Building products with Particle

An hour long workshop showing how to build internet connected temperature sensor using Particle

Transcript

1. BUILDING PRODUCTS WITH PARTICLE
2. WORKSHOP GOALS ▸ Build an Internet connected thermometer using DS18B20 sensor ▸ Discover Particle features useful for product creators ▸ Get familiar with process of creating a product
3. PHOTON AND THE CLOUD
5. ! DEVICE MODES
7. ! Particle.function() ! Particle.variable() ! Particle.publish() ! Particle.subscribe()
8. SUMMARY 1. Setup a device 2. Connect hardware 3. Write firmware 4. Analyze incoming data
9. 1. SETUP A DEVICE
10. DOWNLOAD PARTICLE APP FOR: ! iOS or ! Android
11. CREATE / LOG INTO PARTICLE ACCOUNT
12. POWER ON YOUR DEVICE
13. DEVICE SHOULD BE BLINKING BLUE If not, hold the SETUP button for 3 seconds
14. FIND DEVICE'S WI-FI NAME SUFFIX ON ITS PACKAGING
15. SETUP YOUR DEVICE USING MOBILE APP Setup UI in this app is open source (for ! iOS and ! Android). You can customize and use it for your product.
16. 2. CONNECT HARDWARE Use breadboard that came with your device
17. 3. WRITE FIRMWARE Firmware is the app that runs on the device
18. OPEN ! BUILD IDE
19. GO TO LIBRARIES 1. Search for "ds18x" 2. Click DS18X20 library
20. USE AN EXAMPLE APP 1. Select ONEWIRETEMP.INO 2. Click USE THIS EXAMPLE
21. FLASH THE THE DEVICE WITH YOUR APP by clicking Flash button The device should start blinking magenta
22. 4. ANALYZE INCOMING DATA 1. Go to ! Particle Dashboard 2. Log in with your Particle account 3. Select Logs
23. NEXT STEPS
24. REACT TO INCOMING DATA ▸ Use ! If This Than That AKA IFTTT ▸ Build mobile app for ! iOS or ! Android ▸ Build server app on ! Microsoft Azure ▸ Build apps for other platform using ! our API
25. GO BEYOND THE PROTOTYPE ▸ Scale hardware ! with P0/P1 ▸ Scale deployment ! with fleet management ▸ Go cellular ! with Electron
26. MOVING TO PRODUCTION ▸ FCC/CE certification ! P1 / Photon ▸ ! Service partners ▸ ! Prototype to Production
27. WHERE TO FIND HELP ▸ ! Our community ▸ ! Our reference ▸ ! Getting started guide ▸ Find and tap me on the back
28. THANK YOU!
