Custom Drawing in Compose - Londroid December 2022

Presented at Londroid 2022, custom drawing in Compose covers examples of how to draw custom designs in your Jetpack Compose Apps.

Covering things like:
Modifier.drawBehind
Modifier.drawWithContent
Modifier.drawWithCache
AGSL shaders, Paths and Animations.

Transcript

1. Custom Drawing in
   Compose
   Rebecca Franks (she/her)


   Developer Relations Engineer


   @riggaroo


   View Slide

2. goo.gle/compose-jetlagged-talk


   View Slide

3. View Slide

4. goo.gle/compose-jetlagged


   View Slide

5. • Offset + Size of each rect is based on
   duration of sleep period


   • Rounded Rectangles joined together
   with lines in between periods


   • Gradient across the expanded bars
   Custom Drawing
   Sleep Score Emoji
   Sleep Periods


   with different durations


   View Slide

6. Drawing in Compose
   Canvas(


   onDraw = {


   drawRoundRect(Color.Blue)


   }


   )
   Canvas Composable Modifiers
   Modifier.drawBehind { }


   Modifier.drawWithContent { }


   Modifier.drawWithCache { }




   View Slide

7. Canvas(


   onDraw = {


   drawRoundRect(Color.Blue)


   }


   )
   Canvas Composable


   View Slide

8. @Composable


   fun Canvas(modifier: Modifier, onDraw: DrawScope.() -> Unit) =


   Spacer(modifier.drawBehind(onDraw))


   Canvas implementation
   Just a spacer 🕵


   View Slide

9. Drawing in Compose 🎨
   Draws behind the Composables
   content.


   Can specify the order of draw
   calls.


   Modifier.drawBehind Modifier.drawWithContent
   Objects that are used during
   drawing are cached, until size
   changes or state variables read
   inside change.


   Modifier.drawWithCache


   View Slide

10. • Top left has the coordinate of [0,0]


    • Bottom right has the coordinate of [width, height].


    • Draw calls are performed with pixel measurements
    (not dp).


    • Relative to the parent Composable
    Co-ordinate System
    [width,height]
    [0,0] X axis
    Y axis
    x
    y
    [0,height]
    [width,0]


    View Slide

11. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    Spacer(


    modifier = modifier


    .drawWithCache {


    onDrawBehind {


    // this: DrawScope


    }


    }


    .fillMaxWidth()


    .height(48.dp)


    )


    }




    View Slide

12. DrawScope
    Declarative, stateless drawing API to draw shapes, paths etc without needing to
    maintain your own state.


    View Slide

13. interface DrawScope {


    val center: Offset


    val size: Size


    fun drawLine()


    fun drawRect()


    fun drawImage()


    fun drawRoundRect()


    fun drawPath()


    // etc


    }


    View Slide

14. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    Spacer(


    modifier = modifier


    .drawWithCache {


    onDrawBehind {


    // this: DrawScope


    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

15. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    Spacer(


    modifier = modifier


    .drawWithCache {




    onDrawBehind {




    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

16. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    Spacer(


    modifier = modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

17. fun drawRoundRect(


    brush: Brush,


    topLeft: Offset = Offset.Zero,


    size: Size = this.size.offsetSize(topLeft),


    cornerRadius: CornerRadius = CornerRadius.Zero,


    alpha: Float = 1.0f,


    style: DrawStyle = Fill,


    colorFilter: ColorFilter? = null,


    blendMode: BlendMode = DefaultBlendMode


    )
    Default values


    View Slide

18. View Slide

19. View Slide

20. Draw Text ✍
    From
    Com
    pose 1.3+


    View Slide

21. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    Spacer(


    modifier = modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

22. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    Spacer(


    modifier = modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

23. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    val textMeasurer = rememberTextMeasurer()




    Spacer(


    modifier = modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))




    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))




    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

24. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    val textMeasurer = rememberTextMeasurer()




    Spacer(


    modifier = modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))




    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

25. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    val textMeasurer = rememberTextMeasurer()




    Spacer(


    modifier = modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    drawText(textResult)


    }


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

26. View Slide

27. View Slide

28. View Slide

29. Animate height on
    click ✨


    View Slide

30. @Composable


    fun SleepBar(


    sleepData: SleepDayData,


    modifier: Modifier = Modifier


    ) {


    val textMeasurer = rememberTextMeasurer()




    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

31.



    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

32.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

33.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    )


    }




    View Slide

34.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    .clickable {


    isExpanded = !isExpanded


    }


    )


    }




    View Slide

35.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    .clickable {


    isExpanded = !isExpanded


    }


    )


    }




    View Slide

36.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    val transition = updateTransition(targetState = isExpanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(24.dp)


    .clickable {


    isExpanded = !isExpanded


    }


    )


    }




    View Slide

37.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    val transition = updateTransition(targetState = isExpanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    Spacer(


    modifier = modifier


    .drawWithCache {


    // Our drawing code


    }


    .fillMaxWidth()


    .height(height)


    .clickable {


    isExpanded = !isExpanded


    }


    )


    }




    View Slide

38. View Slide

39. Text Offset
    Animation


    View Slide

40.



    var isExpanded by remember {


    mutableStateOf(false)


    }


    val transition = updateTransition(targetState = expanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    Spacer(


    modifier = Modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    drawText(textResult)


    }


    }


    .fillMaxWidth()


    .height(height)


    .clickable {





    View Slide

41.

    val transition = updateTransition(targetState = expanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    Spacer(


    modifier = Modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    drawText(textResult)


    }


    }


    .fillMaxWidth()


    .height(height)


    .clickable {


    expanded = !expanded






    View Slide

42.

    val transition = updateTransition(targetState = expanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    val textOffset by transition.animateFloat { targetExpanded ->


    if (targetExpanded) 1f else 0f


    }


    Spacer(


    modifier = Modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    drawText(textResult)


    }


    }


    .fillMaxWidth()


    .height(height)


    .clickable {





    View Slide

43.

    val transition = updateTransition(targetState = expanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    val textOffset by transition.animateFloat { targetExpanded ->


    if (targetExpanded) 1f else 0f


    }


    Spacer(


    modifier = Modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    drawText(textResult)


    }


    }


    .fillMaxWidth()






    View Slide

44.

    val transition = updateTransition(targetState = expanded)


    val height by transition.animateDp { targetExpanded ->


    if (targetExpanded) 110.dp else 24.dp


    }


    val textOffset by transition.animateFloat { targetExpanded ->


    if (targetExpanded) 1f else 0f


    }


    Spacer(


    modifier = Modifier


    .drawWithCache {


    val brush =


    Brush.verticalGradient(listOf(YellowVariant, Yellow /*etc*/))


    val textResult = textMeasurer.measure(AnnotatedString("😴"))


    onDrawBehind {


    drawRoundRect(brush, cornerRadius = CornerRadius(10.dp.toPx()))


    translate(left = -textOffset * textResult.size.width) {


    drawText(textResult)


    }


    }


    }


    .fillMaxWidth()






    View Slide

45. Draw Paths ➰


    View Slide

46. View Slide

47. val path = Path()


    var previousPeriod: SleepPeriod? = null


    sleepData.sleepPeriods.forEach { period ->


    previousPeriod = period


    }


    return path




    View Slide

48. if (previousPeriod != null) {


    path.lineTo(x = /..., y = /...) // STEP 1


    }


    val path = Path()


    var previousPeriod: SleepPeriod? = null


    sleepData.sleepPeriods.forEach { period ->


    previousPeriod = period


    }


    return path




    View Slide

49. path.addRect(rect = /...) // STEP 2


    val path = Path()


    var previousPeriod: SleepPeriod? = null


    sleepData.sleepPeriods.forEach { period ->


    if (previousPeriod != null) {


    path.lineTo(x = /..., y = /...) // STEP 1


    }


    previousPeriod = period


    }


    return path




    View Slide

50. val path = Path()


    var previousPeriod: SleepPeriod? = null


    sleepData.sleepPeriods.forEach { period ->


    if (previousPeriod != null) {


    path.lineTo(x = /..., y = /...) // STEP 1


    }


    path.addRect(rect = /...) // STEP 2


    path.moveTo(x = /..., y = /…) // STEP 3


    previousPeriod = period


    }


    return path


    gradi


    View Slide

51. val path = Path()


    var previousPeriod: SleepPeriod? = null


    sleepData.sleepPeriods.forEach { period ->


    if (previousPeriod != null) {


    path.lineTo(x = /..., y = /...) // STEP 1


    }


    path.addRect(rect = /...) // STEP 2


    path.moveTo(x = /..., y = /…) // STEP 3


    previousPeriod = period


    }


    return path


    gradi


    View Slide

52. val path = generateSleepPath(/*pass data*/)


    onDrawBehind {


    drawPath(path, brush = gradientBrush)


    }




    View Slide

53. val path = generateSleepPath(/*pass data*/)


    onDrawBehind {


    drawPath(path, brush = gradientBrush)


    }




    View Slide

54. val path = generateSleepPath(/*pass data*/)


    onDrawBehind {


    // default arg: style = Fill


    drawPath(path, brush = gradientBrush)


    }




    View Slide

55. val path = generateSleepPath(/*pass data*/)


    onDrawBehind {


    // default arg: style = Fill


    drawPath(path, brush = gradientBrush)


    // call draw again with Stroke style


    drawPath(path, brush = gradientBrush


    style = Stroke(/**/),


    )


    }




    View Slide

56. val path = generateSleepPath(/*pass data*/)


    onDrawBehind {


    // default arg: style = Fill


    drawPath(path, brush = gradientBrush)


    // call draw again with Stroke style


    drawPath(path, brush = gradientBrush


    style = Stroke(lineThicknessPx,


    cap = StrokeCap.Round,


    join = StrokeJoin.Round,


    pathEffect = PathEffect.cornerPathEffect(


    cornerRadiusPx * expandedProgress)


    )


    )


    }




    View Slide

57. val path = generateSleepPath(/*pass data*/)


    onDrawBehind {


    // default arg: style = Fill


    drawPath(path, brush = gradientBrush)


    // call draw again with Stroke style


    drawPath(path, brush = gradientBrush


    style = Stroke(/**/),


    )


    }




    View Slide

58. View Slide

59. View Slide

60. Custom ShaderBrush
    with AGSL
    Using AGSL and want to use it with DrawScope in Compose…


    From
    Android T+
    • Based on GLSL (OpenGL)


    • Android T+


    • Runs on GPU so very efficient (parallel pixel calculations)


    View Slide

61. Taken from an


    online shader tool


    View Slide

62. @Composable


    private fun JetLaggedScreen() {


    Column() {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    JetLaggedHeaderTabs()


    TimeGraph()


    }




    View Slide

63. @Language("AGSL")
    val SHADER = """
    uniform float2 resolution;
    uniform float time;
    layout(color) uniform half4 color;
    float4 main(in float2 fragCoord) {
    // do some math to calculate colour per pixel
    return float4(color, 1.0);
    }
    """.trimIndent()
    For each pixel in the area,


    main() is called with the


    coordinate of where its calling from


    View Slide

64. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    }


    View Slide

65. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)




    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    }


    View Slide

66. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    }


    View Slide

67. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)




    shader.setFloatUniform("iResolution", size.width, size.height)


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    }


    View Slide

68. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)




    shader.setFloatUniform("iResolution", size.width, size.height)


    onDrawBehind {


    drawRect(shaderBrush)


    }


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    }


    View Slide

69. View Slide

70. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)




    shader.setFloatUniform("resolution", size.width, size.height)




    onDrawBehind {


    drawRect(shaderBrush)


    }


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()


    }


    }


    View Slide

71. @Composable


    private fun JetLaggedScreen() {


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)




    shader.setFloatUniform("resolution", size.width, size.height)


    onDrawBehind {


    drawRect(shaderBrush)


    }


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()






    View Slide

72. @Composable


    private fun JetLaggedScreen() {


    val time by produceState(0f) {


    while(true) {


    withInfiniteAnimationFrameMillis {


    value = it / 1000f


    }


    }


    }


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)


    shader.setFloatUniform("resolution", size.width, size.height)




    onDrawBehind {


    drawRect(shaderBrush)


    }


    }) {


    JetLaggedHeader()


    JetLaggedSleepSummary()






    View Slide

73. @Composable


    private fun JetLaggedScreen() {


    val time by produceState(0f) {


    while(true) {


    withInfiniteAnimationFrameMillis {


    value = it / 1000f


    }


    }


    }


    Column(modifier = Modifier


    .drawWithCache {


    val shader = RuntimeShader(WAVE_BAR_SHADER_AGSL)


    val shaderBrush = ShaderBrush(shader)


    shader.setFloatUniform("resolution", size.width, size.height)


    onDrawBehind {


    shader.setFloatUniform("time", time)


    drawRect(shaderBrush)


    }


    }) {


    JetLaggedHeader()





    View Slide

74. View Slide

75. Accessing Canvas
    Sometimes you might want to have access to it…


    View Slide

76. @Composable


    private fun JetLaggedApp() {


    val paint = remember { Paint() }


    JetLaggedScreen()


    }




    View Slide

77. @Composable


    private fun JetLaggedApp() {


    val paint = remember { Paint() }


    JetLaggedScreen(modifier = Modifier


    .drawWithContent {


    drawContent()


    })


    }




    View Slide

78. @Composable


    private fun JetLaggedApp() {


    val paint = remember { Paint() }


    JetLaggedScreen(modifier = Modifier


    .drawWithContent {


    val matrix = ColorMatrix().apply {


    setToSaturation(0f)


    }


    paint.colorFilter = colorMatrix(matrix)


    drawIntoCanvas { canvas ->


    canvas.saveLayer(size.toRect(), paint)


    this@drawWithContent.drawContent()


    canvas.restore()


    }


    })


    }




    View Slide

79. 🧛


    View Slide

80. Modifier.drawWithContent
    Determine the drawing order yourself


    * Useful for BlendMode operations


    * Transformations to the content yourself (ie clipping to a complex path)


    * Or drawing on top of content


    View Slide

81. Column(


    modifier = Modifier


    .fillMaxSize()


    .pointerInput("dragging") {


    detectDragGestures { change, dragAmount ->


    pointerOffset += dragAmount


    }


    }


    .onSizeChanged {


    pointerOffset = Offset(it.width / 2f, it.height /2f)


    }


    .drawWithContent {


    drawContent()


    drawRect(Brush.radialGradient(


    listOf(Color.Transparent, Color.Black),


    center = pointerOffset,


    radius = 100.dp.toPx(),


    ))


    }


    ) {


    // content goes here


    }


    View Slide

82. Modifier.graphicsLayer{ }
    Modifier used to apply transformations to a Composable, such as:


    • scaleX, scaleY


    • rotationX, rotationY, rotationZ


    • alpha


    • translationX, translationY


    *Note: Will not change the layout size and placement of the composable


    View Slide

83. Image(painterResource(id = R.drawable.sun_icon),


    contentDescription = "",


    modifier = Modifier


    .size(320.dp)


    )




    View Slide

84. val infinite = rememberInfiniteTransition()


    val rotation by infinite.animateFloat(


    initialValue = 0f,


    targetValue = 360f,


    animationSpec = infiniteRepeatable(


    animation = tween(5000, easing = LinearEasing),


    )


    )


    Image(painterResource(id = R.drawable.sun_icon),


    contentDescription = "",


    modifier = Modifier


    .size(320.dp)


    )




    View Slide

85. val infinite = rememberInfiniteTransition()


    val rotation by infinite.animateFloat(


    initialValue = 0f,


    targetValue = 360f,


    animationSpec = infiniteRepeatable(


    animation = tween(5000, easing = LinearEasing),


    )


    )


    Image(painterResource(id = R.drawable.sun_icon),


    contentDescription = "",


    modifier = Modifier


    .size(320.dp)


    .graphicsLayer {


    rotationZ = rotation


    }


    )




    View Slide

86. View Slide

87. graphicsLayer: RenderEffects
    Intermediate rendering step used to render drawing commands with a
    corresponding visual effect


    * BlurEffect - apply blur


    * RuntimeShader: Custom AGSL shader applied to whole composable


    View Slide

88. @Language("AGSL")


    val WOBBLE_SHADER = """


    uniform float2 resolution;


    uniform float time;


    uniform shader contents;


    vec4 main(in vec2 fragCoord) {


    vec2 uv = fragCoord.xy / resolution.xy * 0.8 + 0.1;




    uv += sin(time * vec2(1.0, 2.0) + uv* 2.0) * 0.01;




    return contents.eval(uv * resolution.xy);


    }


    """.trimIndent()




    View Slide

89. val shader = RuntimeShader(WOBBLE_SHADER)


    Column(Modifier


    .onSizeChanged { size ->


    shader.setFloatUniform(“resolution",


    size.width.toFloat(),


    size.height.toFloat()


    )


    }


    .graphicsLayer {


    renderEffect = android.graphics.RenderEffect


    .createRuntimeShaderEffect(


    shader,


    "contents"


    )


    .asComposeRenderEffect()


    }


    ) {


    // your content here


    }


    View Slide

90. val shader = RuntimeShader(WOBBLE_SHADER)


    Column(Modifier


    .onSizeChanged { size ->


    shader.setFloatUniform(“resolution",


    size.width.toFloat(),


    size.height.toFloat()


    )


    }


    .graphicsLayer {


    renderEffect = android.graphics.RenderEffect


    .createRuntimeShaderEffect(


    shader,


    "contents"


    )


    .asComposeRenderEffect()


    }


    ) {


    // your content here


    }


    View Slide

91. graphicsLayer:
    CompositingStrategy
    New in Compose 1.4+ (alpha right now)


    Refers to how the layer will be composited (put together) with existing content on
    screen.




    View Slide

92. Offscreen
    Forces an offscreen
    buffer.
    Auto ModulateAlpha
    The default mode - no
    offscreen buffer.


    * Unless alpha or
    RenderEffects are set


    Each draw call has
    the alpha applied
    individually.


    View Slide

93. Image(painter = dogImagePainter,
    modifier = Modifier
    .drawWithCache {
    onDrawWithContent {
    drawContent()
    drawCircle(
    Color.Black,
    blendMode = BlendMode.Clear
    )
    drawCircle(
    Color.Red
    )
    }
    }
    )


    View Slide

94. Image(painter = dogImagePainter,
    modifier = Modifier
    .drawWithCache {
    onDrawWithContent {
    drawContent()
    drawCircle(
    Color.Black,
    blendMode = BlendMode.Clear
    )
    drawCircle(
    Color.Red
    )
    }
    }
    )


    View Slide

95. CompositingStrategy.Auto
    Image(painter = dogImagePainter,
    modifier = Modifier
    .graphicsLayer {
    compositingStrategy = Auto
    }
    .drawWithCache {
    onDrawWithContent {
    drawContent()
    drawCircle(
    Color.Black,
    blendMode = BlendMode.Clear
    )
    drawCircle(
    Color.Red
    )
    }
    }
    )


    View Slide

96. CompositingStrategy.Auto
    CompositingStrategy.Offscreen
    Image(painter = dogImagePainter,
    modifier = Modifier
    .graphicsLayer {
    compositingStrategy = Offscreen
    }
    .drawWithCache {
    onDrawWithContent {
    drawContent()
    drawCircle(
    Color.Black,
    blendMode = BlendMode.Clear
    )
    drawCircle(
    Color.Red
    )
    }
    }
    )


    View Slide

97. Having (even more)
    fun with Paths
    goo.gle/compose-gradient-along-path


    View Slide

98. private object HelloPath {
    val path = PathParser().parsePathString(
    "M13.63 248.31C13.63 248.31 51.84 206.67 84.21 169.31C140" +
    ".84 103.97 202.79 27.66 150.14 14.88C131.01 10.23 116.36 29.88 107.26
    45.33C69.7 108.92 58.03 214.33 57.54 302.57C67.75 271.83 104.43 190.85 140.18
    193.08C181.47 195.65 145.26 257.57 154.53 284.39C168.85 322.18 208.22 292.83 229.98
    277.45C265.92 252.03 288.98 231.22 288.98 200.45C288.98 161.55 235.29 174.02 223.3
    205.14C213.93 229.44 214.3 265.89 229.3 284.14C247.49 306.28 287.67 309.93 312.18
    288.46C337 266.71 354.66 234.56 368.68 213.03C403.92 158.87 464.36 86.15 449.06
    30.03C446.98 22.4 440.36 16.57 432.46 16.26C393.62 14.75 381.84 99.18 375.35
    129.31C368.78 159.83 345.17 261.31 373.11 293.06C404.43 328.58 446.29 262.4 464.66
    231.67C468.66 225.31 472.59 218.43 476.08 213.07C511.33 158.91 571.77 86.19 556.46
    30.07C554.39 22.44 547.77 16.61 539.87 16.3C501.03 14.79 489.25 99.22 482.76
    129.35C476.18 159.87 452.58 261.35 480.52 293.1C511.83 328.62 562.4 265.53 572.64
    232.86C587.34 185.92 620.94 171.58 660.91 180.29C616 166.66 580.86 199.67 572.64
    233.16C566.81 256.93 573.52 282.16 599.25 295.77C668.54 332.41 742.8 211.69 660.91
    180.29C643.67 181.89 636.15 204.77 643.29 227.78C654.29 263.97 704.29 268.27 733.08 256"
    )
    }


    View Slide

99. val painter = rememberVectorPainter(
    viewportHeight = bounds.height,
    viewportWidth = bounds.width,
    defaultWidth = bounds.width.dp,
    defaultHeight = bounds.height.dp,
    autoMirror = true
    ) { _, _ ->
    Path(
    HelloPath.path.toNodes(),
    stroke = Brush.linearGradient(colors)
    )
    }
    Image(painter, contentDescription = "hello")


    View Slide

100. val path = remember {
     HelloPath.path.toPath()
     }
     val bounds = path.getBounds()
     val totalLength = remember {
     val pathMeasure = PathMeasure()
     pathMeasure.setPath(path, false)
     pathMeasure.length
     }
     val lines = remember {
     path.asAndroidPath().flatten(0.5f)
     }


     View Slide

101. val totalLength = remember {
     val pathMeasure = PathMeasure()
     pathMeasure.setPath(path, false)
     pathMeasure.length
     }
     val lines = remember {
     path.asAndroidPath().flatten(0.5f)
     }
     Box(modifier = Modifier.fillMaxSize()) {
     Canvas(modifier = Modifier
     .align(Alignment.Center),
     onDraw = {
     lines.forEach { line ->
     drawLine(
     brush = SolidColor(Color.Black),
     start = Offset(line.start.x, line.start.y),
     end = Offset(line.end.x, line.end.y))
     }
     })
     }


     View Slide

102. val totalLength = remember {
     val pathMeasure = PathMeasure()
     pathMeasure.setPath(path, false)
     pathMeasure.length
     }
     val lines = remember {
     path.asAndroidPath().flatten(30f)
     }
     Box(modifier = Modifier.fillMaxSize()) {
     Canvas(modifier = Modifier
     .align(Alignment.Center),
     onDraw = {
     lines.forEach { line ->
     drawLine(
     brush = SolidColor(Color.Black),
     start = Offset(line.start.x, line.start.y),
     end = Offset(line.end.x, line.end.y))
     }
     })
     }


     View Slide

103. val totalLength = remember {
     val pathMeasure = PathMeasure()
     pathMeasure.setPath(path, false)
     pathMeasure.length
     }
     val lines = remember {
     path.asAndroidPath().flatten(0.5f)
     }
     Box(modifier = Modifier.fillMaxSize()) {
     Canvas(modifier = Modifier
     .align(Alignment.Center),
     onDraw = {
     lines.forEach { line ->
     val startColor = interpolateColors(line.startFraction, colors)
     val endColor = interpolateColors(line.endFraction, colors)
     drawLine(
     brush = Brush.linearGradient(listOf(startColor, endColor)),
     start = Offset(line.start.x, line.start.y),
     end = Offset(line.end.x, line.end.y))
     }
     })
     }


     View Slide

104. private fun interpolateColors(
     progress: Float,
     colorsInput: List,
     ): Color {
     val scaledProgress = progress * (colorsInput.size - 1)
     val oldColor = colorsInput[scaledProgress.toInt()]
     val newColor = colorsInput[(scaledProgress + 1f).toInt()]
     val newScaledProgressValue = scaledProgress - floor(progress)
     return lerp(
     start = oldColor,
     stop = newColor,
     fraction = newScaledProgressValue)
     }


     View Slide

105. private fun interpolateColors(
     progress: Float,
     colorsInput: List,
     ): Color {
     val scaledProgress = progress * (colorsInput.size - 1)
     val oldColor = colorsInput[scaledProgress.toInt()]
     val newColor = colorsInput[(scaledProgress + 1f).toInt()]
     val newScaledProgressValue = scaledProgress - floor(progress)
     return lerp(
     start = oldColor,
     stop = newColor,
     fraction = newScaledProgressValue)
     }
     start stop
     fraction


     View Slide

106. View Slide

107. val lines = remember {
     path.asAndroidPath().flatten(30f)
     }
     val progress = remember {
     Animatable(0f)
     }
     LaunchedEffect(Unit) {
     progress.animateTo(
     1f,
     animationSpec = infiniteRepeatable(tween(3000))
     )
     }
     Box(modifier = Modifier.fillMaxSize()) {
     Canvas(modifier = Modifier
     .align(Alignment.Center),
     onDraw = {
     lines.forEach { line ->
     drawLine( //..)
     }
     })
     }


     View Slide

108. val lines = remember {
     path.asAndroidPath().flatten(30f)
     }
     val progress = remember {
     Animatable(0f)
     }
     LaunchedEffect(Unit) {
     progress.animateTo(
     1f,
     animationSpec = infiniteRepeatable(tween(3000))
     )
     }
     Box(modifier = Modifier.fillMaxSize()) {
     Canvas(modifier = Modifier
     .align(Alignment.Center),
     onDraw = {
     val currentLength = totalLength * progress.value
     lines.forEach { line ->
     if (line.startFraction * totalLength < currentLength) {
     drawLine( //..)
     }
     }
     })


     View Slide

109. goo.gle/compose-gradient-along-path


     View Slide

110. goo.gle/compose-graphics-docs


     goo.gle/compose-jetlagged


     goo.gle/compose-jellyfish


     goo.gle/compose-gradient-path


     View Slide

111. Thank you!
     Rebecca Franks (she/her)


     Developer Relations Engineer


     @riggaroo


     View Slide
