ Conclusions
  14. Page 14 © NEC Corporation 2014 NEC and ONOS community

    ▌ Expansion of contributors and sponsors l Increase in the number of carriers and vendors l Close involvement of community- best of breed ideas l Place to talk real life carriers’ use cases to be implemented ▌ Evolution of functionality l Flexible southbound APIs • Providing the capability for ONOS to be trialed and deployed in multi-vendor environments l Flexible northbound APIs • Driven by requirements from a diversity of use-case and orchestration system developers. l Continued focus on performance and scale leadership • Continue to evaluate performance in different use cases and settings.
  15. Page 15 © NEC Corporation 2014 Conclusion ▌ NEC is

    expecting ONOS to provide a common carrier-grade platform on which the operators and vendors can build new value-added SDN/NFV solutions for the industry with following Top-3 high level requirements 1. Multi-layer/domain/vender network operation 2. Network virtualization and network programming 3. Highly reliable network with geographical redundant controller ▌ SDN/NFV Industry needs scalable/robust/high performance open source platform for service provider/carrier space.
