Testing the Spring Framework

Guest lecture to first year CS students at TU Delft.

Transcript

1. © Copyright 2019 Pivotal Software, Inc. All rights Reserved.
   Testing the Spring Framework
   Stéphane Nicoll - @snicoll


   View Slide

2. Who am I?
   ● Software Engineer at Pivotal (Spring Boot, Spring
   Framework and start.spring.io)
   ● Involved in open source for 15 years (Apache Maven,
   Spring Framework)
   ● snicoll on the Web (Twitter, Github) - snicoll@pivotal.io
   ● Based in Liège, Belgium (come over, we have waffles)


   View Slide

3. Who am I?
   ● Software Engineer at Pivotal (Spring Boot, Spring
   Framework and start.spring.io)
   ● Involved in open source for 15 years (Apache Maven,
   Spring Framework)
   ● snicoll on the Web (Twitter, Github) - snicoll@pivotal.io
   ● Based in Liège, Belgium (come over, we have waffles)


   View Slide

4. Prerequisite
   “


   View Slide

5. Prerequisite
   “They have a good notion of Java and OOP, know how to use IntelliJ,
   are used to building tools such as Maven and Gradle, and know JUnit
   5 very well.
   Maurício Aniche


   View Slide

6. Prerequisite
   “They have a good notion of Java and OOP, know how to use IntelliJ,
   are used to building tools such as Maven and Gradle, and know JUnit
   5 very well.
   Maurício Aniche



   View Slide

7. This is what I was doing during my 1st year


   View Slide

8. This is what I was doing during my 1st year


   View Slide

9. Once upon a time…


   View Slide

10. We stored libs in source control



    View Slide

11. We stored libs in source control



    View Slide

12. The power of convention over configuration


    View Slide

13. And we had to configure the infrastructure ourselves

    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xmlns:jpa="http://www.springframework.org/schema/data/jpa"
    xmlns:context="http://www.springframework.org/schema/context"
    xsi:schemaLocation="http://www.springframework.org/schema/data/jpa
    https://www.springframework.org/schema/data/jpa/spring-jpa.xsd
    http://www.springframework.org/schema/context
    https://www.springframework.org/schema/context/spring-context.xsd">



    class="org.springframework.jdbc.datasource.DriverManagerDataSource">











    ${hibernate.dialect}
    ${hibernate.hbm2ddl.auto}
    ${hibernate.show_sql}
    ${hibernate.format_sql}











    View Slide

14. And we had to configure the infrastructure ourselves

    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xmlns:jpa="http://www.springframework.org/schema/data/jpa"
    xmlns:context="http://www.springframework.org/schema/context"
    xsi:schemaLocation="http://www.springframework.org/schema/data/jpa
    https://www.springframework.org/schema/data/jpa/spring-jpa.xsd
    http://www.springframework.org/schema/context
    https://www.springframework.org/schema/context/spring-context.xsd">



    class="org.springframework.jdbc.datasource.DriverManagerDataSource">











    ${hibernate.dialect}
    ${hibernate.hbm2ddl.auto}
    ${hibernate.show_sql}
    ${hibernate.format_sql}












    View Slide

15. And chose which libraries to use (and their versions!)

    org.springframework
    spring-context
    ${spring.version}


    org.springframework
    spring-orm
    ${spring.version}


    org.springframework.data
    spring-data-jpa
    1.3.0.RELEASE



    View Slide

16. And chose which libraries to use (and their versions!)

    org.hibernate.javax.persistence
    hibernate-jpa-2.0-api
    1.0.1.Final


    org.hibernate
    hibernate-entitymanager
    4.1.9.Final
    runtime


    mysql
    mysql-connector-java
    5.1.6
    runtime



    View Slide

17. And chose which libraries to use (and their versions!)

    org.hibernate.javax.persistence
    hibernate-jpa-2.0-api
    1.0.1.Final


    org.hibernate
    hibernate-entitymanager
    4.1.9.Final
    runtime


    mysql
    mysql-connector-java
    5.1.6
    runtime




    View Slide

18. The power of convention over configuration


    View Slide

19. Live Coding
    Enough with the slides already!


    View Slide

20. Summary
    ● Conventions can significantly improve your productivity
    ● Best practices for teams and the ecosystem at large
    ● Provide sane defaults when you don’t or shouldn’t care
    ● Make upgrade and maintenance easier
    ● …. but shouldn’t get in your way
    ● Built on top of an API you could use to implement something slightly or totally
    different
    ● Can be customised without having you to redefine everything
    ● Depending on the scope, not everything can be the target of a convention


    View Slide

21. See you in 15
    Break


    View Slide

22. Why bother testing at all?


    View Slide

23. Testing to reduce risk
    Risk
    None
    YOLO
    Tests
    0 Lots


    View Slide

24. Demo
    CI/CD in action on start.spring.io


    View Slide

25. Unit Tests


    View Slide

26. Unit tests should not require any “framework”
    @Service
    public class SubmissionService {
    @Autowired
    private SubmissionRepository submissions;
    @Transactional
    public Submission create(SubmissionRequest request) {
    Submission submission = new Submission();
    ...
    return this.submissions.save(submission);
    }
    }


    View Slide

27. Unit tests should not require any “framework”
    @Service
    public class SubmissionService {
    private final SubmissionRepository submissions;
    public SubmissionService(SubmissionRepository submissions) {
    this.submissions = submissions;
    }
    @Transactional
    public Submission create(SubmissionRequest request) {
    Submission submission = new Submission();
    ...
    return this.submissions.save(submission);
    }
    }


    View Slide

28. Unit testing a client for an HTTP API
    class SpringBootMetadataReaderTests {
    private final RestTemplate restTemplate = new RestTemplate();
    private final MockRestServiceServer server = MockRestServiceServer.bindTo(
    this.restTemplate).build();
    @Test
    void readAvailableVersions() throws IOException {
    this.server.expect(requestTo("https://spring.io/project_metadata/spring-boot"))
    .andRespond(withSuccess(new ClassPathResource(
    "metadata/sagan/spring-boot.json"), MediaType.APPLICATION_JSON));
    ...
    this.server.verify();
    }
    }


    View Slide

29. Integration Tests


    View Slide

30. @SpringBootTest


    View Slide

31. View Slide

32. @JsonTest
    @WebMvcTest
    @WebFluxTest
    @DataJpaTest
    @JdbcTest
    @JooqTest
    @DataMongoTest
    @DataNeo4jTest
    @DataRedisTest
    @DataLdapTest
    @RestClientTest


    View Slide

33. Slice test example
    @RestClientTest(SpringBootMetadataReader.class)
    class SpringBootMetadataReaderTests {
    @Autowired
    private SpringBootMetadataReader springBootMetadataReader;
    @Autowired
    private MockRestServiceServer server;
    @Test
    void readAvailableVersions() throws IOException {
    this.server.expect(requestTo("https://spring.io/project_metadata/spring-boot"))
    .andRespond(withSuccess(new ClassPathResource(
    "metadata/sagan/spring-boot.json"), MediaType.APPLICATION_JSON));
    ...
    this.server.verify();
    }
    }


    View Slide

34. Slice test example with @MockBean
    @WebMvcTest(controllers = CfpController.class)
    class CfpControllerTest {
    @Autowired
    private MockMvc mvc;
    @MockBean
    private SubmissionService submissionService;
    @Test
    void submitTalk() throws Exception {
    given(this.submissionService.create(any())).willReturn(new Submission());
    this.mvc.perform(post("/submit")
    .param("title", "Alice in Wonderland")
    .param("summary", "my abstract"))
    .andExpect(status().isFound())
    .andExpect(header().string(HttpHeaders.LOCATION,
    "/submit?navSection=submit"));
    verify(this.submissionService).create(any());
    }
    }


    View Slide

35. https://www.testcontainers.org


    View Slide

36. testcontainers example
    @DisabledWithoutDockerTestcontainers
    public class ReactiveRestClientAutoConfigurationTests {
    @Container
    static ElasticsearchContainer elasticsearch = new ElasticsearchContainer();
    private ApplicationContextRunner contextRunner = new ApplicationContextRunner()
    .withConfiguration(AutoConfigurations.of(
    ReactiveRestClientAutoConfiguration.class));
    @Test
    void restClientCanQueryElasticsearchNode() {
    String endpoint = elasticsearch.getContainerIpAddress()
    + ":" + elasticsearch.getFirstMappedPort();
    this.contextRunner.withPropertyValues(
    "spring.data.elasticsearch.client.reactive.endpoints=" + endpoint)
    .run((context) -> {
    ReactiveElasticsearchClient client = context.getBean(
    ReactiveElasticsearchClient.class);
    ...
    });
    }
    }


    View Slide

37. Testing Spring Boot


    View Slide

38. ApplicationContextRunner
    ● Test utility to prepare a mini ApplicationContext suitable for a very precise
    scenario:
    ● Specific auto-configuration(s)
    ● User configuration, if any
    ● Environment tuning (properties customization)
    ● System properties handling
    ● Starts/Stop the context automatically with a ContextConsumer callback
    ● AssertJ style assert
    ● hasSingleBean, doesNotHaveBean, hasFailed
    ● getBean, getBeans, etc


    View Slide

39. ApplicationContextRunner example
    @Test
    void shouldFailWhenNativeTypesAreNotAvailable() {
    this.contextRunner
    .run((context) -> {
    assertThat(context).hasFailed();
    assertThat(context.getStartupFailure())
    .hasRootCauseInstanceOf(
    NativeTypesNotAvailableException.class);
    });
    }


    View Slide

40. ApplicationContextRunner example
    @Test
    void shouldFailWhenNativeTypesAreNotAvailable() {
    this.contextRunner
    .withConfiguration(AutoConfigurations.of(
    Neo4jDataAutoConfiguration.class,
    TransactionAutoConfiguration.class))
    .run((context) -> {
    assertThat(context).hasFailed();
    assertThat(context.getStartupFailure())
    .hasRootCauseInstanceOf(
    NativeTypesNotAvailableException.class);
    });
    }


    View Slide

41. ApplicationContextRunner example
    @Test
    void shouldFailWhenNativeTypesAreNotAvailable() {
    this.contextRunner
    .withConfiguration(AutoConfigurations.of(
    Neo4jDataAutoConfiguration.class,
    TransactionAutoConfiguration.class))
    .withPropertyValues(
    "spring.data.neo4j.uri=bolt://localhost:7687",
    "spring.data.neo4j.use-native-types:true")
    .run((context) -> {
    assertThat(context).hasFailed();
    assertThat(context.getStartupFailure())
    .hasRootCauseInstanceOf(
    NativeTypesNotAvailableException.class);
    });
    }


    View Slide

42. ApplicationContextRunner example
    @Test
    void shouldFailWhenNativeTypesAreNotAvailable() {
    this.contextRunner
    .withConfiguration(AutoConfigurations.of(
    Neo4jDataAutoConfiguration.class,
    TransactionAutoConfiguration.class))
    .withPropertyValues(
    "spring.data.neo4j.uri=bolt://localhost:7687",
    "spring.data.neo4j.use-native-types:true")
    .withClassLoader(new FilteredClassLoader(
    "org.neo4j.ogm.drivers.bolt.types"))
    .run((context) -> {
    assertThat(context).hasFailed();
    assertThat(context.getStartupFailure())
    .hasRootCauseInstanceOf(
    NativeTypesNotAvailableException.class);
    });
    }


    View Slide

43. Classpath tuning
    @RunWith(ModifiedClassPathRunner.class)
    @ClassPathOverrides("javax.servlet:servlet-api:2.5")
    public class NoSuchMethodFailureAnalyzerTests {
    @Test
    public void noSuchMethodErrorIsAnalyzed() {
    Throwable failure = createFailure();
    assertThat(failure).isNotNull();
    FailureAnalysis analysis = new NoSuchMethodFailureAnalyzer()
    .analyze(failure);
    assertThat(analysis).isNotNull();
    ...
    }
    private Throwable createFailure() {
    ...
    }
    }


    View Slide

44. Links
    ● https://spring.io/projects/spring-boot
    ● https://start.spring.io
    ● https://spring.io/guides
    ● https://concourse-ci.org/
    ● Testing Spring Boot Applications (Andy Wilkinson @ Spring I/O 2019): https://
    www.youtube.com/watch?v=5sjFn9BsAds


    View Slide

45. © Copyright 2019 Pivotal Software, Inc. All rights Reserved.
    Thank you!
    @snicoll


    View Slide
