PyConZA 2013: "Building the SKA" by Simon Ratcliffe

The Square Kilometer Array will be one of the prime scientific data generates in the next few decades.

Construction is scheduled to commence in late 2016 and last for the best part of a decade. Current estimates put data volume generation near 1 Exabyte per day with 2-3 ExaFLOPs of processing required to handle this data.

As a host country, South Africa is constructing a large precursor telescope known as MeerKAT. Once complete this will be the most sensitive telescope of it's kind in the world - until dwarfed by the SKA.

We make extensive use of Python from the entire Monitor and Control system through to data handling and processing.

This talk looks at our current usage of Python, and our desire to see the entire high performance processing chain being able to call itself Pythonic.

We will discuss some of the challenges specific to the radio astronomy environment and how we believe Python can contribute, particularly when it comes to the trade off between development time and performance.

Transcript

1. SKA Simon Ratcliffe SSPA www.ska.ac.za *Spartan School of Presentation Aesthetics (in association with Just Say No to Bullets)
2. SR chapeaux MeerKAT SKA DOME
3. <prep type='launch' />
4. In the beginning...
5. There were some hazards...
6. Free time at last.. Kuyunjik Collection, British Museum, London. Kuyunjik Collection, British Museum, London.
7. Just 20,000 stars in the sky = www.stellarium.org
8. ...and just 12 monthly installments I just need a few florins to buy some pants
9. Can I have fifty pounds to mend the shed? = Ewan McTeagle Johannes Hevelius 60ft - 1673
10. Optical Astronomy = ESO/MPG 2.2-m telescope, La Silla
11. http://xkcd.com/273/
12. Radio Astronomy + = = + Jansky VLA, New Mexico
13. 1 Jy = 10-26 Wm-2Hz-1 Eskom ? I canna do it, captain, ye canna alter the laws of physics
14. 105 Jy 108 Jy 0 Jy Baddies Sun @ 5 GHz GSM Phone @ 1km iOS 7
15. Scale Up 1936: Grote Reber 9m 1955: Bernard Lovell 76m 1971: Effelsberg 100m
16. Karoo Array Telescope Scale Out
17. MeerKAT - 2016 Medium Telescope
18. On the ground... http://www.gigapan.com/gigapans/135410
19. Big Telescope Square Kilometer Array – Artists Impression
20. Big Data Andrew Cooper 1000000000000000000 B @ 1 bit per grain of standardised* sand * assumptions apply (10gpmm^3, 3kmx2kmx700m, only valid when calculated on paper napkin, just say no to assumptions) X
21. Big, really big... 1 exbibyte - 1 exabyte 38, 230 x
22. Big Energy Peter M. Kogge. Energy at exaflops. (2009) 16+ MW for SKA
23. How do we build this ?
24. Big Iron
25. Big Iron 10 -100 PFlop Many PFlop up to 500 Tb/s 0.2 - 2.5 EFlop SKA Phase 2 up to 5 Pb/s 1 EFlop/ EMAC … Incoming Data from collectors Switch Buffer store Switch Buffer store HPC Bulk Store Correlator Beamformer UV Processor Imaging: Non-Imaging: Corner Turning Course Delays Fine F-step/ Correlation Visibility Steering Observation Buffer Gridding Visibilities Imaging Image Storage Corner Turning Course Delays Beamforming/ De-dispersion Beam Steering Observation Buffer Time-series Searching Search analysis Object/timing Storage HPC science processing 1 - 5 PFlop Few PFlop Software Complexit y & Data*: 400 - 1000 Gb/s 30 PFlop SKA Phase 1 up to 50 Tb/s 15 PFlop/ PMAC * All numbers made up for increased wow factor Slide Credit: Andy Faulkner
26. Big, serious, grown up compute i-uniVac 9000 Extreme Edition
27. Tegra ARM QorIQ Power Exynos ARM Atom x86 SoC μ Servers TDP IO FLOPS $ ρ
28. cooling Ground Loop Hive FERRO 50 TFLOPS 2 TB RAM 8 TB Flash 20 Gbps 2.5 kW Shielded Rugged Cheap
29. Big Storage MeerKAT has a primary archive of 10 PB SKA will need at least 1 EB in around 2023
30. ebay - $20.29
31. <execute type='imager' stage='2'/>
32. Big Software 200 billion lines of COBOL and counting
33. IO / Cache / FLOPS / kW / $ V ij = M ij B ij G ij D ij E ij P ij T ij V ij IDEAL MAGIC SKA mid
34. Software “Life is too short to write C++” David Beazley
35. Deliver only what is actually needed Scale requires better ideas, not more code Simple is better than complex Optimise last Commodity is king Perfection is an illusion Philosophy (to combat the malaise that is big software)
36. You hip fanboi – don't you know Python is too slow... agggtaaa|tttaccct 0 [cgt]gggtaaa|tttaccc[acg] 3 a[act]ggtaaa|tttacc[agt]t 9 ag[act]gtaaa|tttac[agt]ct 8 agg[act]taaa|ttta[agt]cct 10 aggg[acg]aaa|ttt[cgt]ccct 3 agggt[cgt]aa|tt[acg]accct 4 agggta[cgt]a|t[acg]taccct 3 agggtaa[cgt]|[acg]ttaccct 5 regex_dna (http://shootout.alioth.debian.org/) C: 7.21 seconds Python: 31.7 seconds 4.4 times slower ! { }
37. No really, it is so sloooooow... Laplace solver (http://www.scipy.org/PerformancePython) C: 0.97 seconds Python: 6345.6 seconds 6,500 times slower Suck it Python !
38. You're holding it wrong...
39. Cereal ? Totally serial 6345.6 seconds 2.57 seconds Vectorised* 2469 times faster ! (only 2.6 times slower than C) *Like Totally
40. Simple optimisation gives us close to C performance That's because numpy is just optimised C underneath True, but I didn't actually have to write any C Don't you get paid by the kloc ? Someone else can write code, I am off to the beach.
41. Admittedly, we are still slower than C. But the language itself does not dictate performance*. The compiler / interpeter does. It's not Python, but CPython to blame. *yes, yes, I know. But outrageous claims are my forté, after all I invented the question mark.
42. Ok, so how fast do we need to be ? This is your CPU
43. Optimised gridding ~ 1ns per point per core (Xeon E5-2690) We need 64 Gbps to keep an 8-core CPU busy In reality we have an order of magnitude less
44. If our IO is efficient we can sacrifice an order of magnitude in CPU performance without overall impact* *For our specific data intensive use cases. Terms and conditions apply. If you can read this you are too close.
45. Is our IO efficient ? Yes* * Blah blah blah HDF5 blah blah Blosc blah blah C is the only real language blah blah SPEAD blah blah numpy
46. It's not about the bike language llvm IR bitcode
47. Our biggest cost is development time, not hardware This is where using high level languages, without excessive optimisation, really win.
48. Python 40+ in house modules +
49. My hovercraft is full of eels Images created With KAT-7
50. Control
51. Data Transport - SPEAD Self describing, high speed, low overhead numpy transport connecting a wide range of potentially disparate devices.
52. <fail type='demo' class='epic' /> Data Analysis
53. WWW.SKA.AC.ZA
