Plover: Thought to Text at 240 WPM by Mirabai Knight

PyCon 2013
March 17, 2013

Plover: Thought to Text at 240 WPM by Mirabai Knight

Stenographic technology has been locked down to expensive, proprietary hardware and software for decades, depriving the world of the most efficient text entry system devised to date. Plover, a free, cross-platform steno engine that works with $45 hardware, offers hackers and hobbyists the ability to type at up to 240 WPM in applications ranging from wearable computing to captioning to coding.

PyCon 2013

March 17, 2013
Tweet

More Decks by PyCon 2013

Other Decks in Technology

Transcript

  1. Plover, the Open Source Steno Engine

    View Slide

  2.  Mirabai Knight
    Founder
     Joshua Lifton, PhD
    Cofounder
     Hesky Fisher
    Lead Programmer
    Plus input, testing, and code from the 199 members of the Plover Google Group

    View Slide

  3. Phonetic-Mnemonic
    240 WPM with
    99.9% accuracy

    View Slide

  4. View Slide

  5.  Speed
     Wearability
     Ergonomics
     Paying Work
     Accessibility
     Fluency and Efficiency of Text Entry

    View Slide

  6. View Slide

  7. 22 keys
    4,194,303 possible chords

    View Slide

  8.  No spacebar
     Two-dimensional syllabic chords
     Most words can be written phonetically
     Each stenographer’s dictionary is unique
    STRAPS straps

    View Slide

  9. Encode
    English to
    Steno
    Input
    Chords
    Find longest
    match in
    dictionary
    Output
    definition

    View Slide

  10. PAOEU pie
    THON python

    View Slide

  11. DPLORBL deplorable
    PRIFRL peripheral

    View Slide

  12. original = raw_input("Enter a word:")
    if original.isalpha():
    word = original.lower()
    first = word[0]
    print first
    else:
    print "Not a word."
    QWERTY STENO
    143 54
    Using Plover With Python

    View Slide

  13. b: go Back one
    word
    q: reQord
    maQro?!
    GLERCH: Launch browser
    and perform Google search
    on text in clipboard
    QUARN: Cut highlighted
    text and append to
    prespecified bug-tracking
    document
    QWERTY STENO

    View Slide

  14. • 35 million people with hearing loss in the US
    • <2% know Sign Language
    • <400 Certified Captioners
    • Average captioner age is 50
    • 3 to 8 million people with speech disabilities

    View Slide

  15. • Virtually all steno schools are for-profit
    • Startup costs include $1,000 student
    machine and $500 hobbled software,
    plus ~$12,000/year tuition
    • Nationwide dropout rate is 85%
    • Reaching 225 WPM can take 2 - 6 years

    View Slide

  16. Amateur Professional
    $50 Ukulele $50,000 diamond-encrusted guitar
    Free Music Lessons $60,000 degree from music school
    Lots of Practice No guarantee of employment

    View Slide

  17. HOVER PLOVER

    View Slide

  18. • Fly
    • Plover Aviary
    • Plover Blog
    • Plover Dojo
    • Steno 101
    • Steno Typer
    • Steno Hero Alpha
    Plover Wiki: http://ploversteno.org

    View Slide

  19. CRITERION WINNER
    Speed Steno
    Accuracy Steno
    Customizability Steno
    Portability Voice
    Learning Curve Voice (beginner)/Steno (advanced)
    Privacy Steno
    Determinism Steno
    http://stenoknight.com/speechrec
