MVVM Architecture at Timehop

In this talk, I discuss how we've used MVVM in the Timehop iOS app to create a robust and modular app architecture.

I start by walking through the basics of MVVM in a very simple example app called Userlist.

Next, I detail how the image loading subsystem works in the Timehop app.

Finally, I answer some questions about how Timehop works behind the scenes.

Transcript

1. CHRIS TROTT
   @TWOCENTSTUDIOS
   MVVM ARCHITECTURE
   AT TIMEHOP


   View Slide

2. View Slide

3. View Slide

4. 100K 1M 10M


   View Slide

5. LET’S TALK ABOUT
   ARCHITECTURE


   View Slide

6. Architecture Examples
   • Apple?
   • Open source?
   • Other platforms?
   • Large scale? Small scale?


   View Slide

7. LET’S TALK ABOUT
   MVVM


   View Slide

8. MVVM
   Model View View Model


   View Slide

9. VVMM
   View - View Model - Model


   View Slide

10. Why MVVM?
    • Isolation
    • Reusability
    • Refactorability
    • Testability
    • Predictability


    View Slide

11. VIEWS SHOULD BE
    DUMB


    View Slide

12. VIEWS SHOULD BE
    DUMB SMART
    (ABOUT VIEW STUFF)


    View Slide

13. PUT YOUR SMARTS IN THE
    VIEW MODEL


    View Slide

14. HOW DO WE
    MVVM
    @ TIMEHOP?


    View Slide

15. REACTIVECOCOA + MVVM = ❤️


    View Slide

16. EXAMPLE 1
    Userlist
    https://github.com/timehop/Userlist


    View Slide

17. Ownership
    Data Flow
    VIEW
    VIEW
    MODEL
    CONTROLLER
    DATA
    SOURCE
    VIEW
    VIEW
    MODEL
    CONTROLLER
    DATA
    SOURCE
    RAW
    MODEL
    MODEL
    VIEW
    MODEL


    View Slide

18. Userlist Ownership
    UserController
    UsersViewModel
    UserViewModel
    User
    UserViewModel
    UserViewModel
    UserViewModel
    UsersViewController
    UserCell
    UserCell
    UserCell
    UserCell
    smarter
    dumber


    View Slide

19. Controllers
    • Not UIViewControllers!
    • PONSOs (plain old NSObjects)
    • Convert Raw Models to
    Models
    • Can’t manipulate View Models


    View Slide

20. Userlist Ownership
    UserController
    UsersViewModel
    UserViewModel
    User
    UserViewModel
    UserViewModel
    UserViewModel
    UsersViewController
    UserCell
    UserCell
    UserCell
    UserCell
    smarter
    dumber


    View Slide

21. // User.h
    @interface User : NSObject
    @property (nonatomic, readonly) NSString *name;
    @property (nonatomic, readonly) NSURL *avatarURL;
    - (instancetype)initWithName:(NSString *)name avatarURL:
    (NSURL *)avatarURL;
    @end


    View Slide

22. // UserController.h
    @interface UserController : NSObject
    /// Sends an array of fabricated User objects then completes.
    - (RACSignal *)fetchRandomUsers:(NSUInteger)numberOfUsers;
    @end


    View Slide

23. View Models
    • PONSOs or helper superclass
    • Convert Models to View Models
    • Expose data as observable
    properties
    • Accept events from owners as
    methods or blocks
    • Can’t manipulate Views


    View Slide

24. Userlist Ownership
    UserController
    UsersViewModel
    UserViewModel
    User
    UserViewModel
    UserViewModel
    UserViewModel
    UsersViewController
    UserCell
    UserCell
    UserCell
    UserCell
    smarter
    dumber


    View Slide

25. // UserViewModel.h
    @interface UserViewModel : NSObject
    @property (nonatomic, readonly) NSString *name;
    @property (nonatomic, readonly) UIImage *avatarImage;
    /// Initiate the avatarImage fetch.
    @property (nonatomic, getter=isActive) BOOL active;
    - (instancetype)initWithUser:(User *)user;
    @end


    View Slide

26. // UsersViewModel.h
    @interface UsersViewModel : NSObject
    /// Array of UserViewModel objects.
    /// NSArray
    @property (nonatomic, readonly) NSArray *userViewModels;
    @property (nonatomic, readonly, getter=isLoading) BOOL loading;
    @property (nonatomic, getter=isActive) BOOL active;
    /// Initiate a fetch.
    - (void)fetchRandomUsers;
    @end


    View Slide

27. Views
    • UIViews and UIViewControllers
    • Final conversion to UI
    • Bind to View Models and native
    properties
    • Pass events to View Models
    • Can’t see Models


    View Slide

28. Userlist Ownership
    UserController
    UsersViewModel
    UserViewModel
    User
    UserViewModel
    UserViewModel
    UserViewModel
    UsersViewController
    UserCell
    UserCell
    UserCell
    UserCell
    smarter
    dumber


    View Slide

29. // UserCell.h
    @interface UserCell : UITableViewCell
    @property (nonatomic) UserViewModel *viewModel;
    @end


    View Slide

30. // UserCell.m
    - (instancetype)initWithStyle:(UITableViewCellStyle)style reuseIdentifier:
    (NSString *)reuseIdentifier {
    self = [super initWithStyle:style reuseIdentifier:reuseIdentifier];
    if (self != nil) {
    RAC(self.imageView, image) = RACObserve(self, viewModel.avatarImage);
    RAC(self.textLabel, text) = RACObserve(self, viewModel.name);
    }
    return self;
    }


    View Slide

31. // UsersViewController.h
    @interface UsersViewController : UITableViewController
    @property (nonatomic, readonly) UsersViewModel *viewModel;
    - (instancetype)initWithViewModel:(UsersViewModel *)viewModel;
    @end


    View Slide

32. // UsersViewController.m
    - (void)viewDidLoad {
    [super viewDidLoad];
    [self.tableView
    registerClass:[UserCell class]
    forCellReuseIdentifier:NSStringFromClass([UserCell class])];
    @weakify(self);
    [[RACObserve(self.viewModel, userViewModels)
    ignore:nil]
    subscribeNext:^(id _) {
    @strongify(self);
    [self.tableView reloadData];
    }];
    }


    View Slide

33. // UsersViewController.m
    # pragma mark UITableViewDataSource
    - (NSInteger)tableView:(UITableView *)tableView
    numberOfRowsInSection:(NSInteger)section {
    return [self.viewModel.userViewModels count];
    }
    - (UITableViewCell *)tableView:(UITableView *)tableView
    cellForRowAtIndexPath:(NSIndexPath *)indexPath {
    UserCell *cell = [tableView
    dequeueReusableCellWithIdentifier:NSStringFromClass([UserCell
    class]) forIndexPath:indexPath];
    UserViewModel *viewModel =
    self.viewModel.userViewModels[indexPath.row];
    cell.viewModel = viewModel;
    return cell;
    }


    View Slide

34. // UsersViewController.m
    # pragma mark UITableViewDelegate
    - (void)tableView:(UITableView *)tableView willDisplayCell:
    (UITableViewCell *)cell forRowAtIndexPath:(NSIndexPath
    *)indexPath {
    UserCell *userCell = (UserCell *)cell;
    userCell.viewModel.active = YES;
    }
    - (void)tableView:(UITableView *)tableView
    didEndDisplayingCell:(UITableViewCell *)cell
    forRowAtIndexPath:(NSIndexPath *)indexPath {
    UserCell *userCell = (UserCell *)cell;
    userCell.viewModel.active = NO;
    }


    View Slide

35. Ownership
    Data Flow
    VIEW
    VIEW
    MODEL
    CONTROLLER
    DATA
    SOURCE
    VIEW
    VIEW
    MODEL
    CONTROLLER
    DATA
    SOURCE
    RAW
    MODEL
    MODEL
    VIEW
    MODEL


    View Slide

36. // Raw Model
    @{
    @“name” = @“Taylor Switch”,
    @“avatarURL” = @“http://example.com/taylor_switch.jpg”
    }
    // Model
    @interface User : NSObject
    @property (nonatomic, readonly) NSString *name;
    @property (nonatomic, readonly) NSURL *avatarImageURL;
    @end
    // View Model
    @interface UserViewModel : NSObject
    @property (nonatomic, readonly) NSString *name;
    @property (nonatomic, readonly) UIImage *avatarImage;
    @end
    // View
    @interface UserCell ()
    @property (nonatomic, readonly) UILabel *textLabel;
    @property (nonatomic, readonly) UIImageView *imageView;
    @end


    View Slide

37. EXAMPLE 2
    Image System
    @ Timehop


    View Slide

38. Image System Data Flow
    PROGRESS
    VIEW
    VIEW
    MODEL
    CONTROLLER
    DATA
    SOURCE


    View Slide

39. // ImageController.h
    @interface ImageController : NSObject
    - (instancetype)initWithWebImageManager:(SDWebImageManager *)webImageManager imageManager:
    (PHImageManager *)imageManager cachingImageManager:(PHCachingImageManager
    *)cachingImageManager;
    /// Sends RACTuple(UIImage *downloadedImage, NSNumber *progress)
    /// at unspecified intervals, where progress is a double == 0..1,
    /// and downloadedImage in nil for 0..0.99 and
    /// the complete image for progress == 1.
    ///
    /// Sends RACTuple(nil, @1) if imageURL is nil.
    ///
    /// Sends complete when the final representation of the image has
    /// been returned.
    - (RACSignal *)imageAndProgressWithURL:(NSURL *)imageURL;


    View Slide

40. // ImageViewModel.h
    @interface ImageViewModel : ViewModel
    /// The latest image downloaded from imageURL. May be nil.
    @property (nonatomic, readonly) UIImage *image;
    /// The progress of the current download.
    @property (nonatomic, readonly) CGFloat progress;
    /// ErrorViewModel encapsulates any download error.
    @property (nonatomic, readonly) BOOL hasError;
    @property (nonatomic, readonly) ErrorViewModel *errorViewModel;
    /// Whether any download operation is in progress.
    @property (nonatomic, readonly, getter=isLoading) BOOL loading;
    /// The View layer should call this block when a user taps the image view.
    /// If an image exists and there is no error, it will call `openImageURLBlock`.
    /// If an error exists, it will try to fetch the image again.
    @property (nonatomic, readonly) void (^selectBlock)(void);
    /// Exists on ViewModel superclass.
    /// Setting active to YES triggers the image load unless the image
    /// has already been fetched.
    @property (nonatomic, getter=isActive) BOOL active;
    @property (nonatomic, readonly) NSURL *imageURL;
    - (instancetype)initWithImageURL:(NSURL *)imageURL openImageURLBlock:(void (^)
    (NSURL *))openImageURLBlock imageController:(ImageController *)imageController;


    View Slide

41. // ImageProgressView.h
    /// * Updates the image to the latest value of viewModel.image.
    /// * Shows progress before first image is loaded.
    /// * Shows error view on error.
    /// * Handles taps.
    @interface ImageProgressView : UIView
    @property (nonatomic) ImageViewModel *viewModel;
    @end
    /// ImageView.h
    /// * Updates the image to the latest value of viewModel.image.
    @interface ImageView : UIImageView
    @property (nonatomic) ImageViewModel *viewModel;
    @end


    View Slide

42. // SDWebImageManager+RACSignalSupport.m
    - (RACSignal *)rac_imageAndProgressWithURL:(NSURL *)url options:
    (SDWebImageOptions)options {
    return [RACSignal createSignal:^RACDisposable *(id subscriber) {
    id operation =
    [self downloadImageWithURL:url
    options:options
    progress:^(NSInteger receivedSize, NSInteger expectedSize) {
    if (expectedSize > 0 && receivedSize < expectedSize) {
    [subscriber sendNext:RACTuplePack(nil, @(receivedSize/
    (CGFloat)expectedSize))];
    }
    }
    completed:^(UIImage *image, NSError *error, SDImageCacheType
    cacheType, BOOL finished, NSURL *imageURL) {
    if (error != nil) {
    [subscriber sendError:error];
    }
    [subscriber sendNext:RACTuplePack(image, @1)];
    if (finished) {
    [subscriber sendCompleted];
    }
    }];
    return [RACDisposable disposableWithBlock:^{
    [operation cancel];
    }];
    }];
    }


    View Slide

43. EXAMPLE 3
    Issues & Content
    @ Timehop


    View Slide

44. IssueViewModel
    AlbumViewModel
    UserContentViewModel
    ContentBlockViewModel


    View Slide

45. • IssueViewModel
    • AlbumViewModel[]
    • UserContentViewModel[]
    • ContentBlockViewModel


    View Slide

46. • IssueViewModel
    • AlbumViewModel[]
    • UserContentViewModel[]
    • ContentMetadataViewModel
    • AlbumMetadataViewModel
    • PhotoAlbumViewModel
    • ImageViewModel[]
    • VideoViewModel
    • ImageViewModel
    • TextLinksViewModel
    • EventViewModel
    • LocationViewModel
    • LinkViewModel
    • ImageViewModel
    • InteractionsViewModel
    • SourceActionViewModel
    • ShareViewModel


    View Slide

47. How does a Timehop Issue get loaded?
    VIEW
    VIEW
    MODEL
    CONTROLLER
    DATA
    SOURCE
    NSDICTIONARY
    ISSUE
    VIEWMODELS[]
    ACTIVE
    @YES
    DATEKEY
    “20150309”
    URL
    “/ISSUES/20150309”


    View Slide

48. What happens when you scroll the table view?
    UserContentCell
    TextLinksSlimView
    …
    UserContentViewModel
    TextLinksViewModel
    …
    UserContentViewModel
    TextLinksViewModel
    …
    UserContentViewModel
    TextLinksViewModel
    …


    View Slide

49. What happens when you scroll the table view?
    - (void)tableView:(UITableView *)tableView didEndDisplayingCell:
    (UITableViewCell *)cell forRowAtIndexPath:(NSIndexPath *)indexPath {
    UserContentCell *userContentCell = (UserContentCell *)cell;
    userContentCell.viewModel.active = NO;
    }
    UserContentCell
    TextLinksSlimView
    …
    UserContentViewModel
    TextLinksViewModel
    …
    UserContentViewModel
    TextLinksViewModel
    …


    View Slide

50. What happens when you scroll the table view?
    - (UITableViewCell *)tableView:(UITableView *)tableView cellForRowAtIndexPath:(NSIndexPath
    *)indexPath {
    UserContentCell *cell = [tableView
    dequeueReusableCellWithIdentifier:NSStringFromClass([UserContentCell class])
    forIndexPath:indexPath];
    AlbumViewModel *albumViewModel = self.viewModel.viewModels[indexPath.section];
    UserContentViewModel *userContentViewModel =
    albumViewModel.userContentViewModels[indexPath.row];
    cell.viewModel = userContentViewModel;
    return cell;
    }
    UserContentCell
    TextLinksSlimView
    …
    UserContentViewModel
    TextLinksViewModel
    …
    UserContentViewModel
    TextLinksViewModel
    …


    View Slide

51. What happens when you scroll the table view?
    - (void)tableView:(UITableView *)tableView willDisplayCell:
    (UITableViewCell *)cell forRowAtIndexPath:(NSIndexPath *)indexPath
    {
    UserContentCell *userContentCell = (UserContentCell *)cell;
    userContentCell.viewModel.active = YES;
    }
    UserContentCell
    TextLinksSlimView
    …
    UserContentViewModel
    TextLinksViewModel
    …
    UserContentViewModel
    TextLinksViewModel
    …


    View Slide

52. What happens when you tap a location view?


    View Slide

53. IssueViewModel
    What happens when you tap a location view?
    IssueViewController
    UserContentCell
    LocationView
    AlbumViewModel
    UserContentViewModel
    LocationViewModel
    *tap*
    Location
    View
    Controller


    View Slide

54. IssueViewModel
    What happens when you tap a location view?
    IssueViewController
    UserContentCell
    LocationView
    AlbumViewModel
    UserContentViewModel
    LocationViewModel
    *tap*
    Location
    LocationViewModel
    LocationViewModel
    Location
    View
    Model
    Location
    View
    Controller


    View Slide

55. What happens when you tap a link view?


    View Slide

56. IssueViewModel
    What happens when you tap a link view?
    IssueViewController
    UserContentCell
    LinkSlimView
    AlbumViewModel
    UserContentViewModel
    LinkViewModel
    *tap*
    WebView
    Controller


    View Slide

57. IssueViewModel
    What happens when you tap a link view?
    IssueViewController
    UserContentCell
    LinkSlimView
    AlbumViewModel
    UserContentViewModel
    LinkViewModel
    *tap*
    Link
    WebViewModel
    WebViewModel
    WebView
    Model
    WebView
    Controller


    View Slide

58. // IssueViewController.m
    - (void)viewDidLoad {
    [self.viewModel.presentableViewModelSignal subscribeNext:^(ViewModel *viewModel) {
    if ([viewModel isKindOfClass:[LocationViewModel class]]) {
    LocationViewController *locationViewController = [[LocationViewController
    alloc] initWithViewModel:viewModel];
    [self.navigationController pushViewController:locationViewController
    animated:YES];
    } else if ([viewModel isKindOfClass:[InteractionsDetailViewModel class]]) {
    InteractionsDetailViewController *interactionsDetailViewController =
    [[InteractionsDetailViewController alloc] initWithViewModel:viewModel];
    [self.navigationController pushViewController:interactionsDetailViewController
    animated:YES];
    } else if ([viewModel isKindOfClass:[WebViewModel class]]) {
    WebViewController *webViewController = [[WebViewController alloc]
    initWithViewModel:viewModel];
    [self.navigationController pushViewController:webViewController animated:YES];
    } else if ([viewModel isKindOfClass:[EventDetailViewModel class]]) {
    EventDetailViewController *eventViewController = [[EventDetailViewController
    alloc] initWithViewModel:viewModel];
    [self.navigationController pushViewController:eventViewController
    animated:YES];
    }
    }];
    }


    View Slide

59. Learn more
    • http://www.sprynthesis.com/2014/12/06/
    reactivecocoa-mvvm-introduction/
    • https://github.com/timehop/userlist
    • https://github.com/twocentstudios/longtail
    • https://github.com/edc1591/Bikes
    • https://github.com/jspahrsummers/
    GroceryList


    View Slide

60. QUESTIONS?


    View Slide

61. INTERESTED IN
    REACTIVECOCOA & MVVM?
    TIMEHOP IS HIRING


    View Slide
