Interactive and Active Learning in Social Robots

Slides of my PhD Thesis, entitled "Interactive and Active Learning in Social Robots.

Videos, code, datasets, etc. can be downloaded at:
https://github.com/VGonPa/interactive_and_active_learning

Transcript

1. INTERACTIVE AND ACTIVE LEARNING FOR SOCIAL ROBOTICS Víctor González Pacheco Advisers: Miguel Ángel Salichs María Malfaz Leganés, November 2015
2. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
3. INTRODUCTION
4. THE NEED OF LEARNING IN ROBOTICS 4
5. THE NEED OF LEARNING IN ROBOTICS 4
6. HOW SHOULD ROBOTS LEARN? 5
7. HOW SHOULD ROBOTS LEARN? 5
8. OPEN CHALLENGES Interaction During Learning Label acquisition Deciding when to finish the training Detecting novel concepts that require more training 6 Generally very simple Complex task Why not let the robot take this decision? Novelty detection in robotics
9. OBJECTIVES OF THE THESIS “To develop a system that enables a social robot to learn interactively in a natural way, similarly to how a person would learn from another person.” 7
10. OBJECTIVES OF THE THESIS Multimodal Interaction for Learning Apply Active Learning for learning new concepts “Robot-driven” learning Let the robot decie how much training does it need Enable the robot to detect new concepts Different domains: Pose and object recognition 8
11. RELATED WORK Interaction in Learning. [Rybski et al., 2007] Flexible interaction, but describe tasks, not concepts. Active Learning. Mostly in learning skills. [Rosenthal et al., 2009, 2012], [Cakmak and Thomaz, 2012; Cakmak et al., 2010] AL for concept acquisition We study the impact of innacurate user answers 9
12. RELATED WORK Novelty Detection in robotics Video surveillance [Drews et al., 2013] Room Semantics acquisition [Pinto et al., 2011] We use to detect new concepts to learn 10
13. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
14. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
15. INTERACTIVE LEARNING LEARNING POSES
16. OBJECTIVE To endow a social robot with interactive learning capabilities. 14
17. PLATFORM: Maggie 15
18. SYSTEM OVERVIEW: TRAINING I'm Turned Right ASR "T-Right" Dataset Machine Learning MODEL Kinect What's my pose? You're turned right Pose Classifier TTS Kinect 16
19. SYSTEM OVERVIEW: EXPLOITATION I'm Turned Right ASR "T-Right" Dataset Machine Learning MODEL Kinect What's my pose? You're turned right Pose Classifier TTS Kinect 17
20. SYSTEM OVERVIEW I'm Turned Right ASR "T-Right" Dataset Machine Learning MODEL Kinect What's my pose? You're turned right Pose Classifier TTS Kinect 18
21. KINECT SKELETON MODEL Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot 15 Joints 7 Parameters per joint: (x, y, z, qx, qy, qz, qw) 19
22. GRAMMAR-BASED INTERACTION Two different grammars: Pose definition (up to 9 poses): “I’m standing up, looking to my right.” “Look, Maggie. I am looking towards my right.” Control of the sessions/phases: “Start recording a pose.” “Stop recording.” “End session.” 20
23. SCENARIO DESCRIPTION 180 cm 240 cm 180 cm Robot User User Area Kinect's Field of View 21
24. SCENARIO DESCRIPTION 24 Training Users Teaching 9 poses: Turned (L, F, R) Looking (L, F, R) Pointing (L, F, R) 22
25. SCENARIO DESCRIPTION 24 Training Users Teaching 9 poses: Turned (L, F, R) Looking (L, F, R) Pointing (L, F, R) 22
26. SCENARIO DESCRIPTION 24 Training Users Teaching 9 poses: Turned (L, F, R) Looking (L, F, R) Pointing (L, F, R) 22
27. VIDEO 23
28. VIDEO 23
29. RESULTS 24 TURNED LOOKING POINTING F1 Score Training Users Training Users Training Users J48 RForest SMO
30. CONCLUSION Robot is able to learn by interacting with the user. Grammar-based interaction. It’s powerful, but a bit inflexible: Max. num poses set by grammar programmer 25
31. PUBLISHED RESULTS 26 This section presents a list of journals that have been published during this thesis. The three journals are indexed in the Journal Citation Reports (JCR), being one in the first quartile (Q1) and two in the third quartile (Q3). • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. a. Salichs, “Novelty Detection for Interactive Pose Recognition by a Social Robot,” Int. J. Adv. Robot. Syst., vol. 12, no. 43, p. 1, 2015. • V. Gonzalez-Pacheco, M. Malfaz, F. Fernandez, and M. A. Salichs, “Teaching hu- man poses interactively to a social robot,” Sensors, vol. 13, no. 9, pp. 12406–12430, 2013. • V. Gonzalez-Pacheco, A. Ramey, F. Alonso-Martin, A. Castro-Gonzalez, and M. A. Salichs, “Maggie: A Social Robot as a Gaming Platform,” Int. J. Soc. Robot., vol. 3, no. 4, pp. 371–381, Sep. 2011. 8.4.2 Conferences and Talks • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. A. Salichs, “Using novelty detection in HRI: Enabling robots to detect new poses and actively ask for their labels,” in 2014 IEEE-RAS International Conference on Humanoid Robots, 2014, pp. 1110–1115. Studying what and when to ask for Feature Queries,” in Proc of the 8th HRI Pioneers Workshop, 2013, pp. 3–4. • J. Sequeira, P. Lima, A. Saffiotti, V. Gonzalez-Pacheco, and M. A. Salichs, “MOnarCH: Multi-Robot Cognitive Systems Operating in Hospitals,” in Proc of the ICRA 2013 Workshop on Crossing the Reality Gap – From Single to Multi to Many Robot Systems, 2013, p. 1. • A. Valero-Gomez, J. Gonzalez-Gomez, V. Gonzalez-Pacheco, and M. A. Salichs, “Printable creativity in plastic valley UC3M,” in Proceedings of the 2012 IEEE Global Engineering Education Conference (EDUCON), 2012, pp. 1–9. • A. Ramey, V. González-Pacheco, and M. A. Salichs, “Integration of a low-cost RGB-D sensor in a social robot for gesture recognition,” in Proceedings of the 6th international conference on Human-Robot Interaction - HRI ’11, 2011, pp. 229–230. • F. Alonso-Martin, V. Gonzalez-Pacheco, A. Castro-Gonzalez, A. A. Ramey, M. Yébenes, and M. A. Salichs,“Using a social robot as a gaming platform,” in 2nd International Conference on Social Robotics, 2010, pp. 30–39.
32. INTERACTIVE LEARNING LEARNING POSES
33. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
34. INTERACTIVE LEARNING LEARNING OBJECTS
35. OBJECTIVE Apply Interactive Learning in different domain: hand-held object recognition. 30
36. SYSTEM DESCRIPTION: TRAINING Dataset Kinect ROI Locate Hand Extract 2D Features Extract 3D Features Aggregate Point Cloud Kinect Segment ROI around hand Locate Hand Extract 2D Features Extract 3D Features Point Cloud Match 2D Features Match 3D Features ID OBJECT RGB 31
37. SYSTEM DESCRIPTION: EXPLOITATION Dataset Kinect ROI Locate Hand Extract 2D Features Extract 3D Features Aggregate Point Cloud Kinect Segment ROI around hand Locate Hand Extract 2D Features Extract 3D Features Point Cloud Match 2D Features Match 3D Features ID OBJECT RGB 32
38. SYSTEM DESCRIPTION Dataset Kinect ROI Locate Hand Extract 2D Features Extract 3D Features Aggregate Point Cloud Kinect Segment ROI around hand Locate Hand Extract 2D Features Extract 3D Features Point Cloud Match 2D Features Match 3D Features ID OBJECT RGB 33 OCULAR SYSTEM
39. No speech Arm poses: Extended: learning Folded: recognizing LEARNING INTERACTION 34
40. EXPERIMENT DESCRIPTION Room with mixed natural and artificial light 6 objects Trained with 1, 5 and 10 views per object. 35
41. EXPERIMENT DESCRIPTION Example of different views captured by the system 36
42. RESULTS: LEARNING CURVE 37 0 0,2 0,4 0,6 0,8 1,0 1 View 5 Views 10 Views F1 Score
43. RESULTS COMBINING MATCHERS (10 VIEWS) lator 0.89 0.82 0.85 0.66 0.82 0. l 0.65 0.79 0.71 0.54 0.67 0. able 4.7: F1-score of the RGB and the PC Matchers (10 views per objec F1 Score Object RGB Point Cloud Combined ball 0.62 0.69 0.72 skull 0.67 0.47 0.69 cup 0.61 0.51 0.77 bottle 0.72 0.63 0.89 mobile 0.76 0.53 0.82 calculator 0.85 0.73 0.83 Total 0.71 0.59 0.79 : F1-score comparison for RGB and Point Cloud Matchers combined (10 w = 0.6). 38
44. CONCLUSION System working in real time RGB (2D) prediction performed better than 3D prediction Combining both matchers improves performance System reaches ~80% F1 Score 39
45. INTERACTIVE LEARNING LEARNING OBJECTS
46. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
47. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
48. ACTIVE LEARNING LEARNING POSES
49. MOTIVATION What happens when the robot asks the human and he/she provides an innacurate answer? 44
50. OBJECTIVE Study how the user’s innacurate answers can affect robot learning Domain: pose recognition 45
51. FROM FEATURE QUERIES... Free Speech Queries (FSQ): “Which is the most important limb in this pose?” “Which limbs are important in this case?” Yes/No Queries (YNQ): “Is the hand important?” “Should I pay attention to your head when you are pointing?” Rank Queries (RQ): “How important is your hand?” 46
52. ...TO FEATURE FILTERS Build a Threshold (Th) that is averaged from different answers. Limbs below threshold, are filtered out 47 Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
53. ...TO FEATURE FILTERS Build a Threshold (Th) that is averaged from different answers. Limbs below threshold, are filtered out 47 Example: Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
54. ...TO FEATURE FILTERS Build a Threshold (Th) that is averaged from different answers. Limbs below threshold, are filtered out 47 Example: Users selected: {hand, elbow} Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
55. SCENARIO DESCRIPTION 24 Training Users Teaching 9 poses: Turned (L, F, R) Looking (L, F, R) Pointing (L, F, R) 180 cm 240 cm 180 cm Robot User User Area Kinect's Field of View 48
56. RESULTS: FEATURE FILTERS TURNED 49
57. RESULTS: FEATURE FILTERS LOOKING 50
58. RESULTS: FEATURE FILTERS POINTING 51
59. LEARNING RESULTS LOOKING 52 Random Forest SVM F1 Score Users Users Passive AL - FSQ AL - RQ
60. LEARNING RESULTS POINTING 53 Random Forest SVM F1 Score Users Users Passive AL - FSQ AL - RQ
61. EXTENDED FILTER User-selected limbs + adjacent ones 54 Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
62. EXTENDED FILTER Example: User-selected limbs + adjacent ones 54 Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
63. EXTENDED FILTER Example: User-selected limbs + adjacent ones Users select: {head, neck} 54 Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
64. EXTENDED FILTER Example: User-selected limbs + adjacent ones Users select: {head, neck} Extended Filter (EF): {head, neck, Lshoulder, Rshoulder} 54 Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot
65. EXTENDED FILTER RESULTS LOOKING 55 Random Forest SVM F1 Score Users Users Passive AL - FSQ AL - RQ AL - EF
66. EXTENDED FILTER RESULTS POINTING 56 Random Forest SVM F1 Score Users Users Passive AL - FSQ AL - RQ AL - EF
67. CONCLUSION Sometimes, users give innacurate answers E.g. looking experiment Reducing model accuracy Extended Filter (EF) mitigates this EF also performs well when user provides accurate answers 57
68. PUBLISHED RESULTS 58 8.4. List of Publications • V. Gonzalez-Pacheco, M. Malfaz, and M. A. Salichs, “Asking rank queries in pose learning,” in Proceedings of the 2014 ACM/IEEE international conference on Human-robot interaction - HRI ’14, 2014, pp. 164–165. • V. Gonzalez-Pacheco and M. A. Salichs, “Active Learning for Pose Recognition. Studying what and when to ask for Feature Queries,” in Proc of the 8th HRI Pioneers Workshop, 2013, pp. 3–4. • J. Sequeira, P. Lima, A. Saffiotti, V. Gonzalez-Pacheco, and M. A. Salichs, “MOnarCH: Multi-Robot Cognitive Systems Operating in Hospitals,” in Proc of the ICRA 2013 Workshop on Crossing the Reality Gap – From Single to Multi to Many Robot Systems, 2013, p. 1. • A. Valero-Gomez, J. Gonzalez-Gomez, V. Gonzalez-Pacheco, and M. A. Salichs, “Printable creativity in plastic valley UC3M,” in Proceedings of the 2012 IEEE Global Engineering Education Conference (EDUCON), 2012, pp. 1–9. • Victor Gonzalez-Pacheco, María Malfaz, Álvaro Castro-González, Miguel A. Salichs. How Much should a Social Robot trust the user feedback? Analyzing the impact of Verbal Answers in Active Learning. Int. Journal Social Robotics. 2015 [UNDER REVIEW]
69. ACTIVE LEARNING LEARNING POSES
70. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
71. ACTIVE LEARNING LEARNING OBJECTS
72. OBJECTIVES Let the robot to decide wheter it needs more examples (using Active Learning) Increase richness of the interactions compared to previous version No grammar limiting max num of objects to learn 62
73. PLATFORM MBOT
74. SYSTEM OVERVIEW Interaction Modules AL Module OCULAR 64
75. SYSTEM OVERVIEW 65 FUSION AL Module OCULAR Multimodal Dialog Manager FISSION TTS ASR Predictions Pred. Predictions uncertainty Feedback Config.
76. MUTIMODAL FUSION Data aggregators (vision and language) Receive Input from sensors or other modules Produce higer level information and send it to the Dialogue Manager 66 FUSION AL Module OCULAR Multimodal Dialog Manager FISSION TTS ASR
77. MUTIMODAL FUSION NLP MODULES Functions: Stemming and Lemmatization Part-of-speech tagging Extract object names (nouns) and commands (verbs) 67 FUSION AL Module OCULAR Multimodal Dialog Manager FISSION TTS ASR
78. MUTIMODAL FUSION NLP EXAMPLE “Would you like to learn a new object?” Would/MD you/PRP like/VB to/TO learn/VB a/DT new/JJ obect/NN ?/. => [command: LEARN] “This is a ball” This/DT be/VB a/DT ball/NN =>[object:BALL] 68 FUSION AL Module OCULAR Multimodal Dialog Manager FISSION TTS ASR
79. DIALOGUE MANAGER Rule-based producion system (Iwaki) Processes high level info from Multimodal Fusion Decides what action to perform and tells the Multimodal Fission to execute it Dialogues are pre-coded plans written in XML files 69 FUSION AL Module OCULAR Multimodal Dialog Manager FISSION TTS ASR Iwaki: https://github.com/maxipesfix/iwaki
80. ACTIVE LEARNING MODULE Gets predictions from OCULAR Module Sends uncertainty of prediction to Dialogue Manager (DM) The decision of querying the user or not is made by the DM 70 FUSION AL Module OCULAR Multimodal Dialog Manager FISSION TTS ASR
81. ACTIVE LEARNING MODULE UNCERTAINTY HEURISTICS Margin (Uncertainty Sampling) Jensen-Shannon Divergence (QBC) Committee of 2 members: 2D matcher and 3D matcher 71
82. EXPERIMENT DESCRIPTION 4 objects Mixed natural and artificial light User at 1.5m~1.7m of the robot 72
83. VIDEO 73
84. VIDEO 73
85. RESULTS F1 SCORE 74
86. RESULTS UNCERTAINTY LEVELS Jensen-Shannon Divergence Margin 75
87. CONCLUSION Robot can learn after training session has ended Poor performance of Point Cloud matcher High divergence between matchers Very verbose when querying Use different strategy for querying 76
88. ACTIVE LEARNING LEARNING OBJECTS
89. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
90. INTERACTIVE AND ACTIVE LEARNING NOVELTY DETECTION
91. MOTIVATION 80 What happens when you expose the robot with new concepts? Is it able to detect that it needs more training?
92. Pointing Right Pointing Forward Pointing Left (pointing), where some users used their right hand to point, while others, thei some cases, some users used their right hand to point to their right and their fro hand when pointing to their left (see Figure 7). In fact, we also observed som looked to the direction where they were pointing, while others looked to the ro Figure 7. Examples of how different users pointed during the tra Right Front Left MOTIVATION 80 What happens when you expose the robot with new concepts? Is it able to detect that it needs more training?
93. OBJECTIVES Learn from novel data Filter non-interesting noise Distinguish between known and strange 81
94. NOVELTY DETECTION Novel: new, interesting and strange x y N 1 N 2 o1 o2 3 o 82
95. NOVELTY DETECTION Novel: new, interesting and strange 83 x y N 1 N 2 o1 o2 O3
96. NOVELTY DETECTION Novel: new, interesting and strange 84 x y N 1 N 2 o1 o2 N3
97. Novelty Score Extreme Value Theorem (EVT) In this example, the score of the new data entry is one time units aw value, µ of the normal scores. A value of one means that, a new normal if lays within the 68% of the closests scores to the mean of standard score is higher than 1, the score z ( o1 ) can be considered h 68% of the normal entries, and it can be classified as strange. Imagine we now use a threshold + K and K , instead of +1 and -1 novelty.score ( o1 ) = abs (z ( o1 ) µ) K abs (z ( o1 ) µ) If we develop this expression: 85
98. K curiosity factor z ( o1 )  µ (3.5) the score of the new data entry is one time units away from the average normal scores. A value of one means that, a new entry is labeled as ithin the 68% of the closests scores to the mean of the dataset. If the s higher than 1, the score z ( o1 ) can be considered high with respect to al entries, and it can be classified as strange. use a threshold + K and K , instead of +1 and -1. novelty.score ( o1 ) = abs (z ( o1 ) µ) (3.6) K abs (z ( o1 ) µ) (3.7) Chapter 3. Description of the proposed solution 1 abs (z ( o1 ) µ K ⇥ ) 86
99. 87 YES NO noise YES NO strange? interesting but known by model interesting novelty learn pose interesting? get new pose SYSTEM DIAGRAM
100. EXPERIMENTS 88
101. FILTERED JOINTS Sensors 2013, 13 Figure 3. OpenNI’s kinematic model of the human body—OpenNI (NI stands fo Interaction) algorithms are able to create and track a kinematic model of the human Head Neck Right Shoulder Right Elbow Right Hand Torso Left Shoulder Left Elbow Left Hand Right Hip Right Knee Right Foot Left Hip Left Knee Left Foot This model contains the data that is going to be used in our learning system. The data o instance ( S ) is composed of 15 joints represented as: S = ( t, u, J ) where t is the time-stamp of the data frame, u is the user identification (Here, the user iden to the user being identified by the openNI framework. It is a value between one and fou 9 Joints 7 Parameters per joint: (x, y, z, qx , qy , qz , qw) 89
102. LET’S SEE AN EXAMPLE 90 0 2 4 6 8 10 KM LSA SVM1C GMM noise score 0.06 0.04 0.02 0.00 0.02 0.04 0.06 KM LSA SVM1C GMM strangeness score Observed poses (previous sessions) Current observed pose Observed poses (during session)
103. LET’S SEE AN EXAMPLE 91 0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 KM LSA SVM1C GMM noise score 0.06 0.04 0.02 0.00 0.02 0.04 0.06 KM LSA SVM1C GMM strangeness score Observed poses (previous sessions) Current observed pose Observed poses (during session)
104. LET’S SEE AN EXAMPLE 92 0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 KM LSA SVM1C GMM noise score 0 1 2 3 4 5 6 KM LSA SVM1C GMM strangeness score Observed poses (previous sessions) Current observed pose Observed poses (during session)
105. NOISE FILTER Noise score Users showing same pose 93 Noise score Deciding when new instances start to become interesting by forming clusters. YES NO noise YES NO strange? interesting but known by model interesting novelty learn pose interesting? get new pose
106. STRANGENESS EVALUATION Training Users 0 0,2 0,4 0,6 0,8 1 5 10 20 GMM One Class SVM LSA K-means 94 Detecting “novelties” F1-Score YES NO noise YES NO strange? interesting but known by model interesting novelty learn pose interesting? get new pose
107. Proof of concept Curiosity factor still needs to be calculated and studied experimentally Study our approach in other applications CONCLUSION 95
108. PUBLISHED RESULTS 96 110 8.4 List of Publications 8.4.1 Journals This section presents a list of journals that have been published during this thesis. The three journals are indexed in the Journal Citation Reports (JCR), being one in the first quartile (Q1) and two in the third quartile (Q3). • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. a. Salichs, “Novelty Detection for Interactive Pose Recognition by a Social Robot,” Int. J. Adv. Robot. Syst., vol. 12, no. 43, p. 1, 2015. • V. Gonzalez-Pacheco, M. Malfaz, F. Fernandez, and M. A. Salichs, “Teaching hu- man poses interactively to a social robot,” Sensors, vol. 13, no. 9, pp. 12406–12430, 2013. • V. Gonzalez-Pacheco, A. Ramey, F. Alonso-Martin, A. Castro-Gonzalez, and M. A. Salichs, “Maggie: A Social Robot as a Gaming Platform,” Int. J. Soc. Robot., vol. 3, no. 4, pp. 371–381, Sep. 2011. 8.4.2 Conferences and Talks • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. A. Salichs, “Using novelty 12, no. 43, p. 1, 2015. • V. Gonzalez-Pacheco, M. Malfaz, F. Fernandez, and M. A. Salichs, “Teaching hu- man poses interactively to a social robot,” Sensors, vol. 13, no. 9, pp. 12406–12430, 2013. • V. Gonzalez-Pacheco, A. Ramey, F. Alonso-Martin, A. Castro-Gonzalez, and M. A. Salichs, “Maggie: A Social Robot as a Gaming Platform,” Int. J. Soc. Robot., vol. 3, no. 4, pp. 371–381, Sep. 2011. 8.4.2 Conferences and Talks • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. A. Salichs, “Using novelty detection in HRI: Enabling robots to detect new poses and actively ask for their labels,” in 2014 IEEE-RAS International Conference on Humanoid Robots, 2014, pp. 1110–1115. 156
109. INTERACTIVE AND ACTIVE LEARNING NOVELTY DETECTION
110. Poses Objects Poses Objects Novelties Introduction Part I: Interactive Learning Part II: Interactive and Active Learning Conclusions
111. CONCLUSIONS
112. CONCLUSIONS “To develop a system that enables a social robot to learn interactively in a natural way, similarly to how a person would learn from another person.” 100
113. KEY CONTRIBUTIONS INTERACTIVE LEARNING Developed a system that enables robots to learn while interacting 2 Different approaches Grammar-based Dialogue-based (+ NLP) 101
114. KEY CONTRIBUTIONS ACTIVE LEARNING Studied how innacurate user’s answers might impact learning Extended Filter mitigates this problem Robot uses AL to keep learning after the training session ends by asking questions when its is uncertain Robot can learn new concepts 102
115. FUTURE WORKS INTERACTION Study how robot learning is perceived by humans ACTIVE LEARNING Continuous learning Apply to other domains 103
116. LIST OF PUBLICATIONS
117. JOURNALS 8.4 List of Publications 8.4.1 Journals This section presents a list of journals that have been published during this thesis. The three journals are indexed in the Journal Citation Reports (JCR), being one in the first quartile (Q1) and two in the third quartile (Q3). • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. a. Salichs, “Novelty Detection for Interactive Pose Recognition by a Social Robot,” Int. J. Adv. Robot. Syst., vol. 12, no. 43, p. 1, 2015. • V. Gonzalez-Pacheco, M. Malfaz, F. Fernandez, and M. A. Salichs, “Teaching hu- man poses interactively to a social robot,” Sensors, vol. 13, no. 9, pp. 12406–12430, 2013. • V. Gonzalez-Pacheco, A. Ramey, F. Alonso-Martin, A. Castro-Gonzalez, and M. A. Salichs, “Maggie: A Social Robot as a Gaming Platform,” Int. J. Soc. Robot., vol. 3, no. 4, pp. 371–381, Sep. 2011. 8.4.2 Conferences and Talks • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. A. Salichs, “Using novelty 105
118. CONFERENCES (I) • V. Gonzalez-Pacheco, A. Ramey, F. Alonso-Martin, A. Castro-Gonzalez, and M. A. Salichs, “Maggie: A Social Robot as a Gaming Platform,” Int. J. Soc. Robot., vol. 3, no. 4, pp. 371–381, Sep. 2011. 8.4.2 Conferences and Talks • V. Gonzalez-Pacheco, A. Sanz, M. Malfaz, and M. A. Salichs, “Using novelty detection in HRI: Enabling robots to detect new poses and actively ask for their labels,” in 2014 IEEE-RAS International Conference on Humanoid Robots, 2014, pp. 1110–1115. 156 8.4. List of Publications • V. Gonzalez-Pacheco, M. Malfaz, and M. A. Salichs, “Asking rank queries in pose learning,” in Proceedings of the 2014 ACM/IEEE international conference on Human-robot interaction - HRI ’14, 2014, pp. 164–165. • V. Gonzalez-Pacheco and M. A. Salichs, “Active Learning for Pose Recognition. Studying what and when to ask for Feature Queries,” in Proc of the 8th HRI Pioneers Workshop, 2013, pp. 3–4. • J. Sequeira, P. Lima, A. Saffiotti, V. Gonzalez-Pacheco, and M. A. Salichs, “MOnarCH: Multi-Robot Cognitive Systems Operating in Hospitals,” in Proc of the 106
119. CONFERENCES (II) pose learning,” in Proceedings of the 2014 ACM/IEEE international conference on Human-robot interaction - HRI ’14, 2014, pp. 164–165. • V. Gonzalez-Pacheco and M. A. Salichs, “Active Learning for Pose Recognition. Studying what and when to ask for Feature Queries,” in Proc of the 8th HRI Pioneers Workshop, 2013, pp. 3–4. • J. Sequeira, P. Lima, A. Saffiotti, V. Gonzalez-Pacheco, and M. A. Salichs, “MOnarCH: Multi-Robot Cognitive Systems Operating in Hospitals,” in Proc of the ICRA 2013 Workshop on Crossing the Reality Gap – From Single to Multi to Many Robot Systems, 2013, p. 1. • A. Valero-Gomez, J. Gonzalez-Gomez, V. Gonzalez-Pacheco, and M. A. Salichs, “Printable creativity in plastic valley UC3M,” in Proceedings of the 2012 IEEE Global Engineering Education Conference (EDUCON), 2012, pp. 1–9. • A. Ramey, V. González-Pacheco, and M. A. Salichs, “Integration of a low-cost RGB-D sensor in a social robot for gesture recognition,” in Proceedings of the 6th international conference on Human-Robot Interaction - HRI ’11, 2011, pp. 229–230. • F. Alonso-Martin, V. Gonzalez-Pacheco, A. Castro-Gonzalez, A. A. Ramey, M. Yébenes, and M. A. Salichs,“Using a social robot as a gaming platform,” in 2nd International Conference on Social Robotics, 2010, pp. 30–39. 107
120. ONGOING PUBLICATIONS 108 • Victor Gonzalez-Pacheco, María Malfaz, Álvaro Castro-González, Miguel A. Salichs. How Much should a Social Robot trust the user feedback? Analyzing the impact of Verbal Answers in Active Learning. Int. Journal Social Robotics. 2015 [UNDER REVIEW] • Victor Gonzalez Pacheco, Maria Malfaz, Miguel A. Salichs. Active Learning for in-hand Object Recognition. Sensors. 2016. [IN PREPARATION]
121. 109 SOURCE CODE https://github.com/UC3MSocialRobots/pose_tracker_stack https://github.com/UC3MSocialRobots/ocular_project https://github.com/UC3MSocialRobots/rospy_utils DATASETS: https://github.com/VGonPa/datasets-poses2012
122. INTERACTIVE AND ACTIVE LEARNING FOR SOCIAL ROBOTICS Víctor González Pacheco Advisers: Miguel Ángel Salichs María Malfaz Leganés, November 2015
