Where Did My State Go?

Transcript

1. Where Did My State Go?
   Subhrajyoti Sen
   @iamsubhrajyoti


   View Slide

2. This is a Lifecycle talk


   View Slide

3. The First thing


   View Slide

4. The First thing
   We have all done this


   View Slide

5. The First thing
   We have all done this
   android:name=".main.MainActivity"
   android:screenOrientation="portrait">


   View Slide

6. Is this Enough?


   View Slide

7. NO


   View Slide

8. NO


   View Slide

9. But WHY?


   View Slide

10. Reasons


    View Slide

11. Reasons
    1. Dark Theme


    View Slide

12. Reasons
    1. Dark Theme
    2. Multi-Window


    View Slide

13. Reasons
    1. Dark Theme
    2. Multi-Window
    3. Process Death


    View Slide

14. Dark Theme


    View Slide

15. Dark Theme
    Introduced in Android 10


    View Slide

16. Dark Theme
    Introduced in Android 10
    Can be changed by
    1. System Toggle
    2. AppCompat in-app


    View Slide

17. Dark Theme


    View Slide

18. Dark Theme
    Triggers a uiMode configuration change


    View Slide

19. Dark Theme
    Triggers a uiMode configuration change
    All started Activities are automatically recreated.



    View Slide

20. Dark Theme
    android:name=".MyActivity"
    android:configChanges="uiMode" />


    View Slide

21. Dark Theme
    android:name=".MyActivity"
    android:configChanges="uiMode" />
    This will invoke onConfigurationChanged() and not recreate all started Activities.


    View Slide

22. Multi-Window


    View Slide

23. Multi-Window


    View Slide

24. Multi-Window


    View Slide

25. Multi-Window
    Introduced in Android N


    View Slide

26. Multi-Window
    Introduced in Android N
    A slight change in Lifecycle.


    View Slide

27. Multi-Window
    Introduced in Android N
    A slight change in Lifecycle.
    You can’t completely depend on onPause() and onResume()


    View Slide

28. Multi-Window
    Introduced in Android N
    A slight change in Lifecycle.
    You can’t completely depend on onPause() and onResume()
    screenOrientation
    will be ignored


    View Slide

29. Multi-Window
    Portrait orientation != Vertical device


    View Slide

30. Multi-Window
    Portrait orientation != Vertical device
    android:resizeableActivity="false"
    to opt out of Multi-Window


    View Slide

31. Process Death


    View Slide

32. Process Death
    ●
    The device is running low on memory and the OS kills your app to free up
    memory.


    View Slide

33. Process Death
    ●
    The device is running low on memory and the OS kills your app to free up
    memory.
    ●
    It happens if your app is in the Paused/Stopped state.


    View Slide

34. Process Death
    ●
    The device is running low on memory and the OS kills your app to free up
    memory.
    ●
    It happens if your app is in the Paused/Stopped state.
    ●
    Cannot work around it.


    View Slide

35. Process Death - Testing
    1. Developer Options -> Apps -> Background process limit
    2. Choose ‘No background processes’
    3. Open your app and put in the background
    4. Open another app and switch to your app


    View Slide

36. Process Death - Testing
    1. Put the app in background
    2. adb shell am kill packagename


    View Slide

37. ViewModel


    View Slide

38. ViewModel
    ViewModels persist state across Activity recreation.
    ViewModels do not persist state on process death.


    View Slide

39. ViewModel
    ViewModels persist state across Activity recreation.
    ViewModels do not persist state on process death.
    Use SavedStateHandle to save state.


    View Slide

40. ViewModel - SavedStateHandle


    View Slide

41. ViewModel - SavedStateHandle
    val viewModel = ViewModelProvider(this, SavedStateVMFactory(this))
    .get(MyViewModel::class.java)


    View Slide

42. ViewModel - SavedStateHandle
    val viewModel = ViewModelProvider(this, SavedStateVMFactory(this))
    .get(MyViewModel::class.java)
    class MyViewModel(val state : SavedStateHandle) : ViewModel() {
    fun saveProductId(productId: String) {
    state.set("productId", productId)
    }
    fun getProductId(): String {
    return state.get("productId")?: ""
    }
    }


    View Slide

43. Custom View
    Views can save their own state.
    Views need to have an ID to be able to save state.


    View Slide

44. Custom View
    private class SavedState : BaseSavedState {
    var value = 1
    constructor(superState: Parcelable) : super(superState)
    private constructor(source: Parcel) : super(source) {
    value = source.readInt()
    }
    override fun writeToParcel(out: Parcel, flags: Int) {
    super.writeToParcel(out, flags)
    out.writeInt(value)
    }
    }


    View Slide

45. Custom View
    private class SavedState : BaseSavedState {
    //..
    companion object {
    val CREATOR: Parcelable.Creator =
    object : Parcelable.Creator {
    override fun createFromParcel(source: Parcel) = SavedState(source)
    override fun newArray(size: Int) = arrayOfNulls(size)
    }
    }
    }


    View Slide

46. Custom View
    class CustomView(context: Context) : View(context) {
    var value = 1
    override fun onSaveInstanceState(): Parcelable {
    val superState = super.onSaveInstanceState()
    val state = SavedState(superState)
    state.value = this.value
    return state
    }
    }


    View Slide

47. Custom View
    class CustomView(context: Context) : View(context) {
    override fun onRestoreInstanceState(state: Parcelable) {
    val savedState = state as SavedState
    super.onRestoreInstanceState(savedState.superState)
    this.value = savedState.value
    }
    }


    View Slide

48. What about TESTING?


    View Slide

49. Testing Activity/Fragment Recreation


    View Slide

50. Testing Activity/Fragment Recreation
    Can be done with Espresso


    View Slide

51. Testing Activity/Fragment Recreation
    Can be done with Espresso
    Easier with AndroidX Test


    View Slide

52. Testing Activity/Fragment Recreation
    Can be done with Espresso
    Easier with AndroidX Test
    debugImplementation 'androidx.fragment:fragment-testing:$fragment_version'


    View Slide

53. Testing Fragment Recreation


    View Slide

54. Testing Fragment Recreation
    @RunWith(AndroidJUnit4::class)
    class MyTestSuite {
    @Test fun testRecreation() {
    val scenario = launchFragmentInContainer()
    }
    }


    View Slide

55. Testing Fragment Recreation
    @RunWith(AndroidJUnit4::class)
    class MyTestSuite {
    @Test fun testRecreation() {
    val scenario = launchFragmentInContainer()
    // perform actions
    }
    }


    View Slide

56. Testing Fragment Recreation
    @RunWith(AndroidJUnit4::class)
    class MyTestSuite {
    @Test fun testRecreation() {
    val scenario = launchFragmentInContainer()
    // perform actions
    scenario.recreate()
    }
    }


    View Slide

57. Testing Fragment Recreation
    @RunWith(AndroidJUnit4::class)
    class MyTestSuite {
    @Test fun testRecreation() {
    val scenario = launchFragmentInContainer()
    // perform actions
    scenario.recreate()
    // test events
    }
    }


    View Slide

58. Testing Fragment Lifecycle


    View Slide

59. Testing Fragment Lifecycle
    @RunWith(AndroidJUnit4::class)
    class MyTestSuite {
    @Test fun testLifecycle() {
    val scenario = launchFragmentInContainer()
    }
    }


    View Slide

60. Testing Fragment Lifecycle
    @RunWith(AndroidJUnit4::class)
    class MyTestSuite {
    @Test fun testLifecycle() {
    val scenario = launchFragmentInContainer()
    scenario.moveToState(State.CREATED)
    }
    }


    View Slide

61. Thank You
    @iamsubhrajyoti
