  1. CONTROLLING THE FALSE DISCOVERY
    RATE
    Under the direction of Christian P. Robert
    Speaker: WANG Bing
    25/11/2013

    View Slide

  2. CONTROLLING THE FALSE DISCOVERY RATE
     The common approach to the multiplicity problem calls for controlling
    the family wise error rate (FWER). This approach, though, has faults,
    and we point out a few. A different approach to problems of multiple
    significance testing is presented. It calls for controlling the expected
    proportion of falsely rejected hypotheses-the false discovery rate. This
    error rate is equivalent to the FWER when all hypotheses are true but is
    smaller otherwise. Therefore, in problems where the control of the false
    discovery rate rather than that of the FWER is desired, there is potential
    for a gain in power. A simple sequential Bonferroni-type procedure is
    proved to control the false discovery rate for independent test statistics,
    and a simulation study shows that the gain in power is substantial. The
    use of the new procedure and the appropriateness of the criterion are
    illustrated with examples.

    View Slide

  3. CONTENTS
     Introduction
     Authors
     Abbreviations
     Development of the relevant domain
     Development
     Definition of False Discovery Rate
     Two properties of false discovery rate
     False Discovery Rate Controlling Procedure
     Example of False Discovery Rate Controlling Procedure
     Conclusion

    View Slide

  4. AUTHORS
     Yoav Benjamini:
     His work combines theoretical
    research in statistical methodology
    with applied research that involves
    complex problems with massive
    data. The methodological work is
    on selective and simultaneous
    inference (multiple-comparisons),
    and centers on the “False
    Discovery Rate” (FDR) criterion, as
    well as on general methods for
    data analysis, data mining and
    data visualization.
     Yosef Hochberg
     Ph.D., professor in the School of
    Mathematical Sciences at Tel
    Aviv University, has taught several
    courses in multiple comparisons.
    He has published an impressive
    number of articles and technical
    reports on various statistical
    methods.

    View Slide

  5. ABBREVIATIONS
     FWER: familywise error rate
     MCPs: multiple-comparison procedures
     PCER: per comparison error rate
     FDR: false discovery rate---controlling the
    expected proportion of falsely rejected
    hypotheses

    View Slide

  6. DEVELOPMENT OF THE RELEVANT DOMAIN
    (RELEVANT SCIENTIST AND THEIR CONTRIBUTIONS )
     Connections have been made between the FDR and Bayesian
    approaches (including empirical Bayes methods),
     Storey, John D. (2003). "The positive false discovery rate: A Bayesian
    interpretation and the q-value"
     Generalizing the confidence interval into the False coverage
    statement rate (FCR)
     Benjamini Y, Yekutieli Y (2005). "False discovery rate controlling
    confidence intervals for selected parameters".
     Thresholding wavelets coefficients and model selection
     Donoho D, Jin J; Jin (2006). "Asymptotic minimaxity of false discovery
    rate thresholding for sparse exponential data“

    View Slide

  7. STRUCTURE OF THIS STUDY PAPER
     A formal definition of the FDR.
     Some examples where the control of the FDR is
    desirable
     A simple Bonferroni-type FDR controlling
    procedure.
     A simulation study of the power of the
    procedure.

    View Slide

  8. FALSE DISCOVERY RATE
     m: the problem of testing null hypotheses
     m0
    : true null hypotheses
     m-m0
    : not true null hypotheses
     R: number of hypotheses rejected, an observable random variable
     U,V,S and T: unobservable random variables
     PCER=E(V/m)
     FWER=P(V≥1)

    View Slide

  9. DEFINITION OF FALSE DISCOVERY RATE
     Proportion of the rejected null hypotheses which are
    erroneously rejected: Q=V/(V+S)
     We define the FDR to be the expectation of Q :
    e
    Q
       
    ( ) / ( ) /
    e
    Q E Q E V V S E V R
       

    View Slide

  10. TWO PROPERTIES OF FALSE DISCOVERY
    RATE:
     If all null hypotheses are true, the FDR is equivalent to
    the FWER:
     In this case s=0 and v=r , so if v=0 then Q=0,and if v>0 then
    Q=1,leading to .
     When , the FDR is smaller than or equal to the
    FWER:
     In this case, if v>0 then , leading to
    Taking expectations on both sides we obtain
    and the two can be quite different.
    p-value is the probability of obtaining a test statistic at least as extreme as the one
    that was actually observed. It is corresponding to the true null hypotheses and is
    U(0,1) independent random variables.
       
    1
    e
    P V E Q Q
      
    0
    m m

    / 1
    v r   
    1
    V
    X Q


     
    1
    e
    P V Q
     
       
    ( ) / ( ) /
    e
    Q E Q E V V S E V R
       

    View Slide

  11. EXAMPLES
    3 examples show the relevance of FDR control in
    some typical situations:
     multiple-comparison problem involves an overall decision
     Control of the probability of any error is unnecessarily stringent, as a small
    proportion of errors will not change the overall validity of the conclusion.
     multiple separate decisions without an overall decision being
    required
     Two treatments are compared in multiple subgroups, and separate
    recommendations on the preferred treatments must be made for all
    subgroups
     multiple potential effects are screened to weed out the null effects
     one example is screening of various chemicals for potential drug
    development.

    View Slide

  12. FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     The procedure :
     Consider testing based on the
    corresponding p-values, is in ordered.
     Define the Bonferroni-type multiple-testing
    procedure:
     Let k be the largest i for that then
    reject all , i=1,2,…,k
    q*: maximizes the number of rejections
    1 2
    , ,...,
    m
    H H H
     
    i
    P
     
    *
    i
    i
    P q
    m

    ( )
    i
    H

    View Slide

  13. FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     Theorem 1
    For independent test statistics and for any
    configuration of false null hypotheses, the above
    procedure controls the FDR at .
     Remark.
    The independence of the test statistics corresponding to the false null
    hypotheses is not needed for the proof of the theorem
    *
    q

    View Slide

  14. FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     For any independent p-values
    corresponding to true null hypotheses, and for
    any values that the p-values
    corresponding to false null hypotheses can take,
     FDR controlling procedure:
    0
    0 m m
     
    1 0
    m m m
     
    0 1
    *
    0
    1 1
    ( ) ( | ,..., )
    m m m
    m
    E Q E Q P p P p q
    m

       
      * *
    0
    m
    E Q q q
    m
     
    Lemma.

    View Slide

  15. FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     Define the Hochberg’s procedure:
    Let k be the largest i for that then
    reject all , i=1,2,…,k
     Remark :
    note the relationship between Hochberg’s procedure and the FDR
    controlling procedure when q* is chosen to equal α.
     
    *
    1
    i
    i
    P q
    m i

     
     
    i
    H

    View Slide

  16. EXAMPLE OF FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     Neuhaus et al.(1992) investigated the effects of a new front-
    loaded administration of rt-PA versus those obtained with a
    standard regimen of APSAC, in a randomized multicentre trial in
    421 patients with acute myocardial infarction.
     rt-PA: Thrombolysis with recombinant tissue-type plasminogen activator
     APSAC: anisoylated plasminogen streptokinase activator

    View Slide

  17. EXAMPLE OF FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
    Four families of hypotheses can be identified in the study:
    1. Base-line comparisons(11 hypotheses), where the problem is
    of showing equivalence
    2. Patency of infarct-related artery (8 hypotheses)
    3. Reocclusion rates of patent infarct-related artery (6
    hypotheses)
    4. Cardiac and other events after the start of thrombolytic
    treatment (15 hypotheses)

    View Slide

  18. EXAMPLE OF FALSE DISCOVERY RATE
    CONTROLLING PROCEDURE
     The statement about the mortality is based on a p-
    value of 0.0095.
     The ordered s for the 15 comparisons made are:
    0.0001, 0.0004, 0.0019, 0.0095, 0.0201,
    0.0278, 0.0298, 0.0344, 0.0459, 0.3240,
    0.4262, 0.5719, 0.6528, 0.7590, 1.000 .
     
    i
    p

    View Slide

  19. EXAMPLE OF FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     Controlling the FWER at 0.05, the Bonferroni approach,
    using 0.05/15=0.0033, rejects the 3 hypotheses
    corresponding to the smallest p-value. (0.0001,
    0.0004, 0.0019, correspond to reduced allergic
    reaction, and to two different aspects of bleeding).
     Using Hochberg’s procedure leaves us with the same
    3 hypotheses rejected.

    View Slide

  20. EXAMPLE OF FALSE DISCOVERY RATE CONTROLLING
    PROCEDURE
     Using the FDR controlling procedure with
    comparing sequentially each with 0.05i/15, starting
    with . The first p-value to satisfy the constraint is
    as
    thus we reject the 4 hypotheses having p-value which are
    less than or equal to 0.013.
     we may support now with appropriate confidence the statements
    about mortality decrease, of which we did not have sufficiently strong
    evidence before.
    * 0.05
    q 
     
    i
    p
     
    15
    p  
    4
    p
     
    4
    4
    0.0095 0.05 0.013
    15
    p    

    View Slide

  21. ANOTHER LOOK AT FDR CONTROLLING
    PROCEFURE
    Theorem 2
    Choose α that maximizes the number of rejections at this level, r(α)
    Subject to the constraint αm/ r(α)≤q* (1)
    Proof:
    for each α, if P(i)
    ≤ α ≤ P(i+1)
    ,then r(α)=i. Furthermore, as the ratio on the
    left-hand side of constraint (1) increases in α over the range on which
    r(α) is constant, it is enough to investigate αs which are equal to one of
    the P(i)
    s. this α= P(k)
    satisfies the constraint because α/ r(α)= P(k)
    /k ≤
    q*/m. By considering the largest potential αs first, the procedure yields
    the α with the largest r(α) satisfying the constraint.

    View Slide

  22. POWER COMPARISONS
    The setting
     Using a large simulation study, the family of hypotheses is the
    expectations of m independent normally distribution random
    variables being equal to 0.
     Each individual hypotheses is tested by z-test, and the test
    statistics are independent. We use .
     The configurations of the hypotheses involve m=4, 8, 16, 32,
    64. And the number of truly null hypotheses being
    3m/4, m/2, m/4, 0
     The non-zero expectations were divided into 4 groups and
    placed at L/4, L/2, L3/4, and L in the following ways:
    (a) Linearly Decreasing (D) number of hypotheses of away from 0 in each
    group
    (b) Equally (E) number of hypotheses in each group
    (c) Linearly Increasing (I) number of hypotheses away from 0 in each group
     These expectations were fixed (per configuration) throughout
    the experiment.
     The variance of all variables was set to 1, and L was chosen
    at two levels 5 and 10
    * 0.05
    q 
     

    View Slide

  23. THE ESTIMATES OF THE AVERAGE POWER
     Simulation-based estimates of the average
    power: the proportion of the false null
    hypotheses which are correctly rejected.
     Comparing the three methods
    1. FDR controlling procedure :
    2. Hochberg’s : - - - - - -
    3. The Bonferroni-type : ……..

    View Slide

  24. D E I
    m
    power

    View Slide

  25. RESULT
     The power of all the methods decreases when the number of
    hypotheses tested increases-this is the cost of multiplicity
    control.
     The power is smallest for the D-configuration, where the non-
    null hypotheses are closer to the null, and is largest for I.
     The power of the FDR controlling method is uniformly larger
    than that of the other methods.
     The advantage increases in m. Therefore, the loss of power
    as m increases is relatively small for the FDR controlling
    method in the E- and I-configurations.
     The advantage in some situations is extremely large.
     Hochberg’s method offers a more powerful alternative to the
    Bonferroni method.

    View Slide

  26. CONCLUSION
     The new approach calls for the control of the FDR instead, and
    thereby also the control of the FWER in the weak sense. In
    many applications this is the desirable control against errors
    originating from multiplicity.
     this paper focused on presenting and motivating the controlling
    the FDR, and it can be developed into a simple and powerful
    procedure. Thus the cost paid for the control of multiplicity
    need not be large.

    View Slide

  27. WANG BING
    Thanks so much for your attention!

    View Slide
