A Lever for the Mind

Humans are the cleverest animals in the known universe. But our brains, forged over millions of years in the unforgiving furnace of natural selection, are still primitive. They evolved to be good at hunting animals, making tools, recognising facial expressions and maintaining social bonds, but they’re just not very good at working with several difficult ideas simultaneously, and they’re particularly bad at reasoning about the counterintuitive emergent behaviour of complex non-human systems.

That’s a problem, because complex non-human systems now dominate our world.

Abstraction is our solution to this problem. Abstraction works as an adapter between the fearsome complexity of the universe and our simple primate minds; when the real world is too detailed, too confusing or too counterintuitive for us to work with directly, abstraction gives us big friendly levers to pull on instead. This one powerful idea underlies computers, design, culture, language, and everything else we rely on in our daily work.

This is a talk about abstraction: where it comes from, what it’s for, and how we can use it to make our programs better.

Given at RubyConf 2014 (http://lanyrd.com/2014/rubyconf/) and Bath Ruby Conference 2015 (http://2015.bathruby.org/). A video and transcript is available at https://tomstu.art/a-lever-for-the-mind.

Transcript

1. THE
   A LEVER
   FOR
   MIND
   @tomstuart at RubyConf on 2014-11-19


   View Slide

2. Give me a lever long enough
   and a fulcrum on which to place it,
   and I shall move the world.”
   — Archimedes
   “


   View Slide

3. View Slide

4. ABSTRACTION


   View Slide

5. NUMBERS


   View Slide

6. View Slide

7. View Slide

8. View Slide

9. View Slide

10. View Slide

11. View Slide

12. View Slide

13. View Slide

14. View Slide

15. View Slide

16. View Slide

17. View Slide

18. View Slide

19. View Slide

20. View Slide

21. <


    View Slide

22. View Slide

23. View Slide

24. View Slide

25. View Slide

26. View Slide

27. View Slide

28. View Slide

29. 2
    3 5
    combine
    add
    count count count
    REAL
    ABSTRACT


    View Slide

30. 2
    3 5
    add
    ABSTRACT


    View Slide

31. SUMS


    View Slide

32. 1 + 2 + 3 + 4 + 5 +
    6 + 7 + 8 + 9 + 10 = ?


    View Slide

33. 1 + 2 = 3
    3 + 3 = 6
    6 + 4 = 10
    10 + 5 = 15


    View Slide

34. 15 + 6 = 21
    21 + 7 = 28
    28 + 8 = 36
    36 + 9 = 45
    45 + 10 = 55


    View Slide

35. 1 + 2 + 3 + 4 + 5 +
    6 + 7 + 8 + 9 + 10 = 55


    View Slide

36. 1 + 2 + 3 + 4 + 5 + …
    … + 98 + 99 + 100 = ?


    View Slide

37. ?
    1 + 2 +
    3 + 4 +
    5 + 6 +
    7 + 8 +
    9 + 10 =


    View Slide

38. ?
    1 + 10 +
    2 + 9 +
    3 + 8 +
    4 + 7 +
    5 + 6 =


    View Slide

39. 11 +
    11 +
    11 +
    11 +
    11 = ?


    View Slide

40. 11 +
    11 +
    11 +
    11 +
    11 = 55


    View Slide

41. 1 + 10 +
    2 + 9 +
    3 + 8 +
    4 + 7 +
    5 + 6 = 55


    View Slide

42. 1 + 2 + … + 9 + 10 =
    (10 ÷ 2) × (10 + 1)


    View Slide

43. 1 + 2 + 3 + 4 + 5 + …
    … + 98 + 99 + 100 = ?


    View Slide

44. 1 + 100 +
    2 + 99 +
    49 + 52 +
    50 + 51 = ?
    ⋮


    View Slide

45. 101 +
    101 +
    101 +
    101 = ?
    ⋮


    View Slide

46. 101 +
    101 +
    101 +
    101 = 5,050
    ⋮


    View Slide

47. 1 + 2 + … + 99 + 100 =
    (100 ÷ 2) × (100 + 1)


    View Slide

48. 1 + 2 + … + n =
    (n ÷ 2) × (n + 1)


    View Slide

49. View Slide

50. View Slide

51. View Slide

52. (n + 1) × n ÷ 2
    1 + 2 + … + n =


    View Slide

53. 1 + 2 + … + n =
    (n + 1)
    ×
    n ÷ 2
    ( )


    View Slide

54. 1 + 2 + … + 999 + 1000 =
    ?


    View Slide

55. 1 + 2 + … + 999 + 1000 =
    (1000 ÷ 2) × (1000 + 1)


    View Slide

56. 1 + 2 + … + 999 + 1000 =
    500 × 1001


    View Slide

57. 1 + 2 + … + 999 + 1000 =
    500,500


    View Slide

58. GRAPHS


    View Slide

59. View Slide

60. View Slide

61. View Slide

62. View Slide

63. View Slide

64. View Slide

65. View Slide

66. View Slide

67. View Slide

68. View Slide

69. View Slide

70. View Slide

71. View Slide

72. View Slide

73. View Slide

74. View Slide

75. View Slide

76. View Slide

77. DEGREE
    2


    View Slide

78. DEGREE
    3


    View Slide

79. WALK


    View Slide

80. CONNECTED


    View Slide

81. CONNECTED


    View Slide

82. CONNECTED


    View Slide

83. CONNECTED


    View Slide

84. TRAIL


    View Slide

85. EULERIAN TRAIL


    View Slide

86. EULERIAN TRAIL
    CONNECTED
    OF ODD DEGREE
    AT MOST 2 NODES


    View Slide

87. View Slide

88. TRIANGLES


    View Slide

89. View Slide

90. 4
    4
    5.7


    View Slide

91. 4
    5
    6.4


    View Slide

92. 3
    5.8
    5


    View Slide

93. a
    b
    c a² + b² = c²


    View Slide

94. View Slide

95. View Slide

96. c²


    View Slide

97. View Slide

98. a²
    b²


    View Slide

99. c²
    a²
    b²


    View Slide

100. c²
     a² b²
     + =


     View Slide

101. c²
     a²
     b²


     View Slide

102. c²
     a²
     b²


     View Slide

103. c²
     a²
     b²


     View Slide

104. a
     b
     c a² + b² = c²


     View Slide

105. MATHEMATICS


     View Slide

106. SPOT PATTERNS,
     BUILD REUSABLE
     ABSTRACTIONS


     View Slide

107. BAD
     MATHEMATICS
     EDUCATION


     View Slide

108. View Slide

109. View Slide

110. POKER


     View Slide

111. HIGH CARD
     ONE PAIR
     TWO PAIR


     View Slide

112. THREE OF
     A KIND
     STRAIGHT
     FLUSH


     View Slide

113. Card = Struct.new(:rank, :suit)
     three_of_diamonds = Card.new(3, :diamonds)
     queen_of_hearts = Card.new(12, :hearts)
     ace_of_spades = Card.new(14, :spades)


     View Slide

114. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     # TODO
     end
     end


     View Slide

115. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     highest_card_rank <=> other.highest_card_rank
     end
     # …
     end


     View Slide

116. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     if highest_card_rank == other.highest_card_rank
     without { |c| c.rank == highest_card_rank } <=>
     other.without { |c| c.rank == highest_card_rank }
     else
     highest_card_rank <=> other.highest_card_rank
     end
     end
     # …
     end


     View Slide

117. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     if empty? && other.empty?
     0
     elsif highest_card_rank == other.highest_card_rank
     without { |c| c.rank == highest_card_rank } <=>
     other.without { |c| c.rank == highest_card_rank }
     else
     highest_card_rank <=> other.highest_card_rank
     end
     end
     # …
     end


     View Slide

118. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     if one_pair?
     if other.one_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     else
     if empty? && other.empty?
     0
     elsif other.one_pair?
     -1
     elsif highest_card_rank == other.highest_card_rank
     without { |c| c.rank == highest_card_rank } <=>
     other.without { |c| c.rank == highest_card_rank }
     else
     highest_card_rank <=> other.highest_card_rank
     end
     end
     end
     # …
     end


     View Slide

119. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     if two_pair?
     if other.two_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     elsif one_pair?
     if other.two_pair?
     -1
     elsif other.one_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     else
     if empty? && other.empty?
     0
     elsif other.one_pair? || other.two_pair?
     -1
     elsif highest_card_rank == other.highest_card_rank
     without { |c| c.rank == highest_card_rank } <=>
     other.without { |c| c.rank == highest_card_rank }
     else
     highest_card_rank <=> other.highest_card_rank
     end
     end
     end
     # …
     end


     View Slide

120. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     if three_of_a_kind?
     if other.three_of_a_kind?
     if highest_triple_rank == other.highest_triple_rank
     without { |c| c.rank == highest_triple_rank } <=>
     other.without { |c| c.rank == highest_triple_rank }
     else
     highest_triple_rank <=> other.highest_triple_rank
     end
     else
     1
     end
     elsif two_pair?
     if other.three_of_a_kind?
     -1
     elsif other.two_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     elsif one_pair?
     if other.two_pair? || other.three_of_a_kind?
     -1
     elsif other.one_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     else
     if empty? && other.empty?
     0
     elsif other.one_pair? || other.two_pair? || other.three_of_a_kind?
     -1
     elsif highest_card_rank == other.highest_card_rank
     without { |c| c.rank == highest_card_rank } <=>
     other.without { |c| c.rank == highest_card_rank }
     else
     highest_card_rank <=> other.highest_card_rank
     end
     end
     end
     # …
     end


     View Slide

121. Hand = Struct.new(:cards) do
     include Comparable
     def <=>(other)
     if straight?
     if other.straight?
     if highest_straight_rank == other.highest_straight_rank
     without { |c| c.rank == highest_straight_rank } <=>
     other.without { |c| c.rank == highest_straight_rank }
     else
     highest_straight_rank <=> other.highest_straight_rank
     end
     else
     1
     end
     elsif three_of_a_kind?
     if other.straight?
     -1
     elsif other.three_of_a_kind?
     if highest_triple_rank == other.highest_triple_rank
     without { |c| c.rank == highest_triple_rank } <=>
     other.without { |c| c.rank == highest_triple_rank }
     else
     highest_triple_rank <=> other.highest_triple_rank
     end
     else
     1
     end
     elsif two_pair?
     if other.three_of_a_kind? || other.straight?
     -1
     elsif other.two_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     elsif one_pair?
     if other.two_pair? || other.three_of_a_kind? || other.straight?
     -1
     elsif other.one_pair?
     if highest_pair_rank == other.highest_pair_rank
     without { |c| c.rank == highest_pair_rank } <=>
     other.without { |c| c.rank == highest_pair_rank }
     else
     highest_pair_rank <=> other.highest_pair_rank
     end
     else
     1
     end
     else
     if empty? && other.empty?
     0
     elsif other.one_pair? || other.two_pair? || other.three_of_a_kind? || other.straight?
     -1
     elsif highest_card_rank == other.highest_card_rank
     without { |c| c.rank == highest_card_rank } <=>
     other.without { |c| c.rank == highest_card_rank }
     else
     highest_card_rank <=> other.highest_card_rank
     end
     end
     end
     # …
     end


     View Slide

122. Card = Struct.new(:rank, :suit)
     class Card::Rank
     TWO, THREE, FOUR, FIVE,
     SIX, SEVEN, EIGHT, NINE,
     TEN, JACK, QUEEN, KING, ACE = 13.times.map { new }
     end
     class Card::Suit
     CLUBS, HEARTS, SPADES, DIAMONDS = 4.times.map { new }
     end
     three_of_diamonds = Card.new(Card::Rank::THREE, Card::Suit::DIAMONDS)
     queen_of_hearts = Card.new(Card::Rank::QUEEN, Card::Suit::HEARTS)
     ace_of_spades = Card.new(Card::Rank::ACE, Card::Suit::SPADES)


     View Slide

123. class Card::Rank
     include Comparable
     ORDER = (
     TWO, THREE, FOUR, FIVE,
     SIX, SEVEN, EIGHT, NINE,
     TEN, JACK, QUEEN, KING, ACE = 13.times.map { new }
     )
     def <=>(other)
     ORDER.index(self) <=> ORDER.index(other)
     end
     end


     View Slide

124. class Hand::Category
     include Comparable
     ORDER = (
     HIGH_CARD, ONE_PAIR, TWO_PAIR, THREE_OF_A_KIND,
     STRAIGHT, FLUSH, FULL_HOUSE, FOUR_OF_A_KIND,
     STRAIGHT_FLUSH = 9.times.map { new }
     )
     def <=>(other)
     ORDER.index(self) <=> ORDER.index(other)
     end
     end


     View Slide

125. class << Hand::Category::HIGH_CARD
     def matches?(hand)
     true
     end
     def compare(a, b)
     # …
     end
     end


     View Slide

126. class << Hand::Category::ONE_PAIR
     def matches?(hand)
     pairs(hand).size == 1
     end
     def compare(a, b)
     # …
     end
     end


     View Slide

127. Hand::Rank = Struct.new(:hand) do
     include Comparable
     def category
     Hand::Category::ORDER.
     select { |category| category.matches?(hand) }.max
     end
     def <=>(other)
     if category == other.category
     category.compare(hand, other.hand)
     else
     category <=> other.category
     end
     end
     end


     View Slide

128. Hand = Struct.new(:cards) do
     def rank
     Hand::Rank.new(self)
     end
     end
     if my_hand.rank > your_hand.rank
     puts 'I win!'
     end


     View Slide

129. class Card::Rank
     ORDER = (
     TWO, THREE, FOUR, FIVE,
     SIX, SEVEN, EIGHT, NINE,
     TEN, JACK, QUEEN, KING, ACE = 13.times.map { new }
     )
     def succ
     ORDER[ORDER.index(self).succ]
     end
     end


     View Slide

130. View Slide

131. View Slide

132. low
     high


     View Slide

133. class Card::Rank
     ORDER = (
     TWO, THREE, FOUR, FIVE,
     SIX, SEVEN, EIGHT, NINE,
     TEN, JACK, QUEEN, KING, ACE = 13.times.map { new }
     )
     def succ
     ORDER[ORDER.index(self).succ % ORDER.size]
     end
     end


     View Slide

134. “DESIGN”?


     View Slide

135. When a thing looks complicated,
     it’s possible that we’re looking at
     it wrong and missing some of the
     pieces of the puzzle.”
     — Richard Feynman
     “


     View Slide

136. HOW?


     View Slide

137. FIND THE
     HONEST
     ABSTRACTION


     View Slide

138. FIND THE
     MINIMAL
     ABSTRACTION


     View Slide

139. FIND THE
     INTERESTING THING
     INSIDE THE
     BORING THING


     View Slide

140. BE EXCITED!


     View Slide

141. KEEP YOUR
     PERSPECTIVE


     View Slide

142. IF YOU CAN
     WRITE A PROGRAM,
     YOU’RE GOOD
     AT MATHEMATICS.


     View Slide

143. SORRY!*
     * not sorry


     View Slide

144. THANKS
     @tomstuart, tom@codon.com, http:/
     /codon.com/


     View Slide
