Building connected Product using Android Things

Presented at DevFest CZ , Prague Czech Republic.

In this presentation, Rebecca will look into using the Android Things platform as a way in which you can build connected products using Android. Rebecca will cover controlling your Android Things device with the Google Assistant. She will also talk through some different options for storing data for IoT devices. She will also showcase a few different applications of Android Things.

Transcript

1. Building a connected Product
   using Android Things
   Rebecca Franks
   Android Engineering Lead at DVT
   Google Developer Expert Android
   @riggaroo


   View Slide

2. riggaroo.co.za


   View Slide

3. Outline
   ● Android Things
   ● Google Assistant Integration
   ● Storage Options
   ● Examples


   View Slide

4. Android Things


   View Slide

5. Android Things is an extension of the Android platform for
   IoT and embedded devices.


   View Slide

6. Interactive Ads
   Vending Machines
   Point of Sale
   Stock Control
   Retail
   Cameras
   Gateways
   Access Control
   Smart Meters
   Business
   Asset Tracking
   Fleet Management
   Driver Assist
   Predictive Service
   Logistics
   Security Systems
   Smart Doorbells
   Routers
   Energy Monitors
   Home
   Android Things is ideal for powerful, intelligent
   devices that need to be secure.


   View Slide

7. Similarities
   Any other Android library...
   Android SDK Play Services Firebase
   Android Studio Cloud Platform


   View Slide

8. Differences
   No Play Store Deploy OTAs
   Subset of
   APIs
   Custom
   Hardware
   Single Purpose
   Device


   View Slide

9. Applications
   Launcher Phone Messaging Contacts Calendar Browser Settings
   Application Framework
   Activity
   Manager
   Window Manager Power
   Manager
   Resource
   Manager
   XMPP
   Service
   Content
   Providers
   Wallpapers System UI
   Package
   Manager
   Telephony
   Manager
   Location
   Manager
   Connectivity
   Manager
   View
   System
   Runtime
   Permissions
   Soft
   Keyboards Notifications
   Libraries
   Surface
   Manager
   Media
   Framework
   Chromium SSL HAL
   Audio
   Manager
   SQLite Open GL libc
   Core
   Libraries
   Android
   Runtime (ART)
   Android Runtime
   Linux Kernel
   Display Driver Camera Driver Bluetooth Driver
   Binder (IPC)
   Driver
   USB Driver Audio Driver WiFi Driver
   Power
   Management


   View Slide

10. Applications
    Launcher Phone Messaging Contacts Calendar Browser Settings
    Application Framework
    Activity
    Manager
    Window Manager Power
    Manager
    Resource
    Manager
    XMPP
    Service
    Content
    Providers
    Wallpapers System UI
    Package
    Manager
    Telephony
    Manager
    Location
    Manager
    Connectivity
    Manager
    View
    System
    Runtime
    Permissions
    Soft
    Keyboards Notifications
    Libraries
    Surface
    Manager
    Media
    Framework
    Chromium SSL HAL
    Audio
    Manager
    SQLite Open GL libc
    Core
    Libraries
    Android
    Runtime (ART)
    Android Runtime
    Linux Kernel
    Display Driver Camera Driver Bluetooth Driver
    Binder (IPC)
    Driver
    USB Driver Audio Driver WiFi Driver
    Power
    Management


    View Slide

11. Applications
    Launcher Phone Messaging Contacts Calendar Browser Settings
    Application Framework
    Activity
    Manager
    Window Manager Power
    Manager
    Resource
    Manager
    XMPP
    Service
    Wallpapers System UI
    Package
    Manager
    Telephony
    Manager
    Location
    Manager
    Connectivity
    Manager
    View
    System
    Soft
    Keyboards Notifications
    Libraries
    Surface
    Manager
    Media
    Framework
    Chromium SSL HAL
    Audio
    Manager
    SQLite Open GL libc
    Core
    Libraries
    Android
    Runtime (ART)
    Android Runtime
    Linux Kernel
    Display Driver Camera Driver Bluetooth Driver
    Binder (IPC)
    Driver
    USB Driver Audio Driver WiFi Driver
    Power
    Management
    Things Support Library
    Peripheral
    I/O
    Device
    Management
    User
    Drivers Connectivity


    View Slide

12. SoM
    Architecture
    Google
    Managed BSP


    View Slide

13. Distribution with Android Things
    Android Framework
    Hardware Libraries
    Linux Kernel
    Managed by Google
    Apps
    User Drivers
    Managed by Developers


    View Slide

14. Android Things Console
    ● Manage your Android Things IoT Product
    ● Download and install the latest Android Things system
    ● Build factory images that contain OEM applications along
    with the system image
    ● Push over-the-air (OTA) updates
    partner.android.com/things/console


    View Slide

15. View Slide

16. View Slide

17. View Slide

18. Automatic
    Security Updates
    Signed Images Verified Boot
    A/B Rollback
    Protection


    View Slide

19. Developing for Android
    Things


    View Slide

20. Developer Kits
    NXP I.MX7D Raspberry Pi 3


    View Slide

21. Hardware Integration
    Peripheral Driver Library - Github
    + many more...
    bit.ly/androidthings-github
    Button GPS
    PWM Servo
    RGB LED Strip
    Temperature
    Sensor
    Capacitive
    Touch Buttons
    Peripheral I/O - Low Level Access
    GPIO PWM
    I2C SPI
    UART I2S


    View Slide

22. Build a Motion Sensing
    Camera


    View Slide

23. Motion Sensing Camera


    View Slide

24. Pico i.MX7 Pinout


    View Slide

25. View Slide

26. View Slide

27. View Slide

28. //Automatically added in app level build.gradle
    compileOnly 'com.google.android.things:androidthings:...'


    View Slide

29. //Automatically added in AndroidManifest.xml






    android:name="android.intent.category.IOT_LAUNCHER"/>






    View Slide

30. //Automatically added in AndroidManifest.xml






    android:name="android.intent.category.IOT_LAUNCHER"/>






    View Slide

31. Working with a Motion
    Sensor


    View Slide

32. GPIO
    - General Purpose Input / Output
    - Programmable way to read true / false values (1 or 0) (push
    button, PIR Sensor)
    - Write true/false values (LED)
    - Configurable


    View Slide

33. PIR Sensor


    View Slide

34. Motion Sensor Control


    View Slide

35. //Accessing Sensor Data
    private val motionSensorGpio: Gpio = PeripheralManagerService().openGpio(motionSensorPin)
    fun start() {
    motionSensorGpio.setDirection(Gpio.DIRECTION_IN)
    motionSensorGpio.setActiveType(Gpio.ACTIVE_HIGH)
    motionSensorGpio.setEdgeTriggerType(Gpio.EDGE_BOTH)
    motionSensorGpio.registerGpioCallback(object : GpioCallback() {
    override fun onGpioEdge(gpio: Gpio): Boolean {
    if (gpio.value) {
    motionListener.onMotionDetected()
    } else {
    motionListener.onMotionStopped()
    }
    return true
    }
    })
    }


    View Slide

36. //Accessing Sensor Data
    private val motionSensorGpio: Gpio = PeripheralManagerService().openGpio(motionSensorPin)
    fun start() {
    motionSensorGpio.setDirection(Gpio.DIRECTION_IN)
    motionSensorGpio.setActiveType(Gpio.ACTIVE_HIGH)
    motionSensorGpio.setEdgeTriggerType(Gpio.EDGE_BOTH)
    motionSensorGpio.registerGpioCallback(object : GpioCallback() {
    override fun onGpioEdge(gpio: Gpio): Boolean {
    if (gpio.value) {
    motionListener.onMotionDetected()
    } else {
    motionListener.onMotionStopped()
    }
    return true
    }
    })
    }


    View Slide

37. //Accessing Sensor Data
    private val motionSensorGpio: Gpio = PeripheralManagerService().openGpio(motionSensorPin)
    fun start() {
    motionSensorGpio.setDirection(Gpio.DIRECTION_IN)
    motionSensorGpio.setActiveType(Gpio.ACTIVE_HIGH)
    motionSensorGpio.setEdgeTriggerType(Gpio.EDGE_BOTH)
    motionSensorGpio.registerGpioCallback(object : GpioCallback() {
    override fun onGpioEdge(gpio: Gpio): Boolean {
    if (gpio.value) {
    motionListener.onMotionDetected()
    } else {
    motionListener.onMotionStopped()
    }
    return true
    }
    })
    }


    View Slide

38. LED Control


    View Slide

39. val peripheralManagerService = PeripheralManagerService()
    ledGpio = peripheralManagerService.openGpio(LED_GPIO_PIN)
    ledGpio.setDirection(Gpio.DIRECTION_OUT_INITIALLY_LOW)
    ledGpio.value = true
    ledGpio.close()


    View Slide

40. val peripheralManagerService = PeripheralManagerService()
    ledGpio = peripheralManagerService.openGpio(LED_GPIO_PIN)
    ledGpio.setDirection(Gpio.DIRECTION_OUT_INITIALLY_LOW)
    ledGpio.value = true
    ledGpio.close()


    View Slide

41. val peripheralManagerService = PeripheralManagerService()
    ledGpio = peripheralManagerService.openGpio(LED_GPIO_PIN)
    ledGpio.setDirection(Gpio.DIRECTION_OUT_INITIALLY_LOW)
    ledGpio.value = true
    ledGpio.close()


    View Slide

42. Google Assistant Integration


    View Slide

43. View Slide

44. Smart Home Apps rely on
    Home Graph
    Living Room
    Kitchen
    Bedroom
    Office


    View Slide

45. Smart Home App
    1. Setup an OAuth 2.0 server for account linking.
    2. Create an Actions on Google developer project.
    3. Create an action package, declaring support for Smart Home
    intents.
    4. Provide fulfillment of Smart Home intents. (Cloud function)
    5. Test and submit your app for approval.


    View Slide

46. Smart Home - Setup + SYNC


    View Slide

47. Smart Home - EXECUTE Command


    View Slide

48. Smart Home - QUERY Command


    View Slide

49. View Slide

50. Google Assistant Example
    bit.ly/actions-google
    Hackster Project:
    bit.ly/hack-at-motion-camera


    View Slide

51. Communication + Storage


    View Slide

52. Firebase


    View Slide

53. Firebase
    Realtime
    Database
    Cloud Firestore
    BETA


    View Slide

54. Firebase
    Realtime
    Database
    Cloud Firestore
    - Beta
    - Advanced Querying
    - Automatic Scaling
    - Next Generation
    - Public
    - Store and sync data
    in realtime
    - Hard querying
    BETA


    View Slide

55. Firebase
    Realtime
    Database
    data class User(val name: String? = null, val surname: String? = null)
    val ref = FirebaseDatabase.getInstance().getReference(FIREBASE_MOTION_LOGS).push()
    ref.setValue(User(“Rebecca”,“Franks”))


    View Slide

56. Firebase
    val db = FirebaseFirestore.getInstance()
    val newUser = User("Ada", "Lovelace")
    db.collection("users")
    .add(newUser)
    .addOnSuccessListener { ref -> Log.d(TAG, "Added user with ID: " + ref.id) }
    .addOnFailureListener { err -> Log.w(TAG, "Error adding user", err) }
    Cloud Firestore
    BETA


    View Slide

57. Cloud IoT Core
    BETA


    View Slide

58. What is Cloud IoT Core?
    Device Manager
    Protocol Bridge
    (MQTT, HTTP)


    View Slide

59. What is Cloud IoT Core?


    View Slide

60. Example
    Device
    (Android
    Things)
    Google
    Cloud IoT
    Core
    Cloud
    Pub Sub
    Server or Cloud
    Function
    It is cold
    It is cold
    It is cold
    Turn
    on
    heat
    Turn on heat


    View Slide

61. Or use your own solution…


    View Slide

62. Examples


    View Slide

63. Edison Candle
    Dave Smith
    @devunwired


    View Slide

64. BrailleBox
    Joe Birch
    @hitherejoe


    View Slide

65. AI Candy Dispenser
    Alvaro Viebrantz
    @alvaroviebrantz


    View Slide

66. Wildlife Detector
    Paul Trebilcox-Ruiz
    @PaulTR88


    View Slide

67. Automatic and
    Secure
    The Power of
    Android
    Managed by
    Google
    Summary: Why Android Things?


    View Slide

68. More info:
    docs bit.ly/androidthings
    codelab bit.ly/at-codelab


    View Slide

69. Thank you!
    Rebecca Franks
    Android Engineering Lead at DVT
    @riggaroo


    View Slide
