Amit Ramesh, Qui Nguyen - Building Stream Processing Applications

Do you have a stream of data that you would like to process in real time? There are many components with Python APIs that you can put together to build a stream processing application. We will go through some common design patterns, tradeoffs and available components / frameworks for designing such systems. We will solve an example problem during the presentation to make these points concrete. Much of what will be presented is based on experience gained from building production pipelines for the real-time processing of ad streams at Yelp. This talk will cover topics such as consistency, availability, idempotency, scalability, etc.

https://us.pycon.org/2017/schedule/presentation/392/

Transcript

1. Building Stream Processing
   Applications
   Amit Ramesh Qui Nguyen


   View Slide

2. Yelp’s Mission
   Connecting people with great
   local businesses.


   View Slide

3. I. Why stream processing?
   II. Putting an application together
   Example problem
   Components and data operations
   III. Design principles and tradeoffs
   Horizontal scalability
   Handling failures
   Idempotency
   Consistency versus availability


   View Slide

4. I. Why stream processing?
   II. Putting an application together
   Example problem
   Components and data operations
   III. Design principles and tradeoffs
   Horizontal scalability
   Handling failures
   Idempotency
   Consistency versus availability


   View Slide

5. View Slide

6. Data processing
   measurements
   from a sensor
   clicking on ads


   View Slide

7. Data processing
   measurements
   from a sensor
   clicking on ads
   average value in
   the last minute
   total clicks on a
   day


   View Slide

8. Batch
   Finite chunk of data
   Operations defined over the entire input
   Data processing: Batch or stream
   8


   View Slide

9. Batch
   Finite chunk of data
   Operations defined over the entire input
   Stream
   Unbounded stream of events flowing in
   Events are processed continuously
   (possibly with state)
   Data processing: Batch or stream
   9


   View Slide

10. Why stream processing over batch?
    ● Lower latency on results
    ● Most data is unbounded, so streaming model is more
    flexible


    View Slide

11. Why stream processing over batch?
    ● Lower latency on results
    ● Most data is unbounded, so streaming model is more
    flexible
    Day 12 Day 13


    View Slide

12. Our evolution


    View Slide

13. Our evolution


    View Slide

14. Our evolution


    View Slide

15. Our evolution
    mrjob


    View Slide

16. Our evolution


    View Slide

17. Our evolution


    View Slide

18. I. Why stream processing?
    II. Putting an application together
    Example problem
    Components and data operations
    III. Design principles and tradeoffs
    Horizontal scalability
    Handling failures
    Idempotency
    Consistency versus availability


    View Slide

19. Example problem: ad campaign metrics
    Ad Yelp


    View Slide

20. ad {
    id: 1200834,
    campaign_id: 2001,
    user_id: 9zkjacn81m,
    timestamp: 1490732147
    }
    view {
    id: 1200834,
    timestamp: 1490732150
    }
    click {
    id: 1200834,
    timestamp: 1490732168
    }


    View Slide

21. Metrics (views, clicks) for each
    campaign over time
    Ad Yelp


    View Slide

22. I. Why stream processing?
    II. Putting an application together
    Example problem
    Components and data operations
    III. Design principles and tradeoffs
    Horizontal scalability
    Handling failures
    Idempotency
    Consistency versus availability


    View Slide

23. Source of
    streaming data
    Stream processing pipelines
    Stream
    processing
    engine
    Storage
    Data sink


    View Slide

24. Stream processing pipelines
    Stream
    processing
    engine
    Storage
    Data sink
    Source of
    streaming data


    View Slide

25. Types of operations
    1. Ingestion
    2. Stateless transforms
    3. Stateful transforms
    4. Keyed stateful transforms
    5. Publishing


    View Slide

26. Operations: 1. Ingestion
    Kafka
    Reader
    Operation
    Source


    View Slide

27. Operations: 1. Ingestion
    Kafka
    Reader
    Operation
    Source
    from pyspark.streaming.kafka import KafkaUtils
    ad_stream = KafkaUtils.createDirectStream(
    streaming_context,
    topics=[‘ad_events’],
    kafkaParams={...},
    )


    View Slide

28. Operations: 2. Stateless transforms
    Operation Transform Operation


    View Slide

29. Operations: 2a. Stateless transforms
    Filter
    e.g., filtering


    View Slide

30. Operations: 2a. Stateless transforms
    Filter
    e.g., filtering
    def is_not_from_bot(event):
    return event[‘ip’] not in bot_ips
    filtered_stream = ad_stream.filter(is_not_from_bot)


    View Slide

31. Operations: 2b. Stateless transforms
    Project
    e.g., projection


    View Slide

32. Operations: 2b. Stateless transforms
    Project
    e.g., projection
    desired_fields = [‘ad_id’, ‘campaign_id’]
    def trim_event(event):
    return {key: event[key] for key in desired_fields}
    projected_stream = ad_stream.map(trim_event)


    View Slide

33. Operations: 3. Stateful transforms
    On windows of data
    Transform
    Sliding window


    View Slide

34. Operations: 3. Stateful transforms
    On windows of data
    Transform
    Sliding window
    Tumbling window


    View Slide

35. Operations: 3. Stateful transforms
    e.g., aggregation
    Sum 5 6
    0 1 1 3 0 1 2


    View Slide

36. Operations: 3. Stateful transforms
    e.g., aggregation
    Sum 5 6
    0 1 1 3 0 1 2
    aggregated_stream = event_stream.reduceByWindow(
    func=operator.add,
    windowLength=4,
    slideInterval=3,
    )


    View Slide

37. Operations: 4. Keyed stateful transforms
    Shuffle
    Group events by key (shuffle) within each window before
    transform
    Transform


    View Slide

38. Operations: 4a. Keyed stateful transforms
    c_id: 1
    views: 1
    c_id: 2
    views: 2
    c_id: 1
    views: 1
    c_id: 2
    views: 1
    c_id: 2
    views: 1
    sum
    views
    by c_id
    e.g., aggregate views by campaign_id


    View Slide

39. Operations: 4a. Keyed stateful transforms
    e.g., aggregate views by campaign_id
    aggregated_views = view_stream.reduceByKeyAndWindow(
    func=operator.add,
    windowLength=3,
    slideInterval=3,
    )
    c_id: 1
    views: 1
    c_id: 2
    views: 2
    c_id: 1
    views: 1
    c_id: 2
    views: 1
    c_id: 2
    views: 1
    sum
    views
    by c_id


    View Slide

40. Operations: 4b. Keyed stateful transforms
    Can also be on more than one stream, e.g., join by id
    Shuffle Join


    View Slide

41. Operations: 4b. Keyed stateful transforms
    e.g., join by ad_id
    Join by
    ad_id
    Ad
    ad_id: 11
    c_id: 1
    ad_id: 22
    c_id: 2
    ad_id: 22
    time: 5
    ad_id: 11
    time: 7
    ad_id: 11
    ad: {
    c_id: 1
    },
    view: {
    time: 7
    }
    ad_id: 22
    ad: {
    c_id: 2
    },
    view: {
    time: 5
    }


    View Slide

42. Operations: 4b. Keyed stateful transforms
    windowed_ad_stream = ad_stream.window(
    windowLength=2,
    slideInterval=2,
    )
    windowed_view_stream = view_stream.window(
    windowLength=2,
    slideInterval=2,
    )
    joined_stream = windowed_ad_stream.join(
    windowed_view_stream,
    )
    e.g., join by ad_id


    View Slide

43. Operations: 5. Publishing
    Sink
    File
    writer
    Operation


    View Slide

44. Operations: 5. Publishing
    results_stream.saveAsTextFiles(‘s3://my.bucket/results/’)
    File
    writer
    Operation
    Sink


    View Slide

45. Operations: Summary
    1. Ingestion
    2. Stateless transforms: on single events
    a. Filtering
    b. Projections
    3. Stateful transforms: on windows of events
    4. Keyed stateful transforms
    a. On single streams, transform by key
    b. Join events from several streams by key
    5. Publishing


    View Slide

46. Putting it together: campaign metrics
    Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project


    View Slide

47. read
    Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project
    {
    ip: bot_id,
    ...
    }
    {
    ip: OK_id,
    ...
    }


    View Slide

48. filter
    Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project
    {
    ip: bot_id,
    ...
    }
    {
    ip: OK_id,
    ...
    }


    View Slide

49. project
    Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project
    {
    ip: OK_id,
    scoring: {
    ...
    },
    ...
    }


    View Slide

50. project
    Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project
    {
    ip: OK_id,
    scoring: {
    ...
    },
    ...
    }


    View Slide

51. join by ad id
    er join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    er project
    er project
    {
    ad_id: 1,
    ad_data: ...
    }
    {
    ad_id: 1,
    view_data: ...
    }


    View Slide

52. join by ad id
    er join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    er project
    er project
    {
    ad_id: 1,
    ad_data: ...,
    view_data: ...,
    }


    View Slide

53. transform
    er join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    er project
    er project
    {
    ad_id: 1,
    campaign_id: 7,
    view: true,
    click: false
    }


    View Slide

54. sum by campaign
    oin by
    ad id
    transform
    write
    sum by
    campaign
    transform
    write
    {
    ad_id: 1,
    campaign_id: 7,
    view: true,
    click: false
    }
    {
    ad_id: 23,
    campaign_id: 7,
    view: true,
    click: false
    }


    View Slide

55. sum by campaign
    oin by
    ad id
    transform
    write
    sum by
    campaign
    transform
    write
    {
    campaign_id: 7,
    views: 2,
    clicks: 0
    }


    View Slide

56. write db.write(
    campaign_id=7,
    views=2,
    clicks=0,
    )
    m
    write
    sum by
    campaign
    m
    write


    View Slide

57. Ad campaign metrics pipeline
    Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project


    View Slide

58. I. Why stream processing?
    II. Putting an application together
    Example problem
    Components and data operations
    III. Design principles and tradeoffs
    Horizontal scalability
    Handling failures
    Idempotency
    Consistency versus availability


    View Slide

59. Horizontal scalability: Basic idea


    View Slide

60. Horizontal scalability: Basic idea


    View Slide

61. Horizontal scalability: Basic idea


    View Slide

62. Horizontal scalability: Basic idea


    View Slide

63. Horizontal scalability: Why?


    View Slide

64. Horizontal scalability: Why?


    View Slide

65. Horizontal scalability: How?
    Random
    partitioning
    Partitioning


    View Slide

66. Horizontal scalability: How?
    Ad
    read
    read
    read
    filter
    filter
    filter
    project
    project
    project
    read
    read
    read
    filter
    filter
    filter
    project
    project
    project
    Partitioning
    Random
    partitioning


    View Slide

67. project
    project
    project
    join by ad id
    Horizontal scalability: How?
    Partitioning


    View Slide

68. project
    project
    project
    join by ad id
    Horizontal scalability: How?
    Partitioning
    Keyed partitioning


    View Slide

69. Horizontal scalability: watch out!
    Hot spots / data skew
    transform
    sum by
    campaign
    transform


    View Slide

70. Horizontal scalability: watch out!
    Hot spots / data skew
    Keyed partitioning
    transform
    sum by
    campaign
    transform


    View Slide

71. Horizontal scalability: Summary
    ● Random partitioning for stateless transforms
    ● Keyed partitioning for keyed transformations
    ● Watch out for hot spots, and use appropriate
    mitigation strategy


    View Slide

72. I. Why stream processing?
    II. Putting an application together
    Example problem
    Components and data operations
    III. Design principles and tradeoffs
    Horizontal scalability
    Handling failures
    Idempotency
    Consistency versus availability


    View Slide

73. Idempotency


    View Slide

74. Idempotency
    An idempotent operation can be
    applied more than once and have
    the same effect.


    View Slide

75. Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project


    View Slide

76. Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project
    project
    write


    View Slide

77. What operations are idempotent?
    Transforms: filters, projections, etc
    No side effects!
    Stateful operations


    View Slide

78. Ad filter
    read join by
    ad id
    transform
    write
    sum by
    campaign
    project
    transform
    write
    filter
    read project
    filter
    read project
    project
    write


    View Slide

79. Idempotent writes with unique keys
    campaign_id = 7,
    minute = 20,
    views = 2
    campaign
    _id
    minute views
    7 20 2
    campaign_id = 7,
    minute = 20,
    views = 2


    View Slide

80. Writes that aren’t idempotent
    campaign
    _id
    hour views
    7 2 0


    View Slide

81. Writes that aren’t idempotent
    campaign_id = 7,
    hour = 2,
    views += 1
    campaign
    _id
    hour views
    7 2 1


    View Slide

82. Writes that aren’t idempotent
    campaign_id = 7,
    hour = 2,
    views += 1
    campaign
    _id
    hour views
    7 2 2
    campaign_id = 7,
    hour = 2,
    views += 1


    View Slide

83. Support for idempotency
    campaign_id = 7,
    hour = 2,
    views += 1,
    version = 1 campaign
    _id
    hour views
    7 2 1
    campaign_id = 7,
    hour = 2,
    views += 1
    version = 1


    View Slide

84. Idempotency in streaming pipelines
    Both in output to data sink and in local state (joining,
    aggregation)
    Re-processing of events
    - Some frameworks provide exactly once guarantees


    View Slide

85. Consistency vs. availability


    View Slide

86. Always a tradeoff between
    consistency and availability
    when handling failures


    View Slide

87. Consistency
    Every read sees a current view of the data.
    Availability
    Capacity to serve requests


    View Slide

88. A = 9 A = 9


    View Slide

89. A = 3 A = 3
    A = 3
    A = 3


    View Slide

90. A = 9 A = 9


    View Slide

91. A = 9 A = 9
    Consistency > availability
    A = 3
    A = 3


    View Slide

92. A = 9 A = 9
    Consistency > availability A = 3
    Error: write
    unavailable


    View Slide

93. A = 9 A = 9
    Availability > consistency
    A = 3
    A = 3


    View Slide

94. A = 9 A = 3
    Availability > consistency
    Not consistent:
    3 != 9


    View Slide

95. Prioritizing consistency or availability
    Applies to systems for both your data source and data
    sink
    Source
    Stream
    processing
    engine
    Data sink
    Storage


    View Slide

96. Prioritizing consistency or availability
    Applies to systems for both your data source and data
    sink
    ● Some systems pick one, be aware
    ● Others let you choose
    ○ ex. Cassandra - how many replicas respond to
    write?
    Streaming applications run continuously


    View Slide

97. Prioritizing consistency or availability
    Depends on the needs of your application
    Metrics (views,
    clicks) for each
    campaign over time


    View Slide

98. Prioritizing consistency or availability
    More consistency
    Metrics (views,
    clicks) for each
    campaign over time


    View Slide

99. Prioritizing consistency or availability
    More availability
    Internal graphs
    Metrics (views,
    clicks) for each
    campaign over time


    View Slide

100. Conclusion
     ● Stream processing: data processing with operations on
     events or windows of events
     ● Horizontal scalability, as data will grow and change over
     time
     ● Handle failures appropriately
     ○ Keep operations idempotent, for retries
     ○ Tradeoff between availability and consistency


     View Slide

101. www.yelp.com/careers/
     We're Hiring!


     View Slide

102. @YelpEngineering
     fb.com/YelpEngineers
     engineeringblog.yelp.com
     github.com/yelp


     View Slide
