  1. Reflection in Qt and Beyond Auckland C++ Meetup Presented by

    Tom Isaacson ( @parsley72 ) https://github.com/tomisaacson/reflection-in-Qt
  2. Qt Introduction Used for developing graphical user interfaces (GUIs) and

    multi-platform applications. Non-GUI programs can be also developed, such as command-line tools and consoles for servers. Runs on all major desktop platforms and most mobile or embedded platforms. Supports various compilers, including the GCC C++ compiler and the Visual Studio suite and has extensive internationalization support. Qt also provides Qt Quick, that includes a declarative scripting language called QML that allows using JavaScript to provide the logic. Other features include SQL database access, XML parsing, JSON parsing, thread management and network support.
  3. None
  4. Qt Rough Guide The QObject class is the base class

    of all Qt objects. QObject is the heart of the Qt Object Model. The central feature in this model is a very powerful mechanism for seamless object communication called signals and slots . You can connect a signal to a slot with connect() and destroy the connection with disconnect() . QObject s organize themselves in object trees. When you create a QObject with another object as parent, the object will automatically add itself to the parent's children() list. The parent takes ownership of the object; i.e. it will automatically delete its children in its destructor. You can look for an object by name and optionally type using findChild() or findChildren() .
  5. Using the Meta-Object Compiler (moc) The Meta-Object Compiler, moc, is

    the program that handles Qt's C++ extensions. The moc tool reads a C++ header file. If it finds one or more class declarations that contain the Q_OBJECT macro, it produces a C++ source file containing the meta-object code for those classes. Among other things, meta-object code is required for the signals and slots mechanism, the run-time type information, and the dynamic property system. The C++ source file generated by moc must be compiled and linked with the implementation of the class. If you use qmake to create your makefiles, build rules will be included that call the moc when required, so you will not need to use the moc directly.
  6. None
  7. Legacy code class tColoredObject : public QObject { Q_OBJECT public:

    enum eColor { ColorRed = 1, ColorBlue = 2, ColorGreen = 3 }; tColoredObject() : m_color(ColorRed) {} private: eColor m_color; }; Q_DECLARE_METATYPE(tColoredObject::eColor); int main() { qRegisterMetaType(tColoredObject::eColor); // required to use the enum in signals/slots ... } void HandleColor(tColoredObject::eColor color) { switch (color) { case ColorRed: qDebug("Red"); break; case ColorBlue: qDebug("Blue"); break; case ColorGreen: qDebug("Green"); break; default: assert(0); } }
  8. Enum Class We can replace enum with enum class which

    improves the type safety. If we turn on C4062 in Visual Studio (which is on by default in GCC) we get a warning if an enum class enumerator isn't handled in a switch statement. This is useful to spot where new enumerators need to be handled so we can change the code.
  9. class tColoredObject : public QObject { Q_OBJECT public: enum class

    eColor { Red = 1, Blue = 2, Green = 3 }; tColoredObject() : m_color(tColoredObject::eColor::Red) {} private: eColor m_color; }; Q_DECLARE_METATYPE(tColoredObject::eColor); int main() { qRegisterMetaType(tColoredObject::eColor); ... } void HandleColor(tColoredObject::eColor color) { switch (color) { case tColoredObject::eColor::Red: qDebug("Red"); break; case tColoredObject::eColor::Blue: qDebug("Blue"); break; case tColoredObject::eColor::Green: qDebug("Green"); break; } } But this means the assert we get if the enum class is an undefined value has gone so it's not an exact replacement.
  10. Enum class can still be an unspecified value tColoredObject::eColor color

    = 5; // error: cannot convert 'int' to 'tColoredObject::eColor' in initialization color = static_cast<tColoredObject::eColor>(5); // ok [expr.static.cast]/10: A value of integral or enumeration type can be explicitly converted to a complete enumeration type. The value is unchanged if the original value is within the range of the enumeration values (7.2). Otherwise, the behavior is undefined.
  11. #include <boost/static_assert.hpp> //----------------------------------------------------------------------------- //! Base template function definition for the

    Minimum range of an enum of type T. //! It is expected that the enum shall provide a total template specialization //! for the enum of type T, so this function should not be called. //----------------------------------------------------------------------------- template <typename T> T EnumRangeMin() { BOOST_STATIC_ASSERT_MSG(sizeof(T) == 0, "EnumRangeMin - No template specialization for the EnumRangeMin function for the given enum"); // If you receive this compile time message it means you need to supply a template specialization // for the enum type for which you tried to call 'ConvertIntToEnumLinearRange' e.g.: // template<> eMyEnum EnumRangeMin<eMyEnum>() {return eMinValueForMyEnum;} return static_cast<T>(0); } //----------------------------------------------------------------------------- //! Base template function definition the Maximum range of the enum of type T. //! It is expected that the enum shall provide a total template specialization //! for the enum of type T, so this function should not be called. //----------------------------------------------------------------------------- template <typename T> T EnumRangeMax() { BOOST_STATIC_ASSERT_MSG(sizeof(T) == 0, "EnumRangeMax - No template specialization for the EnumRangeMax function for the given enum"); // If you receive this compile time message it means you need to supply a template specialization // for the enum type for which you tried to call 'ConvertIntToEnumLinearRange' e.g.: // template<> eMyEnum EnumRangeMax<eMyEnum>() {return eMaxValueForMyEnum;} return static_cast<T>(0); }
  12. //----------------------------------------------------------------------------- //! Function to convert a value (of unspecified type)

    to an enum. The value to be converted //! must lie within an enum linear range where: //! EnumRangeMin<T>() <= \a val <= EnumRangeMax<T>() //! If the value that is supplied does not lie within the range the result is either //! the minimum (when too small) or maximum (when too large) range value of the enum. //----------------------------------------------------------------------------- template <typename T, typename V> T ConvertValueToEnumLinearRange(V val) { // If the value is outside the linear range then, we constrain the result to either min or max T minRange = EnumRangeMin<T>(); if (val < static_cast<V>(minRange)) return minRange; T maxRange = EnumRangeMax<T>(); if (val > static_cast<V>(maxRange)) return maxRange; // The value exists within the range, so provide the converted the value return static_cast<T>(val); }
  13. We can use this to recreate the assert we removed

    from the switch: https://godbolt.org/z/QwJqSO template <> tColoredObject::eColor EnumRangeMin<tColoredObject::eColor>() { return tColoredObject::eColor::Red; } template <> tColoredObject::eColor EnumRangeMax<tColoredObject::eColor>() { return tColoredObject::eColor::Green; } void HandleColor(tColoredObject::eColor color) { switch (color) { case tColoredObject::eColor::Red: printf("Red"); break; case tColoredObject::eColor::Blue: printf("Blue"); break; case tColoredObject::eColor::Green: printf("Green"); break; } assert(color == ConvertValueToEnumLinearRange<tColoredObject::eColor>(color)); }
  14. Q_ENUM I was looking into this and I found New

    in Qt 5.5: Q_ENUM and the C++ tricks behind it. This explains the new Q_ENUM().
  15. class tColoredObject : public QObject { Q_OBJECT public: enum class

    eColor { Red = 1, Blue = 2, Green = 3 }; Q_ENUM(eColor) tColoredObject() : m_color(tColoredObject::eColor::Red) {} private: eColor m_color; };
  16. This is great, but it also means you can use

    Qt's reflection. I've added AssertIfValueIsOutsideQEnumRange() which asserts if the enum class value is undefined: template <typename T, typename V> void AssertIfValueIsOutsideQEnumRange(V val) { const QMetaEnum metaEnum = QMetaEnum::fromType<T>(); const int nVal = static_cast<int>(val); const char* keyStr = metaEnum.valueToKey(nVal); if (keyStr == nullptr) { const QString output = QString("AssertIfValueIsOutsideQEnumRange(%1): outside range of %2::%3").arg(nVal).arg(metaEnum.scope()).arg(metaEnum.name()); qDebug(output); } assert(keyStr != nullptr); }
  17. This replaces the assert: void HandleColor(tColoredObject::eColor color) { switch (color)

    { case tColoredObject::eColor::Red: qDebug("Red"); break; case tColoredObject::eColor::Blue: qDebug("Blue"); break; case tColoredObject::eColor::Green: qDebug("Green"); break; } AssertIfValueIsOutsideQEnumRange<tColoredObject::eColor>(color); }
  18. QString from enum class //----------------------------------------------------------------------------- //! Function to convert an

    enum value to a QString. The enum must be declared as Q_ENUM. //----------------------------------------------------------------------------- template <typename T, typename V> QString ConvertQEnumValueToString(V val) { const QMetaEnum metaEnum = QMetaEnum::fromType<T>(); const char* str = metaEnum.valueToKey(static_cast<int>(val)); return QString::fromUtf8(str); }
  19. Q_NAMESPACE Q_ENUM can only be used within a QObject class.

    New in Qt 5.8: meta-object support for namespaces namespace MyNamespace { Q_NAMESPACE enum class SomeEnum { Foo, Bar }; Q_ENUM_NS(SomeEnum) }
  20. From: Tom Isaacson tom.isaacson@Navico.com Sent: Wednesday, December 19, 2018 10:09

    PM To: interest@qt-project.org Subject: Use QMetaEnum::keyCount() to initialise array Is it possible to use QMetaEnum::keyCount() to initialise an array? Something like: const QMetaEnum metaEnum = QMetaEnum::fromType<MyArray>(); int MyArray[metaEnum.keyCount()]; It seems like Q_ENUM declares functions with Q_DECL_CONSTEXPR in C++11 but I can't figure out how to get this to work.
  21. From: Konstantin Shegunov kshegunov@gmail.com Sent: Wednesday, December 19, 2018 10:37

    PM Compiles for me (with g++ 8.2, -std=gnu++11 which is expanded from CONFIG += c++11). From: Nikos Chantziaras realnc@gmail.com Sent: Thursday, December 20, 2018 6:22 AM Unfortunately, that's a variable length array, which is a GNU extension.
  22. From: Nikos Chantziaras realnc@gmail.com Sent: Thursday, December 20, 2018 6:29

    AM Are you sure they're constexpr? From what I can see in Qt 5.12, keyCount() is not constexpr. It's just const. From: Tom Isaacson tom.isaacson@navico.com Sent: Monday, December 31, 2018 8:29 AM You're right, keyCount() isn't. My confusion is that Q_ENUM declares its functions as constexpr: #define Q_ENUM(ENUM) \ friend Q_DECL_CONSTEXPR const QMetaObject *qt_getEnumMetaObject(ENUM) Q_DECL_NOEXCEPT { return &staticMetaObject; } \ friend Q_DECL_CONSTEXPR const char *qt_getEnumName(ENUM) Q_DECL_NOEXCEPT { return #ENUM; } But I don't understand why if the functions that then use them aren't.
  23. From: Tom Isaacson tom.isaacson@navico.com Sent: Monday, December 31, 2018 8:43

    AM To: development@qt-project.org Subject: Use QMetaEnum::keyCount() to initialise array Is it possible to use QMetaEnum::keyCount() to initialise an array? Something like: const QMetaEnum metaEnum = QMetaEnum::fromType<MyArray>(); int MyArray[metaEnum.keyCount()]; After asking this on the Qt-Interest forum I spent a bit of time investigating. Q_ENUM declares functions with Q_DECL_CONSTEXPR: #define Q_ENUM(ENUM) \ friend Q_DECL_CONSTEXPR const QMetaObject *qt_getEnumMetaObject(ENUM) Q_DECL_NOEXCEPT { return &staticMetaObject; } \ friend Q_DECL_CONSTEXPR const char *qt_getEnumName(ENUM) Q_DECL_NOEXCEPT { return #ENUM; }
  24. In my example code above, QMetaEnum::fromType() calls these functions: template<typename

    T> static QMetaEnum fromType() { Q_STATIC_ASSERT_X(QtPrivate::IsQEnumHelper<T>::Value, "QMetaEnum::fromType only works with enums declared as Q_ENUM or Q_FLAG"); const QMetaObject *metaObject = qt_getEnumMetaObject(T()); const char *name = qt_getEnumName(T()); return metaObject->enumerator(metaObject->indexOfEnumerator(name)); } Where it breaks is the last line, because QMetaObject::indexOfEnumerator() uses d.data: int QMetaObject::indexOfEnumerator(const char *name) const { const QMetaObject *m = this; while (m) { const QMetaObjectPrivate *d = priv(m->d.data);
  25. Which is only defined as const: struct { // private

    data const QMetaObject *superdata; const QByteArrayData *stringdata; const uint *data; I don't know how the Meta-Object Compiler creates this but surely it's possible to change it to be constexpr?
  26. From: Thiago Macieira thiago.macieira@intel.com Sent: Tuesday, January 1, 2019 12:52

    AM No, it's not.
  27. From: Thiago Macieira thiago.macieira@intel.com Sent: Thursday, January 3, 2019 12:45

    AM Because the information is not known to the compiler at compile time. You need moc's parsing of the header in order for it to count how many enumerators are there in the enumeration. Like you said, if we had static reflections, we could do this entirely in the compiler -- we would do possibly ALL of moc as part of reflections. But until that happens, moc needs to run and will produce a .cpp with the count.
  28. If you did have access to moc's output, you could

    access the enumeration count in constexpr time. After all, QMetaEnum::keyCount is simply: const int offset = priv(mobj->d.data)->revision >= 8 ? 3 : 2; return mobj->d.data[handle + offset]; Note that moc produces those arrays as "static const", not "constexpr", so it may not be accessible today at constexpr evaluation time. Or it could. I don't remember if "static const" counts as constant expression... The problem is that you have to #include the moc's output in the TU that wants to create the OP's array. And it must be #include'd or built by the build system exactly once.
  29. From: Thiago Macieira thiago.macieira@intel.com Sent: Thursday, January 3, 2019 1:43

    AM To be stricter: it is know to the compiler, but without a constexpr reflection API, we can't get the information out of the compiler and into code.
  30. From: Tom Isaacson tom.isaacson@navico.com Sent: Tuesday, January 8, 2019 7:51

    AM I wonder if moc-ng could handle this? Proof Of Concept: Re-implementing Qt moc using libclang: https://woboq.com/blog/moc-with-clang.html
  31. From: Olivier Goffart olivier@woboq.com Sent: Tuesday, January 8, 2019 8:21

    PM Not really, even if it can generate things in a header for templates, it still generates the actual data in a .cpp file. As it was said before, we can't really have the contents of the QMetaObject. Even verdigris does the same (putting the QMetaObject data in the .cpp) One would have to do more research to find out if it is possible. Maybe putting more data in the QMetaEnum directly. Not sure if this is possible in a binary compatible way. https://github.com/woboq/verdigris
  32. C++ Standards Herb Sutter's Trip report: Winter ISO C++ standards

    meeting (Kona) Reflection TS v1 (David Sankel, Axel Naumann) completed. The Reflection TS international comments have now been processed and the TS is approved for publication. As I mentioned in other trip reports, note again that the TS’s current template metaprogramming-based syntax is just a placeholder; the feedback being requested is on the core “guts” of the design, and the committee already knows it intends to replace the surface syntax with a simpler programming model that uses ordinary compile-time code and not <>-style metaprogramming.
  33. N4746: Working Draft, C++ Extensions for Reflection

  34. C++Now 2019 "The C++ Reflection TS" David Sankel Wednesday, May

    8: 09:00 - 10:30 What is the C++ Reflection TS and what will it do for me? The answer: a lot. This talk explains this exciting new language feature, demonstrates how it is used, and discusses the direction reflection is taking within the C++ standardization committee. David Sankel is a co-author of the Reflection TS and currently serves as its project editor.
  35. CppCon 2018 “Compile-time programming and reflection in C++20 and beyond”

    Louis Dionne https://www.youtube.com/watch?v=CRDNPwXDVp0
  36. Plan 1. Make (almost) all of C++ available in constexpr

    . 2. Provide a constexpr API to query the compiler. 3. Provide a means for modifying the AST (Abstract Syntax Tree).
