Extending WebAssembly Hub to Istio Service Mesh

Solo.io, Google and Istio have teamed up to support WebAssembly in Envoy Proxy and Istio to bring the dynamic extensibility of WebAssembly to Envoy with unmatched agility, reliability and security.

What is WebAssembly?
WebAssembly (Wasm) is a fast, efficient, portable binary instruction format, providing an embeddable and safe execution environment for platform extensions. Wasm extensions, which can be written in multiple languages and executed at a near-native speed, became a popular way to extend web based applications.

Speakers from Solo.io and Google will cover the community feedback and collaboration that led to support for WebAssembly and the joint effort to iterate on WebAssemblyHub to ensure the best developer experience in on-boarding, developing, deploying, managing and sharing WebAssembly extensions.

Watch the presentation https://youtu.be/BfWj-eKUxM8

Learn More:
https://www.solo.io/
https://istio.io/
https://webassemblyhub.io/

Join the Discussion https://slack.solo.io
Follow https://twitter.com/soloio_inc

Transcript

1. Extending Envoy Proxy with WebAssembly Louis Ryan, Google Principal Engineer Idit Levine, Solo.io Founder and CEO Christian Posta, Solo.io Field CTO
2. 2 | Copyright © 2020 2 | Copyright © 2020 Louis Ryan Principal Engineer Google Cloud Christian Costa Field CTO Solo.io Idit Levine Founder & CEO Solo.io
3. 3 | Copyright © 2020 3 | Copyright © 2020 Control and Data Plane
4. 4 | Copyright © 2020 Istio Gloo
5. 5 | Copyright © 2020 Control Path EXTERNAL AUTH RATE LIMITING gRPC TRANSCODER ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER VirtualService : route: / -> svc1 auth: opa: allow = ... auth: opa: allow = ... route: / -> svc1
6. 6 | Copyright © 2020 Data Path EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER POST /dentists Content-Type: application/json Authorization: Bearer xyz {"name":”Dr. Seuss"} POST /com.example.DentistService/AddDentist Content-Type: application/grpc Authorization: Bearer xyz Binary protobuf: \x12\x011\x12\seuss { Method: "POST", Path: "/dentists", Headers: { "Content- Type”:"application/json", "Authorization": "Bearer xyz" } } OK Descriptors {generic_key: "add-drs"} OK gRPC TRANSCODER
7. 7 | Copyright © 2020 Data Path EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER 201 Created Content-Type: application/json {"id": ”2301", "name":”Dr. Seuss"} gRPC TRANSCODER
8. 8 | Copyright © 2020 Control Path EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER CUSTOM gRPC TRANSCODER
9. 9 | Copyright © 2020 ⃞ Use any language ⃞ Fast ⃞ Safe ⃞ No need to compile ⃞ Easy Very powerful, but leaves a lot to wish for…
10. 10 | Copyright © 2020 10 | Copyright © 2020 Extend Data Plane
11. 11 | Copyright © 2020 ⃞ Use any language ⃞ Fast ⃞ Safe ⃞ No need to compile ⃞ Easy EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM EXTERNAL AUTH SERVER RATE LIMITING SERVER CUSTOM gRPC TRANSCODER Gloo – Custom filters ⃞ Use any language ✓ Fast ✓ Safe ⃞ No need to compile ⃞ Easy
12. 12 | Copyright © 2020 Istio - Mixer ⃞ Use any language ⃞ Fast ⃞ Safe ⃞ No need to compile ⃞ Easy ⍻ Use any language ⃞ Fast ⍻ Safe ✓ No need to compile ⍻ Easy
13. 13 | Copyright © 2020 13 | Copyright © 2020 Web Assembly
14. 14 | Copyright © 2020 “WebAssembly: it’s neither web, nor assembly” WebAssembly (abbreviated Wasm) is a binary instruction format for a stack-based virtual machine. Wasm is designed as a portable target for compilation of high-level languages like C/C++/Rust, enabling deployment on the web for client and server applications. -> No Assembly -> Binary Instruction Format -> No Web -> WASI
15. 15 | Copyright © 2020 Portable
16. 16 | Copyright © 2020 Secure
17. 17 | Copyright © 2020 Fast Java Script WebAssembly
18. 18 | Copyright © 2020 Any Language
19. 19 | Copyright © 2020 WebAssembly Outside the Web
20. 20 | Copyright © 2020 ✓ Use any language ✓ Fast ✓ Safe ✓ No need to compile ✓ Easy Very powerful, but leaves a lot to wish for…
21. 21 | Copyright © 2020 21 | Copyright © 2020 Envoy support for WebAssembly
22. 22 | Copyright © 2020 WASM in Envoy EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM CUSTOM gRPC TRANSCODER
23. 23 | Copyright © 2020 WASM in Envoy EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM WASM gRPC TRANSCODER
24. 24 | Copyright © 2020 WASM in Envoy EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM WASM gRPC TRANSCODER Code V8 ABI
25. 25 | Copyright © 2020 ABI: Application Binary Interface
26. 26 | Copyright © 2020 SDK
27. 27 | Copyright © 2020 WASM in Envoy EXTERNAL AUTH RATE LIMITING ROUTER UPSTREAM WASM gRPC TRANSCODER Code V8 ABI Code + SDK
28. 28 | Copyright © 2020 ✓ Use any language ✓ Fast ✓ Safe ✓ No need to compile ⃞ Easy Very powerful, but leaves a lot to wish for…
29. 29 | Copyright © 2020 29 | Copyright © 2020 Developer Experience
30. 30 | Copyright © 2020
31. 31 | Copyright © 2020 SECURITY
32. 32 | Copyright © 2020 Web Assembly Hub SECURITY
33. 33 | Copyright © 2020 ✓ Use any language ✓ Fast ✓ Safe ✓ No need to compile ✓ Easy Very powerful, but leaves a lot to wish for…
34. 34 | Copyright © 2020 34 | Copyright © 2020 Demo
35. 35 | Copyright © 2020 35 | Copyright © 2020 @soloio_inc https://github.com/solo-io
