Michał Tajchert - Android Wear Deep Dive

Transcript

1. Android Wear Deep Dive Michał Tajchert Polidea, Software Engineer
2. Michał Tajchert Android dev in Polidea Warsaw GDG Gadget freak
4. Notifications
5. Notifications Simplicity Context Extension
6. Actions
7. Actions NotificationCompat.Builder notificationBuilder = new NotificationCompat.Builder(this) .setSmallIcon(R.drawable.ic_event) .setContentTitle(eventTitle) .setContentText(eventLocation) .setContentIntent(viewPendingIntent) .addAction(R.drawable.ic_map, “Map Title”, mapPendingIntent);
9. Notification stack NotificationCompat.Builder notificationBuilder = new NotificationCompat.Builder(this) .setSmallIcon(R.drawable.ic_event) .setContentTitle(eventTitle) .setContentText(eventLocation) .setContentIntent(viewPendingIntent) .setGroup(“group_unique_name”)
10. NotificationCompat.WearableExtender
11. Notification NotificationCompat.WearableExtender wearableExtender = new NotificationCompat. WearableExtender() .setHintHideIcon(true) .setBackground(mBitmap); NotificationCompat.Builder notificationBuilder = new NotificationCompat.Builder(this) .setSmallIcon(R.drawable.ic_event) .setContentTitle(eventTitle) .setContentText(eventLocation) .setContentIntent(viewPendingIntent) .extend(wearableExtender);
12. Background 400x400 px or 640x400 px
13. Drawables res/drawables-nodpi
14. Voice Actions
15. Standalone apps!
16. Standalone app • Offline mode • Custom UI • Access to sensors (and more) • Background work • ....
17. APK APK
18. Mobile Module ? Wear Module
19. Google Play Services
20. Data exchanging • DataItem API • Message API
21. Message API
22. DataItem API
23. Data Layer Interfaces interface DataListener { void onDataChanged(DataEventBuffer dataEvents); } interface MessageListener { void onMessageReceived(MessageEvent messageEvent); } interface NodeListener { void onPeerConnected(Node node); void onPeerDisconnected(Node node); }
24. Teleport github.com/Mariuxtheone/Teleport
25. Teleport TeleportClient mTeleportClient = new TeleportClient(this); mTeleportClient.connect(); mTeleportClient.sendMessage("startActivity", null); mTeleportClient.syncInt("myInt", 12345); setOnGetMessageTask(new TeleportService.OnGetMessageTask { @Override protected void onPostExecute(String path) { if (path.equals("startActivity")){ Intent startIntent = new Intent(this, WearActivity.class); startIntent.addFlags(Intent.FLAG_ACTIVITY_NEW_TASK); startActivity(startIntent); };}
26. EventBus
27. BusWear github.com/tajchert/BusWear
28. EventBus
29. EventBus
30. BusWear
31. EventBus.getDefault().post(parcelableObject, this); EventBus.getDefault().postRemote("text", this); EventBus.getDefault().postLocal(object); protected void onCreate(Bundle savedInstanceState) { EventBus.getDefault().register(this); } public void onEvent(ParcelableObject parcelableObject){ } public void onEvent(String text){ } BusWear
35. WearHttp github.com/takahirom/WearHttp
36. WearHttp new WearGetText(MainActivity.this).get("http://example.com/text.txt", new WearGetText.WearGetCallBack() { @Override public void onGet(String contents) { mTextView.setText(contents); } @Override public void onFail(final Exception e) { mTextView.setText(e.getMessage()); } });
37. AndroidWearScripts github.com/tajchert/AndroidWearScripts
38. AndroidWearScripts adb forward tcp:4444 localabstract:/adb-hub adb connect localhost:4444 adb -s localhost:4444 <command> ./main.sh <optional Id> ./screenshot.sh ./install.sh <apk_file> ./listPackages.sh ...
39. Exception handling goo.gl/o46Z1u
40. Exception handling <service android:name=".wear.service.ErrorService" android:process=":error"/> public class WearableApp extends Application { private Thread.UncaughtExceptionHandler mWearUEH = new Thread.UncaughtExceptionHandler() { public void uncaughtException(final Thread thread, final Throwable ex) { //... startService(errorIntent); } }; @Override public void onCreate() { Thread.setDefaultUncaughtExceptionHandler(mWearUEH); } } goo.gl/o46Z1u
41. Sensors
42. • Acceleration (m/s2) • Magnetic Field (μT) • Gyroscope (rad/s) • Proximity (cm) Sensors • Temperature (°C) • Pressure (hPa) • Humidity (%) • Light (lx) • Heartrate
43. Sensors - calculated • Acceleration (m/s2) • Magnetic Field (μT) • Gyroscope (rad/s) • Proximity (cm) • Temperature (°C) • Pressure (hPa) • Humidity (%) • Light (lx) • Heartrate • Steps • Significant Motion • Gravity • Linear Acceleration • Vector Rotation (x3)
44. Magnetic Field - location, field strength
45. Gyroscope - rate or rotation (rad/s)
47. Continuity
48. Views
49. Problem?
50. WearViewStub
51. BoxInsetLayout
52. CircledImageView
53. DismissOverlayView
54. DelayedConfirmationView
55. DelayedConfirmationView
56. GridViewPager
57. CardFragment
58. CardFrame
59. GridViewPager- has beautiful background with parallax effect Here be dragons... isRound() - works only with English language. which sometimes disappears.
60. App that rocks!
61. RAX79Z
62. google.com/+MichalTajchert @tajchert github.com/tajchert www.tajchert.pl Michał Tajchert
