A Personal Assistant for Web Database Caching

A Personal Assistant for Web Database Caching

Presentation given at CAiSE 2000, 12th International Conference on Advanced Information Systems Engineering, Stockholm, Sweden, June 2000

ABSTRACT: To improve the performance of web database access for regular users, we have developed a client caching agent, referred to as a personal assistant. In addition to caching strategies based on data characteristics and user specification, the personal assistant dynamically prefetches information based on previously monitored user access patterns. It is part of an overall multi-layered caching scheme where cache coherency is ensured through cooperation with a server-side database caching agent. The personal assistant has been implemented in Java and integrated into the web architecture for the OMS Pro database management system.

Research paper: https://beatsigner.com/publications/a-personal-assistant-for-web-database-caching.pdf

Beat Signer
PRO

June 07, 2000
Tweet

More Decks by Beat Signer

Other Decks in Science

Transcript

  1. A Personal Assistant for Web
    Database Caching
    Beat Signer, [email protected]
    Institute for Information Systems
    ETH Zurich

    View Slide

  2. Overview
    • Motivation
    • Internet OMS architecture
    • Personal Assistant
    • Cache architecture
    • Performance measurements
    • Conclusion

    View Slide

  3. Motivation
    • Lack of most browsers to cache dynamically
    generated web pages
    • Cooperative client, middle layer and server caches
    to improve performance
    • Reduction of query response times by better
    usage of the available resources

    View Slide

  4. Internet OMS Architecture
    Front-End Agent
    Personal Assistant
    Session Cache
    Active Cache
    Global Cache
    HTTP Server Database Agent
    Web Browser
    OMS
    Database
      
    Internet

    View Slide

  5. Cache Requirements
    • Reduction of response times (latency)
    • Reduction of idle times (e.g. modem connection)
    • Cache consistency
    • Persistence
    • Flexibility (different user skills)
    • Active caching component (local prefetching)
    • Small overhead to maintain cache
    • Optimal usage of available cache resource

    View Slide

  6. Personal Assistant Cache Structure
    Personal Assistant Cache
    query results images
    Session Cache
    query results images
    Personal Cache
    query results images
    Prefetching Cache
    Persistent Client Cache
    Short-Term Cache
    ▪ passive
    ▪ priority 3
    Explicit User Specified Objects
    ▪ permanent
    ▪ passive
    ▪ priority 1
    Long-Term Cache
    ▪ user profile
    ▪ active
    ▪ priority 2
    disjoint

    View Slide

  7. Prefetching Cache Statistics
    LRUB-Cache (fixed size)
    LRUB-Cache
    (fixed size)
    query 1 query 2 query n
    statistic
    next query 1
    next query 2
    next query n
    next query 3
    . . . .
    statistic
    next query 1
    next query 2
    next query n
    next query 3
    . . . .
    statistic
    next query 1
    next query 2
    next query n
    next query 3
    . . . .

    View Slide

  8. Cache Replacement Strategy
    • Least recently used (LRU)
    • Introduce bonus for entries often used in the past
    but not accessed recently → LRUB
    1
    0
    ,
    )
    1
    (
    weight
    i



    +
    = 


    i
    i
    T
    H
    i
    H : Number of hits for cache entry i
    i
    T : Time since last access of cache entry i
    • Weight for cache entry i defined as follows:

    View Slide

  9. q1 q3
    q5
    q9
    q2
    q6
    q4
    q7
    q8
    Advantages of Adaptive Prefetching
    • Assumption: global cache of
    size 4 for most frequently
    used queries → which of the
    6 “hot queries” should be
    cached?
    q1 q3
    q5
    q9
    q2
    q6
    q4
    q7
    q8
    q1 q3
    q5
    q9
    q2
    q6
    q4
    q7
    q8
    • Adaptive prefetching →
    sliding window mechanism,
    i.e. cache of size 2 is
    sufficient!

    View Slide

  10. Cache Administration Tools

    View Slide

  11. Average Response Times
    Average Time Worst Case
    0
    500
    1000
    1500
    2000
    2500
    3000
    3500
    4000
    4500
    5000
    Total Time Query Time Image Time
    time[ms]
    Without Personal Assistant With Personal Assistant
    Average Time Best Case
    0
    500
    1000
    1500
    2000
    2500
    3000
    3500
    4000
    4500
    5000
    Total Time Query Time Image Time
    time[ms]
    Without Personal Assistant With Personal Assistant

    View Slide

  12. Image Response Times
    Average Image Time Worst Case
    0
    500
    1000
    1500
    2000
    2500
    3000
    3500
    4000
    4500
    5000
    Without Personal Assistant With Personal Assistant
    time[ms]
    User 1 User 2 User 3 User 4
    Average Image Time Best Case
    0
    500
    1000
    1500
    2000
    2500
    3000
    3500
    4000
    4500
    5000
    Without Personal Assistant With Personal Assistant
    time[ms]
    User 1 User 2 User 3 User 4

    View Slide

  13. Cache Hit Rates
    • Increased hit rate even in worst case scenario
    (due to larger caches)
    • Front-end agent profits from locality of queries in
    best case scenario
    Front-End Agent
    Personal Assistant
    queries images queries images
    Worst Case Best Case
    13% 4% 33% 29%
    29% 28% 75% 68%

    View Slide

  14. Conclusion
    • Advantages
    ▪ increased cache hit rate
    ▪ reduced response times
    ▪ adaptation to individual users
    ▪ easy to use (transparent)
    ▪ prefetching statistic always up to date
    • Costs
    ▪ database agent eventually has to handle an
    increased number of queries (prefetching) →
    increased server loads
    ▪ overhead to maintain cache consistency

    View Slide

  15. Future Work
    • Use similiar prefetching techniques to build an
    HTTP caching proxy
    • First prototype running at gordon.inf.ethz.ch:9090
