Advanced Rate Limiting Use Cases with Envoy Proxy API and Gloo API Gateway

Applications of all types including monoliths, microservices, serverless functions, and any combination of them often need a way for external clients and users to access them in a safe and secure way. As incoming requests can be numerous and varied, protecting backend services and globally enforcing business limits can become incredibly complex being handled at the application level.

Rate limiting is a strategy that can prevent service outages by protecting the service from being overrun with more requests than it’s resources can process and respond to within the agreed service levels. Rate limits can be set to limit the number of times the service can be called (per second, minute, hour) within a specified time period (total received in a day, week, month).

Attend this session to learn how to leverage Envoy Proxy at the edge to implement advanced rate limiting use cases:
* Configure multiple rate limits per client
* Secure rate limit actions with JSON Web Tokens (JWT)
* Combine rate limits with WAF and Auth
* Gloo control plane to manage Envoy configurations

Watch the talk here https://youtu.be/wVSSfcxjLy8
About Gloo https://www.solo.io/products/gloo/
Read the docs https://docs.solo.io/gloo/latest/
Try the demos yourself https://bit.ly/2BDUpvW
Request a trial https://lp.solo.io/lp-request-a-trial-general
Questions? Join the community at https://slack.solo.io

Transcript

1. Advanced Rate Limiting with Envoy Proxy API and Gloo June 25, 2020
2. 2 | Copyright © 2020 What is Rate Limiting? Goal Protect backend applications from failures caused by intentional and unintentional overloading of network traffic. Definition Rate limiting allows for setting a limit to the amount of incoming traffic an application (API) can accept for processing responses. Rate limiting allows a max number of requests over a specific time interval like per second, minute, or hour and can also have a quota. Example: 100 requests per second for service A
3. 3 | Copyright © 2020 Gloo API Gateway and Ingress Controller ENVOY CONFIG CONTROL PLANE DATA PLANE END USERS Service 1 Service 2 Next Generation API Gateway • Built with Envoy Proxy • Kubernetes and Consul Native • Monolith, Microservices and Serverless Functions • Lightweight, performant, secure Service 3
4. 4 | Copyright © 2020 Rate Limiting with Gloo: How does it work? EXTERNAL AUTH RATE LIMITING gRPC TRANSCODER ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER DATA PLANE CONTROL PLANE ENVOY PROXY FILTERS CONFIGS IN GLOO
5. 5 | Copyright © 2020 Advanced Rate Limiting Use Cases Multiple Rate Limits Per Client ID Rate Limit Traffic Prioritization on HTTP Method Integrating Rate Limits with JWT
6. 6 | Copyright © 2020 Use Case: Multiple Rate Limits Per Client ID Granular control to protect against unplanned bursts in traffic • Define by remote_address • Use real client ID, not Kubernetes cluster or load balancer address • Configure one or multiple rate limits • Nested rate limits spec: ratelimit: descriptors: - key: generic_key value: "per-minute" descriptors: - key: remote_address rateLimit: requestsPerUnit: 20 unit: MINUTE - key: generic_key value: "per-second" descriptors: - key: remote_address rateLimit: requestsPerUnit: 2 unit: SECOND
7. 7 | Copyright © 2020 Use Case: Rate Limit Prioritization by HTTP Method Guarantee high priority traffic when multiple types of requests enter a given service • Define a limit per request type • Critical request will be processed before the lower priority request • Service will never be overloaded by volume of lower priority requests spec: ratelimit: descriptors: # allow 5 calls per minute for any unique host - key: remote_address rateLimit: requestsPerUnit: 5 unit: MINUTE # specifically limit GET requests from unique hosts to 2 per min - key: method value: GET descriptors: - key: remote_address rateLimit: requestsPerUnit: 2 unit: MINUTE
8. 8 | Copyright © 2020 Use Case: Integrate Rate Limiting with JWT Integrating additional security policies • Further protect services • Add JWT configuration above the rate limit configuration in the yml file • JWT token must be verified prior to passing through rate limit filter options: jwt providers: solo: tokenSource: headers: - header: x-token queryParams: - token claimsToHeaders: - claim: type header: x-type - claim: number header: x-number issuer: solo.io jwks: local: key: | -----BEGIN PUBLIC KEY-----
9. 9 | Copyright © 2020 Gloo Open Source and Enterprise Features
10. 10 | Copyright © 2020 Companies Using Gloo Read their stories at www.solo.io/customers
11. 11 | Copyright © 2020 LEARN MORE solo.io/gloo OPEN SOURCE gloo.solo.io ENTERPRISE TRIAL lp.solo.io/lp-request-a-trial-general TRY THE DEMOS bit.ly/2BDUpvW SOLO COMMUNITY slack.solo.io Thank You!
