Swift compiler as a library: obfuscator case

Presented during Mobile Warsaw meetup on 22nd of May 2018

Transcript

1. Swift compiler as a
   library:

   obfuscator case
   Krzysztof Siejkowski


   View Slide

2. In software development,
   obfuscation is the deliberate act of
   creating source or machine code that
   is difficult for humans to understand
   — Wikipedia


   View Slide

3. App Store
   YourApp binary file
   Your source code


   View Slide

4. App Store
   YourApp binary file
   YourApp encrypted (FairPlay)
   Jailbroken device
   YourApp binary file
   Your source code


   View Slide

5. App Store
   YourApp binary file
   YourApp encrypted (FairPlay)
   YourApp decrypted (in memory)
   Memory dump tool
   YourApp binary file
   Jailbroken device
   YourApp binary file
   Your source code


   View Slide

6. App Store
   YourApp binary file
   YourApp encrypted (FairPlay)
   YourApp decrypted (in memory)
   Memory dump tool
   YourApp binary file
   Your source code
   Disassembler (Hopper)
   Assembly/pseudo-code Jailbroken device


   View Slide

7. App Store
   YourApp binary file
   YourApp encrypted (FairPlay)
   YourApp decrypted (in memory)
   Memory dump tool
   YourApp binary file
   Your source code
   Disassembler (Hopper)
   Assembly/pseudo-code Jailbroken device


   View Slide

8. View Slide

9. View Slide

10. View Slide

11. View Slide

12. class MyViewController: UIViewController {}
    class MyView: UIView {}
    class MyModel: NSManagedObject {}
    class MyRuntimeUsingObject: NSObject {}
    class SomeClass {
    @objc func someFunc() {}
    }


    View Slide

13. Obfuscation is more
    than symbol renaming


    Code Obfuscation Techniques for Software Protection

    —PhD thesis by Jan Cappaert





    View Slide

14. How to obfuscate?
    • after compilation
    • during compilation
    • before compilation


    View Slide

15. After compilation:
    binary to binary
    iXGuard (https://www.guardsquare.com/en/ixguard)


    View Slide

16. During compilation:
    source to binary
    Obfuscator-LLVM (https://github.com/obfuscator-llvm/obfuscator)


    View Slide

17. Before compilation:
    source to source
    WE!!!


    View Slide

18. Goal: obfuscate Swift
    code

    by renaming


    View Slide

19. View Slide

20. View Slide

21. Does it work?


    View Slide

22. Does it work?
    YES


    View Slide

23. Not universal tool…
    • no DSYM support
    • no multiple targets
    • no mixed Swift/Obj-C
    • not all Swift constructs supported


    View Slide

24. …but still powerful
    • Storyboards/XIBs renaming
    • various Swift expressions supported
    • excluding configuration
    • very easy to integrate


    View Slide

25. $ bin/sirius -help
    USAGE: sirius -projectrootpath [PROJECTROOTPATH]
    -obfuscatedproject [OBFUSCATEDPROJECTPATH]


    View Slide

26. Xcode project
    Zobfuskowany Xcode project
    Command line interface
    (standalone or as Xcode build step)
    Original Xcode project
    Obfuscated Xcode project (copy or inplace)


    View Slide

27. Original Xcode project
    Xcode project parsing
    Symbols identification
    Generation of new names
    Obfuscated Xcode project (copy or inplace)
    Renaming in the source files


    View Slide

28. Original Xcode project
    Xcode project parsing


    View Slide

29. Original Xcode project
    Xcode project parsing
    Symbols identification


    View Slide

30. Original Xcode project
    Xcode project parsing
    Symbols identification
    Generation of new names


    View Slide

31. Original Xcode project
    Xcode project parsing
    Symbols identification
    Generation of new names
    Obfuscated Xcode project
    Renaming in the source files


    View Slide

32. Obfuscation
    verification
    Original Xcode project
    Xcode project parsing
    Symbols identification
    Generation of new names
    Obfuscated Xcode project
    Renaming in the source files
    Main
    command
    line
    interface


    View Slide

33. Obfuscation
    verification
    Original Xcode project
    Xcode project parsing
    Obfuscated Xcode project
    Main
    command
    line
    interface
    Swift compiler
    Symbols identification
    Generation of new names
    Renaming in the source files


    View Slide

34. View Slide

35. View Slide

36. View Slide

37. View Slide

38. View Slide

39. View Slide

40. View Slide

41. View Slide

42. 1. create new folder in swift/tools

    2. add add_swift_tool_subdirectory function

    to swift/tools/CMakeLists.txt

    3. create new .cpp file with main function

    4. create new CMakeLists.txt for your tool

    5. add add_swift_host_tool function

    to swift/tools//CMakeLists.txt

    and define the source files, executable name and dependencies
    How to add new command line tool?


    View Slide

43. View Slide

44. View Slide

45. View Slide

46. View Slide

47. View Slide

48. View Slide

49. View Slide

50. 1. create new folders in swift/include/swift and swift/lib

    2. add your .h interfaces

    to swift/include/swift/

    3. add your .cpp implementations to swift/lib/

    4. create CMakeLists.txt for your library

    at swift/lib//CMakeLists.txt

    with add_swift_library function

    that defines the source files, library name and dependencies

    5. add add_subdirectory function to swift/lib/CMakeLists.txt

    How to add new library?


    View Slide

51. View Slide

52. View Slide

53. View Slide

54. View Slide

55. View Slide

56. 1. create new folder in swift/unittests

    2. add your .cpp test source code

    to swift/unittests/

    3. create CMakeLists.txt for your unit tests

    at swift/unittests//CMakeLists.txt

    with add_swift_unittest function that

    defines the source files, executable name and dependencies

    4. add add_subdirectory call to swift/unittests/CMakeLists.txt

    How to add unit tests?


    View Slide

57. View Slide

58. View Slide

59. 1. create tool in swift/tools/

    2. (not required, but a good idea) create library

    for the underlying logic

    in swift/include/swift/

    and swift/lib/

    3. add unit tests to swift/unittests/

    4. add integration tests to swift/tests/

    How to create new compiler-based tool?


    View Slide

60. View Slide

61. Abstract

    Syntax

    Tree


    View Slide

62. CompilerInstance Compiler;
    CompilerInvocation Invocation;
    Invocation.setModuleName(ModuleName);
    Invocation.setMainExecutablePath(MainExecutablePath);
    for (const auto &InputFilename : InputFilenames) {
    Invocation.addInputFilename(InputFilename);
    }
    Invocation.setFrameworkSearchPaths(FrameworkPaths);
    Invocation.setSDKPath(SdkPath);
    Invocation.setTargetTriple(Triple);
    if (Compiler.setup(Invocation)) {
    return stringError("Error during compiler setup");
    }
    Compiler.performSema();


    View Slide

63. class SymbolsWalker : public SourceEntityWalker {
    bool visitDeclReference(ValueDecl *, CharSourceRange,
    TypeDecl *, ExtensionDecl *,
    Type, ReferenceMetaData) override;
    }
    for (auto* Unit : Compiler.getMainModule() ->getFiles()) {
    if (auto* Current = dyn_cast(Unit)) {
    SymbolsWalker Walker;
    Walker.walk(&Current);
    }
    }


    View Slide

64. ParamDecl *Parameter = //given from SourceEntityWalker
    auto Name = Parameter ->getName().str().str();
    CharSourceRange Range(Parameter ->getNameLoc(),
    Name.length());


    View Slide

65. auto &SourceManager = Current ->getASTContext().SourceMgr;
    auto BufferId = Current ->getBufferID().getValue();

    std ::error_code Error;
    llvm ::raw_fd_ostream DescriptorStream(Path, Error, F_None);
    SourceEditOutputConsumer Editor(SourceManager,

    BufferId,
    DescriptorStream);



    CharSourceRange Range = // computed slide ago
    auto ReplacingString = // replacement for range in code
    Editor ->ide ::SourceEditConsumer ::accept(SourceManager, Range, ReplacingString);


    View Slide

66. View Slide

67. static llvm ::cl ::opt
    SymbolsJsonPath("symbolsjson",
    llvm ::cl ::desc("Name of the file
    containing extracted
    symbols"),
    llvm ::cl ::cat(ObfuscatorNameMapper));
    int main(int argc, char *argv[]) {
    INITIALIZE_LLVM(argc, argv);
    llvm ::cl ::ParseCommandLineOptions(argc,
    argv,
    “obfuscator-name-mapper");


    View Slide

68. void MappingTraits ::
    mapping(IO &Io, SymbolsJson &Object) {
    Io.mapRequired("symbols", Object.Symbols);
    }
    Input Input(JsonString);
    SymbolsJson Symbols;
    Input >> Symbols;


    View Slide

69. • LLVM Programmer’s Manual

    (http://llvm.org/docs/ProgrammersManual.html)

    • LLVM Coding Standards

    (http://llvm.org/docs/CodingStandards.html)
    • many more!


    View Slide

70. 1. Get familiar with C++11
    Few last practical tips


    View Slide

71. 1. Get familiar with C++11

    2. Use Xcode as IDE (works really well!)
    Few last practical tips


    View Slide

72. 1. Get familiar with C++11

    2. Use Xcode as IDE (works really well!)

    3. Keep Swift compiler in sync

    with Xcode version
    Few last practical tips


    View Slide

73. 1. Get familiar with C++11

    2. Use Xcode as IDE (works really well!)

    3. Keep Swift compiler in sync

    with Xcode version

    4. Don’t let the lack of compiler knowledge

    scare you away!
    Few last practical tips


    View Slide

74. View Slide

75. Pros Cons
    Anything compiler can do,
    you can do too!


    View Slide

76. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool


    View Slide

77. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool
    So many tools are available!


    View Slide

78. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool
    So many tools are available!
    No stable API,
    breaking changes all the time


    View Slide

79. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool
    So many tools are available!
    No stable API,
    breaking changes all the time
    You can leverage

    the existing infrastructure


    View Slide

80. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool
    So many tools are available!
    No stable API,
    breaking changes all the time
    You can leverage

    the existing infrastructure
    You must fit into

    the existing infrastructure


    View Slide

81. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool
    So many tools are available!
    No stable API,
    breaking changes all the time
    You can leverage

    the existing infrastructure
    You must fit into

    the existing infrastructure
    Support for both

    Swift and Objective-C


    View Slide

82. Pros Cons
    Anything compiler can do,
    you can do too!
    Compiler libs are designed for
    compilation, not for your tool
    So many tools are available!
    No stable API,
    breaking changes all the time
    You can leverage

    the existing infrastructure
    You must fit into

    the existing infrastructure
    Support for both

    Swift and Objective-C
    There might be
    better alternatives


    View Slide

83. Alternatives
    • libSyntax
    • SourceKit
    • existing swift tools


    View Slide

84. View Slide

85. • https://github.com/PolideaPlayground/
    SiriusObfuscator-SymbolExtractorAndRenamer

    • Documentation folder has a lot of notes

    on various implementation decisions,

    with details and motivation


    View Slide

86. View Slide

87.
    @KacperHarasim


    View Slide

88. Questions?
    @_siejkowski


    View Slide

89. Thank you!


    View Slide
