Ros Testing Tutorial

A tutorial about Testing in ROS that I gave to the members of my lab.
Code Examples and Exercises in: https://github.com/VGonPa/ros-testing-tutorial

Transcript

1. A Gentle Introduction to Gtest Víctor González Pacheco victor.gonzalez.pacheco@gmail.com March 2014 Test Driven Development in ROS
2. Outline What to expect Motivation Testing Levels Writing your first tests Advice on making good tests Resources Exercise
3. Start with an example Download material at: https://github.com/VGonPa/ros-testing-seminar git clone https://github.com/VGonPa/ros-testing-seminar.git
4. What to expect from this seminar
5. What to expect “Will I become a TDD master with this seminar?”
6. “Actually you might, eventually, if you start writing tests today!”
7. What to expect You will learn where to start, the basics, and where to find more information and help.
8. Motivation
9. Motivation "Tests + Programming" is faster than just "Programming" [1]
10. Motivation SW Evolves Requirements change Bug corrections Optimizations Improvements on design How do you know if a change in your code didn’t break your previous work?
11. Motivation NOT testing is very dangerous: “(Making large changes without tests) is like doing aerial gymnastics without a net.” [1] The later you detect a bug, the more expensive is to fix it: A bug detected in production may be REALLY expensive Let alone if tomorrow you have a demo!
12. Motivation Some advantages of writing tests It forces you to design better code Faster incremental upgrades A clear metric of your progress It lets you refactor with greater confidence Prevents recurring bugs It enables you to blame others! Other people can work with your code more easily
13. Motivation The worst disadvantage It will affect your thinking process... ...and your programming style. But you will become a better programmer!
14. Motivation “I don’t have time to write tests!” Had you done the tests before, now you'd have time to do them! More tests = less time debugging More tests = more time to program features
15. Test Driven Development (TTD) The process Before programming, write tests Write only the needed code to make the tests pass Refactor to eliminate duplicated code, etc. Repeat
16. Test Driven Development (TTD) “Do I really need to write tests first?” It’s much better to write them first, but if you don’t, be sure that your code is properly tested
17. Testing Levels
18. Imagine a simple scenario N1 N2
19. Each node has its own code... N1 N2
20. This is better... N1 N2
21. There you have the first level N1 N2 Library Unit Testing
22. Library Unit testing N1 Library Unit Testing Test only your libraries Code must be ROS Agnostic GTest/Unittest(python)
23. Library Unit testing N1 Test each component separately
24. Library Unit Testing N1 Test for: common cases extreme cases Input errors methods pre and post conditions
25. Now let’s test the node itself N1 N2 Node Level Testing
26. Node Level Unit testing N1 Node Level Testing Test Node start/shutdown Test Node external API services, published topics, subscribed topics (params?) RosTest + GTest/Unittest
27. And, finally, the whole system N1 N2 Integration/Regression Testing
28. Integration Testing N1 N2 Test multiple nodes working as expected RosTest + GTest/Unittest
29. Testing Levels: Overview N1 N2 Library Unit Testing Node Level Testing Integration/Regression Testing
30. Writing your first tests in ROS
31. Gtest and rostest ROS provides two tools for executing tests: gtest and rostest
32. GTest Google’s tool for unit testing Regular cpp files Executed with any of the following: ./my_test_file make test # needs macro in CMakeLists.txt rosmake <package_name> -t # needs macro in CMakeLists.txt http://wiki.ros.org/gtest Gtest and rostest
33. GTest Gtest tutorials are quite good. We won’t cover them here. Read them if you don’t know how to write Gtests. Gtest and rostest
34. Gtest and rostest rostest roslaunch extension to launch tests .launch syntax with added <test> tag executed with any of the following: rostest <pgk_name> <test_name>.test make test # needs macro in CMakeLists.txt rosmake <package_name> -t # needs macro in CMakeLists.txt http://wiki.ros.org/rostest http://wiki.ros.org/rostest/Writing http://wiki.ros.org/roslaunch/XML/test <------ <test> tag reference
35. Where should I use each one? N1 N2 Node Integration/Regression Library Gtest Rostest (+ Gtest)
36. Package structure with tests my_ros_pkg/ CMakeLists.txt bin/ build/ msg/ ... src/ test/ <--- gtests go here test/ <--- rostests go here
37. Installation GTest Install: bash> sudo apt-get install libgtest-dev In your header files: #include <gtest/gtest.h> GMock Install bash> sudo apt-get install google-mock In your header files: #include <gmock/gmock.h>
38. Gtest CMakeLists.txt # add gtest rosbuild_add_gtest(test/my_test test/mytest.cpp [other sources]) # link required libraries target_link_libraries(test/mytest linked_libraries)
39. rostest CMakeLists.txt # add the test executable, # keep it from being built by "make all" rosbuild_add_executable(test_mynode EXCLUDE_FROM_ALL src/test/test_mynode.cpp) # Link test_mynode against gtest # and add a dependency to the "test" target rosbuild_add_gtest_build_flags(test_mynode) # Make sure rostest launches test/mynode.test during "make test" rosbuild_add_rostest(test/mynode.test)
40. Let’s see an example Checkout the package rostest_node_example from the material
41. Some advise How to make good tests
42. What to test Example: max(list_of_ints) Normal cases max([10,3,0,-1,8]) Extreme cases max([3,3,3,3,3,3]) max(2) Error cases max([‘aaa’,3,nan,None]) max([])
43. What not to test The test itself Modules that cannot be broken (or that there is no solution): System calls Hardware failures Modules from which your code depends on: Standard Libraries, modules written by others, etc. They already have (or should have) their own tests Exhaustive tests
44. Writing more “testable” code Sometimes it’s difficult to test a component in isolation Dependencies between components Some components might be on the network (eg. sockets) Some components might needuser input Some comopnents might just be slow to test
45. Writing more “testable” code Solution: Break dependencies Program against interfaces Specify dependencies in the constructor Use mocks in your tests
46. Common features of good tests A good test should be: Independent 1. You do not need to read other tests to understand what a test does 2. If a test fails, it should be easy to find the bug 3. Each test focuses on a single aspect Repetible Quick: Use mocks Small: Enables you to easily spot bugs. Big tests functions have many parts affecting each other
47. Beware the Unit-Integration Chimera! Unit Testing Sweet spot Integration Testing Sweet spot It will eat your productivity!
48. Bibliography and Resources
49. Bibliography and Resources B. Eckel, "Thinking in C++ Volume 2". (online version) Google C++ Testing Framework project Project: http://code.google.com/p/googletest/ Guía inicial: http://code.google.com/p/googletest/wiki/V1_6_Primer Avanzado: http://code.google.com/p/googletest/wiki/V1_6_AdvancedGuide Ejemplos: http://code.google.com/p/googletest/wiki/V1_6_Samples Dependency injection, mocks: Google Mock: http://code.google.com/p/googlemock/
50. Bibliography and Resources ROS Unit Testing: http://wiki.ros.org/UnitTesting ROS GTest: http://wiki.ros.org/gtest ROS rostest: http://wiki.ros.org/rostest
51. Bibliography and Resources This seminar has been greatly inspired from this talk from Zhanyong Wan: Effective C++ Testing Using Google Test There you will find more information regarding Gtest and Unit testing in general
52. Questions? https://github.com/VGonPa/ros-testing-seminar
53. Excercise
54. 1. Counter node’s counter should be initiated by parameter to any number 2. Factorial calculates factorial of counter 3. Test the library, node and integration using gtest + rostests counter_node factorial_node /counter /factorial /do_increment
55. This seminar is licensed under the Creative Commons license CC Attribution 4.0 International You are free to use and adapt this presentation as long as you give credit to the author. More information can be found here: http://creativecommons.org/licenses/by/4.0/
