MVP+Reactive+Dagger

A general presentation about the advantages of Model View Presenter pattern, Reactive and Dagger 2 in our projects.

Transcript

1. MVP + Reactive + Dagger
2. Before: Without MVP + Reactive * Android Application Architecture, article in medium.com by Ivan Carballo.
3. Now: With MVP + Reactive * Architecture Guidelines by ribot.
4. MVP
5. Advantages MVP • Activities and Fragments become very lightweight. Their only responsibilities are to set up/update the UI and handle user events. Therefore, they become easier to maintain. • We can now easily write unit tests for the presenters by mocking the view layer. Before, this code was part of the view layer so we couldn’t unit test it. The whole architecture becomes very test-friendly. • If the data manager is becoming bloated, we can mitigate this problem by moving some code to the presenters.
7. Implementing MVP public class MainActivity extends BaseActivity implements MainMvpView { @Inject MainPresenter mMainPresenter; @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); ... mMainPresenter.attachView(this); mMainPresenter.loadMovies(); } @Override public void showMovies(List<Movie> movies) { mMoviesAdapter.setmMovies(movies); } } MainActivity.java
8. Implementing MVP public interface MainMvpView extends MvpView { void showMovies(List<Movie> movies); void showMoviesEmpty(); void showError(); void syncMovies(String title); } MainMvpView.java
9. Implementing MVP public class MainPresenter extends BasePresenter<MainMvpView> { @Override public void attachView(MainMvpView mvpView) { super.attachView(mvpView); } @Override public void detachView() { ... } public void loadMovies() { ... } } MainPresenter.java public void loadMovies() { compositeSubscription.add(mDataManager.getMovies() ... .subscribe(response -> { if (response.isEmpty()) { getMvpView().showMoviesEmpty(); } else { getMvpView().showMovies(response); } }, throwable -> { Timber.e(throwable, "There was an error loading movies."); getMvpView().showError(); })); } All logic in my Presenter
10. Reactive
11. Reactive world In a reactive world, we can't just wait for the results of the events, we provide a clear sequence of reactions to the events that are going to happen. - Observable - Observer - Subscriber - Subscriptions - Subjects
12. Advantages Reactive • RxJava Observables and operators remove the need for having nested callbacks. • The interactors (DataManager) takes over responsibilities that were previously part of the view layer. Hence, it makes Activities and Fragments more lightweight. • Moving code from Activities and Fragments to the DataManager and helpers means that writing unit tests becomes easier. • Clear separation of responsibilities. Helper classes or the interactors (DataManager) can be easily mocked.
13. Implementing Reactive
14. Implementing Reactive public void loadMovies() { checkViewAttached(); compositeSubscription.add(mDataManager.getMovies() .observeOn(AndroidSchedulers.mainThread()) .subscribeOn(Schedulers.io()) .subscribe(response -> { if (response.isEmpty()) { getMvpView().showMoviesEmpty(); } else { getMvpView().showMovies(response); } }, throwable -> { Timber.e(throwable, "There was an error loading the movies."); getMvpView().showError(); })); } loadMovies() method in MainPresenter.java Observable Subscriber (Observer) Subscription
15. Implementing Reactive public void loadMovies() { checkViewAttached(); compositeSubscription.add(mDataManager.getMovies() .observeOn(AndroidSchedulers.mainThread()) .subscribeOn(Schedulers.io()) .subscribe(response -> { if (response.isEmpty()) { getMvpView().showMoviesEmpty(); } else { getMvpView().showMovies(response); } }, throwable -> { Timber.e(throwable, "There was an error loading the movies."); getMvpView().showError(); })); } Result over main thread Process over other thread Any error Response loadMovies() method in MainPresenter.java
16. Implementing Reactive public Observable<List<Movie>> getMovies() { return mDatabaseHelper.getMovies() .distinct(); } Observable in DataManager.java public Observable<List<Movie>> getMovies() { return mDb.createQuery(Db.MovieTable.TABLE_NAME, "SELECT * FROM " + Db.MovieTable.TABLE_NAME) .mapToList(cursor -> Db.MovieTable.parseCursor(cursor)); } Observable in DatabaseHelper.java Subject = Observer + Observable
17. So ...
18. SearchView with Reactive public void loadSearch() { mCompositeSubscription .add(RxSearchView.queryTextChanges( ((MainActivity) getMvpView()).getSearchView()) .filter(charSequence -> !TextUtils.isEmpty(charSequence)) .throttleLast(100, TimeUnit.MILLISECONDS) .debounce(200, TimeUnit.MILLISECONDS) .onBackpressureLatest() .observeOn(AndroidSchedulers.mainThread()) .map(s -> s.toString()) .subscribe(getMvpView()::syncMovies, throwable -> { getMvpView().showError(); })); } SearchView
19. Dagger
20. Without Dagger Activity Fragment Service View Object Bus MovieApi Network Client Disk Cache Picasso SessionManager PreferencesHelper
21. Implementing Dagger ApplicationComponent ApplicationModule Activity Fragment Service View Object ActivityComponent ActivityModule NetworkModule StorageModule Bus MovieApi Application @ApplicationContext Context Activity @ActivityContext Context PreferencesHelper
22. Advantages Dagger • Easier unit and integration testing because the dependency graph is created for us, we can easily swap out modules that make network responses and mock out this behavior. • Since dependencies can be injected and configured externally we can reuse those components. • We can just change the implementation of any object without having to make a lot of changes in our codebase, since that object instantiation resides in one place isolated and decoupled.
23. Dagger: Components @Singleton @Component(modules = {ApplicationModule.class, NetworkModule.class}) public interface ApplicationComponent { void inject(SyncService syncService); ... MovieApiInterface movieApi(); } ApplicationComponent.java @PerActivity @Component(dependencies = ApplicationComponent.class, modules = ActivityModule.class) public interface ActivityComponent { void inject(MainActivity mainActivity); } ActivityComponent.java
24. Dagger: Modules @Module public class ApplicationModule { protected final Application mApplication; public ApplicationModule(Application application) { this.mApplication = application; } ... @Provides Application provideApplication() { return mApplication; } } ApplicationModule.java @Module public class ActivityModule { private Activity mActivity; public ActivityModule(Activity activity) { this.mActivity = activity; } @Provides @ActivityContext Context provideContext() { return mActivity; } } ActivityModule.java
25. Dagger: Scopes & Qualifiers @Scope @Retention(RetentionPolicy.RUNTIME) public @interface PerActivity { } PerActivity.java @Qualifier @Retention(RetentionPolicy.RUNTIME) public @interface ApplicationContext { } ApplicationContext.java @Qualifier @Retention(RetentionPolicy.RUNTIME) public @interface ActivityContext { } ActivityContext.java
26. Repo Example https://github.com/yaircarreno/QueryMovies
27. Q & A
28. References • Clean Architecture by Pedro Vicente and Jorge Barroso: https://goo.gl/U8M8B9 • Dependency Injection with Dagger 2 by Jake Wharton: https://goo.gl/pweC7P • Grokking RxJava, Part 1: The Basics by Dan Lew: http://goo.gl/60AYDU • Android Application Architecture by Iván Carballo: https://goo.gl/6xX2oW
