Hello, declarative world

We know that a computer is an imperative machine: a CPU reads one instruction after another, and performs one operation after another, with each operation modifying the state of its registers and memory. But that doesn’t mean we HAVE to write our computer programs as imperative step-by-step recipes; there are other interesting ways to specify a computation.

Ruby’s billed as a “multi-paradigm” language, but, let’s face it, we use it to write imperative object-oriented programs. I'm interested in different ways of programming computers, because I reckon imperative programs are far too low-level and overspecified, which is why as a species we're generally terrible at writing them.

One interesting alternative is declarative programming, where we tell the computer about the problem we want to solve instead of exactly what steps to take to solve it. That idea’s been around for a long time but has recently begun to reappear everywhere.

In this talk I want to encourage you to think outside of your normal programming habits; I’ll present a more abstract and declarative style called relational programming, and show you how to implement a minimal relational language in Ruby. (Dog whistle: this is μKanren.)

Given at Joy of Coding 2015 (http://lanyrd.com/2015/joyofcoding/) and the London Ruby User Group (http://lrug.org/meetings/2015/august/). A video and expanded transcript are available at https://tomstu.art/hello-declarative-world, and the code is available at http://github.com/tomstuart/kanren.

Transcript

1. HELLO,
   DECLARATIVE
   WORLD
   http://codon.com/hello-declarative-world


   View Slide

2. View Slide

3. View Slide

4. UNSTRUCTURED
   PROCEDURAL
   FUNCTIONAL
   DECLARATIVE
   IMPERATIVE
   MORE
   ABSTRACT


   View Slide

5. PROGRAMMER
   (A HUMAN)
   SOLVER
   (A MACHINE)
   HOW
   WHAT


   View Slide

6. UNSTRUCTURED
   PROCEDURAL
   FUNCTIONAL
   RELATIONAL
   DECLARATIVE
   IMPERATIVE
   MORE
   ABSTRACT


   View Slide

7. “FUNCTION”
   19
   23
   42
   x
   y
   x + y


   View Slide

8. “RELATION”
   y is 5
   x = y
   x is 5
   y is ?


   View Slide

9. “RELATION”
   x is 4
   x < y
   y is 5
   x is ? x is 3
   x is 2
   x is 1
   x is 0


   View Slide

10. LET’S BUILD
    OUR OWN!


    View Slide

11. GOAL
    STATE STATE
    STATE
    STATE
    ⋮


    View Slide

12. VARIABLES


    View Slide

13. >> x, y = Variable.new(:x),
    Variable.new(:y)
    => [x, y]
    >> x == x
    => true
    >> x == y
    => false
    >> x == Variable.new(:x)
    => false


    View Slide

14. class Variable
    def initialize(name)
    @name = name
    end
    def inspect
    @name
    end
    end


    View Slide

15. STATES


    View Slide

16. class State
    def initialize(variables = [], values = {})
    @variables, @values = variables, values
    end
    attr_reader :variables, :values
    end


    View Slide

17. >> state = State.new
    => #
    >> state, (x, y, z) =
    state.create_variables [:x, :y, :z]
    => [#,
    [x, y, z]]
    >> state.variables
    => [x, y, z]
    >> state =
    state.assign_values x => y, y => z, z => 5
    => #@values={x=>y, y=>z, z=>5}>
    >> state.values
    => {x=>y, y=>z, z=>5}


    View Slide

18. class State
    def create_variables(names)
    new_variables =
    names.map { |name| Variable.new(name) }
    [
    State.new(variables + new_variables, values),
    new_variables
    ]
    end
    def assign_values(new_values)
    State.new(variables, values.merge(new_values))
    end
    end


    View Slide

19. >> state.values
    => {x=>y, y=>z, z=>5}
    >> state.value_of x
    => 5
    >> state.value_of 7
    => 7
    >> state, (a, b, c) =
    state.create_variables [:a, :b, :c]
    => [#, [a, b, c]]
    >> state.value_of a
    => a


    View Slide

20. class State
    def value_of(key)
    if values.has_key?(key)
    value_of values.fetch(key)
    else
    key
    end
    end
    end


    View Slide

21. UNIFICATION


    View Slide

22. >> state, (x, y) =
    State.new.create_variables [:x, :y]
    => [#,
    [x, y]]
    >> state = state.unify(x, x)
    => #
    >> state.values
    => {}


    View Slide

23. >> state = state.unify(x, y)
    => #y}>
    >> state.values
    => {x=>y}
    >> state = state.unify(x, 5)
    => #y, y=>5}>
    >> state.values
    => {x=>y, y=>5}
    >> state.value_of x
    => 5
    >> state.unify(y, 6)
    => nil


    View Slide

24. class State
    def unify(a, b)
    a, b = value_of(a), value_of(b)
    if a == b
    self
    elsif a.is_a?(Variable)
    assign_values a => b
    elsif b.is_a?(Variable)
    assign_values b => a
    end
    end
    end


    View Slide

25. GOALS


    View Slide

26. class Goal
    def initialize(&block)
    @block = block
    end
    def pursue_in(state)
    @block.call state
    end
    end


    View Slide

27. BASIC
    GOALS


    View Slide

28. EQUAL
    VALUE VALUE


    View Slide

29. >> state, (x, y, z) =
    State.new.create_variables [:x, :y, :z]
    => [#,
    [x, y, z]]
    >> goal = Goal.equal(x, 5)
    => #>
    >> states = goal.pursue_in(state)
    => #:each>
    >> states.next
    => #5}>
    >> _.values
    => {x=>5}
    >> states.next
    StopIteration: iteration reached an end


    View Slide

30. def Goal.equal(a, b)
    Goal.new do |state|
    state = state.unify(a, b)
    Enumerator.new do |yielder|
    yielder.yield state if state
    end
    end
    end


    View Slide

31. WITH VARIABLES
    GOAL
    X Y …


    View Slide

32. >> goal = Goal.with_variables { |x| Goal.equal(x, 5) }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> state = states.first
    => #5}>
    >> state.values
    => {x=>5}


    View Slide

33. def Goal.with_variables(&block)
    names = block.parameters.
    map { |type, name| name }
    Goal.new do |state|
    state, variables =
    state.create_variables(names)
    goal = block.call(*variables)
    goal.pursue_in state
    end
    end


    View Slide

34. COMBINING
    GOALS


    View Slide

35. EITHER
    GOAL GOAL


    View Slide

36. >> goal = Goal.with_variables { |x|
    Goal.either(Goal.equal(x, 5), Goal.equal(x, 6))
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.next.values
    => {x=>5}
    >> states.next.values
    => {x=>6}


    View Slide

37. def Goal.either(first_goal, second_goal)
    Goal.new do |state|
    first_stream = first_goal.pursue_in(state)
    second_stream = second_goal.pursue_in(state)
    first_stream.interleave_with(second_stream)
    end
    end


    View Slide

38. >> letters = 'a'.upto('z')
    => #
    >> numbers = 1.upto(10)
    => #
    >> letters.interleave_with(numbers).entries
    => ["a", 1, "b", 2, "c", 3, "d", 4, "e", 5,
    "f", 6, "g", 7, "h", 8, "i", 9, "j",
    10, "k", "l", "m", "n", "o", "p", "q",
    "r", "s", "t", "u", "v", "w", "x", "y",
    "z"]


    View Slide

39. >> letters = ['a', 'b', 'c'].cycle
    => #
    >> numbers = 1.upto(Float::INFINITY)
    => #
    >> letters.interleave_with(numbers).take(50)
    => ["a", 1, "b", 2, "c", 3, "a", 4, "b", 5,
    "c", 6, "a", 7, "b", 8, "c", 9, "a", 10,
    "b", 11, "c", 12, "a", 13, "b", 14, "c",
    15, "a", 16, "b", 17, "c", 18, "a", 19,
    "b", 20, "c", 21, "a", 22, "b", 23, "c",
    24, "a", 25]


    View Slide

40. class Enumerator
    def interleave_with(other)
    enumerators = self, other
    Enumerator.new do |yielder|
    until enumerators.empty?
    loop do
    enumerator = enumerators.shift
    yielder.yield enumerator.next
    enumerators.push enumerator
    end
    end
    end
    end
    end


    View Slide

41. BOTH
    GOAL GOAL


    View Slide

42. >> goal = Goal.with_variables { |x, y|
    Goal.both(
    Goal.equal(x, 5),
    Goal.equal(y, 7)
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => ##:each>
    >> states.next.values
    => {x=>5, y=>7}


    View Slide

43. >> goal = Goal.with_variables { |a, b|
    Goal.both(
    Goal.equal(a, 7),
    Goal.either(
    Goal.equal(b, 5),
    Goal.equal(b, 6)
    )
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.next.values
    => {a=>7, b=>5}
    >> states.next.values
    => {a=>7, b=>6}


    View Slide

44. >> goal = Goal.with_variables { |x|
    Goal.both(
    Goal.equal(1, x),
    Goal.equal(x, 2)
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => ##:each>
    >> states.next.values
    StopIteration: iteration reached an end


    View Slide

45. def Goal.both(first_goal, second_goal)
    Goal.new do |state|
    states = first_goal.pursue_in(state)
    second_goal.pursue_in_each(states)
    end
    end


    View Slide

46. class Goal
    def pursue_in_each(states)
    Enumerator.new do |yielder|
    results = pursue_in(states.next)
    results =
    results.interleave_with(pursue_in_each(states))
    results.each do |state|
    yielder.yield state
    end
    end
    end
    end


    View Slide

47. WITH
    VARIABLES
    G
    X Y …
    EQUAL
    V V
    STATE
    VARIABLE
    EITHER
    G G
    BOTH
    G G


    View Slide

48. µKANREN


    View Slide

49. WHAT CAN
    IT DO?


    View Slide

50. >> pair = Pair.new(5, 9)
    => (5, 9)
    >> pair.left
    => 5
    >> pair.right
    => 9


    View Slide

51. Pair = Struct.new(:left, :right) do
    def inspect
    "(#{left.inspect}, #{right.inspect})"
    end
    end


    View Slide

52. >> goal = Goal.with_variables { |x, y|
    Goal.equal(
    Pair.new(3, x),
    Pair.new(y, Pair.new(5, y))
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> state = states.first
    => #@values={y=>3, x=>(5, 3)}>
    >> state.values
    => {y=>3, x=>(5, 3)}


    View Slide

53. class State
    def unify(a, b)
    a, b = value_of(a), value_of(b)
    if a == b
    self
    elsif a.is_a?(Variable)
    assign_values a => b
    elsif b.is_a?(Variable)
    assign_values b => a
    end
    end
    end


    View Slide

54. end
    end
    end
    elsif a.is_a?(Pair) && b.is_a?(Pair)
    state = unify(a.left, b.left)
    state.unify(a.right, b.right) if state
    class State
    def unify(a, b)
    a, b = value_of(a), value_of(b)
    if a == b
    self
    elsif a.is_a?(Variable)
    assign_values a => b
    elsif b.is_a?(Variable)
    assign_values b => a


    View Slide

55. else
    key
    end
    end
    end
    class State
    def value_of(key)
    if values.has_key?(key)
    value_of values.fetch(key)


    View Slide

56. else
    key
    end
    end
    end
    class State
    def value_of(key)
    if values.has_key?(key)
    value_of values.fetch(key)
    elsif key.is_a?(Pair)
    Pair.new(
    value_of(key.left),
    value_of(key.right)
    )


    View Slide

57. class State
    def results(n)
    variables.first(n).
    map { |variable| value_of(variable) }
    end
    def result
    results(1).first
    end
    end


    View Slide

58. >> state.values
    => {y=>3, x=>(5, 3)}
    >> state.variables
    => [x, y]
    >> state.results 2
    => [(5, 3), 3]
    >> state.result
    => (5, 3)


    View Slide

59. LISTS


    View Slide

60. ['a', 'b', 'c']
    ('a', ('b', ('c', •)))


    View Slide

61. EMPTY_LIST = :empty
    def to_list(array)
    if array.empty?
    EMPTY_LIST
    else
    first, *rest = array
    Pair.new(first, to_list(rest))
    end
    end


    View Slide

62. >> to_list ['a', 'b', 'c']
    => ('a', ('b', ('c', :empty)))


    View Slide

63. def from_list(list)
    if list == EMPTY_LIST
    []
    else
    first, rest = list.left, list.right
    [first, *from_list(rest)]
    end
    end


    View Slide

64. >> from_list \
    Pair.new('a',
    Pair.new('b',
    Pair.new('c', EMPTY_LIST)
    )
    )
    => ['a', 'b', 'c']


    View Slide

65. >> goal = Goal.with_variables { |x, y, z|
    Goal.equal(
    to_list([x, 2, z]),
    to_list([1, y, 3])
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => ##:each>
    >> states.next.values
    => {x=>1, y=>2, z=>3}


    View Slide

66. def append(a, b, c)
    Goal.either(
    Goal.both(
    Goal.equal(a, EMPTY_LIST),
    Goal.equal(b, c)
    ),
    Goal.with_variables { |first, rest_of_a, rest_of_c|
    Goal.both(
    Goal.both(
    Goal.equal(a, Pair.new(first, rest_of_a)),
    Goal.equal(c, Pair.new(first, rest_of_c))
    ),
    append(rest_of_a, b, rest_of_c)
    )
    }
    )
    end


    View Slide

67. >> goal = Goal.with_variables { |x|
    append(
    to_list(['h', 'e']),
    to_list(['l', 'l', 'o']),
    x
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> state.next.result
    => ("h", ("e", ("l", ("l", ("o", :empty)))))
    >> from_list _
    => ["h", "e", "l", "l", "o"]


    View Slide

68. >> goal = Goal.with_variables { |x|
    append(
    x,
    to_list(['l', 'o']),
    to_list(['h', 'e', 'l', 'l', 'o'])
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> from_list states.next.result
    => ["h", "e", "l"]


    View Slide

69. >> goal = Goal.with_variables { |x, y|
    append(
    x,
    y,
    to_list(['h', 'e', 'l', 'l', 'o'])
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.next.results(2)
    => [:empty,
    ("h", ("e", ("l", ("l", ("o", :empty)))))]
    >> _.map { |list| from_list(list) }
    => [[], ["h", "e", "l", "l", "o"]]


    View Slide

70. >> states.next.results(2).
    map { |list| from_list(list) }
    => [["h", "e"], ["l", "l", "o"]]
    >> states.next.results(2).
    map { |list| from_list(list) }
    => [["h"], ["e", "l", "l", "o"]]
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.next.results(2)
    => [:empty,
    ("h", ("e", ("l", ("l", ("o", :empty)))))]
    >> _.map { |list| from_list(list) }
    => [[], ["h", "e", "l", "l", "o"]]


    View Slide

71. >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.each do |state|
    p state.results(2).map { |list| from_list(list) }
    end
    [[], ["h", "e", "l", "l", "o"]]
    [["h"], ["e", "l", "l", "o"]]
    [["h", "e"], ["l", "l", "o"]]
    [["h", "e", "l"], ["l", "o"]]
    [["h", "e", "l", "l"], ["o"]]
    [["h", "e", "l", "l", "o"], []]
    => nil


    View Slide

72. NUMBERS


    View Slide

73. 3
    (+, (+, (+, •)))


    View Slide

74. INC, ZERO = :+, :z
    def to_peano(number)
    if number.zero?
    ZERO
    else
    Pair.new(INC, to_peano(number - 1))
    end
    end


    View Slide

75. >> to_peano 3
    => (:+, (:+, (:+, :z)))


    View Slide

76. def from_peano(peano)
    if peano == ZERO
    0
    else
    from_peano(peano.right) + 1
    end
    end


    View Slide

77. >> from_peano \
    Pair.new(INC,
    Pair.new(INC,
    Pair.new(INC, ZERO)
    )
    )
    => 3


    View Slide

78. def add(x, y, z)
    Goal.either(
    Goal.both(
    Goal.equal(x, ZERO),
    Goal.equal(y, z)
    ),
    Goal.with_variables { |smaller_x, smaller_z|
    Goal.both(
    Goal.both(
    Goal.equal(x, Pair.new(INC, smaller_x)),
    Goal.equal(z, Pair.new(INC, smaller_z))
    ),
    add(smaller_x, y, smaller_z)
    )
    }
    )
    end


    View Slide

79. >> goal = Goal.with_variables { |x|
    add(
    to_peano(5),
    to_peano(3),
    x
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.next.result
    => (:+, (:+, (:+, (:+, (:+, (:+, (:+, (:+,
    :z))))))))
    >> from_peano _
    => 8


    View Slide

80. >> goal = Goal.with_variables { |x|
    add(
    x,
    to_peano(3),
    to_peano(8)
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> from_peano states.next.result
    => 5


    View Slide

81. >> goal = Goal.with_variables { |x, y|
    add(
    x,
    y,
    to_peano(8)
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.each do |state|
    p state.results(2).map { |peano|
    from_peano(peano)
    }
    end
    [0, 8]


    View Slide

82. >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.each do |state|
    p state.results(2).map { |peano|
    from_peano(peano)
    }
    end
    [0, 8]
    [1, 7]
    [2, 6]
    [3, 5]
    [4, 4]
    [5, 3]
    [6, 2]
    [7, 1]
    [8, 0]
    => nil


    View Slide

83. def multiply(x, y, z)
    Goal.either(
    Goal.both(
    Goal.equal(x, ZERO),
    Goal.equal(z, ZERO)
    ),
    Goal.with_variables { |smaller_x, smaller_z|
    Goal.both(
    Goal.both(
    Goal.equal(x, Pair.new(INC, smaller_x)),
    add(smaller_z, y, z)
    ),
    multiply(smaller_x, y, smaller_z)
    )
    }
    )
    end


    View Slide

84. >> goal = Goal.with_variables { |x|
    multiply(
    to_peano(3),
    to_peano(8),
    x
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.next.result
    => (:+, (:+, (:+, (:+, (:+, (:+, (:+, (:+,
    (:+, (:+, (:+, (:+, (:+, (:+, (:+, (:+,
    (:+, (:+, (:+, (:+, (:+, (:+, (:+, (:+,
    :z))))))))))))))))))))))))
    >> from_peano _
    => 24


    View Slide

85. >> goal = Goal.with_variables { |x, y|
    multiply(
    x,
    y,
    to_peano(24)
    )
    }
    => #>
    >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.take(8).each do |state|
    p state.results(2).map { |peano|
    from_peano(peano)
    }
    end
    [1, 24]
    [2, 12]
    [3, 8]


    View Slide

86. >> states = goal.pursue_in(State.new)
    => #:each>
    >> states.take(8).each do |state|
    p state.results(2).map { |peano|
    from_peano(peano)
    }
    end
    [1, 24]
    [2, 12]
    [3, 8]
    [4, 6]
    [6, 4]
    [8, 3]
    [12, 2]
    [24, 1]
    => nil


    View Slide

87. BE
    DECLARATIVE


    View Slide

88. PROGRAMMER
    (A HUMAN)
    SOLVER
    (A MACHINE)
    HOW
    WHAT


    View Slide

89. THANKS.
    @tomstuart
    http://codon.com/hello-declarative-world


    View Slide
