Vagrant, Puppet & Chef #FTW

My Vagrant talk at #FOWA 2013 in London

Transcript

2. Hi, my name is Thijs
3. I’m @ThijsFeryn on Twitter
4. I’m an at Evangelist
5. I’m a at board member
7. Create and configure lightweight, reproducible, and portable development environments.
8. Written in Ruby By Mitchell Hashimoto in 2010
9. A layer on top of
12. WHY? WHY? WHY?
14. •Environment per project •Dev ~= Test ~= Staging ~= Prod •Easy to define & transport •Easy to tear down •Provisionable: infrastructure as code •Versionable •Shared across the team
15. $"vagrant Usage:"vagrant"[.v]"[.h]"command"[<args>] """".v,"..version""Print"the"version"and"exit. """".h,"..help"""""Print"this"help. Available"subcommands: """""box """""destroy """""halt """""init """""package """""plugin """""provision """""reload """""resume """""ssh """""ssh.config """""status """""suspend """""up
16. $"vagrant"init".h Usage:"vagrant"init"[box.name]"[box.url] Generates a Vagrantfile “vagrant init”, innit?
17. •Select base box •Choose virtualization provider •Configure VM parameters •Configure networking •Tweak SSH settings •Mount local folders •Provision machine What does a Vagrantfile do?
18. $"vagrant"init A"`Vagrantfile`"has"been"placed"in"this" directory."You"are"now ready"to"`vagrant"up`"your"first"virtual" environment!"Please"read the"comments"in"the"Vagrantfile"as"well" as"documentation"on `vagrantup.com`"for"more"information"on" using"Vagrant. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""base" end
19. $"vagrant"init"precise32"http:// files.vagrantup.com/precise32.box A"`Vagrantfile`"has"been"placed"in"this" directory."You"are"now ready"to"`vagrant"up`"your"first"virtual" environment!"Please"read the"comments"in"the"Vagrantfile"as"well"as" documentation"on `vagrantup.com`"for"more"information"on" using"Vagrant. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""precise32" ""config.vm.box_url"=""http:// files.vagrantup.com/precise32.box""" end
20. $vagrant"up Bringing"machine"'default'"up"with"'virtualbox'"provider... [default]"Box"'precise32'"was"not"found."Fetching"box"from"specified"URL"for the"provider"'virtualbox'."Note"that"if"the"URL"does"not"have a"box"for"this"provider,"you"should"interrupt"Vagrant"now"and"add the"box"yourself."Otherwise"Vagrant"will"attempt"to"download"the full"box"prior"to"discovering"this"error. Downloading"or"copying"the"box... Extracting" box...################################################################%" (Rate:"/s,"Estimated"time"remaining:")) Successfully"added"box"'precise32'"with"provider"'virtualbox'! [default]"Importing"base"box"'precise32'... [default]"Matching"MAC"address"for"NAT"networking... [default]"Setting"the"name"of"the"VM... [default]"Clearing"any"previously"set"forwarded"ports... [default]"Creating"shared"folders"metadata... [default]"Clearing"any"previously"set"network"interfaces... [default]"Preparing"network"interfaces"based"on"configuration... [default]"Forwarding"ports... [default]".."22"=>"2222"(adapter"1) [default]"Booting"VM... [default]"Waiting"for"VM"to"boot."This"can"take"a"few"minutes. [default]"VM"booted"and"ready"for"use! [default]"Configuring"and"enabling"network"interfaces... [default]"Mounting"shared"folders... [default]".."/vagrant
21. Boxes
22. http://vagrantbox.es
23. https://github.com/ jedi4ever/veewee Build your own boxes
24. $"vagrant"box Usage:"vagrant"box"<command>"[<args>] Available"subcommands: """""add """""list """""remove """""repackage
25. $"vagrant"box"list precise32"""""""(virtualbox) $"vagrant"box"remove"precise32"virtualbox Removing"box"'precise32'"with"provider"'virtualbox'... $"vagrant"box"add"precise32"http://files.vagrantup.com/ precise32.box"..provider"virtualbox Downloading"or"copying"the"box... Extracting" box...##################################################### ###########%"(Rate:"/s,"Estimated"time"remaining:")) Successfully"added"box"'precise32'"with"provider" 'virtualbox'! $"vagrant"box"repackage"precise32"virtualbox $"ls".lh .rw.r..r..""1"thijs""staff"""275M"10"okt"16:06"package.box
26. $"vagrant"box"list precise32"""""""(virtualbox) $"vagrant"box"remove"precise32"virtualbox Removing"box"'precise32'"with"provider"'virtualbox'... $"vagrant"box"add"precise32"http://files.vagrantup.com/ precise32.box"..provider"virtualbox Downloading"or"copying"the"box... Extracting" box...##################################################### ###########%"(Rate:"/s,"Estimated"time"remaining:")) Successfully"added"box"'precise32'"with"provider" 'virtualbox'! $"vagrant"box"repackage"precise32"virtualbox $"ls".lh .rw.r..r..""1"thijs""staff"""275M"10"okt"16:06"package.box #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""precise32" ""config.vm.box_url"=""http:// files.vagrantup.com/precise32.box""" end Vagrantfile can do this too
27. $"tar"xvzf"package.box x"./box.disk1.vmdk x"./box.ovf x"./metadata.json x"./Vagrantfile Content of a box file
28. Vagrant up & running
29. $"vagrant"up Bringing"machine"'default'"up"with"'virtualbox'"provider... [default]"Importing"base"box"'precise32'... [default]"Matching"MAC"address"for"NAT"networking... [default]"Setting"the"name"of"the"VM... [default]"Clearing"any"previously"set"forwarded"ports... [default]"Creating"shared"folders"metadata... [default]"Clearing"any"previously"set"network"interfaces... [default]"Preparing"network"interfaces"based"on"configuration... [default]"Forwarding"ports... [default]".."22"=>"2222"(adapter"1) [default]"Booting"VM... [default]"Waiting"for"VM"to"boot."This"can"take"a"few"minutes. [default]"VM"booted"and"ready"for"use! [default]"Configuring"and"enabling"network"interfaces... [default]"Mounting"shared"folders... [default]".."/vagrant When VM doesn’t exist
30. $"vagrant"up Bringing"machine"'default'"up"with"'virtualbox'"provider... [default]"VirtualBox"VM"is"already"running. $"vagrant"status Current"machine"states: default""""""""""""""""""running"(virtualbox) When VM exists & is running
31. $"vagrant"suspend [default]"Saving"VM"state"and"suspending"execution... $"vagrant"status Current"machine"states: default""""""""""""""""""saved"(virtualbox) $"vagrant"up Bringing"machine"'default'"up"with"'virtualbox'"provider... [default]"Resuming"suspended"VM... [default]"Booting"VM... [default]"Waiting"for"VM"to"boot."This"can"take"a"few" minutes. [default]"VM"booted"and"ready"for"use! Suspend & resume
32. $"vagrant"halt [default]"Attempting"graceful"shutdown"of"VM... $"vagrant"status Current"machine"states: default""""""""""""""""""poweroff"(virtualbox) $"vagrant"up Bringing"machine"'default'"up"with"'virtualbox'"provider... [default]"Setting"the"name"of"the"VM... [default]"Clearing"any"previously"set"forwarded"ports... [default]"Creating"shared"folders"metadata... [default]"Clearing"any"previously"set"network"interfaces... [default]"Preparing"network"interfaces"based"on"configuration... [default]"Forwarding"ports... [default]".."22"=>"2222"(adapter"1) [default]"Booting"VM... [default]"Waiting"for"VM"to"boot."This"can"take"a"few"minutes. [default]"VM"booted"and"ready"for"use! [default]"Configuring"and"enabling"network"interfaces... [default]"Mounting"shared"folders... [default]".."/vagrant Stop & start
33. $"vagrant"destroy Are"you"sure"you"want"to"destroy"the"'default'"VM?"[y/N]"y [default]"Forcing"shutdown"of"VM... [default]"Destroying"VM"and"associated"drives... $"vagrant"status Current"machine"states: default""""""""""""""""""not"created"(virtualbox) Destroy
34. Connect
35. $"vagrant"ssh Linux"debian.7"3.2.0.4.amd64"#1"SMP"Debian"3.2.46.1"x86_64 The"programs"included"with"the"Debian"GNU/Linux"system"are" free"software; the"exact"distribution"terms"for"each"program"are"described" in"the individual"files"in"/usr/share/doc/*/copyright. Debian"GNU/Linux"comes"with"ABSOLUTELY"NO"WARRANTY,"to"the" extent permitted"by"applicable"law. Last"login:"Mon"Jul"15"13:13:36"2013"from"10.0.2.2 vagrant@debian.7:~$"sudo"su root@debian.7:/home/vagrant No login or password required
36. root@debian.7:/home/vagrant#"cat".ssh/authorized_keys ssh.rsa" AAAAB3NzaC1yc2EAAAABIwAAAQEA6NF8iallvQVp22WDkTkyrtvp9eWW6A8 YVr+kz4TjGYe7gHzIw +niNltGEFHzD8+v1I2YJ6oXevct1YeS0o9HZyN1Q9qgCgzUFtdOKLv6Iedp lqoPkcmF0aYet2PkEDo3MlTBckFXPITAMzF8dJSIFo9D8HfdOV0IAdx4O7P tixWKn5y2hMNG0zQPyUecp4pzC6kivAIhyfHilFR61RGL +GPXQ2MWZWFYbAGjyiYJnAmCP3NOTd0jMZEnDkbUvxhMmBYSdETk1rRgm +R4LOzFUGaHqHDLKLX +FIPKcF96hrucXzcWyLbIbEgE98OHlnVYCzRdK8jlqm8tehUc9c9WhQ==" vagrant"insecure"public"key Public key
37. $"vagrant"ssh.config Host"default ""HostName"127.0.0.1 ""User"vagrant ""Port"2222 ""UserKnownHostsFile"/dev/null ""StrictHostKeyChecking"no ""PasswordAuthentication"no ""IdentityFile""/Users/thijs/.vagrant.d/insecure_private_key" ""IdentitiesOnly"yes ""LogLevel"FATAL Username, host, port & private key location
38. $"cat"~/.vagrant.d/insecure_private_key .....BEGIN"RSA"PRIVATE"KEY..... MIIEogIBAAKCAQEA6NF8iallvQVp22WDkTkyrtvp9eWW6A8YVr+kz4TjGYe7gHzI w+niNltGEFHzD8+v1I2YJ6oXevct1YeS0o9HZyN1Q9qgCgzUFtdOKLv6IedplqoP kcmF0aYet2PkEDo3MlTBckFXPITAMzF8dJSIFo9D8HfdOV0IAdx4O7PtixWKn5y2 hMNG0zQPyUecp4pzC6kivAIhyfHilFR61RGL+GPXQ2MWZWFYbAGjyiYJnAmCP3NO Td0jMZEnDkbUvxhMmBYSdETk1rRgm+R4LOzFUGaHqHDLKLX+FIPKcF96hrucXzcW yLbIbEgE98OHlnVYCzRdK8jlqm8tehUc9c9WhQIBIwKCAQEA4iqWPJXtzZA68mKd ELs4jJsdyky+ewdZeNds5tjcnHU5zUYE25K+ffJED9qUWICcLZDc81TGWjHyAqD1 Bw7XpgUwFgeUJwUlzQurAv+/ySnxiwuaGJfhFM1CaQHzfXphgVml+fZUvnJUTvzf TK2Lg6EdbUE9TarUlBf/xPfuEhMSlIE5keb/Zz3/LUlRg8yDqz5w+QWVJ4utnKnK iqwZN0mwpwU7YSyJhlT4YV1F3n4YjLswM5wJs2oqm0jssQu/BT0tyEXNDYBLEF4A sClaWuSJ2kjq7KhrrYXzagqhnSei9ODYFShJu8UWVec3Ihb5ZXlzO6vdNQ1J9Xsf 4m+2ywKBgQD6qFxx/Rv9CNN96l/4rb14HKirC2o/orApiHmHDsURs5rUKDx0f9iP cXN7S1uePXuJRK/5hsubaOCx3Owd2u9gD6Oq0CsMkE4CUSiJcYrMANtx54cGH7Rk EjFZxK8xAv1ldELEyxrFqkbE4BKd8QOt414qjvTGyAK+OLD3M2QdCQKBgQDtx8pN CAxR7yhHbIWT1AH66+XWN8bXq7l3RO/ukeaci98JfkbkxURZhtxV/HHuvUhnPLdX 3TwygPBYZFNo4pzVEhzWoTtnEtrFueKxyc3+LjZpuo+mBlQ6ORtfgkr9gBVphXZG YEzkCD3lVdl8L4cw9BVpKrJCs1c5taGjDgdInQKBgHm/fVvv96bJxc9x1tffXAcj 3OVdUN0UgXNCSaf/3A/phbeBQe9xS+3mpc4r6qvx+iy69mNBeNZ0xOitIjpjBo2+ dBEjSBwLk5q5tJqHmy/jKMJL4n9ROlx93XS+njxgibTvU6Fp9w+NOFD/HvxB3Tcz 6+jJF85D5BNAG3DBMKBjAoGBAOAxZvgsKN+JuENXsST7F89Tck2iTcQIT8g5rwWC P9Vt74yboe2kDT531w8+egz7nAmRBKNM751U/95P9t88EDacDI/Z2OwnuFQHCPDF llYOUI+SpLJ6/vURRbHSnnn8a/XG+nzedGH5JGqEJNQsz+xT2axM0/W/CRknmGaJ kda/AoGANWrLCz708y7VYgAtW2Uf1DPOIYMdvo6fxIB5i9ZfISgcJ/bbCUkFrhoH +vq/5CIWxCPp0f85R4qxxQ5ihxJ0YDQT9Jpx4TMss4PSavPaBH3RXow5Ohe+bYoQ NE5OgEXk2wVfZczCZpigBKbKZHNYcelXtTt/nP3rsCuGcM4h53s= .....END"RSA"PRIVATE"KEY..... Private key
39. The portability of a Vagrantfile
40. Add Vagrantfile to VCS
41. Share Vagrantfile Share dev env
42. Infrastructure as code
43. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""precise32" ""config.vm.box_url"=""http:// files.vagrantup.com/precise32.box""" end You probably remember this one
44. Networking
45. config.vm.network":forwarded_port,"guest:"80,"host:"8080 config.vm.network":public_network config.vm.network":private_network,"ip:""192.168.10.10" Networking Bridged network Port forwarding Private IP space
46. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""precise32" ""config.vm.box_url"=""http://files.vagrantup.com/ precise32.box""" ""config.vm.network":private_network,"ip:""192.168.10.10" end $"vagrant"up ... [default]"Preparing"network"interfaces"based"on" configuration... [default]"Forwarding"ports... [default]".."22"=>"2222"(adapter"1) Yes, there is port forwarding involved
47. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""precise32" ""config.vm.box_url"=""http://files.vagrantup.com/ precise32.box""" ""config.vm.network":forwarded_port,"guest:"80,"host:"8080 end $"vagrant"up ... [default]"Preparing"network"interfaces"based"on" configuration... [default]"Forwarding"ports... [default]".."22"=>"2222"(adapter"1) [default]".."80"=>"8080"(adapter"1) There’s port 80
48. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.box"=""precise32" ""config.vm.box_url"=""http://files.vagrantup.com/ precise32.box""" ""config.vm.network":public_network end
49. $"vagrant"up ... Bringing"machine"'default'"up"with"'virtualbox'" provider... [default]"Clearing"any"previously"set"forwarded"ports... [default]"Creating"shared"folders"metadata... [default]"Clearing"any"previously"set"network" interfaces... [default]"Available"bridged"network"interfaces: 1)"en1:"Wi.Fi"(AirPort) 2)"en0:"Ethernet 3)"p2p0 What"interface"should"the"network"bridge"to?"1 [default]"Preparing"network"interfaces"based"on" configuration... [default]"Forwarding"ports... [default]".."22"=>"2222"(adapter"1) Choose interface
50. config.vm.network""public_network",":bridge"=>"'en1:"Wi. Fi"(AirPort)' Assign interface in Vagrantfile
51. Synced folders
52. Local filesystem available in VM
53. Save directly from your editor/IDE
54. $"vagrant"up ... [default]"Mounting"shared"folders... [default]".."/vagrant config.vm.synced_folder""web/",""/var/www" $"vagrant"up ... [default]"Mounting"shared"folders... [default]".."/vagrant [default]".."/var/www Extra mount Default mount
55. VM properties
56. config.vm.hostname"=""mymachine" config.vm.provider":virtualbox"do"|v| ""v.customize"["modifyvm",":id,"'..chipset',"'ich9'] ""v.customize"["modifyvm",":id,""..natdnshostresolver1",""on"] ""v.customize"["modifyvm",":id,""..ioapic",""on"] ""v.customize"["modifyvm",":id,""..memory","2048] ""v.customize"["modifyvm",":id,""..cpus",""4"] ""#v.gui"="true end VM properties
57. Provisioning
58. •Add specific software •Create configuration files •Execute commands •Create users •Manage services •Automatically executed on vagrant up Provisioning
59. Having an exact copy of your production environment
60. •Shell •Ansible •Chef Solo •Chef Client •Puppet Apply •Puppet Agent Provisioning
61. Shell
62. Shell config.vm.provision":shell,":inline"=>""mount" .t"tmpfs".o"size=50m,mode=0777"tmpfs"/vagrant/ app/cache" Mount RAM disk volume
63. Shell $script"="<<SCRIPT echo"I"am"provisioning... date">"/etc/vagrant_provisioned_at SCRIPT Vagrant.configure("2")"do"|config| ""config.vm.provision""shell","inline:"$script end Inject Ruby
64. Shell Vagrant.configure("2")"do"|config| ""config.vm.provision""shell","path:""script.sh" end Point to script in your current folder Vagrant.configure("2")"do"|config| ""config.vm.provision""shell","path:""https:// example.com/provisioner.sh" end Point to external script
66. Written in Ruby By Opscode in 2009
67. Written in Ruby By Puppet Labs in 2005
68. •Written in Ruby •Open source with enterprise revenue model •Similar features •Both have a standalone and server-side edition •Supported by a large community •Modularized components •Use packages for software installs •Use templating for custom files •Filesystem methods •... Chef & Puppet
69. Chef vs Puppet Chef Puppet Modules Actions Language Running order Approach Programming style Cookbooks Modules Recipes Manifests Ruby extended with DSL DSL Sequential “Random” Define actions Define state Procedural “OO-like”
70. Let’s do some Chef!
71. •Download cookbooks (https://github.com/opscode-cookbooks) •Configure chef.cookbooks_path in Vagrantfile •Add recipes using chef.add_recipe in Vagrantfile •Configure attributes with chef.json •Group custom actions in custom cookbook How to use Chef Solo
72. config.vm.provision":chef_solo"do"|chef| """chef.cookbooks_path"="./tools/chef/cookbooks" """chef.add_recipe""mysql::server" """chef.json"="{" """""mysql""=>"{ """""""""server_root_password""=>""foo", """""""""server_repl_password""=>""foo", """""""""server_debian_password""=>""foo" """""}"""""""""""""" """} end Vagrantfile
73. Cookbook layout cookbook ├──"README.md ├──"attributes ├──"definitions ├──"files │"""└──"default ├──"libraries ├──"metadata.rb ├──"providers ├──"recipes │"""└──"default.rb ├──"resources └──"templates """"└──"default
74. MySQL attributes default['mysql']['port']"""""""""""""""""""""""="3306 default['mysql']['nice']"""""""""""""""""""""""="0 case"node['platform_family'] when"'debian' ""default['mysql']['server']['packages']""""="%w[mysql.server] ""default['mysql']['service_name']""""""""""="'mysql' ""default['mysql']['basedir']"""""""""""""""="'/usr' ""default['mysql']['data_dir']""""""""""""""="'/var/lib/mysql' ""default['mysql']['root_group']""""""""""""="'root' ""default['mysql']['mysqladmin_bin']""""""""="'/usr/bin/mysqladmin' ""default['mysql']['mysql_bin']"""""""""""""="'/usr/bin/mysql' ""default['mysql']['conf_dir']""""""""""""""="'/etc/mysql' ""default['mysql']['confd_dir']"""""""""""""="'/etc/mysql/conf.d' ""default['mysql']['socket']""""""""""""""""="'/var/run/mysqld/ mysqld.sock' ""default['mysql']['pid_file']""""""""""""""="'/var/run/mysqld/ mysqld.pid' ""default['mysql']['old_passwords']"""""""""="0 ""default['mysql']['grants_path']"""""""""""="'/etc/mysql/grants.sql' ...
75. MySQL server recipe ... group"'mysql'"do ""action":create end user"'mysql'"do ""comment"'MySQL"Server' ""gid"""""'mysql' ""system""true ""home""""node['mysql']['data_dir'] ""shell"""'/sbin/nologin' end node['mysql']['server']['packages'].each"do"|name| ""package"name"do """"action""":install """"notifies":start,"'service[mysql]',":immediately ""end end ...
76. MySQL template [client] host"""""="localhost user"""""="debian.sys.maint password"="<%="node['mysql']['server_debian_password']"%> socket"""="<%="node['mysql']['socket']"%> [mysql_upgrade] host"""""="localhost user"""""="debian.sys.maint password"="<%="node['mysql']['server_debian_password']"%> socket"""="<%="node['mysql']['socket']"%> basedir""="/usr
77. •Cron •Directory •Execute •File •Git •Group •Link •Log •Package •Service •Template •User •... Typical Chef resources
78. Let’s do it ourselves execute"'update"apt'"do """"command""apt.get"update" """"action":run end package"'mysql.server'"do """"action""":install """"notifies":start,"'service[mysql]',":immediately end package"'apache2'"do """"action""":install """"notifies":start,"'service[apache2]',":delayed end package"'php5'"do """"action""":install """"notifies":reload,"'service[apache2]',":delayed end ./tools/chef/cookbooks/project/recipes/default.rb
79. Let’s do it ourselves execute"'assign.root.password'"do """"command""/usr/bin/mysqladmin".u"root"password"'#{node['project'] ['server_root_password']}'" """"action":run """"only_if""/usr/bin/mysql".u"root".e"'show"databases;'" end service"'mysql'"do """"service_name"'mysql' """"supports":status"=>"true,":restart"=>"true,":reload"=>"true """"action""":enable end service"'apache2'"do """"service_name"'apache2' """"supports":status"=>"true,":restart"=>"true,":reload"=>"true """"action""":enable end ./tools/chef/cookbooks/project/recipes/default.rb
80. Let’s do it ourselves #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| config.vm.box"=""precise32" config.vm.box_url"=""http://files.vagrantup.com/ precise32.box" config.vm.synced_folder""web/",""/var/www" config.vm.provision":chef_solo"do"|chef chef.cookbooks_path"="./tools/chef/cookbooks" chef.add_recipe""project" chef.json"="{" "project""=>"{ "server_root_password""=>""foo" }"""""""""""""" } end" end
81. $"vagrant"up ... [default]"Mounting"shared"folders... [default]".."/vagrant [default]".."/tmp/vagrant.chef.1/chef.solo.1/cookbooks [default]"Running"provisioner:"chef_solo... Generating"chef"JSON"and"uploading... Running"chef.solo... ... Provisioning
82. [2013.10.21T10:37:22+00:00]"INFO:"***"Chef"11.4.4"*** [2013.10.21T10:37:22+00:00]"INFO:"Setting"the"run_list"to" ["recipe[project]"]"from"JSON [2013.10.21T10:37:22+00:00]"INFO:"Run"List"is"[recipe[project]] [2013.10.21T10:37:22+00:00]"INFO:"Run"List"expands"to"[project] [2013.10.21T10:37:22+00:00]"INFO:"Starting"Chef"Run"for"debian.7.1.0 [2013.10.21T10:37:22+00:00]"INFO:"Running"start"handlers [2013.10.21T10:37:22+00:00]"INFO:"Start"handlers"complete. [2013.10.21T10:37:24+00:00]"INFO:"Processing"package[mysql.server]"action" install"(project::default"line"1) [2013.10.21T10:37:59+00:00]"INFO:"package[mysql.server]"sending"start" action"to"service[mysql]"(immediate) [2013.10.21T10:37:59+00:00]"INFO:"Processing"service[mysql]"action"start" (project::default"line"10) [2013.10.21T10:37:59+00:00]"INFO:"Processing"execute[assign.root.password]" action"run"(project::default"line"5) [2013.10.21T10:37:59+00:00]"INFO:"execute[assign.root.password]"ran" successfully [2013.10.21T10:37:59+00:00]"INFO:"Processing"service[mysql]"action"enable" (project::default"line"10) [2013.10.21T10:37:59+00:00]"INFO:"Chef"Run"complete"in"37.208173462"seconds [2013.10.21T10:37:59+00:00]"INFO:"Running"report"handlers [2013.10.21T10:37:59+00:00]"INFO:"Report"handlers"complete
83. Let’s do some Puppet!
84. •Download modules (https://github.com/puppetlabs/) •Configure puppet.module_path, puppet.manifests_path & puppet.manifest_file in Vagrantfile •Provisioning flow happens in the main manifest •Configure attributes with puppet.facter How to use Puppet Apply
85. config.vm.provision":puppet"do"|puppet| """puppet.manifests_path"=""./tools/puppet/manifests" """puppet.module_path"=""./tools/puppet/modules" """puppet.manifest_file""=""init.pp" """puppet.options"="['..verbose'] end Vagrantfile include"mysql::server init.pp class"{"'::mysql::server': ""root_password"=>"'foo' } Override password Default
86. Module layout module ├──"README.md ├──"files ├──"lib ├──"metadata.json ├──"spec ├──"manifests │"""└──"init.pp │"""└──"params.pp ├──"resources └──"templates └──"tests
87. MySQL params class"mysql::params"{ ""$manage_config_file"""""="true ""$old_root_password""""""="'' ""$purge_conf_dir"""""""""="false ""$restart""""""""""""""""="false ""$root_password""""""""""="'UNSET' ""$server_package_ensure""="'present' ""$server_service_manage""="true ""$server_service_enabled"="true ""#"mysql::bindings ""$bindings_enable"""""""""="false ""$java_package_ensure"""""="'present' ""$java_package_provider"""="undef ""$perl_package_ensure"""""="'present' ""$perl_package_provider"""="undef ""$php_package_ensure""""""="'present' ""$php_package_provider""""="undef ""$python_package_ensure"""="'present' ""$python_package_provider"="undef ""$ruby_package_ensure"""""="'present' ""$ruby_package_provider"""="undef
88. MySQL params 2 ... case"$::osfamily"{ """"'RedHat':"{ """"""if"$::operatingsystem"=="'Fedora'"and" (is_integer($::operatingsystemrelease)"and"$::operatingsystemrelease">=" 19"or"$::operatingsystemrelease"==""Rawhide")"{ """"""""$client_package_name"="'mariadb' """"""""$server_package_name"="'mariadb.server' """"""}"else"{ """"""""$client_package_name"="'mysql' """"""""$server_package_name"="'mysql.server' """"""} """"""$basedir"""""""""""""="'/usr' """"""$config_file"""""""""="'/etc/my.cnf' """"""$datadir"""""""""""""="'/var/lib/mysql' """"""$log_error"""""""""""="'/var/log/mysqld.log' """"""$pidfile"""""""""""""="'/var/run/mysqld/mysqld.pid' """"""$root_group""""""""""="'root' """"""$server_service_name"="'mysqld' """"""$socket""""""""""""""="'/var/lib/mysql/mysql.sock' """"""$ssl_ca""""""""""""""="'/etc/mysql/cacert.pem' """"""$ssl_cert""""""""""""="'/etc/mysql/server.cert.pem' """"""$ssl_key"""""""""""""="'/etc/mysql/server.key.pem'
89. MySQL server manifest class"mysql::server"( ""$config_file"""""""""""""="$mysql::params::config_file, ""$manage_config_file""""""="$mysql::params::manage_config_file, ""$old_root_password"""""""="$mysql::params::old_root_password, ""$override_options""""""""="{}, ""$package_ensure""""""""""="$mysql::params::server_package_ensure, ""$package_name""""""""""""="$mysql::params::server_package_name, ""$purge_conf_dir""""""""""="$mysql::params::purge_conf_dir, ""$remove_default_accounts"="false, ""$restart"""""""""""""""""="$mysql::params::restart, ""$root_group""""""""""""""="$mysql::params::root_group, ""$root_password"""""""""""="$mysql::params::root_password, ""$service_enabled"""""""""=" $mysql::params::server_service_enabled, ""$service_manage""""""""""="$mysql::params::server_service_manage, ""$service_name""""""""""""="$mysql::params::server_service_name, ""$service_provider""""""""=" $mysql::params::server_service_provider, ""#"Deprecated"parameters ""$enabled"""""""""""""""""="undef, ""$manage_service""""""""""="undef )"inherits"mysql::params"{ ...
90. MySQL template [client] user=root host=localhost <%"unless"scope.lookupvar('mysql::server::root_password')" =="'UNSET'".%> password='<%=" scope.lookupvar('mysql::server::root_password')"%>' <%"end".%> socket=<%="@options['client']['socket']".%> ERB style too!
91. •Computer •Cron •Exec •File •Filebucket •Group •Host •Interface •Package •Service •Sshkey •User Typical Puppet resources
92. Let’s do it ourselves exec"{""apt.update": """"command"=>""/usr/bin/apt.get"update", } package"{"'mysql.server': """"ensure""=>"present, """"require"=>"Exec['apt.update'], """"notify"=>"Service['mysql'], } package"{"'apache2': """"ensure""=>"present, """"require"=>"Exec['apt.update'], """"notify"=>"Package['php5'], } package"{"'php5': """"ensure""=>"present, """"require"=>"Exec['apt.update'], """"notify"=>"Service['apache2'], } ./tools/puppet/manifests/init.pp
93. Let’s do it ourselves exec"{"'assign.root.password': """"command"=>""/usr/bin/mysqladmin".u"root"password"$root_password", """"require"=>"Package["mysql.server"], """"onlyif""=>""/usr/bin/mysql".u"root".e"'show"databases;'" } """" service"{""mysql": """"name"""""""=>""mysql", """"ensure"""""=>"running, """"enable"""""=>"true, """"hasrestart"=>"true, """"require""""=>"Package["mysql.server"], }"""" service"{""apache2": """"name"""""""=>""apache2", """"ensure"""""=>"running, """"enable"""""=>"true, """"hasrestart"=>"true, """"require""""=>"Package["apache2"], } ./tools/puppet/manifests/init.pp
94. Let’s do it ourselves #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| config.vm.box"=""precise32" config.vm.box_url"=""http://files.vagrantup.com/ precise32.box" config.vm.synced_folder""web/",""/var/www" config.vm.provision":puppet"do"|puppet| """puppet.manifests_path"=""puppet/manifests" """puppet.module_path"=""puppet/modules" """puppet.manifest_file""=""init.pp" """puppet.facter"="{ """"root_password""=>""foo", """} """puppet.options"="['..verbose'] end" end
95. $"vagrant"up ... [default]"Mounting"shared"folders... [default]".."/vagrant [default]".."/tmp/vagrant.puppet/manifests [default]".."/tmp/vagrant.puppet/modules.0 [default]"Running"provisioner:"puppet... Running"Puppet"with"init.pp... Notice:"/Stage[main]//Exec[apt.update]/returns:"executed" successfully Notice:"/Stage[main]//Package[mysql.server]/ensure:"ensure" changed"'purged'"to"'present' Service[mysql] Notice:"/Stage[main]//Service[mysql]:"Triggered"'refresh'"from" 1"events Notice:"/Stage[main]//Exec[assign.root.password]/returns:" executed"successfully Notice:"/Stage[main]//Package[apache2]/ensure:"ensure"changed" 'purged'"to"'present' Notice:"/Stage[main]//Package[php5]/ensure:"ensure"changed" 'purged'"to"'present' Notice:"/Stage[main]//Service[apache2]:"Triggered"'refresh'" from"1"events Notice:"Finished"catalog"run"in"222.55"seconds Provisioning
96. Re-provision VM $"vagrant"provision When machine is running
97. Chef or Puppet?
98. Problems with provisioning
99. •Provisioning is often slow (especially when installing lots of packages) •Quality of public cookbooks/manifests •Support on cookbooks/manifests •Writing it yourself can be difficult •Some cookbooks/manifests only work on certain Linux distros Problems with provisioning
100. Re-distribute current VM $"vagrant"package •Possible solution for slow provisioning •Is not the same as vagrant box repackage •Use exported box as new base box •No provisioning required on startup •Possibility of doing “light” provisioning instead
101. Multi-machine setup
102. #".*."mode:"ruby".*. #"vi:"set"ft=ruby": Vagrant.configure("2")"do"|config| ""config.vm.provision""shell","inline:""/usr/bin/apt.get"update""""" ""config.vm.box"=""debian.7.1.0" "" ""config.vm.define""web","primary:"true"do"|web| """"""web.vm.hostname"=""web" """"""web.vm.network":private_network,"ip:""192.168.33.10" """"""web.vm.synced_folder""web/",""/var/www""""""" """"""web.vm.provision":puppet"do"|puppet| """"""""""puppet.manifests_path"=""./tools/puppet/manifests" """"""""""puppet.module_path"=""./tools/puppet/modules" """"""""""puppet.manifest_file""=""web.pp" """"""""""puppet.options"="['..verbose']"""" """"""end"""""" ""end ""config.vm.define""db""do"|db|" """"""db.vm.hostname"=""db" """"""db.vm.network":private_network,"ip:""192.168.33.11" """"""db.vm.provision":puppet"do"|puppet| """"""""""puppet.manifests_path"=""./tools/puppet/manifests" """"""""""puppet.module_path"=""./tools/puppet/modules" """"""""""puppet.manifest_file""=""db.pp" """"""""""puppet.options"="['..verbose'] """"""""""puppet.facter"="{ """""""""""""""root_password""=>""foo", """"""""""}"""""" """"""end"""""" ""end"" end
103. $"vagrant"up Bringing"machine"'web'"up"with"'virtualbox'"provider... Bringing"machine"'db'"up"with"'virtualbox'"provider... [web]"Importing"base"box"'debian.7.1.0'... [web]"Matching"MAC"address"for"NAT"networking... [web]"Setting"the"name"of"the"VM... [web]"Clearing"any"previously"set"forwarded"ports... [web]"Creating"shared"folders"metadata... [web]"Clearing"any"previously"set"network"interfaces... [web]"Preparing"network"interfaces"based"on"configuration... [web]"Forwarding"ports... [web]".."22"=>"2222"(adapter"1) [web]"Booting"VM... [web]"Waiting"for"VM"to"boot."This"can"take"a"few"minutes. [web]"VM"booted"and"ready"for"use! [web]"Configuring"and"enabling"network"interfaces... [web]"Mounting"shared"folders... [web]".."/vagrant [web]".."/var/www [web]".."/tmp/vagrant.puppet/manifests [web]".."/tmp/vagrant.puppet/modules.0 [web]"Running"provisioner:"shell... [web]"Running:"inline"script [web]"Running"provisioner:"puppet... Running"Puppet"with"web.pp...
104. [db]"Importing"base"box"'debian.7.1.0'... [db]"Matching"MAC"address"for"NAT"networking... [db]"Setting"the"name"of"the"VM... [db]"Clearing"any"previously"set"forwarded"ports... [db]"Fixed"port"collision"for"22"=>"2222."Now"on"port"2200. [db]"Creating"shared"folders"metadata... [db]"Clearing"any"previously"set"network"interfaces... [db]"Preparing"network"interfaces"based"on"configuration... [db]"Forwarding"ports... [db]".."22"=>"2200"(adapter"1) [db]"Booting"VM... [db]"Waiting"for"VM"to"boot."This"can"take"a"few"minutes. [db]"VM"booted"and"ready"for"use! [db]"Configuring"and"enabling"network"interfaces... [db]"Mounting"shared"folders... [db]".."/vagrant [db]".."/tmp/vagrant.puppet/manifests [db]".."/tmp/vagrant.puppet/modules.0 [db]"Running"provisioner:"shell... [db]"Running:"inline"script [db]"Running"provisioner:"puppet... Running"Puppet"with"db.pp...
105. Control the machines
106. vagrant"up vagrant"ssh vagrant"destroy vagrant"up"web vagrant"ssh"web vagrant"destroy"web vagrant"up"db vagrant"ssh"db vagrant"destroy"db All VM’s Primary VM All VM’s
107. And$ on$that$ bombshell$...
108. vagrant'up #FTW
