Video streaming acceleration with Varnish

In this presentation, I'm explaining how video streaming via HTTP works. We'll focus on the HLS standard.

The goal of the presentation is to explain the challenges when delivering video via the web and how Varnish can accelerate that delivery.

See https://feryn.eu/speaking/video-streaming-acceleration-varnish/ for more details

Transcript

1. View Slide

2. VIDEO IS BIG !


   View Slide

3. ONLINE VIDEO IS DOMINATING


   View Slide

4. OVERTTHETOP


   View Slide

5. View Slide

6. PACKAGING


   View Slide

7. HTTP VIDEO PACKAGING FORMATS
   ✓ HLS
   ✓ MPEG-DASH
   ✓ CMAF


   View Slide

8. HTTP LIVE STREAMING (HLS)


   View Slide

9. VIDEO.MP4
   STREAM.M3U8
   STREAM_01.TS
   STREAM_02.TS
   STREAM_03.TS ENCODING & PACKAGING
   VIDEO: H264
   AUDIO: AAC


   View Slide

10. #EXTM3U
    #EXT-X-VERSION:3
    #EXT-X-TARGETDURATION:6
    #EXT-X-MEDIA-SEQUENCE:0
    #EXT-X-PLAYLIST-TYPE:VOD
    #EXTINF:6.000000,
    stream_00.ts
    #EXTINF:6.000000,
    stream_01.ts
    #EXTINF:6.000000,
    stream_02.ts
    #EXTINF:6.000000,
    stream_03.ts
    #EXTINF:6.000000,
    stream_04.ts
    #EXTINF:6.000000,
    stream_05.ts
    #EXTINF:6.000000,
    stream_06.ts
    #EXTINF:6.000000,
    stream_07.ts
    #EXTINF:6.000000,
    stream_08.ts
    #EXTINF:6.000000,
    stream_09.ts
    #EXTINF:5.280000,
    stream_010.ts
    #EXT-X-ENDLIST
    STREAM.M3U8


    View Slide

11. PLAYER NEEDS TO SUPPORT HLS


    View Slide

12.




    setup='{}'>







    View Slide

13. WHAT TOOL DO WE USE
    TO ENCODE & PACKAGE?


    View Slide

14. View Slide

15. ffmpeg -i video.mp4 \
    -c:v libx264 -crf 21 \
    -preset veryfast -g 25 -sc_threshold 0 \
    -c:a aac -b:a 128k -ac 2 \
    -f hls -hls_time 4 -hls_playlist_type vod stream.m3u8


    View Slide

16. View Slide

17. HI, I'M THIJS


    View Slide

18. I'M AN
    EVANGELIST
    AT


    View Slide

19. View Slide

20. View Slide

21. +-5,000,000 WEBSITES
    20% OF THE TOP 10K WEBSITES


    View Slide

22. View Slide

23. I'M @THIJSFERYN


    View Slide

24. View Slide

25. CONTENT DELIVERY CHALLENGES


    View Slide

26. HEAVY COMPUTING


    View Slide

27. NETWORK
    CAPACITY


    View Slide

28. SERVER
    CAPACITY


    View Slide

29. THROWING
    SERVERS
    AT THE PROBLEM


    View Slide

30. MO' MONEY
    MO' SERVERS
    MO' PROBLEMS


    View Slide

31. CACHE


    View Slide

32. DON’T RECOMPUTE
    IF THE DATA
    HASN’T CHANGED


    View Slide

33. REVERSE CACHING PROXY


    View Slide

34. NORMALLY
    USER SERVER


    View Slide

35. WITH REVERSE CACHING PROXY
    USER PROXY SERVER


    View Slide

36. View Slide

37. WHY NOT
    USE A CDN?


    View Slide

38. VARNISH IS CDN SOFTWARE!


    View Slide

39. CDNS WITH MANY
    POINTS OF PRESENCE
    WILL DDOS YOUR ORIGIN


    View Slide

40. VARNISH VARNISH VARNISH
    ORIGIN


    View Slide

41. CDN CDN CDN
    ORIGIN
    VARNISH


    View Slide

42. WHY IS VARNISH
    SO POWERFUL?


    View Slide

43. WHY IS VARNISH SO POWERFUL?
    ✓ EXTREMELY LOW RESOURCE
    ✓ EXTREMELY STABLE
    ✓ 100 GBIT PER SERVER
    ✓ NO DISK ACCESS AT RUNTIME
    ✓ REQUEST COALESCING
    ✓ VARNISH CONFIGURATION LANGUAGE
    ✓ VMODS
    ✓ COMPLIES TO HTTP BEST PRACTICES
    ✓ ENTERPRISE FEATURES*


    View Slide

44. ORIGIN
    VARNISH
    REQUEST
    COALESCING


    View Slide

45. LIVE STREAMING
    VS
    VIDEO ON DEMAND


    View Slide

46. LIVE
    ✓ LOW LATENCY
    ✓ CONSTANT PLAYLIST UPDATES
    ✓ LOW TTL ON PLAYLISTS
    ✓ ONLY THE LAST X SEGMENTS ARE
    REQUIRED
    ✓ SEGMENT SIZE TRADEOFF


    View Slide

47. VOD
    ✓ NO PLAYLIST UPDATES
    ✓ HIGH TTL ON PLAYLISTS
    ✓ ALL SEGMENTS ARE REQUIRED
    ✓ STORAGE REQUIREMENTS
    ✓ PRE-FETCHING POSSIBLE


    View Slide

48. HEAD VS LONG TAIL
    HEAD
    LONG TAIL


    View Slide

49. STORAGE


    View Slide

50. WHERE VARNISH STORES ITS OBJECTS
    ✓ MEMORY
    ✓ DISK
    ✓ MASSIVE STORAGE ENGINE (ENTERPRISE ONLY)


    View Slide

51. MEMORY MEMORY
    ORIGIN
    ORIGIN
    MEMORY MEMORY MEMORY MEMORY MEMORY


    View Slide

52. MEMORY MEMORY
    ORIGIN
    ORIGIN
    DISK DISK DISK


    View Slide

53. ADAPTIVE BITRATE STREAMS


    View Slide

54. STREAM_0.M3U8
    STREAM_01.TS
    STREAM_02.TS
    STREAM_03.TS
    STREAM_1.M3U8
    STREAM_11.TS
    STREAM_12.TS
    STREAM_13.TS
    MASTER.M3U8
    LOW BITRATE HIGH BITRATE
    ADAPTIVE BITRATE STREAMS


    View Slide

55. #EXTM3U
    #EXT-X-VERSION:3
    #EXT-X-STREAM-
    INF:BANDWIDTH=1020800,RESOLUTION=1080x1920,CODECS="avc1.640028,mp4a.40.2"
    stream_0.m3u8
    #EXT-X-STREAM-
    INF:BANDWIDTH=2890800,RESOLUTION=1080x1920,CODECS="avc1.640028,mp4a.40.2"
    stream_1.m3u8
    MASTER.M3U8


    View Slide

56. ffmpeg -i video.mp4 -g 25 -sc_threshold 0 \
    -map v:0 -c:v:0 libx264 -b:v:0 800k \
    -map v:0 -c:v:1 libx264-b:v:1 2500k \
    -map a:0 -c:a aac -b:a 128k -ac 2 \
    -f hls -hls_time 6 hls_playlist_type vod \
    -master_pl_name master.m3u8 \
    -var_stream_map "v:0,a:0 v:1,a:0" stream_%v.m3u8


    View Slide

57. LIVE STREAMING


    View Slide

58. ffmpeg -listen 1 -i rtmp://0.0.0.0/live/stream \
    -threads 0 -preset veryfast -g 25 -sc_threshold 0 \
    -map v:0 -c:v:0 libx264 -b:v:0 800k \
    -map v:0 -c:v:1 libx264 -b:v:1 2500k \
    -map a:0 -c:a aac -b:a 128k -ac 2 \
    -f hls -hls_time 6 -hls_flags delete_segments \
    -hls_list_size 5 -hls_delete_threshold 1 \
    -master_pl_name master.m3u8 \
    -var_stream_map "v:0,a:0 v:1,a:1" /storage/hls/live/
    stream_%v.m3u8


    View Slide

59. FFMPEG WEBSERVER VARNISH
    RTMP STREAM
    HLS FILES HTTP HTTP
    GOPRO


    View Slide

60. DIGITAL RIGHTS MANAGEMENT


    View Slide

61. $ openssl rand 16 > enc.key
    $ openssl rand -hex 16
    230f26620bfafa3cd420cb68c0647415
    ENC.KEYINFO
    /live/enc.key
    /storage/hls/live/enc.key
    230f26620bfafa3cd420cb68c0647415


    View Slide

62. ffmpeg -listen 1 -i rtmp://0.0.0.0/live/stream \
    -threads 0 -preset veryfast -g 25 -sc_threshold 0 \
    -map v:0 -c:v:0 libx264 -b:v:0 800k \
    -map v:0 -c:v:1 libx264 -b:v:1 2500k \
    -map a:0 -c:a aac -b:a 128k -ac 2 \
    -f hls -hls_time 6 -hls_flags delete_segments \
    -hls_list_size 5 -hls_delete_threshold 1 \
    -master_pl_name master.m3u8 \
    -hls_key_info_file /storage/hls/live/enc.keyinfo \
    -var_stream_map "v:0,a:0 v:1,a:1" /storage/hls/live/
    stream_%v.m3u8


    View Slide

63. #EXTM3U
    #EXT-X-VERSION:3
    #EXT-X-TARGETDURATION:5
    #EXT-X-MEDIA-SEQUENCE:15
    #EXT-X-KEY:METHOD=AES-128,URI="/live/
    enc.key",IV=0x230f26620bfafa3cd420cb68c0647415
    #EXTINF:3.200000,
    stream_015.ts
    #EXTINF:4.800000,
    stream_016.ts
    #EXTINF:3.200000,
    stream_017.ts
    #EXTINF:4.800000,
    stream_018.ts
    #EXTINF:1.088000,
    stream_019.ts
    #EXT-X-ENDLIST
    STREAM_0.M3U8
    PLAYER
    SUPPORTS DRM


    View Slide

64. .TS FILES ARE ENCODED AND
    CAN ONLY BE DECODED BY THE PLAYER


    View Slide

65. ENC.KEY SHOULD BE PROTECTED


    View Slide

66. vcl 4.1;
    import http;
    backend default {
    .host = "1.2.3.4";
    .port = "80";
    }
    sub vcl_recv {
    if(req.url ~ "^/live") {
    if (req.http.Authorization != "Basic YWRtaW46YWRtaW4=") {
    return (synth(401, "Restricted"));
    }
    }
    unset req.http.Authorization;
    }
    sub vcl_backend_response {
    if(bereq.url ~ "^/live/stream_[0-9]+\.m3u8$" || bereq.url == "/live/master.m3u8") {
    set beresp.grace = 0s;
    set beresp.ttl = 1s;
    }
    }
    sub vcl_synth {
    if (resp.status == 401) {
    set resp.http.WWW-Authenticate =
    {"Basic realm="Restricted area""};
    }
    }


    View Slide

67. View Slide

68. VARNISH ENTERPRISE
    ✓ CLIENT SSL TERMINATION
    ✓ BACKEND SSL CONNECTIONS
    ✓ PARALLEL ESI
    ✓ MASSIVE STORAGE ENGINE
    ✓ ENCRYPTION
    ✓ THROTTLING
    ✓ RATE LIMITING
    ✓ PREFETCHING
    ✓ GEOLOCATION
    ✓ AUTHENTICATION
    ✓ EDGESTASH
    ✓ CUSTOM STATISTICS
    ✓ ADMIN MODULE
    ✓ SUPPORT
    ✓ HIGH AVAILABILITY


    View Slide

69. HTTPS://AWS.AMAZON.COM/QUICKSTART/ARCHITECTURE/VARNISH/


    View Slide

70. MASSIVE STORAGE ENGINE


    View Slide

71. MSE
    ✓ MIX OF MEMORY AND DISK
    ✓ SMARTER LRU
    ✓ LESS DISK FRAGMENTATION
    ✓ INTELLIGENT STORAGE ROUTING
    ✓ MODULAR


    View Slide

72. MEMORY MEMORY
    ORIGIN
    ORIGIN
    DISK DISK DISK


    View Slide

73. env: {
    id = "myenv";
    memcache_size = "100G";
    };
    ENVIRONMENT
    CONFIGURATION


    View Slide

74. env: {
    id = "myenv";
    memcache_size = "100G";
    books = ( {
    id = "book1";
    directory = "/var/lib/mse/book1";
    database_size = "1G";
    stores = ( {
    id = "store-1-1";
    filename = "/var/lib/mse/stores/disk1/store-1-1.dat";
    size = "1T";
    }, {
    id = "store-1-2";
    filename = "/var/lib/mse/stores/disk2/store-1-2.dat";
    size = "1T";
    } );
    }
    };


    View Slide

75. HIGH PERFORMANCE HTTP LOGIC BOX


    View Slide

76. NO MORE ORIGIN


    View Slide

77. vcl 4.1;
    import file;
    backend default {
    .host = "origin";
    .port = "80";
    }
    sub vcl_init {
    new root = file.init("/var/www/html/");
    }
    sub vcl_backend_fetch {
    set bereq.backend = root.backend();
    }
    sub vcl_backend_response {
    if(bereq.url ~ "^/live/stream_[0-9]+\.m3u8$" || bereq.url == "/live/master.m3u8") {
    set beresp.grace = 0s;
    set beresp.ttl = 1s;
    }
    }


    View Slide

78. DEVICE DETECTION &
    BITRATE LIMITATION


    View Slide

79. vcl 4.1;
    import xbody;
    include "devicedetect.vcl";
    backend default {
    .host = "origin";
    .port = "80";
    }
    sub vcl_recv {
    call devicedetect;
    set req.http.X-UA-Device-Prefix = regsub(req.http.X-UA-Device,"(\w+)\-.*","\1");
    }
    sub vcl_backend_response {
    if(bereq.url == "/live/master.m3u8" ){
    set beresp.http.vary = "X-UA-Device-Prefix";
    if(bereq.http.X-UA-Device-Prefix == "mobile") {
    xbody.regsub("\#EXT-X-STREAM-INF:BANDWIDTH=2890800.*\nstream_.*", "");
    }
    }
    }


    View Slide

80. VIDEO SEGMENT PREFETCHING


    View Slide

81. vcl 4.1;
    import http;
    import std;
    backend default {
    .host = "origin";
    .port = "80";
    }
    sub vcl_recv {
    if (req.url ~ "^/(live|vod)/.+\.ts$") {
    http.init(0);
    http.req_set_max_loops(0,1);
    http.req_copy_headers(0);
    http.req_set_method(0, "HEAD");
    set req.http.x-next-url = http.prefetch_next_url();
    std.log("Prefetching " + req.http.x-next-url);
    http.req_set_url(0, req.http.x-next-url);
    http.req_send_and_finish(0);
    }
    }


    View Slide

82. THE VMOD ECOSYSTEM
    HTTPS://VARNISH-CACHE.ORG/VMODS/
    HTTPS://DOCS.VARNISH-SOFTWARE.COM/VARNISH-CACHE-PLUS/VMODS/


    View Slide

83. DEMO TIME?


    View Slide

84. View Slide

85. View Slide

86. HTTPS://FERYN.EU
    HTTPS://TWITTER.COM/THIJSFERYN
    HTTPS://INSTAGRAM.COM/THIJSFERYN


    View Slide
