  1. LibreOffice – how we
    handle
    interoperability
    Miklos Vajna
    2015-05-12

    View Slide

  2. 2 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    About Miklos

    From Hungary

    More blurb: http://vmiklos.hu/

    Google Summer of Code 2010/2011

    Rewrite of the Writer RTF import/export

    Writer developer since Feb 2012

    Contractor at Collabora since Sep 2013

    View Slide

  3. 3 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Agenda

    What is:

    LibreOffice, The Document Foundation

    Collabora Productivity

    How we handle interoperability

    Examples

    What's new in LibreOffice 4.4/5.0

    View Slide

  4. 4 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    What is LibreOffice,
    The Document Foundation?

    LibreOffice is a free and open source
    office suite

    Writer, Calc, Impress, etc.

    Available on Windows, Linux, OS X

    The Document Foundation

    Non-profit organization behind the project

    Handles everything except development

    View Slide

  5. 5 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    No Single Vendor Dominance

    No one
    can control
    more than 30%
    of the votes
    in any statutory
    body of TDF

    View Slide

  6. 6 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Total Unique IP Addresses Seen
    0
    20,000,000
    40,000,000
    60,000,000
    80,000,000
    100,000,000
    120,000,000
    Windows
    MacOSX
    Linux
    Tracking direct download
    Update Ping origins.
    Excludes all Linux Distributions
    downloads
    ~120m so far ( + Linux )
    This time last year was ~65m

    View Slide

  7. 7 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    2013 vs. 2014 commits by
    affiliation
    2013
    2014
    0 5,000 10,000 15,000 20,000 25,000 30,000
    SYNERZIP
    SUSE
    RedHat
    Openismus
    Nou & Off
    New Contributors
    Munich
    MultiCoreWare
    Linagora
    Lanedo
    Known contributors
    KACST
    ITOMIG
    Igalia
    IBM
    Ericsson
    Collabora
    CloudOn
    CIB
    Canonical
    Assigned
    Apache Volunteer
    ALTA

    View Slide

  8. 8 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Committers per month
    0
    20
    40
    60
    80
    100
    120
    140 Xamarin
    T
    ata Consultancy Services
    SYNERZIP
    SUSE
    Sonicle
    SIL
    RedHat
    Oracle
    Openismus
    Nou & Off
    New Contributors
    Munich
    MultiCoreWare
    Linagora
    Lanedo
    Known contributors
    KACST
    ITOMIG
    Igalia
    IBM
    Ericsson
    Collabora
    CloudOn
    CIB
    Canonical
    Assigned
    Apache Volunteer
    ALTA

    View Slide

  9. 9 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    What is
    Collabora Productivity?

    LibreOffice is developed by a healthy mix of:

    Volunteers

    Companies paying full-time developers

    Collabora Ltd.

    Leading open source consultancy

    8 years of experience, 90+ people

    Collabora Productivity Ltd.

    Dedicated to Enterprise LibreOffice

    Provides Level-3 support (code issues) to all
    Novell/SUSE LibreOffice clients

    Architects of LibreOffice's OOXML export filters

    View Slide

  10. How we handle
    interoperability ↔ ODF

    View Slide

  11. 11 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Interoperability

    Ability to handle files we didn't produce

    Files are just an on-disk representation

    Of what is in the memory

    Of a collection of features

    #1 use-case is of course Microsoft Office

    OOXML, binary formats, RTF

    Both standards and non-standards

    View Slide

  12. 12 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    What is a feature?

    Document model

    UNO API

    Layout / View

    Filters

    Tests

    UI

    Documentation

    Specification

    View Slide

  13. 13 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Handling interoperability

    Worst case

    Includes all aspects of a new feature

    Best case

    Only filter part is missing

    That's why there is no xslxToPdf()

    File → model → file

    So that for N formats, 2N filters are enough
    – Instead of N2

    View Slide

  14. 14 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Importing Non-standards

    A new project from April:
    Document Liberation

    Fits TDF's mission well.

    Home for re-usable,
    legacy un-documented
    proprietary file-formats
    Eg. Visio, Keynote, MS
    Publisher, MS Works, Corel
    Draw, Adobe Pagemaker...

    View Slide

  15. 15 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Using new Standards

    Importing, rendering & allow a walk-
    through of Khronos' Collada files:

    View Slide

  16. 16 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    4 levels of “handling”

    Feature is already in core

    Implement the feature in core

    Implement the result of the feature in core

    Just preserve it

    View Slide

  17. 17 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Case #0: feature is already in
    core

    RTF import,
    groupshape support

    View Slide

  18. 18 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Case #1: Implement the feature in
    core

    View Slide

  19. 19 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Case #2: Import the result of the
    feature in the filter

    E.g. Table styles, document themes

    SmartArt import

    On import, apply the result of that as direct
    formatting

    Better, than nothing, but no real editing can
    be performed

    View Slide

  20. 20 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Case #3: Just preserve it

    If a feature is completely unsupported by
    core, it makes sense to first just preserve it

    Use case:

    Long document

    Full of complicated features

    Just want to correct a typo

    View Slide

  21. 21 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    We do it for ODF already

    css::xml::ParaUserDefinedAttributesSupplier

    css::xml::TextUserDefinedAttributesSupplier

    css::xml::UserDefinedAttributesSupplier

    “The idea behind this property is that a parser
    can throw away all attributes that it cannot
    handle by itself […] can be written back
    without loss.”

    WW8 as well:
    SwTOXBase::maMSTOCExpression

    View Slide

  22. Examples

    View Slide

  23. 23 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Character borders in Writer

    New in LibreOffice 4.2

    Thanks to Tamás Zolnai

    View Slide

  24. 24 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Nested comments

    New in LibreOffice 4.3

    View Slide

  25. 25 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Writer: better OOXML shape
    interop

    View Slide

  26. 26 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Writer / Text box shapes
    “Fix Text Boxes !” - thanks to CloudOn
    Red-lining in custom shape
    text-boxes.
    Embedded smart-art
    object inside custom-shape

    View Slide

  27. 4.4 developments

    View Slide

  28. 28 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    UI re-work: complete in 4.4

    A huge extremely mechanical task:

    Clean UI

    Many thanks to:
    Caolán McNamara (Red Hat) - for his incredible work here, and also
    Szymon Kłos, Michal Siedlaczek, Olivier Hallot (EDX), Andras Timar
    (Collabora), Jan Holesovsky (Collabora), Katarina Behrens, Thomas
    Arnhold, Maxim Monastirsky, Manal Alhassoun, Palenik Mihály, and
    many others ...
    4.0 4.1 4.2 4.3 4.4
    0
    100
    200
    300
    400
    500
    600
    700
    800
    900
    Progress on UI / dialog layout
    Layout UI
    old dlg
    old tab-page
    Remaining

    View Slide

  29. 29 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Parallelised XLSX loading
    (boxes are threads).

    Split XML Parse &
    Sheet populate

    Parallelised Sheet
    Loading …

    Parallel to GPU
    compilation
    Unzip,
    XML Parse,
    Tokenize
    Thread 1 Thread 2
    Populate
    Sheet Data
    Structures.
    Unzip,
    XML Parse,
    Tokenize
    Populate
    Sheet Data
    Structures.
    … etc.
    =COVAR(A1:A300,B1:B300)
    → OpenCL code
    → Ready to execute kernels
    Progress bar
    thread

    View Slide

  30. 30 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    3D charting ...

    Streaming data through calc and get
    high FPS, attractive 3D chart
    rendering

    View Slide

  31. 31 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    4.4 Other platforms: Android
    Viewer kindly funded by Smoose

    View Slide

  32. 32 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    De-confusing read-only mode.
    LibreOffice will now display an infobar to indicate visibly
    when a document is being opened in read-only mode.
    (Samuel Mehrbrodt, Joren De Cuyper)

    View Slide

  33. What's next:
    LibreOffice 5.0

    View Slide

  34. 34 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Writer: Improved Interop.
    Word compatible text highlighting thanks to Tamás Zolnai

    Both highlighting and shading are preserved during import / export of Microsoft
    Word documents.

    New compatibility option to specify how to export LibreOffice character
    background to Microsoft Office file formats: as highlighting or as shading.

    To use this option, go to Tools Option Load/Save Microsoft Office.
    ▸ ▸ ▸

    View Slide

  35. 35 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Calc: Conditional Formatting
    Data bars in conditional formatting can now have a solid background
    thanks to Katarina Behrens (CIB)
    Data bars can be displayed without showing their underlying values thanks
    to Katarina Behrens (CIB)

    View Slide

  36. 36 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    PDF signing & Time-
    stamping ...
    Export to PDF now supports the Time-Stamp Protocol (IETF standard
    RFC 3161). The address of a Time-Stamp Authority can be specified
    in the security options of PDF settings (Tor Lillqvist, Collabora) –
    thanks to Wilhelm Tux & donors for a successful crowd funding !

    View Slide

  37. 37 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Improved Sidebars:

    View Slide

  38. 38 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    LibreOfficeKit

    A very simple C & C++ API for LibreOffice

    Exposes file-format filters
    – Ideal for indexing / extraction: “convert * → HTML”

    Exposes tiled rendering
    – Convert document fragments → Images

    Exposes editing / selection events
    – Convert Editing → event flow in each direction.

    A very simple ~header-only API – no linking

    fully abstract: fn pointers, opaque structs etc.

    No sockets opened, no plugins / simple init.

    Global error messages.

    LibreOffice Online, Android, 'loconv' built on this.

    View Slide

  39. 39 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    New Platform bits for 5.0 ...

    Native windows 64bit - thanks to David
    Ostrovsky (CIB),

    Also mergedlibs on Windows to improve cold-
    start: linking ~much of the app into 1x DLL
    instead of many.

    Android / Editing

    Online

    View Slide

  40. 40 / 40
    Protocols Plugfest Europe 2015, Zaragoza | Miklos Vajna
    Summary

    During the past year, lots of interop.
    problems got fixed in Writer

    TextBox

    OOXML strict / drawingML

    Nested comments

    Lots of small filter improvements

    Thanks for listening! :-)

    Slides: http://vmiklos.hu/odp

    View Slide
