J’et aan je rekker met Elasticsearch Deur Thijs Feryn

‘k Goan ’t in 1 slide uutleg’n

•Full-text zoek database •NoSQL database •Analytics engine •Geschreven in Java
•Lucene gebaseerd ( ~Solr) •Omgekeerde indices •Gemakkelijk vo te Schaaln (~Elastic) •RESTFul interface (HTTP/JSON) •Schemaloos •Real-time (subiet & direct) •Den ELK hoop

Zie ‘j nog mee?

keireltjes Thijs Yo Ik zien

En ik zien @ThijsFeryn ip Twitter

’k Zien bie Evangelist

En ’k zitt’n van ook in ’t besteur

’k Weunen in Diksmude

Aan de Pluum’n

Juuste niet bachten de Kupe

https://www.elastic.co/ downloads/elasticsearch

{ "status" : 200, "name" :
"War V", "cluster_name" : "elasticsearch", "version" : { "number" : "1.5.2", "build_hash" : "62ff9868b4c8a0c45860bebb259e21980778ab1c", "build_timestamp" : "2015-‐04-‐27T09:21:06Z", "build_snapshot" : false, "lucene_version" : "4.10.4" }, "tagline" : "You Know, for Search" } http://localhost:9200

RDBMS Elasticsearch Database Table Row Index Type Document

POST /my-‐index {"acknowledged":true} POST/my-‐index/my-‐type {
"key" : "value", "date" : "2015-‐05-‐10", "counter" : 1, "tags" : ["tag1","tag2","tag3"] } { "_index": "my-‐index", "_type": "my-‐type", "_id": "AU089olr9oI99a_rK9fi", "_version": 1, "created": true } CREATE DATABASE my-‐index INSERT INTO my-‐index.my-‐type (key,date,counter,tags) VALUES ("value","2015-‐05-‐10",1,"tag1,tag2,tag3") Bevestigienge

BAFFE ! We zien vertrok’n

GET/my-‐index/my-‐type/AU089olr9oI99a_rK9fi?pretty { "_index": "my-‐index",
"_type": "my-‐type", "_id": "AU089olr9oI99a_rK9fi", "_version": 1, "found": true, "_source": { "key": "value", "date": "2015-‐05-‐10", "counter": 1, "tags": [ "tag1", "tag2", "tag3" ] } } Document iphaaln ip ID Document & meta data SELECT * FROM my-‐index.my-‐type WHERE id="AU089olr9oI99a_rK9fi"

GET /my-‐index/_mapping?pretty { "my-‐index": {
"mappings": { "my-‐type": { "properties": { "counter": { "type": "long" }, "date": { "type": "date", "format": "dateOptionalTime" }, "key": { "type": "string" }, "tags": { "type": "string" } } } } } } Schemaloos? Nie echt wi … “Smiet met ze klakke” voe de mapping

Expliciete mappinge … met echte gegevens

Data importeren van MySQL nor ElasticSearch

{ "category": [
"Default Category", "Men", "Shirts" ], "entity_id": "231", "created_at": "2013-‐03-‐05 06:48:12", "updated_at": "2013-‐03-‐05 09:27:15", "name": "French Cuff Cotton Twill Oxford", "price": "190.0000", "description": "Made with wrinkle resistant cotton twill, this French-‐cuffed luxury dress shirt is perfect for Business Class frequent flyers.", "sku": "msj000" } SELECT GROUP_CONCAT(distinct c.name) as category,p.entity_id, p.created_at, p.updated_at, p.name, p.price, p.short_description as description,p.sku FROM catalog_product_flat_1 p JOIN `catalog_category_product_index` AS `cat_index` ON cat_index.product_id=p.entity_id JOIN `catalog_category_flat_store_1` AS `c` ON cat_index.category_id=c.entity_id WHERE cat_index.store_id = 1 AND cat_index.visibility=1 GROUP BY p.name ORDER BY p.entity_id

POST /products { "mappings": {
"product" : { "_id" : { "path" : "entity_id" }, "properties" : { "entity_id" : {"type" : "integer"}, "name" : { "type" : "string", "index" : "not_analyzed", "fields" : { "raw" : { "type" : "string", "analyzer": "english" } } }, "description" : { "type" : "string", "index" : "not_analyzed", "fields" : { "raw" : { "type" : "string", "analyzer": "english" } } }, "price" : {"type" : "double"}, "sku" : {"type" : "string", "index" : "not_analyzed"}, "created_at" : {"type" : "date", "format" : "YYYY-‐MM-‐dd HH:mm:ss"}, "updated_at" : {"type" : "date", "format" : "YYYY-‐MM-‐dd HH:mm:ss"} , "category" : { "type" : "string", "index" : "not_analyzed" } } } } } Expliciete mapping bie ’t maken van de index

"entity_id" : {"type" : "integer"},
"name" : { "type" : "string", "index" : "not_analyzed", "fields" : { "raw" : { "type" : "string", "analyzer": "english" } } }, "description" : { "type" : "string", "index" : "not_analyzed", "fields" : { "raw" : { "type" : "string", "analyzer": "english" } } }, "price" : {"type" : "double"}, "sku" : {"type" : "string", "index" : "not_analyzed"}, "created_at" : {"type" : "date", "format" : "YYYY-‐MM-‐dd HH:mm:ss"}, "updated_at" : {"type" : "date", "format" : "YYYY-‐MM-‐dd HH:mm:ss"} , "category" : { "type" : "string", "index" : "not_analyzed" } Not analyzed? English analyzer?

Analyzed vs non-analyzed

Full-text vs exact wèèrde

Analyzer •Character filters •Tokenizers •Token filters Vervangt tekens voe analyzed
text Zet tekst omme in tokens Toevoegen, verwijderen of wijzigen tokens

Ingebouwde analyzers •Standard •Simple •Whitespace •Stop •Keyword •Pattern •Language •Snowball
•Custom Standard tokenizer Lowercase token filter English stop word token filter

Set the shape to semi-transparent by calling set_trans(5) set, the,
shape, to, semi, transparent, by, calling, set_trans, 5 set, the, shape, to, semi, transparent, by, calling, set, trans Set, the, shape, to, semi-transparent, by, calling, set_trans(5) set, shape, semi, transpar, call, set_tran, 5 Standard Simple Whitespace English

Zelve een analyzer maakt PUT /my_index {
"settings": { "analysis": { "char_filter": { "&_to_and": { "type": "mapping", "mappings": [ "&=> and "] }}, "filter": { "my_stopwords": { "type": "stop", "stopwords": [ "the", "a" ] }}, "analyzer": { "my_analyzer": { "type": "custom", "char_filter": [ "html_strip", "&_to_and" ], "tokenizer": "standard", "filter": [ "lowercase", "my_stopwords" ] }} }}}

Zoek’n

GET /products/product/_search?pretty { "took": 2,
"timed_out": false, "_shards": { "total": 1, "successful": 1, "failed": 0 }, "hits": { "total": 192, "max_score": 1, "hits": [ { "_index": "products", "_type": "product", "_id": "231", "_score": 1, "_source": { "category": [ "Default Category", "Men", "Shirts" ], "entity_id": "231", "created_at": "2013-‐03-‐05 06:48:12", "updated_at": "2013-‐03-‐05 09:27:15", "name": "French Cuff Cotton Twill Oxford", "price": "190.0000", "description": "Made with wrinkle resistant cotton twill, this French-‐cuffed luxury dress shirt is perfect for Business Class frequent flyers.", "sku": "msj000" } }, … SELECT * FROM products.product

GET /products/product/_search?pretty POST /products/product/_search?pretty {
"query": { "match_all": {} } } Zoek’n “lite” vs De hele query DSL SELECT * FROM products.product

GET /products/product/_search? pretty&q=name.raw:Blazer POST /products/product/_search?pretty {
"query": { "match": { "name.raw": "Blazer" } } } SELECT * FROM products.product WHERE name LIKE "%Blazer%" Zoek’n “lite” vs De hele query DSL

SELECT * FROM products.product WHERE
name = "Linen Blazer" POST /products/product/_search? pretty { "query": { "match": { "name.raw": "Linen Blazer" } } } POST /products/product/_search? pretty { "query": { "filtered": { "query": { "match_all": {} }, "filter": { "term": { "name": "Linen Blazer" } } } } } 2 producten gevoend’n 1 product gevoend’n SELECT * FROM products.product WHERE name LIKE "%Linen%" OR name LIKE "%Blazer%"

Filter vs Query

Filter •Emme pries? Ja of neen •Go ’t nie relevant
moet zien •Rapper & cachebaar •Voe non-analyzed data Query •Oevele pries emme? •Voe full-text search •Ip analyzed/tokenized data

Match Query Multi Match Query Bool Query Boosting Query Common
Terms Query Constant Score Query Dis Max Query Filtered Query Fuzzy Like This Query Fuzzy Like This Field Query Function Score Query Fuzzy Query GeoShape Query Has Child Query Has Parent Query Ids Query Indices Query Match All Query More Like This Query Nested Query Prefix Query Query String Query Simple Query String Query Range Query Regexp Query Span First Query Span Multi Term Query Span Near Query Span Not Query Span Or Query Span Term Query Term Query Terms Query Top Children Query Wildcard Query Minimum Should Match Multi Term Query Rewrite Template Query

And Filter Bool Filter Exists Filter Geo Bounding Box Filter
Geo Distance Filter Geo Distance Range Filter Geo Polygon Filter GeoShape Filter Geohash Cell Filter Has Child Filter Has Parent Filter Ids Filter Indices Filter Limit Filter Match All Filter Missing Filter Nested Filter Not Filter Or Filter Prefix Filter Query Filter Range Filter Regexp Filter Script Filter Term Filter Terms Filter Type Filter

Filter voorbeeld

POST /products/product/_search?pretty { "query": {
"filtered": { "filter": { "ids": { "values": [231,234,258] } } } } } SELECT * FROM products.product WHERE entity_id IN (231,234,258)

"filtered": { "filter": { "bool": { "must": [ { "range": { "price": { "gte": 100, "lte": 400 } } } ], "must_not": [ { "term": { "name": "Convertible Dress" } } ], "should": [ { "term": { "category": "Women" } }, { "term": { "category": "New Arrivals" } } ] } } } } } SELECT * FROM products.product WHERE price BETWEEN 100 AND 400 AND name != "Convertible Dress" AND (category = "Women" OR category = "New Arrivals")

"filtered": { "filter": { "prefix": { "name": "Slim" } } } } } SELECT * FROM products.product WHERE name LIKE "Slim%"

{ "filtered" : {
"filter" : { "geo_distance_range" : { "from" : "200km", "to" : "400km", "pin.location" : { "lat" : 40, "lon" : -‐70 } } } } } vereist “geo point” type veld

Relevansje

{ "took": 1, "timed_out":
false, "_shards": { "total": 1, "successful": 1, "failed": 0 }, "hits": { "total": 2, "max_score": 3.3350093, "hits": [ { "_index": "products", "_type": "product", "_id": "243", "_score": 3.3350093, "fields": { "name": [ "Linen Blazer" ] } }, { "_index": "products", "_type": "product", "_id": "246", "_score": 0.5954286, "fields": { "name": [ "Stretch Cotton Blazer" ] } } ] } } POST /products/product/_search?pretty { "fields": ["name"], "query": { "match": { "name.raw": "Linen Blazer" } } } 2 keers pries, dus relevanter

{ "took": 1, "timed_out":
false, "_shards": { "total": 1, "successful": 1, "failed": 0 }, "hits": { "total": 1, "max_score": 1, "hits": [ { "_index": "products", "_type": "product", "_id": "243", "_score": 1, "fields": { "name": [ "Linen Blazer" ] } } ] } } POST /products/product/_search?pretty { "query": { "filtered": { "query": { "match_all": {} }, "filter": { "term": { "name": "Linen Blazer" } } } } } Gin relevansje ip filters Score is ossan 1

POST /products/product/_search?pretty { "fields": ["name","description"],
"query": { "bool": { "must": [ { "match": { "description.raw": "suit" } } ], "should": [ { "match": { "name.raw": "coat" } } ] } } } Just mo zoek’n achter “suit” Relevansje doen toenemen otte name “coat” bevat

POST /products/product/_search?pretty { "fields": ["price","name","description","category"],
"query": { "bool": { "must": [ { "filtered": { "filter": { "bool": { "must": [ { "range": { "price": { "gte": 100, "lte": 400 } } }, { "term": { "category": "Men" } } ] } } } } ], "should": [ { "match": { "category": "New Arrivals" } } ] } } } Relevansje doen toeneemn Gecombi neerde filters

"bool": { "must": [ { "match_all": {} } ], "should": [ { "match": { "description.raw": { "query": "comfort", "boost": 2 } } }, { "match": { "name.raw": { "query": "tee", "boost": 3 } } } ] } } } Query- time boosting Relevansje doen toeneemn

Ol d’ index’en Ol de types

SELECT * FROM *.tbl_a* WHERE
key LIKE ‘%val%’ •Over ol de databases •Wildcard database queries •Wildcard tabel queries SQL kan da nie

/_search /products/_search /products/product/_search /products,clients/_search /pro*/_search
/pro*,cli*/_search /products/product,invoice/_search /products/pro*/_search /_all/product/_search /_all/product,invoice/_search /_all/pro*/_search

Multi “vanolles”

Aggregations

Group by dat tuug gepakt et

SELECT COUNT(category) FROM products.product GROUP BY category
Aggregations in SQL Metric Bucket

SELECT COUNT(category) FROM products.product GROUP BY category
POST /products/product/_search? pretty&search_type=count { "aggs": { "number_of_categories" : { "cardinality": { "field": "category" } } } } Metric Bucket Juuste mo aggs, gin docs

POST /products/product/_search?pretty { "fields": ["category","price","name"],
"query": { "match": { "name.raw": "blazer" } }, "aggs": { "avg_price": { "avg": { "field": "price" } }, "min_price" : { "min": { "field": "price" } }, "max_price" : { "max": { "field": "price" } }, "number_of_products_per_category" : { "terms": { "field": "category", "size": 10 } } } } Meerdere groep’n nevest de query

"aggregations": {
"min_price": { "value": 455 }, "number_of_products_per_category": { "doc_count_error_upper_bound": 0, "sum_other_doc_count": 0, "buckets": [ { "key": "Blazers", "doc_count": 2 }, { "key": "Default Category", "doc_count": 2 }, { "key": "Men", "doc_count": 2 } ] }, "max_price": { "value": 490 }, "avg_price": { "value": 472.5 } } Aggregation output Drill down search

Min Aggregation Max Aggregation Sum Aggregation Avg Aggregation Stats Aggregation
Extended Stats Aggregation Value Count Aggregation Percentiles Aggregation Percentile Ranks Aggregation Cardinality Aggregation Geo Bounds Aggregation Top hits Aggregation Scripted Metric Aggregation Global Aggregation Filter Aggregation Filters Aggregation Missing Aggregation Nested Aggregation Reverse nested Aggregation Children Aggregation Terms Aggregation Significant Terms Aggregation Range Aggregation Date Range Aggregation IPv4 Range Aggregation Histogram Aggregation Date Histogram Aggregation Geo Distance Aggregation GeoHash grid Aggregation

Elasticsearch beheer’n

Verschillige manieren … mo w’en der geen tied voorn

Clusteringe

1 node Cluster met 2 nodes Cluster met 3 nodes

Configuraasje voorbeeld cluster.name: my-‐cluster node.name: my-‐node node.rack:
my-‐location node.master: true node.data: true http.enabled: true index.number_of_shards: 5 index.number_of_replicas: 1 discovery.zen.minimum_master_nodes: 2

CAP theorem

CAP theorem Consistence Availability Partition tolerance

GET /_cat

GET /_cat =^.^= /_cat/allocation /_cat/shards /_cat/shards/{index}
/_cat/master /_cat/nodes /_cat/indices /_cat/indices/{index} /_cat/segments /_cat/segments/{index} /_cat/count /_cat/count/{index} /_cat/recovery /_cat/recovery/{index} /_cat/health /_cat/pending_tasks /_cat/aliases /_cat/aliases/{alias} /_cat/thread_pool /_cat/plugins /_cat/fielddata /_cat/fielddata/{fields} Gin JSON mo platn tekst

GET /_cat/shards?v index shard prirep state
docs store ip node my-‐index 2 r STARTED 6 7.2kb 192.168.10.142 node3 my-‐index 2 p STARTED 6 9.5kb 192.168.10.142 node2 my-‐index 0 p STARTED 4 7.1kb 192.168.10.142 node3 my-‐index 0 r STARTED 4 4.8kb 192.168.10.142 node2 my-‐index 3 r STARTED 5 7.1kb 192.168.10.142 node1 my-‐index 3 p STARTED 5 7.2kb 192.168.10.142 node3 my-‐index 1 p STARTED 1 2.4kb 192.168.10.142 node1 my-‐index 1 r STARTED 1 2.4kb 192.168.10.142 node2 my-‐index 4 p STARTED 5 9.5kb 192.168.10.142 node1 my-‐index 4 r STARTED 5 9.4kb 192.168.10.142 node3 5 shards & 1 standoard 1 replica

GET /_cat/health? v&h=cluster,status,node.total,shards,pri,unassign,init cluster status node.total shards
pri unassign init mycluster green 3 12 6 0 0 De gezoentied van de cluster

De ELK hoop

Logs Ommzetn & verzetn Ipsloan Afficheren

Elasticsearch integreern

’t Is REST, trek je plan!

’t Is REST, trek je plan! Vaneestekee uut Javascript? Toegank
beveiligen AJAX #FTW Achter een proxy Gin backend code

Of gebruukt een SDK PHP Java Perl Python Ruby .NET
