  1. Relational Databases on AWS Pierre GOUDJO Amazon RDS and Aurora

  2. There are mainly two ways to run your database workloads

    on AWS
  3. Fully Managed vs Self-Managed

  4. None
  5. None
  6. None
  7. Amazon RDS Supported database management systems

  8. Instances

  9. Instances • A DB instance is an isolated database environment

    running in the cloud. • A DB instance can contain multiple user-created databases • Amazon RDS supports access to databases using any compatible SQL client application • You can have up to 40 DB instances in an account with some limitations
  10. Instances Instance classes • The instance class determines the CPU,

    memory capacity and network bandwidth of an RDS DB instance • Each instance class relates to an EC2 instance type • There is three types of instance classes • Standard (M instances) • Memory Optimised (X, R and Z instances) • Burstable Performance (T instances)
  11. Instances Instance storage • Amazon RDS uses EBS volumes as

    underlying storage • 3 types of storages • General Purpose SSD: cost e ff ective, for various workloads • Provisioned IOPS SSD: for I/O intensive workload • Magnetic
  12. Multi-AZ Deployment

  13. RDS instances live inside an AZ

  14. Multi-AZ deployment of RDS instances

  15. Multi-AZ • Multi-AZ deployment aims to provide High-availability and failover

    support for DB instances • In Multi-AZ, RDS automatically provisions and maintains a synchronous standby replica in a di ff erent AZ • Standby instances are not used to scale database read • DB instances using Multi-AZ can have increased write and commit latency due to synchronous replication
  16. Failover scenario in Multi-AZ deployment of RDS instances

  17. Failover scenario in Multi-AZ deployment of RDS instances

  18. Failover scenario in Multi-AZ deployment of RDS instances

  19. Multi-AZ Notes • Standby replica automatically switches over to primary

    in case of disruption • Failover uses DNS to switch the primary and the standby replica • Failover times are typically 60–120 seconds • Developer should be cautious of DNS cache retention to avoid longer disruption
  20. Read replica deployment

  21. Read replica deployment

  22. Read replica • Read replica are used to reduce the

    load on the primary DB instance • Really practical in heavy-read scenarios • Can’t be used to write data
  23. Read replica can be used in Multi-AZ deployment of RDS

  24. Cross-region read replica

  25. Read replica Notes • Cross-region read replica doesn’t work on

    SQL server • On Oracle, there is two mode of read replica • Read-only: Default mode • Mounted: The replica doesn’t accept user connection • It is possible to promote a read replica to primary instance • For MySQL and MariaDB databases, it is possible to replicate a DB external to RDS
  26. None
  27. Security

  28. Authentication • RDS support several ways to authenticate database users

    • Password-based authentication • IAM database authentication • Kerberos authentication
  29. Data protection • RDS uses TLS connection to protect data

    in transit • It is possible to rotate SSL/TLS certi fi cate for optimum protection • It is possible to encrypt data on RDS instance via AES-256 encryption • RDS integrates with AWS KMS for key management
  30. Snapshots • Backup of RDS instance can be created •

    The process can be either • Manual • Automated • The backup snapshots of a DB instance are incremental
  31. Point-in-time recovery • You can restore a DB instance to

    a speci fi c point in time, creating a new DB instance • You can restore to any point within your backup retention period • RDS uploads transaction logs for DB instances to Amazon S3 every 5 minutes
  32. Logging and monitoring • Amazon RDS integrates well with CloudWatch

    • Alarms • Real-time OS metrics • Performance insights • Amazon integrates well with CloudTrail Logs • Database Logs can be retrieved
  33. Amazon RDS Proxy

  34. RDS Proxy is a connection pooling proxy that allows your

    applications to share databases connections
  35. RDS proxy with some AWS lambda

  36. Amazon RDS Proxy • RDS Proxy is an alternative to

    PgBouncer, PgPool, ProxySql or HirakiCP • RDS Proxy is ideal in a serverless environment as it reduce the burden of connection management on the database • The price depends on the RDS instance type used by your database. The larger the database instance, the more you end up paying
  37. RDS proxy during failover AWS claims that RDS Proxy improve

    failover times by 30%-60%
  38. RDS Proxy eliminates the need to store database credentials anywhere

    in the code
  39. AWS RDS on VMware

  40. None
  41. None
  42. None
  43. None
  44. AWS RDS on VMware Advantages • Reduces operational overhead •

    Good fi rst step before migrating to RDS on AWS in heavy VMware utilisation scenario • Easy scaling of instances • Cloudwatch metrics • Automatic and manual backup of on-premises databases • Point-in-time recovery
  45. AWS RDS on VMware Limitations • No Multi-AZ support •

    No read replica in another region support • Works only for MySQL, PostgreSQL, SQL Server • No encryption at rest • No replication with external databases
  46. Amazon Aurora

  47. Amazon Aurora is a fully managed relational database engine that's

    compatible with MySQL and PostgreSQL
  48. None
  49. • A RDBMS is made of multiple layers • For

    most RDBMS, these layers are tightly integrated Anatomy of a RDBMS
  50. None
  51. Typical Mirrored Architecture of RDBMS on RDS

  52. Aurora tackles database scaling by decoupling the storage layer

  53. None
  54. Amazon Aurora Architecture

  55. None
  56. Aurora single master topology Up to 15 aurora nodes

  57. Aurora multi-master topology

  58. Aurora multi-master pro/cons Better use multi-master with a sharding architecture

  59. Amazon Aurora Global Database Asynchronous replication

  60. Amazon Aurora Global databases • An Aurora global database consists

    of one primary AWS Region where your data is mastered, and up to fi ve read-only secondary AWS Regions • Aurora replicates data to the secondary AWS Regions using dedicated infrastructure, with latency typically under a second • Aurora global databases doesn’t support • Multi-master clusters • Serverless v1 • Backtracking (Fast Point-in-time recovery)
  61. Aurora serverless

  62. Aurora Serverless • The capacity allocated to your Aurora Serverless

    v1 DB cluster seamlessly scales up and down based on the load generated by your client application • When it does need to perform a scaling operation, Aurora Serverless v1 fi rst tries to identify a scaling point, a moment when no queries are being processed • Aurora Serverless might not be able to fi nd a scaling point for the following reasons: • Long-running queries • In-progress transactions • Temporary tables or table locks
  63. None
