2022 Compose Camp Pathway 1-2: State and Theming in Jetpack Compose

Transcript

1. This work is licensed under the Apache 2.0 License
   State and Theming in Jetpack Compose
   Pathway 1-2


   View Slide

2. Speaker
   skydoves
   @github_skydoves
   Android Developer Advocate @ Stream
   엄재웅 (Jaewoong Eum)


   View Slide

3. View Slide

4. Codelab Guidelines


   View Slide

5. This work is licensed under the Apache 2.0 License
   https://github.com/gdgand/ComposeCamp2022
   Codelab Guidelines
   Fork the project on GitHub


   View Slide

6. This work is licensed under the Apache 2.0 License
   Codelab Guidelines
   ● Clone the project
   ● Checkout to a new branch


   View Slide

7. Compose Phases


   View Slide

8. This work is licensed under the Apache 2.0 License
   Compose Phases
   Which UI to draw
   Where to place UI.
   Measurement and
   placement
   How it renders


   View Slide

9. This work is licensed under the Apache 2.0 License
   Recomposition
   Update UI
   (Click the Checkbox)


   View Slide

10. This work is licensed under the Apache 2.0 License
    @Composable
    private fun WellnessTaskItem(..) {
    Text()
    Checkbox()
    IconButton()
    }
    Recomposition


    View Slide

11. This work is licensed under the Apache 2.0 License
    Recomposition
    @Composable
    private fun WellnessTaskItem(..) {
    Text()
    Checkbox()
    IconButton()
    }
    Update UI
    (Click the Checkbox)
    @Composable
    private fun WellnessTaskItem(..) {
    Text()
    Checkbox()
    IconButton()
    }
    Recomposition


    View Slide

12. This work is licensed under the Apache 2.0 License
    Recomposition
    @Composable
    private fun WellnessTaskItem(..) {
    Text()
    Checkbox()
    IconButton()
    }
    Smart Recomposition
    Update UI
    (Click the Checkbox)
    @Composable
    private fun WellnessTaskItem(..) {
    Text()
    Checkbox()
    IconButton()
    }
    Skip
    Skip
    Recomposition


    View Slide

13. This work is licensed under the Apache 2.0 License
    Recomposition and Performance
    https://getstream.io/blog/jetpack-compose-guidelines/
    https://youtu.be/EOQB8PTLkpY


    View Slide

14. State in Compose


    View Slide

15. This work is licensed under the Apache 2.0 License
    What's the State?
    State
    An interface that has a value property
    during the execution of a Composable
    function.
    MutableState
    A mutable value holder where reads to the
    value property during the execution of a
    Composable function. Any changes to value
    will schedule recomposition of any
    composable functions that read value.


    View Slide

16. This work is licensed under the Apache 2.0 License
    State and Recomposition
    Composition Display UI
    User Event
    Update State
    @Composable


    View Slide

17. This work is licensed under the Apache 2.0 License
    State and Recomposition
    Composition Display UI
    User Event
    Update State
    @Composable


    View Slide

18. This work is licensed under the Apache 2.0 License
    State and Recomposition
    Composition Display UI
    User Event
    Update State
    @Composable


    View Slide

19. This work is licensed under the Apache 2.0 License
    State and Recomposition
    Composition Updated UI
    User Event
    Update State
    Recomposition
    @Composable


    View Slide

20. This work is licensed under the Apache 2.0 License
    What's the State?
    Value Holder
    A value holder where reads to the
    value property during the execution
    of a Composable function.
    Recomposition Trigger
    When the value property is written to
    and changed, recomposition of any
    subscribed Recompose scopes will
    be scheduled.
    Observable
    The current Recompose scope
    will observe states and be
    subscribed to changes of that
    value.


    View Slide

21. This work is licensed under the Apache 2.0 License
    State in Composable
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    Column(modifier = modifier.padding(16.dp)) {
    // Changes to count are now tracked by Compose
    val count: MutableState = mutableStateOf(0)
    Text("You've had ${count.value} glasses.")
    Button(onClick = { count.value++ }, Modifier.padding(top = 8.dp)) {
    Text("Add one")
    }
    }
    }


    View Slide

22. This work is licensed under the Apache 2.0 License
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    Column(modifier = modifier.padding(16.dp)) {
    // Changes to count are now tracked by Compose
    val count: MutableState = mutableStateOf(0)
    Text("You've had ${count.value} glasses.")
    Button(onClick = { count.value++ }, Modifier.padding(top = 8.dp)) {
    Text("Add one")
    }
    }
    }
    State in Composable
    Compilation error!


    View Slide

23. This work is licensed under the Apache 2.0 License
    State in Composable
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    val count: MutableState = mutableStateOf(0)
    ..
    }
    Initialize states


    View Slide

24. This work is licensed under the Apache 2.0 License
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    Column(modifier = modifier.padding(16.dp)) {
    var count by remember { mutableStateOf(0) }
    Text("You've had $count glasses.")
    Button(onClick = { count++ }, Modifier.padding(top = 8.dp)) {
    Text("Add one")
    }
    }
    }
    State and Remember
    Remember
    Composable functions can use the
    remember API to store an object in
    memory.


    View Slide

25. This work is licensed under the Apache 2.0 License
    RemeberSaveable
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    val count: MutableState by rememberSaveable { mutableStateOf(0) }
    ..
    }
    RememberSaveable
    It behaves similarly to remember, but
    the stored value will survive the activity
    or process recreation using the saved
    instance state mechanism.
    ● Configuration changes
    ● Switch between dark and light mode
    ● Change language settings


    View Slide

26. This work is licensed under the Apache 2.0 License
    Remember and Recomposition
    @Composable
    fun ContactList(
    contacts: List,
    comparator: Comparator
    ) {
    LazyColumn(Modifier) {
    items(contacts.sortedWith(comparator)) { contact ->
    // ...
    }
    }
    }


    View Slide

27. This work is licensed under the Apache 2.0 License
    Remember and Recomposition
    @Composable
    fun ContactList(
    contacts: List,
    comparator: Comparator
    ) {
    LazyColumn(Modifier) {
    // DON'T DO THIS
    items(contacts.sortedWith(comparator)) { contact ->
    // ...
    }
    }
    }


    View Slide

28. This work is licensed under the Apache 2.0 License
    Remember and Recomposition
    @Composable
    fun ContactList(
    contacts: List,
    comparator: Comparator,
    ) {
    val sortedContacts = remember(contacts, sortComparator) {
    contacts.sortedWith(sortComparator)
    }
    LazyColumn {
    items(sortedContacts) {
    // ...
    }
    …


    View Slide

29. This work is licensed under the Apache 2.0 License
    Stateful vs Stateless
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    val count: MutableState by remember { mutableStateOf(0) }
    ..
    }
    Stateful


    View Slide

30. This work is licensed under the Apache 2.0 License
    Stateful vs Stateless
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    val count: MutableState by remember { mutableStateOf(0) }
    ..
    }
    @Composable
    fun WaterCounter(
    modifier: Modifier = Modifier,
    count: Int = 0
    ) {
    ...
    }
    Stateful Stateless


    View Slide

31. This work is licensed under the Apache 2.0 License
    Why Stateless?
    Single source of truth
    By moving state instead of
    duplicating it, we're ensuring there's
    only one source of truth. This helps
    avoid bugs.
    Decoupled
    The state for the stateless
    Composable may be stored
    anywhere. It increases the reusability
    of the stateless Composable.
    Encapsulated
    Only stateful composables will
    be able to modify their state. It's
    completely internal.


    View Slide

32. This work is licensed under the Apache 2.0 License
    State Hoisting
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    Column(modifier = modifier.padding(16.dp)) {
    var count by remember { mutableStateOf(0) }
    Text("You've had $count glasses.")
    Button(onClick = { count++ }, Modifier.padding(top = 8.dp)) {
    Text("Add one")
    }
    }
    }


    View Slide

33. This work is licensed under the Apache 2.0 License
    State Hoisting
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    Column(modifier = modifier.padding(16.dp)) {
    var count by remember { mutableStateOf(0) }
    Text("You've had $count glasses.")
    Button(onClick = { count++ }, Modifier.padding(top = 8.dp)) {
    Text("Add one")
    }
    }
    }
    State
    Read state
    Write state


    View Slide

34. This work is licensed under the Apache 2.0 License
    State Hoisting
    @Composable
    fun WaterCounter(modifier: Modifier = Modifier) {
    Column(modifier = modifier.padding(16.dp)) {
    var count by remember { mutableStateOf(0) }
    Text("You've had $count glasses.")
    Button(onClick = { count++ }, Modifier.padding(top = 8.dp)) {
    Text("Add one")
    }
    }
    }
    @Composable
    fun StatelessCounter(
    count: Int,
    onIncrement: () -> Unit,
    modifier: Modifier = Modifier
    ) {
    Column(modifier = modifier.padding(16.dp)) {
    Text("You've had $count glasses.")
    Button(onClick = onIncrement, Modifier.padding(top = 8.dp))
    {
    Text("Add one")
    }
    }
    }


    View Slide

35. This work is licensed under the Apache 2.0 License
    State Hoisting
    @Composable
    fun StatefulCounter() {
    var waterCount by remember { mutableStateOf(0) }
    StatelessCounter(waterCount, { waterCount++ })
    }
    State
    State
    @Composable
    fun StatelessCounter(count: Int, onIncrement: () -> Unit) {
    Text("You've had $count glasses.")
    Button(onClick = onIncrement, Modifier.padding(top = 8.dp))
    {
    ..
    }
    Stateful
    Stateless


    View Slide

36. CompositionLocal


    View Slide

37. This work is licensed under the Apache 2.0 License
    CompositionLocal
    Composable A
    Composable B
    Composable C
    @Composable
    fun ComposableA() {
    ComposableB(Color.White)
    }
    @Composable
    fun ComposableB(color: Color) {
    ComposableC(Color.White)
    }
    @Composable
    fun ComposableC(color: Color) {
    ..
    }


    View Slide

38. This work is licensed under the Apache 2.0 License
    CompositionLocal
    Composable A
    Composable B
    Composable C
    @Composable
    fun ComposableA() {
    ComposableB(Color.White)
    }
    @Composable
    fun ComposableB(color: Color) {
    ComposableC(Color.White)
    }
    @Composable
    fun ComposableC(color: Color) {
    ..
    }


    View Slide

39. This work is licensed under the Apache 2.0 License
    CompositionLocal
    Composable A
    Composable B
    Composable C
    @Composable
    fun ComposableA() {
    ComposableB(Color.White)
    }
    @Composable
    fun ComposableB(color: Color) {
    ComposableC(Color.White)
    }
    @Composable
    fun ComposableC(color: Color) {
    ..
    }
    Dependency


    View Slide

40. This work is licensed under the Apache 2.0 License
    CompositionLocal
    Composable A
    Composable B
    Composable C
    @Composable
    fun ComposableA() {
    CompositionLocalProvider(LocalColor provides color) { ..
    }
    @Composable
    fun ComposableB() {
    ComposableC()
    }
    @Composable
    fun ComposableC() {
    val color = LocalColor.current
    }


    View Slide

41. This work is licensed under the Apache 2.0 License
    CompositionLocal
    By Elye


    View Slide

42. This work is licensed under the Apache 2.0 License
    CompositionLocal
    https://developer.android.com/jetpack/compose/compositionlocal
    val ColorCompositionLocal = staticCompositionLocalOf {
    error("No Color provided")
    }
    CompositionLocalProvider(ColorCompositionLocal provides color) {
    MyComposableFunction(...)
    }
    @Composable
    fun MyComposableFunction() {
    val color = ColorCompositionLocal.current
    }


    View Slide

43. Compose Theming


    View Slide

44. This work is licensed under the Apache 2.0 License
    Material Design


    View Slide

45. This work is licensed under the Apache 2.0 License
    Material Design in Compose
    Color Typography Shape


    View Slide

46. This work is licensed under the Apache 2.0 License
    MaterialTheme
    @Composable
    fun JetnewsTheme(content: @Composable () -> Unit) {
    MaterialTheme(
    colorScheme = myColorScheme,
    shapes = MyShapes,
    typography = MyTypography,
    content = content
    )
    }


    View Slide

47. This work is licensed under the Apache 2.0 License
    MaterialTheme
    @Composable
    fun MaterialTheme(..) {
    CompositionLocalProvider(
    LocalColorScheme provides rememberedColorScheme,
    LocalIndication provides rippleIndication,
    LocalRippleTheme provides MaterialRippleTheme,
    LocalShapes provides shapes,
    LocalTextSelectionColors provides selectionColors,
    LocalTypography provides typography,
    ) {
    ProvideTextStyle(value = typography.bodyLarge, content = content)
    }
    }


    View Slide

48. This work is licensed under the Apache 2.0 License
    MaterialTheme
    @Composable
    fun MyMaterialTheme(..) {
    val isDarkTheme = isSystemInDarkTheme()
    val colorScheme = if (isDarkTheme) {
    darkColorSceme
    } else {
    lightColorSceme
    }
    MaterialTheme(colorScheme = colorScheme) {
    MyScreen()
    }
    }


    View Slide

49. Thank you!
    This work is licensed under the Apache 2.0 License


    View Slide
