Advanced Networking with RxJava + Retrofit

Advanced Networking with RxJava + Retrofit

A dive into solving some of the more difficult problems that engineers face when trying to integrate RxJava + networking into an application.

Presented to the New York Android Developers Meetup on Tuesday, May 9th, 2017 at SeatGeek.

Stephen D'Amico

May 10, 2017
Tweet

More Decks by Stephen D'Amico

Other Decks in Programming

Transcript

  1. Networking with RxJava + Retrofit
    Beyond the canonical REST example
    Stephen D’Amico - @sddamico - SeatGeek - May 2017

    View Slide

  2. The Basics
    I bet at some point in your journey of
    learning networking with RxJava +
    Retrofit, you’ve seen a code example
    that looks something like this...
    interface SeatGeekApi {
    @GET("events")
    Observable getUpcomingEvents();
    }
    Retrofit retrofit = new Retrofit.Builder()
    .baseUrl("https://api.seatgeek.com/")
    .build();
    SeatGeekApi api = retrofit.create(SeatGeekApi.class);
    api.getUpcomingEvents()
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe(events -> {
    // do something with events
    }, error -> {
    // handle errors
    });

    View Slide

  3. But, what doesn't this handle?
    ● Retrying requests when they fail
    ● Dealing with specific response codes
    ● Showing loading indicators in your UI
    ● Configuration changes/subscription management
    ● Probably other cases you have

    View Slide

  4. Let's see how we can improve…

    View Slide

  5. What if my request fails?

    View Slide

  6. Retrying requests
    Network requests on mobile can fail
    due to a multitude of reasons.
    Often, you'll want some sort of
    mechanism for retrying a request.
    getRequestObservable()
    .subscribe(response -> {
    // handle response
    });

    View Slide

  7. Retrying requests -
    Naive approach
    The most simple way is to recreate
    your source Observable every time
    that you want to make a request.
    private void makeRequest() {
    getRequestObservable()
    .subscribe(getObserver());
    }
    private Observer getObserver() {
    return new Observer<>() {

    @Override
    public void onError(Throwable t) {
    if (someCondition) {
    makeRequest();
    }
    }
    }
    }

    View Slide

  8. Retrying requests -
    retryWhen()
    RxJava has retryWhen()!
    retryWhen() can be a little tricky to
    grok. Let's walk through it:
    ● retryWhen() is called once
    per subscription
    ● It's given an Observable of the
    errors by the parent stream
    (Observable)
    ● As long as the Observable
    returned from retryWhen()
    does not complete or error, the
    parent will be resubscribed
    // this code retries the request three times, with a 5s delay,
    // then 10s, then 15s
    getRequestObservable()
    .retryWhen(attempt -> {
    return attempt
    .zipWith(Observable.range(1, 3), (n, i) -> i)
    .flatMap(i ->
    return Observable.timer(5 * i, TimeUnit.SECONDS);
    })
    })
    .subscribe(viewModel -> {
    // handle updated request state
    });

    View Slide

  9. Retrying requests -
    retryWhen()
    Some of you might be very concerned
    though, automatic retries are
    dangerous business! If you retry too
    often you can easily have your apps
    DDOS'ing your servers.
    So, let's only retry when the user wants
    to retry… Fortunately this is easy to do
    with Relays/Subjects
    PublishRelay retryRequest = PublishRelay.create();
    getRequestObservable()
    .retryWhen(attempt -> retryRequest)
    .subscribe(viewModel -> {
    // handle updated request state
    });
    @OnClick(R.id.retry_view)
    public void onRetryClicked() {
    retryRequest.call(System.currentTimeMillis);
    }

    View Slide

  10. My API has very specific response codes…

    View Slide

  11. Using
    Response
    In our canonical example, we're using
    an Observable representing the typed
    body of the response document. This
    is not a requirement!
    If you need access to metadata about
    the response, you can use
    Observable>
    One nicety of this approach is that
    server responses in the 400-500 level
    will not cause an exception in your
    stream.
    interface SeatGeekApi {
    @GET("events")
    Observable> getUpcomingEvents();
    }
    Retrofit retrofit = new Retrofit.Builder()
    .baseUrl("https://api.seatgeek.com/")
    .build();
    SeatGeekApi api = retrofit.create(SeatGeekApi.class);
    api.getUpcomingEvents()
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe(eventsResponse -> {
    int responseCode = eventsResponse.code();
    switch (responseCode) {
    HTTP_301:

    HTTP_403:

    }
    }, error -> {
    // note: only handle i/o errors!
    });

    View Slide

  12. Using
    Response -
    Just errors
    Always using Response can be
    cumbersome though if you only want
    to check error codes. Fortunately,
    Retrofit has you covered with
    HttpException.
    You can check your error in onError to
    see if you have an HttpException to
    work with.
    interface SeatGeekApi {
    @GET("events")
    Observable getUpcomingEvents();
    }
    Retrofit retrofit = new Retrofit.Builder()
    .baseUrl("https://api.seatgeek.com/")
    .build();
    SeatGeekApi api = retrofit.create(SeatGeekApi.class);
    api.getUpcomingEvents()
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe(eventsResponse -> {
    // do something with events
    }, error -> {
    if (error instanceof HttpException) {
    Response response = ((HttpException)error).response();
    switch (response.code()) { … }
    } else {
    // handle other errors
    }
    });

    View Slide

  13. Using
    Response -
    With share()
    Sometimes to help with readability or
    because you have specific branching
    conditions downstream, it can be
    useful to multicast your request with
    share().
    share() lets multiple subscribers
    handle the data provided from
    upstream, in our case this is the
    network response.
    In this example, we're able to set up
    dedicated subscribers for specific
    response codes.
    interface SeatGeekApi {
    @GET("events")
    Observable> getUpcomingEvents();
    }
    Observable> eventsResponse = api.getUpcomingEvents()
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .share();
    eventsResponse
    .filter(Response::isSuccessful)
    .subscribe(this::handleSuccessfulResponse);
    eventsResponse
    .filter(response -> response.code() == HTTP_403)
    .subscribe(this::handle403Response);
    eventsResponse
    .filter(response -> response.code() == HTTP_304)
    .subscribe(this::handle304Response);

    View Slide

  14. My designer wants a loading indicator…

    View Slide

  15. Showing loading
    The goal with showing a loading state
    is that you'll want a simple way to
    show loading without tightly coupling
    your UI to the request stream
    First, we'll look at the naive approach...
    api.getUpcomingEvents()
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .subscribe(events -> {
    // do something with events
    }, error -> {
    // handle errors
    });

    View Slide

  16. Showing loading -
    Naive approach
    What are the problems here?
    ● We've tightly coupled our UI to
    the stream
    ● These lambdas leak references
    to our Views (more on
    subscription management in a
    bit)
    ● Can't handle "streams", only
    works as a single request
    api.getUpcomingEvents()
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .doOnSubscribe(() -> loadingIndicator.show())
    .doOnUnsubscribe(() -> loadingIndicator.hide())
    .subscribe(events -> {
    // do something with events
    }, error -> {
    // handle errors
    });

    View Slide

  17. Showing loading -
    Splitting streams
    So, let's try something new. What if our
    loading state was actually a separate
    stream?
    This gives us flexibility to have our UI
    subscribe to the loading state
    separately
    enum RequestState {
    IDLE, LOADING, COMPLETE, ERROR
    }
    BehaviorRelay state = BehaviorRelay.create(RequestState.IDLE);
    void publishRequestState(RequestState requestState) {
    Observable.just(requestState)
    .observeOn(AndroidSchedulers.mainThread()) // ensure state updates
    // are on proper thread
    .subscribe(state);
    }
    api.getUpcomingEvents()
    .doOnSubscribe(() -> publishRequestState(RequestState.LOADING))
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .doOnError(t -> publishRequestState(RequestState.ERROR))
    .doOnComplete(() -> publishRequestState(RequestState.COMPLETE))
    .subscribe(events -> {
    // do something with events
    }, error -> {
    // handle errors
    });

    View Slide

  18. Showing loading -
    Splitting streams
    Let's look at how the UI then
    subscribes to our request state then…
    We can now manage our view updates
    separately from the request stream!
    enum RequestState {
    IDLE, LOADING, COMPLETE, ERROR
    }
    BehaviorRelay state = BehaviorRelay.create(RequestState.IDLE);
    state.subscribe(requestState -> {
    switch(requestState) {
    IDLE:
    break;
    LOADING:
    loadingIndicator.show();
    errorView.hide();
    break;
    COMPLETE:
    loadingIndicator.hide();
    break;
    ERROR:
    loadingIndicator.hide();
    errorView.show();
    break;
    }
    );

    View Slide

  19. Showing loading -
    Splitting streams
    We can extend this model then to
    other aspects of the request!
    Now we've decoupled the UI from the
    request stream completely, success!
    BehaviorRelay state = BehaviorRelay.create(RequestState.IDLE);
    BehaviorRelay response = BehaviorRelay.create();
    BehaviorRelay errors = BehaviorRelay.create();

    void executeRequest() {
    api.getUpcomingEvents()
    .doOnSubscribe(() -> publishRequestState(RequestState.LOADING))
    .subscribeOn(Schedulers.io())
    .observeOn(AndroidSchedulers.mainThread())
    .doOnError(t -> publishRequestState(RequestState.ERROR))
    .doOnComplete(() -> publishRequestState(RequestState.COMPLETE))
    .subscribe(response, errors);
    }

    View Slide

  20. Showing loading -
    Splitting streams
    Now our UI can subscribe
    independently to the data and errors
    and handle them separately as
    desired.
    BehaviorRelay state = BehaviorRelay.create(RequestState.IDLE);
    BehaviorRelay response = BehaviorRelay.create();
    BehaviorRelay errors = BehaviorRelay.create();
    state.subscribe(requestState -> updateLoadingView(requestState));
    response.subscribe(eventsResponse -> showEventsResponse(eventsResponse));
    errors.subscribe(throwable -> extractAndShowError(throwable));

    View Slide

  21. Showing loading -
    Splitting streams
    You can always combine these
    streams together in the UI if you don't
    like handling to be spread out…
    BehaviorRelay state = BehaviorRelay.create(RequestState.IDLE);
    BehaviorRelay> response =
    BehaviorRelay.create(Optional.absent());
    BehaviorRelay> errors = BehaviorRelay.create(Optional.absent());
    class RequestViewModel {
    public final RequestState state;
    public final Optional response;
    public final Optional errors;
    RequestViewModel(...) { … }
    }
    Observable.combineLatest(state, response, errors, RequestViewModel::new)
    .subscribe(viewModel -> {
    // handle updated request state
    });

    View Slide

  22. How about configuration changes?

    View Slide

  23. Subscription
    management
    RxJava, like AsyncTask and other
    asynchronous patterns do not work
    with the Android lifecycles by default…
    RxJava provides a method to
    unsubscribe from streams via
    Disposable
    But the key question is how to use it
    properly?
    Disposable disposable = Observable
    .combineLatest(state, response, errors, RequestViewModel::new)
    .subscribe(viewModel -> {
    // handle updated request state
    });
    ...
    disposable.dispose(); // when?

    View Slide

  24. Subscription
    management -
    Basic Disposable
    Basic Disposable usage is hopefully
    straightforward.
    Keep a reference to the returned object
    from your subscription and then
    dispose() of it in an appropriate lifecycle
    method.
    class MyActivity extends Activity {
    Disposable disposable;

    disposable = Observable
    .combineLatest(state, response, errors, ViewModel::new)
    .subscribe(getSubscriber());

    public void onStop() {
    disposable.dispose();
    }
    }

    View Slide

  25. Subscription
    management -
    CompositeDisposable
    CompositeDisposable is a very useful tool
    if you have your UI subscribed to multiple
    streams.
    You can add() Disposables to it so that
    you can have them all be disposed at the
    same time!
    Note: This can be very convenient in a
    MVP-like system where you want all your
    subscriptions to end in an unbind()
    method.
    class MyActivity extends Activity {
    CompositeDisposable disposables = new CompositeDisposable();

    disposables.add(state.subscribe(getStateSubscriber()));
    disposables.add(result.subscribe(getResultSubscriber()));
    disposables.add(error.subscribe(getErrorSubscriber()));

    public void onStop() {
    disposable.clear();
    }
    }

    View Slide

  26. Subscription
    management -
    nonConfigurationInstance
    Out of the box, there's not an easy way to
    continue an Observable stream across
    configuration changes.
    However, we can coopt the Android
    Activity's
    onRetainNonConfigurationInstance()
    so that our stream is accessible again
    after a configuration change…
    Note: this is also a handy strategy for
    keeping your Presenter/Dagger graph
    around for your next Activity
    class MyActivity extends Activity {
    Observable request;
    Disposable disposable;
    public void onCreate(Bundle instanceState) {
    request = getLastNonConfigurationInstance();
    }

    request = Observable
    .combineLatest(state, response, errors, ViewModel::new)
    .cache();
    disposable = request
    .subscribe(getSubscriber());

    public void onStart() {
    if (request != null && disposable == null) {
    disposable = request
    .subscribe(getSubscriber()); // can null request field
    // in subscriber
    }
    }
    Object onRetainNonConfigurationInstance() {
    return request;
    }
    public void onStop() {
    disposable.dispose();
    }
    }

    View Slide

  27. Subscription
    management -
    RxLifecycle
    https://github.com/trello/RxLifecycle
    RxLifecycle gives a simple way to tie
    subscriptions to your
    Activity/Fragment lifecycle.
    When a corresponding lifecycle event
    occurs, the Disposable will be
    dispose() 'd
    class MyActivity extends RxAppCompatActivity {
    ...
    Observable
    .combineLatest(state, response, errors, ViewModel::new)
    .compose(bindToLifecycle())
    .subscribe(viewModel -> {
    // handle updated request state
    });

    }

    View Slide

  28. Subscription
    management -
    RxLifecycle + retain
    If we want to retain our Observable,
    that works with RxLifecycle too.
    class MyActivity extends Activity {
    Observable request;
    public void onCreate(Bundle instanceState) {
    request = getLastNonConfigurationInstance();
    }

    request = Observable
    .combineLatest(state, response, errors, ViewModel::new)
    .cache();
    request
    .compose(bindToLifecycle())
    .subscribe(getSubscriber());

    public void onStart() {
    if (request != null) {
    request
    .compose(bindToLifecycle())
    .subscribe(getSubscriber());
    }
    }
    Object onRetainNonConfigurationInstance() {
    return request;
    }
    public void onStop() {
    disposable.dispose();
    }
    }

    View Slide

  29. Subscription
    management -
    RxLifecycle + MVP
    You can customize your MVP
    Presenter as well to take advantage of
    similar functionality!
    Now, you can bind your observation of
    the request streams and never worry
    about your view being detached.
    enum PresenterLifecycle {
    STOPPED,
    STARTED
    }
    class RxPresenter extends Presenter {
    BehaviorRelay presenterLifecycle =
    BehaviorRelay.create(PresenterLifecycle.STOPPED);
    void bind(V view) {
    presenterLifecycle.call(PresenterLifecycle.STARTED);
    }
    void unbind() {
    presenterLifecycle.call(PresenterLifecycle.STOPPED);
    }
    protected LifecycleTransformer bindToLifecycle() {
    return RxLifecycle.bind(presenterLifecycleObservable, lifecycle -> {
    switch (lifecycle) {
    case STARTED:
    return PresenterLifecycle.STOPPED;
    case STOPPED:
    default:
    return PresenterLifecycle.STARTED;
    }
    });
    }
    }

    View Slide

  30. Questions?

    View Slide

  31. Thanks!
    About me…
    name: Stephen D’Amico
    twitter: @sddamico
    github: sddamico
    Shameless plug…
    seatgeek.com/jobs

    View Slide
