A seminar for the National Cancer Institute "Containers and Workflows Interest Group".

10th August 2018

Transcript

1. NEXTFLOW REPRODUCIBLE COMPUTATIONAL WORKFLOWS ACROSS CLOUDS AND CLUSTERS NCI Containers and Workflows Interest Group Seminar Evan Floden 10 August 2018
2. AGENDA • The challenges with computational workflows • Nextflow main principles • Handling parallelisation and portability • Deployments scenarios • Comparison with other tools • Future plans
3. GENOMIC WORKFLOWS • Data analysis applications performs computation to generate information from (large) genomic datasets • Embarrassingly parallelisation, can spawn 100s-100k jobs over distributed cluster • Mash-up of many different tools and scripts (dependancies!) • Complex dependency trees and configuration → very fragile ecosystem
4. Steinbiss et al., Companion parassite genome annotation pipeline, DOI: 10.1093/nar/gkw292
5. A LOT OF MOVING PARTS • 70 tasks • 55 external scripts • 39 software tools & libraries
6. To reproduce the result of a typical
 computational biology paper
 requires 280 hours. ≈1.7 months!
8. THE SAME APPLICATION DEPLOYED IN DIFFERENT ENVIRONMENTS PRODUCES DIFFERENT RESULTS (!)
9. * Di Tommaso P, et al., Nextflow enables computational reproducibility, Nature Biotech, 2017
10. Platform Amazon Linux Debian Linux Mac OSX Number of chromosomes 36 36 36 Overall length (bp) 32,032,223 32,032,223 32,032,223 Number of genes 7,781 7,783 7,771 Gene density 236.64 236.64 236.32 Number of coding genes 7,580 7,580 7570 Average coding length (bp) 1,764 1,764 1,762 Number of genes with multiple CDS 113 113 111 Number of genes with known function 4,147 4,147 4,142 Number of t-RNAs 88 90 88 Comparison of the Companion pipeline annotation of Leishmania infantum genome executed across different platforms * * Di Tommaso P, et al., Nextflow enables computational reproducibility, Nature Biotech, 2017
11. CHALLENGES • Reproducibility: replicate results over time • Portability: run across different platforms • Scalability: ie. deploy big distributed workloads • Usability: streamline execution and deployment of complex • Consistency: track changes and revisions consistently for code, config files and binary dependencies
12. PUSH-THE-BUTTON PIPELINES
13. HOW? • Fast prototyping 㱺 custom DSL that enables tasks composition, simplifies most use cases + general purpose programming lang. for corner cases • Easy parallelisation 㱺 declarative reactive programming model based on dataflow paradigm, implicit portable parallelism • Self-contained 㱺 functional approach, a task execution is idempotent ie. cannot modify the state of other tasks + isolate dependencies with containers • Portable deployments 㱺 executor abstraction layer + deployment configuration from implementation logic
14. Orchestration & Parallelisation Scalability & Portability Deployment & Reproducibility containers Git GitHub
15. TASK EXAMPLE bwa mem reference.fa sample.fq \ | samtools sort -o sample.bam
16. process align_sample { input: file 'reference.fa' from genome_ch file 'sample.fq' from reads_ch output: file 'sample.bam' into bam_ch script: """ bwa mem reference.fa sample.fq \ | samtools sort -o sample.bam """ } TASK EXAMPLE bwa mem reference.fa sample.fq \ | samtools sort -o sample.bam
17. TASKS COMPOSITION process index_sample { input: file 'sample.bam' from bam_ch output: file 'sample.bai' into bai_ch script: """ samtools index sample.bam """ } process align_sample { input: file 'reference.fa' from genome_ch file 'sample.fq' from reads_ch output: file 'sample.bam' into bam_ch script: """ bwa mem reference.fa sample.fq \ | samtools sort -o sample.bam """ }
18. DATAFLOW • Declarative computational model for parallel process executions • Processes wait for data, when an input set is ready the process is executed • They communicate by using dataflow variables i.e. async FIFO queues called channels • Parallelisation and tasks dependencies are implicitly defined by process in/out declarations
19. HOW PARALLELISATION WORKS data x data y data z task 1 task 2 task 3 data z channel process out z data y data x out y out x
20. HOW PARALLELISATION WORKS samples_ch = Channel.fromPath('data/sample.fastq') process FASTQC { input: file reads from samples_ch output: file 'fastqc_logs' into fastqc_ch """ mkdir fastqc_logs fastqc -o fastqc_logs -f fastq -q ${reads} """ }
21. samples_ch = Channel.fromPath('data/*.fastq') process FASTQC { input: file reads from samples_ch output: file 'fastqc_logs' into fastqc_ch """ mkdir fastqc_logs fastqc -o fastqc_logs -f fastq -q ${reads} """ } HOW PARALLELISATION WORKS
22. IMPLICIT PARALLELISM clustalo Channel.fromPath("data/*.fastq") clustalo FASTQC
23. HANDLING FILE PAIRS Channel.fromFilePairs("*_{1,2}.fq") ( gut, [gut_1.fq, gut_2.fq] ) ( lung, [lung_1.fq, lung_2.fq] ) ( liver, [liver_1.fq, liver_2.fq] ) gut_1.fq gut_2.fq liver_1.fq liver_2.fq lung_1.fq lung_2.fq
24. process FASTQC { input: set pair_id, file(reads) from samples_ch output: file 'fastqc_logs' into fastqc_ch """ mkdir fastqc_logs fastqc -o fastqc_logs -f fastq -q ${reads} """ } ( gut, [gut_1.fq, gut_2.fq] ) ( lung, [lung_1.fq, lung_2.fq] ) ( liver, [liver_1.fq, liver_2.fq] )
25. DEPLOYMENT SCENARIOS
26. LOCAL EXECUTION • Common development scenario • Dependencies can be managed using a container runtime • Parallelisations is managed spawning posix processes • Can scale vertically using fat server / shared mem. machine nextflow OS local storage docker/singularity laptop / workstation
27. CENTRALISED ORCHESTRATION computer cluster • Nextflow orchestrates workflow execution submitting jobs to a compute cluster eg. SLURM • It can run in the head node or a compute node • Requires a shared storage to exchange data between tasks • Ideal for corse-grained parallelisms NFS/Lustre cluster node cluster node cluster node cluster node submit jobs cluster node nextflow
28. DISTRIBUTED ORCHESTRATION login node NFS/Lustre job request cluster node cluster node launcher wrapper nextflow cluster nextflow driver nextflow worker nextflow worker nextflow worker HPC cluster • A single job request allocates the desired computes nodes • Nextflow deploys its own embedded compute cluster • The main instance orchestrate the workflow execution • The worker instances execute workflow jobs (work stealing approach)
29. jvm docker workers CLOUD DEPLOYMENT jvm docker NF driver NF daemon AWS EFS storage master setup cloud
 cluster GH repo Docker hub deploy dependencies upload code & deps computing
 cluster application pull code
30. KUBERNETES • Next generation native cloud clustering for containerised workloads • There's the need of workflow orchestration • Latest NF version includes a new command that streamline the workflow deployment to K8s
31. K8S DEPLOYMENT
32. PORTABILITY
33. PORTABILITY process { executor = 'slurm' queue = 'my-queue' memory = '8 GB' cpus = 4 container = 'user/image' }
34. PORTABILITY process { executor = 'awsbatch' queue = 'my-queue' memory = '8 GB' cpus = 4 container = 'user/image' }
35. CONFIGURATION DECOUPLING
 IS THE KEY TO PORTABLE DEPLOYMENTS
36. DEMO!
37. A QUICK COMPARISON
38. GALAXY vs. NEXTFLOW • Command line oriented tool • Can incorporate any tool w/o any extra adapter • Fine control over tasks parallelisation • Scalability 100㱺1M jobs • One liner installer • Suited for production workflows + bioinformaticians • Web based platform • Built-in integration with many tools and dataset • Little control over tasks parallelisation • Scalability 10㱺1K jobs • Complex installation and maintenance • Suited for training + less experienced bioinformaticians
39. SNAKEMAKE vs. NEXTFLOW • Command line oriented tool • Push model • Can manage any data structure • Compute DAG at runtime • Built-in support for clusters and cloud • No (yet) support for sub-workflows • Built-in support for Git/GitHub, etc., manage pipeline revisions • Groovy/JVM based • Command line oriented tool • Pull model • Rules defined using file name patterns • Compute DAG ahead • Custom scripts for cluster deployments • Support for sub-workflows • No support for source code management system • Python based
40. CWL vs. NEXTFLOW • Language + app. runtime • DSL on top of a general purpose programming lang. • Concise, fluent (at least try to be!) • Single implementation, quick iterations • Language specification • Declarative meta- language (YAML/JSON) • Verbose • Many vendors/ implementations (and specification version)
41. CONTAINERISATION
42. CONTAINER vs. VM • Lighter: MB vs GB • Faster startup: ms/secs vs minutes • Virtualise a process/application instead of a OS/Hardware • Immutable: don't change over time, thus guarantee replicability over executions. • Composable: the output of one container is directly consumable as input by another container. • Transparent: they are created with a well defined automated procedure.
43. CONTAINERISATION Nextflow job job job
44. SUPPORTED PLATFORMS
45. CONTAINERISATION • Nextflow envisioned the use of software containers to fix computational reproducibility • Mar 2014 (ver 0.7), support for Docker • Dec 2016 (ver 0.23), support for Singularity Nextflow job job job
46. SINGULARITY FEATURES Kurtzer et al. Singularity: Scientific containers for mobility of compute. PLoS ONE 12(5): e0177459
47. BENCHMARK* * Di Tommaso P, Palumbo E, Chatzou M, Prieto P, Heuer ML, Notredame C. (2015)
 The impact of Docker containers on the performance of genomic pipelines. PeerJ 3:e1273
 https://dx.doi.org/10.7717/peerj.1273 container execution can have an impact on short running tasks ie. < 1min
48. WHEN USE CONTAINERS? ALWAYS!
49. CONTAINER DEFINITION EXAMPLES
50. BEST PRACTICES • Helps to isolate dependencies from dev or local deployment environment • Provides a reproducibles sandbox for third party users • Binary images preserve against software decay • Make it transparent ie. always include the Dockerfile • Docker image format is de-facto standard, it can be executed by different runtime eg. Singularity, Shifter, uDocker, etc.
51. EXTRA STUFF
52. • Community effort to collect production ready analysis pipelines built with Nextflow • Initially supported by SciLifeLab, QBiC and A*Star Genome Institute Singapore • https://nf-co.re Alexander
 Peltzer Phil Ewels Andreas Wilm Maxime Garcia + others
54. DEMO!
55. EXECUTION REPORT
56. EXECUTION REPORT
57. EXECUTION REPORT
58. EXECUTION TIMELINE
60. DAG VISUALISATION
61. EDITORS !
62. WHAT'S NEXT
63. IMPROVEMENTS • Better meta-data and provenance handling • Nextflow server for real-time monitoring • Workflow composition aka sub-workflows
64. CONDA SUPPORT SCRIPT CONFIG
65. MORE CLOUDS
66. DATA INTEGRATION • Allow direct query over SQL/NoSQL datasources • Uniform access to local and remote big-data repositories such as Athena, DynamoDB, BigQuery, etc • Query result is mapped to Nextflow channel structure triggering process executions
67. APACHE SPARK • Native support for Apache Spark clusters and execution model • Allow hybrid Nextflow and Spark applications • Mix the best of the two worlds, Nextflow for legacy tools/corse grain parallelisation and Spark for fine grain/distributed execution eg. GATK4
68. NOTEBOOKS • Combine interactive computing with the heavy CPU work • Jupyter implementation (iNextflow) • RMarkdown
69. • Participate in Cloud Work Stream working group • TES: Task Execution API (working prototype) • WES: Workflow Execution API • Enable interoperability with GA4GH complaint platforms eg. Cancer Genomics Cloud and Broad FireCloud
70. DOCKSTORE INTERGRATION • Allow sharing and execution of pipelines and/ or tasks/tools through common infrastructure
71. WHO IS USING NEXTFLOW?
72. CONCLUSION • Data analysis reproducibility is hard and it's often underestimated. • Nextflow does not provide a magic solution but enables best-practices and provide support for community and industry standards. • It strictly separates the application logic from the configuration and deployment logic, enabling self-contained workflows. • Applications can be easily deployed across different environment in a reproducible manner with a single command. • The functional/reactive model allows applications to scale to millions of jobs with ease.
73. ACKNOWLEDGMENTS Emilio Palumbo Cedric Notredame Notredame Lab, CRG http://nextflow.io Paolo Di Tommaso @PaoloDiTommaso Evan Floden @evanfloden
74. WORKSHOP TUTORIAL https://github.com/nextflow-io/rmghc-2018
