The Hidden Docs in Angular

The official Angular documentation gives an excellent hands-on tutorial, but there are still many advanced Angular practical skills that are not detailed taught on the official website. In this sharing, I will focus on various practical skills you may not know about in Angular.

Transcript

1. The Hidden Docs In Angular 谢亚东（执衡） Senior Front-end Engineer Alibaba
2. 谢亚东（执衡） Senior Front-end Engineer Alibaba
4. Angular Evolution 2.0 4.0 5.0 6.0 7.0 8.0 9.0 2016 Sep 2019 Nov
5. import { Component } from '@angular/core'; @Component({ selector: 'app-root', template: `<div><h2>Hello {{name}}</h2></div>`, }) export class AppComponent { name = 'Angular'; } 2.0 4.0 6.0 defineComponent({ type: AppComponent, selectors: [ ["app-root"] ], decls: 3, vars: 1, template: function AppComponent_Template(rf, ctx) { if (rf & 1) { elementStart(0, "div"); elementStart(1, "h2"); text(2); elementEnd(); elementEnd(); } if (rf & 2) { advance(2); textInterpolate1("Hello ", ctx.name, ""); } }, encapsulation: 2 }); 9.0.0-rc.3 Code After Compiler
6. 4.0 1170 KB 9.0.0-rc.3 gzip 30 KB Bundle Size After Compiler 8.0 133 KB Differential Loading 9.0.0-rc.3 94.8 KB Ivy 5.0 152 KB
7. Broccoli Webpack Bazel 2 3 4 Command-Line Interface @angular/cli +
8. Stable & Reliable
9. DATE STABLE RELEASE COMPATIBILITY October/November 2019 9.0.0 ^8.0.0 May 2020 10.0.0 ^9.0.0 Release schedule & Semantic Versioning ng update & Update Guide ng update @angular/cli @angular/core
10. The Hidden Docs in Angular
11. The Hidden Docs in Angular
12. Change Detection The Hidden Docs in
13. @Component({ selector: "hello", template: ` <div>{{ count }}</div> <button (click)="add()">add</button> <button (click)="minus()">minus</button> ` }) export class HelloComponent { count = 0; add() { this.count += 1; } minus() { this.count -= 1; } } Counter Change Detection DEMO
14. Change Detection React Change to state cause change detection setState or hooks Angular ?
15. When to Trigger Change Detection? • Events: all browser events (click, mouseover, keyup, etc.) • Timers: setTimeout() and setInterval() • XHR: Ajax requests Browser Async API
16. When to Trigger Change Detection? Monkey Patch zone.js • Events: all browser events (click, mouseover, keyup, etc.) • Timers: setTimeout() and setInterval() • XHR: Ajax requests Browser Async API DEMO
17. this.applicationRef.tick() this._zone.onMicrotaskEmpty.subscribe( { next: () => { this._zone.run(() => { this.tick(); }); } }); _loadComponent(componentRef) { this.tick(); } Explore the Source Code ApplicationRef Demo with zone.js
18. for (let view of this._views) { view.detectChanges(); } this.applicationRef.tick() ChangeDetectionRef CD CD CD CD CD CD CD CD CD CD CD this.cdr.detectChanges() Explore the Source Code
19. for (let view of this._views) { view.detectChanges(); } this.applicationRef.tick() ChangeDetectionRef CD CD CD CD CD CD CD CD CD CD CD Demo with ChangeDetectionRef Explore the Source Code
20. detach() markForCheck() detectChanges() OnPush ChangeDetectionRef Explore the Source Code
21. ViewModel View Detection Sequence Why is it important? DEMO
22. Error: ExpressionChangedAfterItHasBeenCheckedError: Expression has changed after it was checked. DEMO
23. 1. update bound properties for all child components 2. call OnChanges, OnInit, DoCheck and AfterContentInit lifecycle hooks on all child components 3. update DOM for the current component 4. run change detection for a child component 5. call ngAfterViewInit lifecycle hook for all child components Detection Sequence Sequence is slightly different under Ivy engine
24. One Way Data Flow Unidirectional Data Flow VS
25. Summary 1. When 2. Source Code 3. Detection Sequence zone.js + tick ApplicationRef + ChangeDetectionRef ViewModel —> View & Unidirectional Data Flow
26. Component | Directive 1. Selector 2. @Input 3. Content Projection 4. Dynamic Component The Hidden Docs in
27. Selector
28. Selector const _SELECTOR_REGEXP = new RegExp( '(\\:not\\()|' + //":not(" '([-\\w]+)|' + // "tag" '(?:\\.([-\\w]+))|' + // ".class" // "-" should appear first in the regexp below as FF31 parses "[.-\w]" as a range '(?:\\[([-.\\w*]+)(?:=([\"\']?)([^\\]\"\']*)\\5)?\\])|' + // "[name]", "[name=value]", // "[name="value"]", // "[name='value']" '(\\))|' + // ")" '(\\s*,\\s*)', // "," 'g'); export interface Component extends Directive Explore the Source Code 1. :not() 2. Tag 3. Attribute Same Selector
29. Attribute Selector in Component VS 1. Supporting Original Attributes <button ngx-button disabled>{{name}}</button> <ngx-button ngxDisabled></ngx-button> .parent > .child{ height: 200px; background: gray; } 2. Keep DOM structure <div class="parent"> <div class="child" ngx-attribute></div> </div>
30. Tag Selector in Directive Lighthouse Scoring import { Directive, HostBinding } from '@angular/core'; @Directive({ selector: 'a[target="_blank"]:not([rel="noopener"])' }) export class SafeLinkDirective { @HostBinding('style.color') color = 'red'; @HostBinding('rel') rel = 'noopener'; }
31. @Input
32. typeof @Input data Input Correction <check [data]="true"></check> <check bind-data="true"></check> <check data="true"></check> <check data="{{true}}"></check> this.data === true
33. @Input as Attribute <button disabled></button> <button [disabled]="true"></button> <button [disabled]="false"></button> @Input() set ngxOpen(value) { this._open = this.coerceBooleanProperty(value); } get ngxOpen() { return this._open; } coerceBooleanProperty(value: any): boolean { return value != null && `${value}` !== "false"; } <ngx-attribute [ngxOpen]="true"></ngx-attribute> <ngx-attribute [ngxOpen]="false"></ngx-attribute> <ngx-attribute ngxOpen></ngx-attribute> @InputBoolean() ngxOpen = false; Decorators
34. @Input with * <div *ngIf="heroes else loading"> ... </div> <ng-template #loading> <div>Loading...</div> </ng-template> @Input() set ngIfElse(templateRef: TemplateRef<NgIfContext>|null) { assertTemplate('ngIfElse', templateRef); this._elseTemplateRef = templateRef; this._elseViewRef = null; // clear previous view if any. this._updateView(); } DEMO
35. Content Projection
36. Content Projection <ng-content select="slot-name"></ng-content> Multi-Slot 1. Tag Selector 2. Attribute Selector 3. Not Selector 4. Default Selector 5. ngProjectAs
37. Content Projection Component Interacting ContentChildren 1. ChangeDetection Error 2. NgTemplateOutlet
38. Content Projection Component Interacting Dependency Injection 1. NgTemplateOutlet 2. Get Root Component <app-dropdown> <app-menu> <app-menu-item></app-menu-item> <app-menu-item></app-menu-item> <app-menu-item></app-menu-item> </app-menu> </app-dropdown> <app-menu> <app-menu-item></app-menu-item> <app-menu-item></app-menu-item> <app-menu-item></app-menu-item> </app-menu> <app-menu-item></app-menu-item> <app-menu-item></app-menu-item> <app-menu-item></app-menu-item>
39. Content Projection Content Empty Detection <nz-badge [nzCount]="25"></nz-badge> <nz-badge [nzCount]="5"> <a class="head-example"></a> </nz-badge>
40. Content Projection Content Empty Detection ContentObserver Demo MutationObserver
41. Content Projection Copy Content <copy [copy]="8"> <button>copy me</button> </copy> <button>copy me</button> X 8
42. Content Projection Copy Content <ng-template> * Demo
43. Content Projection Move Content <tabset> <tab title="title 1">content 1</app-tab> <tab title="title 2">content 2</app-tab> <tab title="title 3">content 3</app-tab> </tabset> content 3 content 2 content 1
44. Content Projection Move Content <tabset> <tab title="title 1">content 1</app-tab> <tab title="title 2">content 2</app-tab> <tab title="title 3">content 3</app-tab> </tabset> title 1 title 2 title 3 content 1
45. Content Projection Move Content <ng-template> <ng-content></ng-content> </ng-template> Eager Load Lazy Load VS
46. Dynamic Component
47. Dynamic Component The missing compile Template String compile Dynamic Component
48. Dynamic Component The missing compile export function createCompiler(compilerFactory: CompilerFactory) { return compilerFactory.createCompiler([compilerOptions]); } providers: [ { provide: COMPILER_OPTIONS, useValue: compilerOptions, multi: true }, { provide: CompilerFactory, useClass: JitCompilerFactory, deps: [COMPILER_OPTIONS] }, { provide: Compiler, useFactory: createCompiler, deps: [CompilerFactory] } ], const dynamicComponent = Component({ template })( class { context = context; } ); const dynamicModule = NgModule({ declarations : [ dynamicComponent ], exports : [ dynamicComponent ], entryComponents: [ dynamicComponent ], imports : [ FormsModule ] })(class DynamicModule { }); this.compiledModule = await this.compiler.compileModuleAndAllComponentsAsync(dynamicModule); DEMO
49. Dynamic Component Ivy Render import { Component, ɵrenderComponent as renderComponent, Injector, ɵLifecycleHooksFeature as LifecycleHooksFeature } from "@angular/core"; @Component({ selector : 'app-root', templateUrl: './app.component.html', styleUrls : ['./app.component.css'] }) export class AppComponent { constructor(private injector: Injector) { import('./dynamic/dynamic.component').then(({ DynamicComponent }) => { renderComponent(DynamicComponent, { injector, host: '#slot', hostFeatures: [LifecycleHooksFeature] }); }); } }
