MAPS WITH DJANGO PAOLO MELCHIORRE ~ www.paulox.net © 2020 Paolo
Melchiorre (CC BY-SA)

Paolo Melchiorre ~ www.paulox.net 🌐 www.paulox.net 🐍 PSF fellow 🦄
DSF member 󰠁 Django Girls+ coach 🚀 Djangonaut navigator 󰏢 PyCon Italia organizer 🐬 Python Pescara founder Paolo Melchiorre 3 © 2022 Bartek Pawlik (CC BY-NC-SA)

5 © 2020 Paolo Melchiorre (CC BY-SA) 1.883 m 6.178
ft 0 km 0 mi 27 km 17 mi 0 km 0 mi

Paolo Melchiorre ~ www.paulox.net • Static or Dynamic • Interactive
or view-only • Raster or Vector tiles • Spatial databases • Javascript library Web maps 6

Paolo Melchiorre ~ www.paulox.net 7 Web mapping “… process of
using the maps delivered by Geographic Information Systems (G.I.S.) on the Internet …” — “Web mapping”, Wikipedia

Paolo Melchiorre ~ www.paulox.net 9 Requirements $ python3 --version Python
3.12.3 $ python3 -m venv ~/.mymap $ source ~/.mymap/bin/activate $ python -m pip install django ... Successfully installed asgiref-3.8.1 django-5.1.1 sqlparse-0.5.1

Paolo Melchiorre ~ www.paulox.net 10 Creating the ‘mymap’ project $
cd ~/Projects $ python -m django startproject mymap $ tree --noreport mymap/ mymap/ ├── manage.py └── mymap ├── asgi.py ├── __init__.py ├── settings.py ├── urls.py └── wsgi.py

Paolo Melchiorre ~ www.paulox.net 11 Creating the ‘markers’ app $
cd mymap $ python -m django startapp markers $ tree --noreport markers/ markers/ ├── admin.py ├── apps.py ├── __init__.py ├── migrations │ └── __init__.py ├── models.py ├── tests.py └── views.py

Paolo Melchiorre ~ www.paulox.net 12 Activating the ‘markers’ app #
mymap/mymap/settings.py ... INSTALLED_APPS = [ "django.contrib.admin", "django.contrib.auth", "django.contrib.contenttypes", "django.contrib.sessions", "django.contrib.messages", "django.contrib.staticfiles", "markers", ]

Paolo Melchiorre ~ www.paulox.net 13 Adding the ‘map’ template  <!DOCTYPE html> <html lang="en"> <head> <title>Markers Map</title> <meta name="viewport" content="width=device-width, initial-scale=1.0" /> </head> <body> </body> </html>

Paolo Melchiorre ~ www.paulox.net 14 Adding ‘markers’ urls # mymap/markers/urls.py
from django.urls import path from django.views.generic import TemplateView urlpatterns = [ path( "map/", TemplateView.as_view(template_name="map.html") ), ]

Paolo Melchiorre ~ www.paulox.net 15 Updating ‘mymap’ urls # mymap/mymap/urls.py
from django.contrib import admin from django.urls import include, path urlpatterns = [ path("admin/", admin.site.urls), path("", include("markers.urls")), ]

ft 0 km 0 mi 27 km 17 mi 2 km 1,25 mi

Paolo Melchiorre ~ www.paulox.net • JavaScript library for maps •
Free Software • Desktop & Mobile friendly • Light (~42 KB of gzipped JS) • Well documented Leaﬂet 18

Paolo Melchiorre ~ www.paulox.net 19 Updating the ‘map’ template -
header  {% load static %} <head>  <link href="{% static 'map.css' %}" rel="stylesheet" /> <link href="https://unpkg.com/leaflet/dist/leaflet.css" rel="stylesheet" crossorigin="" /> <script src="https://unpkg.com/leaflet/dist/leaflet.js" crossorigin=""></script> </head>

Paolo Melchiorre ~ www.paulox.net 20 Updating the ‘map’ template -
body  {% load static %} <!DOCTYPE html> <html lang="en">  <body> <div id="map"></div> <script defer src="{% static 'map.js' %}"></script> </body> </html>

Paolo Melchiorre ~ www.paulox.net 21 Adding the ‘map’ CSS /*
mymap/markers/static/map.css */ html, body { height: 100%; margin: 0; } #map { height: 100%; width: 100%; }

Paolo Melchiorre ~ www.paulox.net 22 Adding the ‘map’ JavaScript //
mymap/markers/static/map.js const osm = "https://www.osm.org/copyright"; const copy = `© <a href='${osm}'>OpenStreetMap</a>`; const url = "https://{s}.tile.osm.org/{z}/{x}/{y}.png"; const layer = L.tileLayer(url, {attribution: copy}); const map = L.map("map", {layers: [layer]}); map.fitWorld();

Paolo Melchiorre ~ www.paulox.net 23 Show the empty web map
$ python -m manage runserver Watching for file changes with StatReloader Performing system checks... System check identified no issues (0 silenced). September 24, 2024 - 11:38:00 Django version 5.1, using settings 'mymap.settings' Starting development server at http://127.0.0.1:8000/ Quit the server with CONTROL-C.

ft 0 km 0 mi 27 km 17 mi 6 km 3,75 mi

Paolo Melchiorre ~ www.paulox.net 27 🌍 GeoDjango django.contrib.gis (v1.0 ~2008)
Fields, backends, queries, admin, … Spatialite backend (v1.1 ~2009) Multiple backends (v1.2 ~2010) OpenLayers-based widgets (v1.6 ~2013) GeoJSON serializer (v1.8 ~2015) GeoIP2 Geolocation (v1.9 ~2016)

Paolo Melchiorre ~ www.paulox.net • OSGeo library • Free Software
• Read/Write geospatial data • Raster/Vector formats • Command line interface GDAL 28

Paolo Melchiorre ~ www.paulox.net 29 Installing GDAL $ # Ubuntu
(20.04 - 24.04) / Debian (11 - 12) $ sudo apt install gdal-bin FROM python:3.12-slim-bookworm RUN apt-get install --assume-yes --no-install-recommends \ libgdal32

Paolo Melchiorre ~ www.paulox.net 30 Activating GeoDjango # mymap/mymap/settings.py ...
INSTALLED_APPS = [ "django.contrib.admin", "django.contrib.auth", "django.contrib.contenttypes", "django.contrib.sessions", "django.contrib.messages", "django.contrib.staticfiles", "django.contrib.gis", "markers", ]

Paolo Melchiorre ~ www.paulox.net • SQLite spatial extension • Vector
geodatabase functions • Free Software • Simple architecture • Single ﬁle SpatiaLite 31

Paolo Melchiorre ~ www.paulox.net 32 Installing SpatiaLite $ # Ubuntu
(20.04 - 24.04) / Debian (10 - 12) $ sudo apt install libsqlite3-mod-spatialite FROM python:3.12-slim-bookworm RUN apt-get install --assume-yes --no-install-recommends \ libsqlite3-mod-spatialite

Paolo Melchiorre ~ www.paulox.net 33 Activating SpatiaLite # mymap/settings.py ...
DATABASES = {"default": { "ENGINE": "django.contrib.gis.db.backends.spatialite", "NAME": BASE_DIR / "db.sqlite3", }}

Paolo Melchiorre ~ www.paulox.net 34 Adding the Marker model #
mymap/markers/models.py from django.contrib.gis.db import models class Marker(models.Model): name = models.CharField(max_length=255) location = models.PointField() def __str__(self): return self.name

Paolo Melchiorre ~ www.paulox.net 35 Adding the Marker admin #
mymap/markers/admin.py from django.contrib.gis import admin from markers.models import Marker @admin.register(Marker) class MarkerAdmin(admin.GISModelAdmin): list_display = ("name", "location")

Paolo Melchiorre ~ www.paulox.net 36 Creating migrations $ python -m
manage makemigrations Migrations for 'markers': markers/migrations/0001_initial.py + Create model Marker

Paolo Melchiorre ~ www.paulox.net 37 Applying migrations $ python -m
manage migrate Operations to perform: Apply all migrations: admin, auth, contenttypes, markers, sessions Running migrations: ... Applying markers.0001_initial... OK ...

Paolo Melchiorre ~ www.paulox.net 38 Creating a superuser $ python
-m manage createsuperuser Username (leave blank to use 'paulox'): Email address: Password: Password (again): Superuser created successfully.

Paolo Melchiorre ~ www.paulox.net 39 Running the project $ python
-m manage runserver Watching for file changes with StatReloader Performing system checks... System check identified no issues (0 silenced). September 24, 2024 - 11:45:00 Django version 5.1, using settings 'mymap.settings' Starting development server at http://127.0.0.1:8000/ Quit the server with CONTROL-C.

Paolo Melchiorre ~ www.paulox.net 41 Updating the view - part
1 # markers/views.py import json from django.core.serializers import serialize from django.views.generic import ListView from markers.models import Marker class MapView(ListView): context_object_name = "markers" model = Marker template_name = "map.html"

Paolo Melchiorre ~ www.paulox.net 42 Updating the view - part
2 # markers/views.py class MapView(ListView): ... def get_context_data(self, **kwargs): context = super().get_context_data(**kwargs) context["markers"] = json.loads( serialize("geojson", context["markers"]) ) return context

Paolo Melchiorre ~ www.paulox.net 43 Adding ‘markers’ urls # mymap/markers/urls.py
from django.urls import path from markers.views import MapView urlpatterns = [ path("map/", MapView.as_view()), ]

Paolo Melchiorre ~ www.paulox.net 44 Inserting markers in the template
 {% load static %} <!DOCTYPE html> <html lang="en">  <body> <div id="map"></div> {{ markers|json_script:"markers-data" }} <script defer src="{% static 'map.js' %}"></script> </body> </html>

Paolo Melchiorre ~ www.paulox.net 45 Generated GeoJSON { "type": "FeatureCollection",
"crs": {"type":"name", "properties":{"name":"EPSG:4326"}}, "features": [{ "id": 1, "type": "Feature", "properties": { "name": "Monte Amaro 2793m", "pk": "1" }, "geometry": {"type": "Point", "coordinates":[14.0, 42.0]} }] }

Paolo Melchiorre ~ www.paulox.net 46 Rendering all markers in the
map // markers/static/map.js // ... // map.fitWorld(); const data = document.getElementById("markers-data"); const markers = JSON.parse(data.textContent) let feature = L.geoJSON(markers) .bindPopup(function (layer) { return layer.feature.properties.name; }) .addTo(map); map.fitBounds(feature.getBounds());

Paolo Melchiorre ~ www.paulox.net 47 Show the populated web map

ft 0 km 0 mi 27 km 17 mi 7 km 4,35 mi

Paolo Melchiorre ~ www.paulox.net 51 GeoDjango Compatibility Table • Spatial
Lookups (18/31) • Database functions (15/32) • Aggregate Functions (0/5) MariaDB 49% • Spatial Lookups (31/31) • Database functions (32/32) • Aggregate Functions (5/5) PostGIS 100% • Spatial Lookups (22/31) • Database functions (30/32) • Aggregate Functions (4/5) Spatialite 82% • Spatial Lookups (18/31) • Database functions (16/32) • Aggregate Functions (0/5) MySQL 50%

Paolo Melchiorre ~ www.paulox.net • PostgreSQL extension • Best* GeoDjango
backend • Spatial data types • Spatial indexing • Spatial functions PostGIS 52

Paolo Melchiorre ~ www.paulox.net 53 Requirements # requirements.txt django~=5.1.0 django-filter~=24.3.0
djangorestframework~=3.15.0 djangorestframework-gis~=1.1.0 psycopg[binary]~=3.2.0

Paolo Melchiorre ~ www.paulox.net 54 Installing requirements $ python -m
pip install -r requirements.txt ... Successfully installed django-filter-24.3 djangorestframework-3.15.2 djangorestframework-gis-1.1 psycopg-3.2.2 psycopg-binary-3.2.2 typing-extensions-4.12.2

Paolo Melchiorre ~ www.paulox.net 55 Activating PostGIS # mymap/mymap/settings.py DATABASES
= { "default": { "ENGINE": "django.contrib.gis.db.backends.postgis", "HOST": "database", "NAME": "mymap", "PASSWORD": "password", "PORT": 5432, "USER": "postgres", } }

Paolo Melchiorre ~ www.paulox.net Applying migrations to PostgreSQL 56 $
python -m manage migrate Operations to perform: Apply all migrations: admin, auth, contenttypes, markers, sessions Running migrations: ... Applying markers.0001_initial... OK ...

Paolo Melchiorre ~ www.paulox.net 57 Activating Django REST Framework #
mymap/settings.py INSTALLED_APPS = [ ... "rest_framework", "rest_framework_gis", "markers", ]

Paolo Melchiorre ~ www.paulox.net 58 Adding the Marker serializer #
mymap/markers/serializers.py from rest_framework_gis import serializers from markers.models import Marker class MarkerSerial(serializers.GeoFeatureModelSerializer): class Meta: fields = ("id", "name") geo_field = "location" model = Marker

Paolo Melchiorre ~ www.paulox.net 59 Adding the Marker viewset #
mymap/markers/viewsets.py from rest_framework import viewsets from rest_framework_gis import filters from markers.models import Marker from markers.serializers import MarkerSerial class MarkerViewSet(viewsets.ReadOnlyModelViewSet): bbox_filter_field = "location" filter_backends = [filters.InBBoxFilter] queryset = Marker.objects.all() serializer_class = MarkerSerial

Paolo Melchiorre ~ www.paulox.net 60 Adding API ‘markers’ urls #
mymap/markers/api.py from rest_framework import routers from markers.viewsets import MarkerViewSet router = routers.DefaultRouter() router.register(r"markers", MarkerViewSet) urlpatterns = router.urls

Paolo Melchiorre ~ www.paulox.net 61 Updating ‘mymap’ urls # mymap/mymap/urls.py
from django.contrib import admin from django.urls import include, path urlpatterns = [ path("admin/", admin.site.urls), path("api/", include("markers.api")), path("", include("markers.urls")), ]

Paolo Melchiorre ~ www.paulox.net 62 Trying to locate the user
// mymap/markers/static/map.js // ... // map.fitWorld(); map.locate() .on("locationfound", (e) => map.setView(e.latlng, 8)) .on("locationerror", () => map.setView([0, 0], 5)); const layerGroup = L.layerGroup().addTo(map); // ...

Paolo Melchiorre ~ www.paulox.net 63 Fetch required markers // mymap/markers/static/map.js
// ... async function load_markers() { const bounds = map.getBounds().toBBoxString(); const markers_url = `/api/markers/?in_bbox=${bounds}`; const response = await fetch(markers_url); const geojson = await response.json(); return geojson; } // ...

Paolo Melchiorre ~ www.paulox.net 64 Rendering markers incrementally // mymap/markers/static/map.js
// ... async function render_markers() { const markers = await load_markers(); layerGroup.clearLayers(); L.geoJSON(markers) .bindPopup((layer) => layer.feature.properties.name) .addTo(layerGroup); } map.on("moveend", render_markers);

Paolo Melchiorre ~ www.paulox.net 65 Show the populated web map

ft 0 km 0 mi 27 km 17 mi 13,5 km 8,5 mi

Paolo Melchiorre ~ www.paulox.net 70 What’s next • Markers customization
• Relational ﬁltering • Clustering frontend/backend • Geocoding services • ...

Paolo Melchiorre ~ www.paulox.net 71 Tips • docs in djangoproject.com
• details in postgis.net • source code in github.com • questions in gis.stackexchange.com

Paolo Melchiorre ~ www.paulox.net 72 License CC BY-SA 4.0 This
work is licensed under a Creative Commons Attribution-ShareAlike 4.0 International License. CC

Paolo Melchiorre ~ www.paulox.net @pauloxnet /paolomelchiorre @pauloxnet www.paulox.net 73 @[email protected]
