Brian Warner - Magic Wormhole: Simple Secure File Transfer

"magic-wormhole" is a simple tool to move files from one computer to another, like "scp" but without the setup. By telling the recipient just a few secret words, the file is safely encrypted and delivered directly to the correct machine. The talk will explain the security mechanics, the cryptography (NaCl and SPAKE2), and how to use the underlying open-source library in your own applications.

https://us.pycon.org/2016/schedule/presentation/1838/

Transcript

1. Move Things From One Computer to Another,
   Safely
   Brian Warner
   magic-wormhole.io
   PyCon 2016


   View Slide

2. me == Brian Warner
   • Buildbot, Foolscap, Versioneer
   • AllMyData: Tahoe-LAFS
   • Mozilla: Add-On SDK, Firefox Sync, Persona, Firefox Accounts
   • Today: Magic Wormhole
   warner@lothar.com
   @lotharrr
   github.com/warner


   View Slide

3. Magic-Wormhole: a
   File Transfer Program
   • Securely moves a file from one computer to another
   • or a directory, or a string
   • My claim: easier than all other secure tools
   • Especially for moving to an unrelated computer


   View Slide

4. What It Looks Like
   pip install magic-wormhole


   View Slide

5. What It Looks Like
   pip install magic-wormhole


   View Slide

6. What It Looks Like
   pip install magic-wormhole


   View Slide

7. Solved Problem?
   • What's wrong with the tools we currently use?


   View Slide

8. "easily". "safely".
   dictate string
   to sender
   dictate string
   to receiver
   needs
   proximity
   eavesdroppers
   send email ~30 chars
   ISPs, CAs,
   internet
   upload to
   FTP/HTTP
   ~60 chars
   server, ISPs,
   CAs, internet
   dropbox ~60 chars Dropbox, CAs
   + URL
   shortener
   ~20 chars
   Shortening Service,
   lucky guessers,
   Dropbox, CAs
   USB drive X eww cooties
   SSH/scp
   ~740 char
   pubkey
   none
   magic
   wormhole
   ~20 chars none


   View Slide

9. How Does It Work?
   • Rendezvous Message Exchange
   • PAKE, Key Agreement
   • IP Address Exchange
   • Transit Connection
   • Data Transfer


   View Slide

10. Rendezvous Server
    typical code: 1-liberty-assume
    Channel
    ID


    View Slide

11. PAKE-based Security
    P assword
    A uthenticated
    K ey
    E xchange
    1992: EKE
    1997: SRP
    2005: SPAKE2
    2008: J-PAKE


    View Slide

12. SPAKE2
    diagram credit: Dan Boneh
    Alice Bob
    pw pw
    pip install spake2


    View Slide

13. Security of PAKE
    • Weak Secret + Interaction == Strong Secret
    • Passive eavesdropper gets zero information
    • Active MitM gets one guess per protocol run
    • failed guess == zero information
    • failed guesses are visible to users


    View Slide

14. Wormhole Codes
    2-company-spyglass
    Channel
    ID
    aardvark
    absurd
    accrue
    acme
    adrift
    adult
    afflict
    ahead
    aimless
    Algol
    allow
    alone
    ammo
    ancient
    apple
    artist
    assume
    Athens
    aardvark
    absurd
    accrue
    acme
    adrift
    adult
    afflict
    ahead
    aimless
    Algol
    allow
    alone
    ammo
    ancient
    apple
    artist
    assume
    Athens
    len(words)==256


    View Slide

15. Single Use
    • Wormhole codes are single-use, forward-secure
    • Default code: 2 words * (256-word list) == 16 bits
    • 65536 possible codes, equally likely
    • User must retry 655 times before attacker has 1%
    chance of success


    View Slide

16. Laziness Improves Security


    View Slide

17. IP Address Exchange
    • Find addresses with ifconfig
    • Listen on TCP ports
    • Exchange addresses+ports
    • Try to connect, trade encrypted handshakes
    • First successful connection wins


    View Slide

18. Data Relay Server


    View Slide

19. Encrypted Transit
    • Provides encrypted record pipe
    • Uses NaCl SecretBox (Salsa20/Poly1305)
    • Keys are HKDF(masterkey, purpose)
    • Data is hashed (SHA256) during transit
    • Final ACK confirms the hash


    View Slide

20. Library API
    w = wormhole(AppID, relay_url)
    w.set_code("1-peachy-seabird")
    w.send(b"hello")
    answer = w.get()


    View Slide

21. Future Work
    • GUI, pre-packaged installers, browser extension
    • Negotiate better transports:
    • WebRTC, ICE/STUN, libutp
    • Tor Onion Services
    • Add SPAKE2 to libsodium
    • Port to other languages: JavaScript, Go, Rust


    View Slide

22. Beyond File Transfer
    • Use this anywhere you need to deliver a credential
    • Provisioning new client devices
    • Pairing client devices to each other
    • Populating addressbook entries in
    communication/messaging systems


    View Slide

23. Provisioning Clients
    Old New
    Type password into server
    Type password into client
    Get Wormhole code from server
    Type code into client


    View Slide

24. Messaging Apps
    Old New
    Alice sends public key to server
    Bob asks server for Alice's key
    Alice shows Wormhole code to
    Bob
    Bob gets Alice's key from Alice
    (via wormhole)


    View Slide

25. Add PAKE to your Toolbox
    • Cryptographic tools disseminate too slowly
    • We need good examples, compelling use cases,
    helpful libraries
    • File transfer is a foot in the door. PAKE is the rest.


    View Slide

26. Magic-Wormhole
    Move Things From One Computer to Another,
    Safely
    Brian Warner
    https://github.com/warner/magic-wormhole
    warner@lothar.com
    Thanks To: Rackspace, Twisted, Glyph, djb, 2255-19
    @lotharrr
    magic-wormhole.io
    pip install magic-wormhole


    View Slide
