Getting Started with Time Series Data

At the NoSQL Matters Conference in Dublin 2014 I gave a talk on getting started with time series data, where I presented some basics and how you can query and model your data using InfluxDB.

Transcript

1. Getting Started with Time Series Data Sebastian Cohnen, @tisba
 stormforger.com, @StormForgerApp
 NoSQL Matters 2014, Dublin, Sep. 2014 with InfluxDB
2. About me • Sebastian Cohnen, M. Sc. • Developer & Founder from Cologne, Germany • (Web-) Architectures, Performance & Scalability • Founder of StormForger.com; load test HTTP-based systems
3. Time Series Data • Data, which has an inherent relation to time, e.g… • Sensor Data, Log Data • Stock Prices • "Events" in general
4. Use Cases • (statistical) Analysis • Summaries and Aggregations • Visualization • Dashboards,
 Monitoring & Alerting
5. Time Series Database (TSDB) • Make use of the inherent relation to time • (almost) everything builds around “ORDER BY time” • Examples: RRDTool, carbon (Graphite), OpenTSDB, … and InfluxDB
6. Wish List for TSDBs • Flexible Query Language; e.g. SQL-like • Stream Processing • Full control over Downsampling & Retention Policies
9. InfluxDB • written in Go, Open Source since 04/2013 • HTTP (binary protocol planned) • SQL-like Query Language • Clustering Support
10. Data Model • Databases • Time Series (“Tables”) • Points/Events (“Rows”): schema-less, key-value pairs
11. Let's take a look…
12. Example Data time host value mount 1409665622000 a.example.com 42 /mnt 1409137873000 b.example.com 23 /mnt
13. Writing Data [{ "name" : "hd_used", ! "columns" : ["time", "value", "host", "mount"], "points" : [ [1409665622000, 42, "a.example.com", "/mnt"], [1409137873000, 23, "b.example.com", "/mnt"] ] ! }] POST "http://localhost:8086/db/matters-dub-2014/series" database time series points
14. [{ "name": "hd_used", "columns": [ "time", "sequence_number", "value", "host", "mount" ], "points": [ [ 1409137878266, 10001, 42, "a.example.com", "/mnt" ], … ] }] GET "http://localhost:8086/db/ matters-dub-2014/series?q=$QUERY" Querying Data SELECT * FROM hd_used
15. InfluxDB Query Language
16. SQL-like SELECT status, duration, path FROM production.web.server01.requests WHERE time > now() - 1h
17. Aggregation SELECT COUNT(duration) AS request_count, MEDIAN(duration) AS median, PERCENTILE(duration, 95.0) AS p95, PERCENTILE(duration, 99.0) AS p99 FROM production.web.server01.requests WHERE time > "2014-09-03 00:00:00.000" AND time < "2014-09-05" GROUP BY time(1m)
18. Regular Expressions SELECT COUNT(duration) AS request_count FROM production.web.server01.requests WHERE time > "2014-09-03 00:00:00.000" AND time < "2014-09-05" ! AND user_agent =~ /.*Chrome.*/ ! GROUP BY time(1m)
19. Selecting Multiple Series SELECT COUNT(duration) AS request_count ! FROM production.web.server01.requests, production.web.server02.requests ! WHERE time > "2014-09-03 00:00:00.000" AND time < "2014-09-05"
20. …or via Regular Expressions SELECT COUNT(duration) AS request_count ! FROM /production\.web\.server\d{2}\.requests/ ! ! WHERE time > "2014-09-03 00:00:00.000" AND time < "2014-09-05"
21. Join SELECT errors_per_minute.value /
 page_views_per_minute.value ! FROM errors_per_minute INNER JOIN page_views_per_minute a1 b1 a2 b2 a3 a3 a1 b2 a2 b1 b3 a3 t1 t2 t3 t4
22. Merge SELECT COUNT(duration) FROM production.web.server01.requests MERGE production.web.server02.requests a1 b1 a2 b2 a3 a3 a1 b2 a2 b1 b3 a3
23. Continuous Queries “Stream Processing”
24. Continuous Queries • Idea: Process data as it arrives, not (only) at query time • Continuous Queries can be defined via "SQL" and run continuously • Support for backfilling (e.g. when creating new queries on existing data)
25. Continuous Queries: Use Cases • Organizing, Fanout • Downsampling & Aggregation
26. Organizing Data
27. time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 SELECT path, duration FROM http_requests GROUP BY http_status response_times.500 … response_times.200 Input Events http_requests INTO response_times.[http_status]
28. SELECT Across Series SELECT PERCENTILE(duration, 95.0) FROM /response_times\..*/ { "response_times.200": [{ "percentile": 5.058, "time": 0 }], "response_times.500": [{ "percentile": 63.761, "time": 0 }] }
29. Downsample & Aggregate Data
30. Goals • group by status code • keep 1 data point per minute • calculate 95th percentile & mean duration • put results into response_times.1m.$status_code
31. time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 time: 1409137878266 path: /example.html duration: 0.23 status: 200 SELECT MEAN(duration) AS mean, PERCENTILE(duration, 95.0) AS p95 FROM http_requests GROUP BY time(1m), http_status INTO response_times.1m.[http_status] http_requests response_times.1m.500 … response_times.1m.200 1min 1min 1min
32. SELECT time, p95, mean FROM /response_times\.1m\..*/ SELECT time, p95, mean FROM response_times.1m.200 WHERE time > "2014-09-03 00:00:00.000" AND time < "2014-09-05"
33. InfluxDB UIs • build-in (Simple Management) • http://grafana.org/ • https://github.com/ hakobera/influga
34. :-)
35. Q&A Sebastian Cohnen, @tisba
 stormforger.com, @StormForgerApp
 NoSQL Matters 2014, Dublin, Sep. 2014
