HEVC Video with Alpha Channel @TachibanaKaoru 2019/7/24 #potatotips
About Me @TachibanaKaoru Freelance iOS Engineer झຯɿϘϧμϦϯάɺBotWͰཾͷྡྷङ ࠷ۙͷςʔϚɿཱྀΛ͠ͳ͕ΒࣄΛ͢Δ όϦౡɺαϯτϦʔχౡɺόϯίΫɺόϧηϩφɺΞΠεϥϯυ
Alpha Channel alpha channel each pixel include transparency information popular
in images
Alpha Channel alpha channel each pixel include transparency information popular
in images
video codec support alpha channel Apple ProRes 4444 WebM VP8
media with alpha Image Video High bitrate PNG, TIFF Apple
ProRes 4444 Flexible bitrate HEIF, HEIFS HEVC with alpha
HEVC support os iOS 13~ tvOS13 ~ macOS Catalina ~
Playback AVPlayerͰͷ࠶ੜ
Demo Sample Code https://github.com/TachibanaKaoru/ HEVCAlphaSample
Encoding HEVC video with API Color Chroma key from Apple
ProRes 4444 to HEVC with alpha
Color Chroma key
let asset = AVAsset(url: sourceURL) guard let exportSession = AVAssetExportSession(asset:
asset, presetName: AVAssetExportPresetHEVCHighestQualityWithAlpha) else { print("Failed to create export session to HEVC with alpha.") handleExportCompletion(.failed) return } // Make CIFilter let filter = makeChromaKeyFilter(usingHueFrom: 0.3, to: 0.4, brightnessFrom: 0.05, to: 1.0 ) let chromaKeyComposition = AVVideoComposition(asset: asset, applyingCIFiltersWithHandler: { request in let source = request.sourceImage.clampedToExtent() filter.setValue(source, forKey: kCIInputImageKey) let output = filter.outputImage! // Provide the filter output to the composition request.finish(with: output, context: nil) }) // Export exportSession.outputURL = destinationURL exportSession.outputFileType = .mov exportSession.videoComposition = chromaKeyComposition exportSession.exportAsynchronously { handleExportCompletion(exportSession.status) }
let asset = AVAsset(url: sourceURL) guard let exportSession = AVAssetExportSession(asset:
asset, presetName: AVAssetExportPresetHEVCHighestQualityWithAlpha) else { print("Failed to create export session to HEVC with alpha.") handleExportCompletion(.failed) return } // Make CIFilter let filter = makeChromaKeyFilter(usingHueFrom: 0.3, to: 0.4, brightnessFrom: 0.05, to: 1.0 ) let chromaKeyComposition = AVVideoComposition(asset: asset, applyingCIFiltersWithHandler: { request in let source = request.sourceImage.clampedToExtent() filter.setValue(source, forKey: kCIInputImageKey) let output = filter.outputImage! // Provide the filter output to the composition request.finish(with: output, context: nil) }) // Export exportSession.outputURL = destinationURL exportSession.outputFileType = .mov exportSession.videoComposition = chromaKeyComposition exportSession.exportAsynchronously { handleExportCompletion(exportSession.status) }
let asset = AVAsset(url: sourceURL) guard let exportSession = AVAssetExportSession(asset:
asset, presetName: AVAssetExportPresetHEVCHighestQualityWithAlpha) else { print("Failed to create export session to HEVC with alpha.") handleExportCompletion(.failed) return } // Make CIFilter let filter = makeChromaKeyFilter(usingHueFrom: 0.3, to: 0.4, brightnessFrom: 0.05, to: 1.0 ) let chromaKeyComposition = AVVideoComposition(asset: asset, applyingCIFiltersWithHandler: { request in let source = request.sourceImage.clampedToExtent() filter.setValue(source, forKey: kCIInputImageKey) let output = filter.outputImage! // Provide the filter output to the composition request.finish(with: output, context: nil) }) // Export exportSession.outputURL = destinationURL exportSession.outputFileType = .mov exportSession.videoComposition = chromaKeyComposition exportSession.exportAsynchronously { handleExportCompletion(exportSession.status) }
from Apple ProRes 4444 to HEVC with alpha
let asset = AVAsset(url: sourceURL) AVAssetExportSession.determineCompatibility(ofExportPreset: AVAssetExportPresetHEVCHighestQualityWithAlpha, with: asset, outputFileType:
.mov) { compatible in if compatible { guard let exportSession = AVAssetExportSession(asset: asset, presetName: AVAssetExportPresetHEVCHighestQualityWithAlpha) else { handleExportCompletion(.failed) return } // Export exportSession.outputURL = destinationURL exportSession.outputFileType = .mov exportSession.exportAsynchronously { handleExportCompletion(exportSession.status) } } else { handleExportCompletion(.failed) } }
let asset = AVAsset(url: sourceURL) AVAssetExportSession.determineCompatibility(ofExportPreset: AVAssetExportPresetHEVCHighestQualityWithAlpha, with: asset, outputFileType:
.mov) { compatible in if compatible { guard let exportSession = AVAssetExportSession(asset: asset, presetName: AVAssetExportPresetHEVCHighestQualityWithAlpha) else { handleExportCompletion(.failed) return } // Export exportSession.outputURL = destinationURL exportSession.outputFileType = .mov exportSession.exportAsynchronously { handleExportCompletion(exportSession.status) } } else { handleExportCompletion(.failed) } }
let asset = AVAsset(url: sourceURL) AVAssetExportSession.determineCompatibility(ofExportPreset: AVAssetExportPresetHEVCHighestQualityWithAlpha, with: asset, outputFileType:
.mov) { compatible in if compatible { guard let exportSession = AVAssetExportSession(asset: asset, presetName: AVAssetExportPresetHEVCHighestQualityWithAlpha) else { handleExportCompletion(.failed) return } // Export exportSession.outputURL = destinationURL exportSession.outputFileType = .mov exportSession.exportAsynchronously { handleExportCompletion(exportSession.status) } } else { handleExportCompletion(.failed) } }
·ͱΊ HEVCiOS13͔Β͑ΔAlpha͖ͭಈըϑΥʔϚοτͰ͢ɻ ࠶ੜAVPlayerWKWebViewͰ؆୯ʹͰ͖·͢ɻ SpriteKitɺSceneKitɺMetalͰ࠶ੜՄೳɻARͰ͑·͢ɻ
Links HEVC Video with Alpha https://developer.apple.com/videos/play/wwdc2019/506/ Using HEVC Video with
Alpha https://developer.apple.com/documentation/avfoundation/ media_assets_playback_and_editing/using_hevc_video_with_alpha HEVC Video with Alpha https://developer.apple.com/av-foundation/HEVC-Video-with-Alpha-Interoperability- Profile.pdf
