Effective Android Architecture - MWDC

Yet another talk on Android architecture at MWDC 2015

Transcript

1. EFFECTIVE ANDROID
   ARCHITECTURE


   View Slide

2. Hi, I am Richa


   View Slide

3. EFFECTIVE ANDROID
   ARCHITECTURE


   View Slide

4. View Slide

5. View Slide

6. View Slide

7. View Slide

8. View Slide

9. Who all has ever used
   MVC?


   View Slide

10. MVC


    View Slide

11. MVP ?
    MVC ?
    MVVM ?


    View Slide

12. MODEL VIEW CONTROLLER
    Interact with DB Render Model Handle view events
    Update model
    Invoke next UI
    Table of Responsibilities


    View Slide

13. Mobile
    Web
    Desktop


    View Slide

14. View Slide

15. MODEL VIEW CONTROLLER
    Interact with DB Render Model Handle view events
    Interact with network Manage view state Update model
    Navigation
    Interact with system
    components
    Handle system events
    Update view on system
    events


    View Slide

16. Model
    public class CourseModel {
    Course getFromDatabase() {
    // fetch from db, or local cache
    }
    Course getFromNetwork() {
    // fetch from apis, cache when possible
    }
    }


    View Slide

17. View
    public class ExpandableCourseListActivity
    {
    void onSaveInstanceState(Bundle b) {
    // save all expanded states
    }
    }


    View Slide

18. Controller
    void onClick() {}
    void onModelUpdated() {}
    void onNewNotification() {}
    void onLocationUpdated(Location loc) {}
    void takePhoto(Activity context) {}
    void launchView(Activity context ) {}


    View Slide

19. View Slide

20. View Slide

21. MVC
    ??


    View Slide

22. MODEL VIEW CONTROLLER
    Interact with DB Render Model Handle view events
    Interact with network Manage view state Update model
    Navigation
    Interact with system
    components
    Handle system events
    Update view on system
    events


    View Slide

23. Interactor?


    View Slide

24. JUnit +
    Mocking


    View Slide

25. MODEL VIEW CONTROLLER INTERACTOR
    Retrieve data from
    DB
    Render Model
    Handle view
    events
    Interact with
    external entities
    Retrieve data from
    network
    Manage view
    state
    Navigation
    Forward system
    events to view
    Forward model
    updates to view


    View Slide

26. View Model ?


    View Slide

27. JUnit +
    Mocking
    Android +
    Mocking
    Espresso +
    Mocking


    View Slide

28. MODEL VIEW CONTROLLER INTERACTOR VIEW MODEL
    Retrieve data
    from Network
    Render View
    Model
    Handle view
    events
    Interact with
    external
    entities
    View state /
    behavior
    Retrieve data
    from network
    Navigation
    Update view
    state


    View Slide

29. Presenter ?


    View Slide

30. MODEL VIEW PRESENTER INTERACTOR VIEW MODEL
    Retrieve data
    from DB
    Render View
    Model
    Handle view
    events
    Interact with
    external
    entities
    View state /
    behavior
    Retrieve data
    from network
    Navigation
    Update view
    state


    View Slide

31. Espresso +
    Mocking
    JUnit +
    Mocking
    JUnit +
    Mocking
    Android +
    Mocking
    Data Source


    View Slide

32. ENTITIES VIEW PRESENTER INTERACTOR VIEW MODEL
    Get data from
    Data Sources
    Render View
    Model
    Handle view
    events
    Interact with
    external
    entities
    View state /
    behavior
    Navigation
    Update view
    state


    View Slide

33. FlowController ?


    View Slide

34. Android +
    Mocks


    View Slide

35. ENTITIES VIEW PRESENTER INTERACTOR VIEW MODEL
    FLOW
    CONTROLLER
    Get data
    from Data
    Sources
    Render View
    Model
    Handle view
    events

    Update view
    state
    Interact

    with external
    entities
    View state /
    behavior
    Navigation


    View Slide

36. View Slide

37. Apply Dependency
    Inversion


    View Slide

38. View Slide

39. View Slide

40. View Slide

41. S ingle Responsibility Principle
    O pen/Closed Principle
    L iskov Substitution Principle
    I nterface Segregation Principle
    D ependency Inversion Principle


    View Slide

42. Architecture is about
    Intents not Frameworks
    - Uncle Bob


    View Slide

43. View Slide

44. Implementation in
    Practice


    View Slide

45. Activity
    Video
    Module
    Activity
    Quiz
    Module
    Navigation
    Main
    Activity
    Shell
    App
    Catalog
    Activity
    Catalog
    Module
    url Intent
    Intent
    Register
    with url
    Modules


    View Slide

46. Deep links
    Shell
    App
    Video
    Activity
    Video
    Module
    Catalog
    Activity
    Catalog
    Module
    register register
    url
    Intent
    Intent


    View Slide

47. ViewModels Save/Restore
    View
    Models
    Presenter
    Retainable
    Fragments
    Parcelables
    onSaveInstanceState
    onSaveInstanceState


    View Slide

48. Chain of Responsibility
    View
    Presenter
    Interactor
    Network
    Persistence •Result
    •Error


    View Slide

49. View Slide

50. The Cons


    View Slide

51. Dealing with context
    Presenter(Context context)
    Interactor(Context context)
    NetworkClient(Context context)
    PersistenceClient(Context context)
    context.getSystemService(“SERVICE”)
    context.startActivity(intent)
    context.startActivityForResult(intent)


    View Slide

52. Tedium
    ~ 7 classes per feature/module


    View Slide

53. Adopting as a team
    Educating new hires


    View Slide

54. Key Takeaways


    View Slide

55. Ship the latest ideas


    View Slide

56. Refactor or Not?


    View Slide

57. Validate


    View Slide

58. Iterate, Iterate, Iterate


    View Slide

59. Code Demo - Sample app


    View Slide

60. Source Code
    https://github.com/richk/
    CourseraDemoApp


    View Slide

61. Classes
    • MainActivity
    • CatalogFlowController
    • CatalogActivity
    • CatalogPresenter
    • CatalogViewModel
    • CatalogInteractor


    View Slide

62. MainActivity
    void onCreate() {
    CatalogFlowController.getInstance()
    .launchCatalogActivity();
    }


    View Slide

63. CatalogFlowController
    void launchCatalogActivity(Context c) {
    Intent intent = …;
    c.startActivity(intent)
    }


    View Slide

64. CatalogActivity
    CatalogPresenter presenter;
    void onCreate() {
    presenter = new CatalogPresenter(this);
    }


    View Slide

65. CatalogActivity
    void onResume() {
    Action1 action = ;
    presenter.subscribeToUpdates(action)
    }


    View Slide

66. CatalogActivity
    void onPause() {
    presenter.unsubscribeToUpdates();
    }


    View Slide

67. CatalogPresenter
    CatalogInteractor interactor;
    CatalogPresenter(Context c) {
    viewModel = new CatalogViewModel();
    interactor = new CatalogInteractor(c);
    loadCatalog();
    }


    View Slide

68. CatalogPresenter
    void loadCatalog() {
    interactor.loadCourses()
    .subscribe(new Action1<>() {
    @Override
    public void call(List courses) {
    // action
    }
    });
    }


    View Slide

69. CatalogPresenter
    void subscribeToUpdates(Action1 a) {
    viewModel.subscribeToUpdates(a);
    }
    void unsubscribeToUpdates() {
    viewModel.unsubscribeToUpdates();
    }


    View Slide

70. CatalogViewModel
    public final BehaviorSubject catalog =
    BehaviorSubject.create();
    public void subscribeToCatalog(Action1 action) {
    catalog.subscribe(action);
    }
    public void unsubscribeToCatalog() {
    catalog.unsubscribe();
    }


    View Slide

71. CatalogInteractor
    Context mContext;
    public CatalogInteractor(Context context) {
    mContext = context;
    }
    public Observable loadCatalog() {
    return catalogDataSource.loadCatalog();
    }


    View Slide

72. View Slide

73. View Slide

74. Coursera is hiring!


    View Slide

75. Questions ?


    View Slide

76. @richa123
    rkhandelwal@coursera.org
    richk
    in/richak
    Thank You


    View Slide
