Getting your feet wet with RxJava

Presented in Feb '18 at JUG NCR Meetup, New Delhi.
https://www.meetup.com/Delhi-NCR-JUG/events/245487927/

Transcript

1. Getting your feet wet with
   RxJava
   Ragunath Jawahar • @ragunathjawahar


   View Slide

2. REACTIVE FUNCTIONAL


   View Slide

3. FUNCTIONAL
   • Functions are first-class citizens
   • Immutability
   • No side-effects
   • Referential transparency
   • Declarative
   • Favours concurrency


   View Slide

4. private boolean isDivisibleBy2(int number) {
   return number % 2 == 0;
   }
   Example 1


   View Slide

5. private boolean isDivisibleBy2(int number) {
   return number % 2 == 0;
   }
   Example 1


   View Slide

6. integers
   .stream()
   .map(number -> isDivisibleBy2(number) ? "Even" : "Odd");
   Example 2


   View Slide

7. integers
   .stream()
   .map(number -> isDivisibleBy2(number) ? "Even" : "Odd");
   Example 2


   View Slide

8. integers
   .stream()
   .map(number -> isDivisibleBy2(number) ? "Even" : "Odd");
   Example 2


   View Slide

9. integers
   .stream()
   .map(number -> isDivisibleBy2(number) ? "Even" : "Odd");
   Example 2


   View Slide

10. REACTIVE


    View Slide

11. View Slide

12. View Slide

13. View Slide

14. View Slide

15. REACTIVE
    • Responsive
    • Resilient
    • Elastic
    • Message Driven


    View Slide

16. REACTIVE
    • Speed Traps
    • Fire Alarms
    • Airbags
    • Autonomous Vehicles
    • Excel
    • GUI Systems
    • Hystrix
    Real World Examples


    View Slide

17. ~ Callbacks ~
    An imperative way to build reactive systems.


    View Slide

18. login(“username", “password", new Callback() {
    public void onSuccess(String authToken) {
    // Do something...
    }
    });


    View Slide

19. login(“username", “password", new Callback() {
    public void onSuccess(String authToken) {
    // Do something...
    }
    });


    View Slide

20. login(“username", “password", new Callback() {
    public void onSuccess(String authToken) {
    // Do something...
    }
    public void onFailure(Exception e) {
    // Show error message...
    }
    });


    View Slide

21. RxJava


    View Slide

22. A library for composing asynchronous and event-
    based programs using observable sequences for
    the Java VM.


    View Slide

23. Where is it used?
    • Back-end to build highly scalable systems.
    • Front-end to create maintainable code.


    View Slide

24. RxJava
    • Primitives
    • Operators


    View Slide

25. Primitive - Observable
    • Produces events
    • Usually lazy
    • Can produce one, many or zero events
    •Serialized access


    View Slide

26. button
    .setOnClickListener(click -> doSomething());
    buttonClicksObservable
    .subscribe(click -> doSomething());
    Callback
    RxJava


    View Slide

27. button
    .setOnClickListener(click -> doSomething());
    buttonClicksObservable
    .subscribe(click -> doSomething());
    Callback
    RxJava


    View Slide

28. button
    .setOnClickListener(click ->
    api.authenticate(username, password, new Callback() {
    public void onSuccess(String authToken) {
    // Save Token
    }
    public void onLoginFailed(LoginException e) {
    // Show Error
    }
    })
    );
    Callback


    View Slide

29. button
    .setOnClickListener(click ->
    api.authenticate(username, password, new Callback() {
    public void onSuccess(String authToken) {
    // Save Token
    }
    public void onLoginFailed(LoginException e) {
    // Show Error
    }
    })
    );
    Callback


    View Slide

30. button
    .setOnClickListener(click ->
    api.authenticate(username, password, new Callback() {
    public void onSuccess(String authToken) {
    // Save Token
    }
    public void onLoginFailed(LoginException e) {
    // Show Error
    }
    })
    );
    Callback


    View Slide

31. button
    .setOnClickListener(click ->
    api.authenticate(username, password, new Callback() {
    public void onSuccess(String authToken) {
    // Save Token
    }
    public void onLoginFailed(LoginException e) {
    // Show Error
    }
    })
    );
    Callback


    View Slide

32. button
    .setOnClickListener(click ->
    api.authenticate(username, password, new Callback() {
    public void onSuccess(String authToken) {
    // Save Token
    }
    public void onLoginFailed(LoginException e) {
    // Show Error
    }
    })
    );
    Callback


    View Slide

33. button
    .setOnClickListener(click ->
    api.authenticate(username, password, new Callback() {
    public void onSuccess(String authToken) {
    // Save Token
    }
    public void onLoginFailed(LoginException e) {
    // Show Error
    }
    })
    );
    Callback


    View Slide

34. buttonClicksObservable
    .flatMap(click -> api.authenticate(username, password))
    .onErrorReturn(null)
    .subscribe(authToken ->
    if (authToken != null) saveToken(authToken) else showError();
    );
    RxJava


    View Slide

35. buttonClicksObservable
    .flatMap(click -> api.authenticate(username, password))
    .onErrorReturn(null)
    .subscribe(authToken ->
    if (authToken != null) saveToken(authToken) else showError();
    );
    RxJava


    View Slide

36. buttonClicksObservable
    .flatMap(click -> api.authenticate(username, password))
    .onErrorReturn(null)
    .subscribe(authToken ->
    if (authToken != null) saveToken(authToken) else showError();
    );
    RxJava


    View Slide

37. buttonClicksObservable
    .flatMap(click -> api.authenticate(username, password))
    .onErrorReturn(null)
    .subscribe(authToken ->
    if (authToken != null) saveToken(authToken) else showError();
    );
    RxJava


    View Slide

38. buttonClicksObservable
    .flatMap(click -> api.authenticate(username, password))
    .onErrorReturn(null)
    .subscribe(authToken ->
    if (authToken != null) saveToken(authToken) else showError();
    );
    RxJava


    View Slide

39. buttonClicksObservable
    .flatMap(click -> api.authenticate(username, password))
    .onErrorReturn(null)
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe(authToken ->
    if (authToken != null) saveToken(authToken) else showError();
    );
    RxJava


    View Slide

40. Observable - Anatomy
    Data
    Error
    Completion


    View Slide

41. Observable - Anatomy
    Data
    Error
    Completion


    View Slide

42. Observable - Anatomy
    Data
    Error
    Completion


    View Slide

43. Observable - Anatomy
    Data
    Error
    Completion


    View Slide

44. Primitive - Subscriber
    • onNext(T)
    • onError(Throwable)
    • onComplete()


    View Slide

45. RxJava - Operators
    • Single Observable
    • Multiple Observable
    • Higher-Order Observables
    •Finite and infinite Observables (any of the
    above)


    View Slide

46. Marble Diagrams


    View Slide

47. filter


    View Slide

48. map


    View Slide

49. debounce


    View Slide

50. delay


    View Slide

51. interval


    View Slide

52. amb


    View Slide

53. merge


    View Slide

54. combineLatest


    View Slide

55. zip


    View Slide

56. flatMap


    View Slide

57. onError*


    View Slide

58. retry*


    View Slide

59. Error Handling
    • Exceptions are normal
    • Error handling operators
    • Retry operators


    View Slide

60. Declarative Threading
    • Using Schedulers
    • subscribeOn(Scheduler)
    • observeOn(Scheduler)


    View Slide

61. Debugging
    • Could be a pain 
    • Use doOn* operators to inspect the
    pipeline
    • Traceur (RxJava 2)


    View Slide

62. Testing
    • Mockito
    • Subjects / Relays


    View Slide

63. Further Reading
    André Staltz


    View Slide

64. Questions?


    View Slide
