The Quest for the Holy Grail of Continuous Delivery

Continuous Delivery of Node.JS Apps With Docker from Scratch to Production.

Presented at:
- #wenode event http://wenode.barcelonajs.org/speaker/dimitris-kapanidis.html
- #scbcn14 event https://github.com/JavierCane/Software-Craftsmanship-Barcelona-2014

Transcript

1. View Slide

2. Dimitris Kapanidis
   @spiddy
   https://github.com/spiddy
   docker-barcelona-spain
   https://www.linkedin.com/in/kapanidis
   .io


   View Slide

3. Discover, compose & deploy container stacks in your cloud
   Simple docker hosting, built for developers.
   .io
   wordpress:
   image: wordpress:4.1.0
   ports:
   - “80”
   links:
   - mysql
   mysql:
   image: orchardup/mysql
   environment:
   - MYSQL_DATABASE=wordpress
   mysql
   wordpress
   Stackfile / fig.yml


   View Slide

4. What is Docker?


   View Slide

5. Docker Intro
   Photo Credit Weasly Grizzly at Pixeljoint


   View Slide

6. Docker is an open
   platform for developers
   and sysadmins to build,
   ship, and run
   distributed applications


   View Slide

7. Docker
   Virtual Machines


   View Slide

8. Develop your App
   Ship your App
   myapp


   View Slide

9. myapp
   Dockerfile
   FROM ubuntu:12.04
   RUN apt­get ­y install ruby
   ADD . /app/
   EXPOSE 3000
   CMD rails server
   Base Image
   Install Dependencies
   Add Files to Container
   Expose Port
   Launch Command


   View Slide

10. Scale your App
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp
    myapp


    View Slide

11. View Slide

12. Index
    ●
    Process Workflow
    ●
    Production Topology
    ●
    Bootstrap a Mean.io Project
    ●
    Dockerize
    ●
    CI Build Test & Deploy
    ●
    CI Backup & Monitor


    View Slide

13. Process Workflow
    Developer
    push
    trigger execute
    Production
    deploy
    test
    build


    View Slide

14. db
    Production Topology
    proxy
    web
    web
    users


    View Slide

15. Bootstrap Mean.io Project
    > npm install ­g meanio
    > mean init wenode


    View Slide

16. Launch locally
    > npm install
    > grunt


    View Slide

17. Execute Tests
    > grunt test


    View Slide

18. > git remote add origin ...
    > git push origin
    Version Control (GitHub)


    View Slide

19. Create Jenkins Server (Harbur)


    View Slide

20. Create Jenkins Server (Harbur)


    View Slide

21. Create Jenkins Server (Harbur)


    View Slide

22. Jenkins: Create New Job


    View Slide

23. Jenkins: Configure Job


    View Slide

24. Jenkins: Build Now
    npm not found


    View Slide

25. Add Dockerfile


    View Slide

26. Build Container
    > docker build ­t spiddy/wenode .
    web


    View Slide

27. Run Container (Fail Database)
    > docker run spiddy/wenode
    web
    Could not connect to MongoDB


    View Slide

28. Find localhost IP on Docker
    web


    View Slide

29. Configure Database IP
    web


    View Slide

30. Run Container
    web
    > docker run ­p 3000:3000
    spiddy/wenode


    View Slide

31. web
    Run Container
    > docker run ­p 3000:3000
    spiddy/wenode


    View Slide

32. db
    Add fig.yml
    web


    View Slide

33. db
    Configure Database
    web


    View Slide

34. Run Containers
    db
    web
    > fig up


    View Slide

35. db
    web
    Run Containers
    > fig up


    View Slide

36. Job: Bootstrap Production
    db
    proxy
    fs
    docker run -d -p 8080 -v /var/run/docker.sock:/tmp/docker.sock -t jwilder/nginx-proxy
    docker run –name wenode_data busybox true
    docker run -d -p 27017 –name db mongo:2.7.6


    View Slide

37. Job: Build wenode


    View Slide

38. Job: Build wenode


    View Slide

39. Job: Build wenode output


    View Slide

40. Job: Test wenode


    View Slide

41. Job: Test wenode output


    View Slide

42. Job: Deploy wenode


    View Slide

43. Deploy wenode output


    View Slide

44. GitHub Webhook


    View Slide

45. Process Workflow
    Developer
    push
    trigger execute
    Production
    deploy
    test
    build


    View Slide

46. db
    Production Topology
    proxy
    web
    web
    users


    View Slide

47. Alternative Topology
    users
    web db
    db
    web
    proxy


    View Slide

48. Backup Process
    backup
    danhixon/backup­base
    1 32 0
    docker run --rm --link db:mongodb \
    -e AWS_ACCESS_KEY_ID=xxx
    -e AWS_SECRET_ACCESS_KEY=xxx \
    docker-backup-mongodb backup perform -t daily_mongodb


    View Slide

49. Backup Process Config


    View Slide

50. Backup Process Triggers


    View Slide

51. Backup Process Diagram
    backup
    Dump db
    Encrypt
    Upload to S3
    Amazon
    S3
    backup
    Restore db
    Decrypt
    Download from S3
    db
    private
    public


    View Slide

52. Monitoring Process
    google/cadvisor
    21 486495 0


    View Slide

53. Alert Process
    execute
    heartbeat
    Production


    View Slide

54. Thank You


    View Slide
