Apache Spark Training [Spark Core, Spark SQL, Tungsten]

All code examples are available here https://github.com/zaleslaw/Spark-Tutorial

Gitbook with notes for this training could be found here
https://www.gitbook.com/book/zaleslaw/data-processing-book/details

You can find here slides of my Open Apache Spark Training and links to video tutorial (in Russian).

Transcript

1. Spark Training
   Alexey Zinovyev, Java/BigData Trainer in EPAM


   View Slide

2. About
   With IT since 2007
   With Java since 2009
   With Hadoop since 2012
   With Spark since 2014
   With EPAM since 2015


   View Slide

3. 3
   Training from Zinoviev Alexey
   Contacts
   E-mail : Alexey_Zinovyev@epam.com
   Twitter : @zaleslaw @BigDataRussia
   vk.com/big_data_russia Big Data Russia
   + Telegram @bigdatarussia
   vk.com/java_jvm Java & JVM langs
   + Telegram @javajvmlangs


   View Slide

4. 4
   Training from Zinoviev Alexey
   Github
   Spark Tutorial: Core, Streaming, Machine Learning
   https://github.com/zaleslaw/Spark-Tutorial


   View Slide

5. 5
   Training from Zinoviev Alexey
   Gitbook
   Обработка данных на Spark 2.2 и Kafka 0.10
   www.gitbook.com/book/zaleslaw/data-processing-book


   View Slide

6. 6
   Training from Zinoviev Alexey
   Spark
   Family


   View Slide

7. 7
   Training from Zinoviev Alexey
   Spark
   Family


   View Slide

8. 8
   Training from Zinoviev Alexey
   WHAT IS BIG DATA?


   View Slide

9. 9
   Training from Zinoviev Alexey
   Joke about Excel


   View Slide

10. 10
    Training from Zinoviev Alexey
    Every 60 seconds…


    View Slide

11. 11
    Training from Zinoviev Alexey
    Is BigData about PBs?


    View Slide

12. 12
    Training from Zinoviev Alexey
    Is BigData about PBs?


    View Slide

13. 13
    Training from Zinoviev Alexey
    It’s hard to …
    • .. store
    • .. handle
    • .. search in
    • .. visualize
    • .. send in network


    View Slide

14. 14
    Training from Zinoviev Alexey
    How to handle
    all these stuff?


    View Slide

15. 15
    Training from Zinoviev Alexey
    Just do it … in parallel


    View Slide

16. 16
    Training from Zinoviev Alexey
    Parallel Computing vs Distributed Computing


    View Slide

17. 17
    Training from Zinoviev Alexey
    Modern Java in 2016
    Big Data in 2014


    View Slide

18. 18
    Training from Zinoviev Alexey
    Batch jobs produce reports. More and more..


    View Slide

19. 19
    Training from Zinoviev Alexey
    But customer can wait forever (ok, 1h)


    View Slide

20. 20
    Training from Zinoviev Alexey
    Hadoop Architecture


    View Slide

21. 21
    Training from Zinoviev Alexey
    HDFS Architecture


    View Slide

22. 22
    Training from Zinoviev Alexey
    Daemons in YARN


    View Slide

23. 23
    Training from Zinoviev Alexey
    Different
    scheduling
    algorithms


    View Slide

24. 24
    Training from Zinoviev Alexey
    Hive Data Model


    View Slide

25. 25
    Training from Zinoviev Alexey
    Machine Learning EVERYWHERE


    View Slide

26. 26
    Training from Zinoviev Alexey
    Data Lake in promotional brochure


    View Slide

27. 27
    Training from Zinoviev Alexey
    Data Lake in production


    View Slide

28. 28
    Training from Zinoviev Alexey
    Simple Flow in Reporting/BI systems


    View Slide

29. 29
    Training from Zinoviev Alexey
    WHY SHOULD WE USE
    SPARK?


    View Slide

30. 30
    Training from Zinoviev Alexey
    Advantages
    • native Python, Scala, R interface
    • interactive shells
    • in-memory caching of data, specified by the user
    • > 80 highly efficient distributed operations, any
    combination of them
    • capable of reusing Hadoop ecosystem, e.g. HDFS, YARN


    View Slide

31. 31
    Training from Zinoviev Alexey
    MapReduce vs Spark


    View Slide

32. 32
    Training from Zinoviev Alexey
    MapReduce vs Spark


    View Slide

33. 33
    Training from Zinoviev Alexey
    MapReduce vs Spark


    View Slide

34. 34
    Training from Zinoviev Alexey
    Let’s use Spark. It’s fast!


    View Slide

35. 35
    Training from Zinoviev Alexey
    SPARK INTRO


    View Slide

36. 36
    Training from Zinoviev Alexey
    Say me R..say me D.. Say me D again
    • Dataset
    • Distributed
    • Resilient


    View Slide

37. 37
    Training from Zinoviev Alexey
    Single
    Thread
    collection


    View Slide

38. 38
    Training from Zinoviev Alexey
    No perf
    issues,
    right?


    View Slide

39. 39
    Training from Zinoviev Alexey
    The main concept
    more partitions = more parallelism


    View Slide

40. 40
    Training from Zinoviev Alexey
    Loading
    val localData = (5,7,1,12,10,25)
    val ourFirstRDD = sc.parallelize(localData)
    val textFile = sc.textFile("hdfs://...")


    View Slide

41. 41
    Training from Zinoviev Alexey
    Loading
    val localData = (5,7,1,12,10,25)
    val ourFirstRDD = sc.parallelize(localData)
    val textFile = sc.textFile("hdfs://...")


    View Slide

42. 42
    Training from Zinoviev Alexey
    Loading
    val localData = (5,7,1,12,10,25)
    val ourFirstRDD = sc.parallelize(localData)
    // from file
    val textFile = sc.textFile("hdfs://...")


    View Slide

43. 43
    Training from Zinoviev Alexey
    Loading
    // Wildcards, running on directories, text and archives
    sc.textFile("/my/directory")
    sc.textFile("/my/directory/*.txt")
    sc.textFile("/my/directory/*.gz")
    // Read directory and return as filename/content pairs
    sc.wholeTextFiles
    // Read sequence file
    sc.sequenceFile[TKey, TValue]
    // Takes an arbitrary JobConf and InputFormat class
    sc.hadoopRDD
    sc.newAPIHadoopRDD
    // SerDe
    rdd.saveAsObjectFile
    sc.objectFile


    View Slide

44. 44
    Training from Zinoviev Alexey
    Spark
    Context


    View Slide

45. 45
    Training from Zinoviev Alexey
    RDD OPERATIONS


    View Slide

46. 46
    Training from Zinoviev Alexey
    Word
    Count
    val textFile = sc.textFile("hdfs://...")
    val counts = textFile
    .flatMap(line => line.split(" "))
    .map(word => (word, 1))
    .reduceByKey(_ + _)
    counts.saveAsTextFile("hdfs://...")


    View Slide

47. 47
    Training from Zinoviev Alexey
    Word
    Count
    val textFile = sc.textFile("hdfs://...")
    val counts = textFile
    .flatMap(line => line.split(" "))
    .map(word => (word, 1))
    .reduceByKey(_ + _)
    counts.saveAsTextFile("hdfs://...")


    View Slide

48. 48
    Training from Zinoviev Alexey
    Word
    Count
    val textFile = sc.textFile("hdfs://...")
    val counts = textFile
    .flatMap(line => line.split(" "))
    .map(word => (word, 1))
    .reduceByKey(_ + _)
    counts.saveAsTextFile("hdfs://...")


    View Slide

49. 49
    Training from Zinoviev Alexey
    What’s the difference between
    actions and transformations?


    View Slide

50. 50
    Training from Zinoviev Alexey
    RDD Chain


    View Slide

51. 51
    Training from Zinoviev Alexey
    Transformations
    • map, flatMap, filter
    • groupByKey, reduceByKey, sortByKey
    • mapValues, distinct
    • join, union
    • sample


    View Slide

52. 52
    Training from Zinoviev Alexey
    FlatMap explanation


    View Slide

53. 53
    Training from Zinoviev Alexey
    Map explanation


    View Slide

54. 54
    Training from Zinoviev Alexey
    ReduceByKey explanation


    View Slide

55. 55
    Training from Zinoviev Alexey
    Actions
    • reduce
    • collect, first, take, foreach
    • count(), countByKey()
    • saveAsTextFile()


    View Slide

56. 56
    Training from Zinoviev Alexey
    What’s the difference between
    PairRDD and usual RDD?


    View Slide

57. 57
    Training from Zinoviev Alexey
    Pair RDD


    View Slide

58. 58
    Training from Zinoviev Alexey
    RDD Demo


    View Slide

59. 59
    Training from Zinoviev Alexey
    PERSISTENCE


    View Slide

60. 60
    Training from Zinoviev Alexey
    Caching in Spark
    • Frequently used RDD can be stored in memory
    • One method, one short-cut: persist(), cache()
    • SparkContext keeps track of cached RDD
    • Serialized or deserialized Java objects


    View Slide

61. 61
    Training from Zinoviev Alexey
    Full list of options
    • MEMORY_ONLY
    • MEMORY_AND_DISK
    • MEMORY_ONLY_SER
    • MEMORY_AND_DISK_SER
    • DISK_ONLY
    • MEMORY_ONLY_2, MEMORY_AND_DISK_2


    View Slide

62. 62
    Training from Zinoviev Alexey
    Spark Core Storage Level
    • MEMORY_ONLY (default for Spark Core)
    • MEMORY_AND_DISK
    • MEMORY_ONLY_SER
    • MEMORY_AND_DISK_SER
    • DISK_ONLY
    • MEMORY_ONLY_2, MEMORY_AND_DISK_2


    View Slide

63. 63
    Training from Zinoviev Alexey
    Spark Streaming Storage Level
    • MEMORY_ONLY (default for Spark Core)
    • MEMORY_AND_DISK
    • MEMORY_ONLY_SER (default for Spark Streaming)
    • MEMORY_AND_DISK_SER
    • DISK_ONLY
    • MEMORY_ONLY_2, MEMORY_AND_DISK_2


    View Slide

64. 64
    Training from Zinoviev Alexey
    BUILDING


    View Slide

65. 65
    Training from Zinoviev Alexey
    Development tools
    • Console REPL ($SPARK_HOME/sbin/spark-shell)


    View Slide

66. 66
    Training from Zinoviev Alexey
    Development tools
    • Console REPL ($SPARK_HOME/sbin/spark-shell)
    • Apache Zeppelin


    View Slide

67. 67
    Training from Zinoviev Alexey
    Run Zeppelin


    View Slide

68. 68
    Training from Zinoviev Alexey
    Development tools
    • Console REPL ($SPARK_HOME/sbin/spark-shell)
    • Apache Zeppelin
    • IntelliJ IDEA Community + Scala Plugin


    View Slide

69. 69
    Training from Zinoviev Alexey
    Development tools
    • Console REPL ($SPARK_HOME/sbin/spark-shell)
    • Apache Zeppelin
    • IntelliJ IDEA Community + Scala Plugin
    • Don’t forget about SBT or adding spark’s jars


    View Slide

70. 70
    Training from Zinoviev Alexey
    SBT build
    name := "Spark-app"
    version := "1.0"
    scalaVersion := "2.11.11"
    libraryDependencies += "org.apache.spark" % "spark-
    core_2.11" % "2.2.0"
    libraryDependencies += "org.apache.spark" % "spark-
    sql_2.11" % "2.2.0"


    View Slide

71. 71
    Training from Zinoviev Alexey
    SBT build
    name := "Spark-app"
    version := "1.0"
    scalaVersion := "2.11.11"
    libraryDependencies += "org.apache.spark" % "spark-
    core_2.11" % "2.2.0“ % "provided"
    libraryDependencies += "org.apache.spark" % "spark-
    sql_2.11" % "2.2.0“ % "provided"


    View Slide

72. 72
    Training from Zinoviev Alexey
    SPARK ARCHITECTURE


    View Slide

73. 73
    Training from Zinoviev Alexey
    YARN + Driver


    View Slide

74. 74
    Training from Zinoviev Alexey
    Worker Nodes and Executors


    View Slide

75. 75
    Training from Zinoviev Alexey
    Spark Application


    View Slide

76. 76
    Training from Zinoviev Alexey
    Job Stages


    View Slide

77. 77
    Training from Zinoviev Alexey
    DAG Scheduler
    • Build stages of tasks
    • Submit them to lower level scheduler
    • Lower level scheduler will schedule data based on locality
    • Resubmit failed stages if outputs are lost


    View Slide

78. 78
    Training from Zinoviev Alexey
    Scheduler Optimizations


    View Slide

79. 79
    Training from Zinoviev Alexey
    Task in Spark
    • Unit of work to execute on in an executor thread
    • Unlike MR, there is no "map" vs "reduce" task
    • Each task apply set of transformations to same partitions in
    the RDD
    • Each task either partitions its output for "shuffle", or send
    the output back to the driver


    View Slide

80. 80
    Training from Zinoviev Alexey
    CONFIGURING


    View Slide

81. 81
    Training from Zinoviev Alexey
    Cluster Modes
    • Local mode


    View Slide

82. 82
    Training from Zinoviev Alexey
    Cluster Modes
    • Local mode
    • Stand-alone mode


    View Slide

83. 83
    Training from Zinoviev Alexey
    Cluster Modes
    • Local mode
    • Stand-alone mode
    • Yarn


    View Slide

84. 84
    Training from Zinoviev Alexey
    Cluster Modes
    • Local mode
    • Stand-alone mode
    • Yarn
    • Mesos


    View Slide

85. 85
    Training from Zinoviev Alexey
    Spark Master URL
    • local, local[n], local[*], local[K,F], local[*,F]
    • spark://host:port or spark://host1:port, host2:port
    • yarn-client or yarn-cluster
    • mesos://host:port


    View Slide

86. 86
    Training from Zinoviev Alexey
    SUBMIT


    View Slide

87. 87
    Training from Zinoviev Alexey
    Submit
    ./bin/spark-submit \
    --class com.epam.SparkJob1 \
    --master spark://192.168.101.101:7077 \
    --executor-memory 2G \
    --total-executor-cores 10 \
    /path/to/artifact.jar \


    View Slide

88. 88
    Training from Zinoviev Alexey
    A common deployment strategy
    is to submit your application from a gateway
    machine that is physically co-located with your
    worker machines


    View Slide

89. 89
    Training from Zinoviev Alexey
    Submit
    ./bin/spark-submit \
    --class com.epam.SparkJob1 \
    --master mesos://192.168.101.101:7077 \
    --executor-memory 2G \
    --deploy-mode cluster \
    --total-executor-cores 10 \
    /path/to/artifact.jar \


    View Slide

90. 90
    Training from Zinoviev Alexey
    STANDALONE CLUSTER


    View Slide

91. 91
    Training from Zinoviev Alexey
    Start
    master
    ./sbin/start-master.sh
    spark://192.168.101.101:7077


    View Slide

92. 92
    Training from Zinoviev Alexey
    Start
    slave ./sbin/start-slave.sh 192.168.101.101:7077


    View Slide

93. 93
    Training from Zinoviev Alexey
    Standalone Cluster Architecture


    View Slide

94. 94
    Training from Zinoviev Alexey
    Standalone Cluster Architecture with Resources


    View Slide

95. 95
    Training from Zinoviev Alexey
    EC2 Scripts for Spark 2.2
    https://github.com/amplab/spark-ec2


    View Slide

96. 96
    Training from Zinoviev Alexey
    MONITORING


    View Slide

97. 97
    Training from Zinoviev Alexey
    Start
    history-
    server
    ./sbin/start-historyserver.sh
    open http://192.168.101.101:18080


    View Slide

98. 98
    Training from Zinoviev Alexey
    Open web UI and enjoy


    View Slide

99. 99
    Training from Zinoviev Alexey
    Every Spark application launches a web UI
    • A list of scheduler stages and tasks
    • A summary of RDD sizes and memory usage
    • Environmental information
    • Information about the running executors


    View Slide

100. 100
     Training from Zinoviev Alexey
     Spark Training: Act 2
     Alexey Zinovyev, Java/BigData Trainer in EPAM


     View Slide

101. 101
     Training from Zinoviev Alexey
     RDD INTERNALS


     View Slide

102. 102
     Training from Zinoviev Alexey
     Do it
     parallel


     View Slide

103. 103
     Training from Zinoviev Alexey
     I’d like
     NARROW


     View Slide

104. 104
     Training from Zinoviev Alexey
     Map, filter, filter


     View Slide

105. 105
     Training from Zinoviev Alexey
     GroupByKey, join


     View Slide

106. 106
     Training from Zinoviev Alexey
     Is it a graph with tasks and dependencies?


     View Slide

107. 107
     Training from Zinoviev Alexey
     RDD Lineage is …
     (aka RDD operator graph or RDD dependency graph)
     a graph of all the parent RDDs of a RDD.


     View Slide

108. 108
     Training from Zinoviev Alexey
     I’d like
     NARROW


     View Slide

109. 109
     Training from Zinoviev Alexey
     toDebugString prints …
     The execution DAG or physical execution plan is
     the DAG of stages.


     View Slide

110. 110
     Training from Zinoviev Alexey
     spark
     .logLineage
     $ ./bin/spark-shell --conf spark.logLineage=true
     scala> sc.textFile("README.md", 4).count
     ...
     15/10/17 14:46:42 INFO SparkContext: Starting job: count at
     :25
     15/10/17 14:46:42 INFO SparkContext: RDD's recursive dependencies:
     (4) MapPartitionsRDD[1] at textFile at :25 []
     | README.md HadoopRDD[0] at textFile at :25 []


     View Slide

111. 111
     Training from Zinoviev Alexey
     Partitions
     Demo


     View Slide

112. 112
     Training from Zinoviev Alexey
     Spark
     Family


     View Slide

113. 113
     Training from Zinoviev Alexey
     SCHEMA + RDD


     View Slide

114. 114
     Training from Zinoviev Alexey
     Data sources and formats


     View Slide

115. 115
     Training from Zinoviev Alexey
     New RDD
     for each
     case


     View Slide

116. 116
     Training from Zinoviev Alexey
     Define schema for data to extract with SQL


     View Slide

117. 117
     Training from Zinoviev Alexey
     Case class for RDD
     User (height: Int (not null), name: String, age: Int)


     View Slide

118. 118
     Training from Zinoviev Alexey
     Let’s think about tables


     View Slide

119. 119
     Training from Zinoviev Alexey
     The main concept
     DataFrames are composed of Row objects, along
     with a schema that describes the data types of each
     column in the row


     View Slide

120. 120
     Training from Zinoviev Alexey
     RDD->DF
     val usersRdd = sqlContext
     .jsonFile("hdfs://localhost:9000/users.json")
     val df = usersRdd.toDF()
     val newRDD = df.rdd
     df.show()


     View Slide

121. 121
     Training from Zinoviev Alexey
     DATAFRAMES


     View Slide

122. 122
     Training from Zinoviev Alexey
     DataFrame’s nature
     • Like RDD with schema but it’s not RDD now
     • Distributed collection of data grouped into named columns
     • Domain-specific designed for common tasks under
     structured data
     • Available in Python, Scala, Java, and R (via SparkR)
     • Mutate from SchemaRDD


     View Slide

123. 123
     Training from Zinoviev Alexey
     DataFrame as SQL
     • Selecting columns and filtering
     • Joining different data sources
     • Aggregation (count, sum, average, etc)
     • Plotting results with Pandas (with PySpark)


     View Slide

124. 124
     Training from Zinoviev Alexey
     Input & Output


     View Slide

125. 125
     Training from Zinoviev Alexey
     Input & Output


     View Slide

126. 126
     Training from Zinoviev Alexey
     Custom Data Sources


     View Slide

127. 127
     Training from Zinoviev Alexey
     DataFrames
     Demo


     View Slide

128. 128
     Training from Zinoviev Alexey
     SPARK SQL


     View Slide

129. 129
     Training from Zinoviev Alexey
     Run SQL
     val df = spark.read.json(“/home/users.json”)
     df.createOrReplaceTempView(“users”)
     val sqlDF = spark.sql("SELECT name FROM users")
     sqlDF.show()


     View Slide

130. 130
     Training from Zinoviev Alexey
     Spark SQL advantages
     • Spark SQL allows relational queries expressed in SQL,
     HiveQL, or Scala to be executed using Spark
     • Unifies Stack with Spark Core, Spark Streaming etc.
     • Hive compatibility
     • Standard connectivity (JDBC, ODBC)


     View Slide

131. 131
     Training from Zinoviev Alexey
     Spark SQL
     Demo


     View Slide

132. 132
     Training from Zinoviev Alexey
     HIVE INTEGRATION


     View Slide

133. 133
     Training from Zinoviev Alexey
     Hive Support


     View Slide

134. 134
     Training from Zinoviev Alexey
     If you have a Hive in Spark application
     • Support for writing queries in HQL
     • Catalog info from Hive MetaStore
     • Tablescan operator that uses Hive SerDes
     • Wrappers for Hive UDFs, UDAFs, UDTFs


     View Slide

135. 135
     Training from Zinoviev Alexey
     Hive
     val hive = new HiveContext(spark)
     hive.hql(“CREATE TABLE IF NOT EXISTS src (key INT,
     value STRING)”)
     hive.hql(“LOAD DATA LOCAL INPATH ‘…/kv1.txt’ INTO
     TABLE src”)
     val results = hive.hql(“FROM src SELECT key,
     value”).collect()


     View Slide

136. 136
     Training from Zinoviev Alexey
     Hive
     val hive = new HiveContext(spark)
     hive.hql(“CREATE TABLE IF NOT EXISTS src (key INT,
     value STRING)”)
     hive.hql(“LOAD DATA LOCAL INPATH ‘…/kv1.txt’ INTO
     TABLE src”)
     val results = hive.hql(“FROM src SELECT key,
     value”).collect()


     View Slide

137. 137
     Training from Zinoviev Alexey
     Hive
     val hive = new HiveContext(spark)
     hive.hql(“CREATE TABLE IF NOT EXISTS src (key INT,
     value STRING)”)
     hive.hql(“LOAD DATA LOCAL INPATH ‘…/WarAndPeace.txt’
     INTO TABLE src”)
     val results = hive.hql(“FROM src SELECT key,
     value”).collect()


     View Slide

138. 138
     Training from Zinoviev Alexey
     Hive
     val hive = new HiveContext(spark)
     hive.hql(“CREATE TABLE IF NOT EXISTS src (key INT,
     value STRING)”)
     hive.hql(“LOAD DATA LOCAL INPATH ‘…/WarAndPeace.txt’
     INTO TABLE src”)
     val results = hive.hql(“FROM src SELECT key,
     value”).collect()


     View Slide

139. 139
     Training from Zinoviev Alexey
     How to cache in memory?


     View Slide

140. 140
     Training from Zinoviev Alexey
     Easy to cache
     sql.cacheTable(“people”)


     View Slide

141. 141
     Training from Zinoviev Alexey
     The main problem of this approach


     View Slide

142. 142
     Training from Zinoviev Alexey
     THORNY PATH TO
     DATASETS


     View Slide

143. 143
     Training from Zinoviev Alexey
     History of Spark APIs


     View Slide

144. 144
     Training from Zinoviev Alexey
     RDD
     rdd.filter(_.age > 21) // RDD
     df.filter("age > 21") // DataFrame SQL-style
     df.filter(df.col("age").gt(21)) // Expression style
     dataset.filter(_.age < 21); // Dataset API


     View Slide

145. 145
     Training from Zinoviev Alexey
     History of Spark APIs


     View Slide

146. 146
     Training from Zinoviev Alexey
     SQL
     rdd.filter(_.age > 21) // RDD
     df.filter("age > 21") // DataFrame SQL-style
     df.filter(df.col("age").gt(21)) // Expression style
     dataset.filter(_.age < 21); // Dataset API


     View Slide

147. 147
     Training from Zinoviev Alexey
     Expression
     rdd.filter(_.age > 21) // RDD
     df.filter("age > 21") // DataFrame SQL-style
     df.filter(df.col("age").gt(21)) // Expression style
     dataset.filter(_.age < 21); // Dataset API


     View Slide

148. 148
     Training from Zinoviev Alexey
     History of Spark APIs


     View Slide

149. 149
     Training from Zinoviev Alexey
     DataSet
     rdd.filter(_.age > 21) // RDD
     df.filter("age > 21") // DataFrame SQL-style
     df.filter(df.col("age").gt(21)) // Expression style
     dataset.filter(_.age < 21); // Dataset API


     View Slide

150. 150
     Training from Zinoviev Alexey
     DataSet = RDD’s types + DataFrame’s Catalyst
     • RDD API
     • compile-time type-safety
     • off-heap storage mechanism
     • performance benefits of the Catalyst query optimizer
     • Tungsten


     View Slide

151. 151
     Training from Zinoviev Alexey
     DataSet = RDD’s types + DataFrame’s Catalyst
     • RDD API
     • compile-time type-safety
     • off-heap storage mechanism
     • performance benefits of the Catalyst query optimizer
     • Tungsten


     View Slide

152. 152
     Training from Zinoviev Alexey
     Structured APIs in SPARK


     View Slide

153. 153
     Training from Zinoviev Alexey
     Unified API in Spark 2.0
     DataFrame = Dataset[Row]
     Dataframe is a schemaless (untyped) Dataset now


     View Slide

154. 154
     Training from Zinoviev Alexey
     Define
     case class
     case class User(email: String, footSize: Long, name: String)
     // DataFrame -> DataSet with Users
     val userDS =
     spark.read.json("/home/tmp/datasets/users.json").as[User]
     userDS.map(_.name).collect()
     userDS.filter(_.footSize > 38).collect()
     ds.rdd // IF YOU REALLY WANT


     View Slide

155. 155
     Training from Zinoviev Alexey
     Read JSON
     case class User(email: String, footSize: Long, name: String)
     // DataFrame -> DataSet with Users
     val userDS =
     spark.read.json("/home/tmp/datasets/users.json").as[User]
     userDS.map(_.name).collect()
     userDS.filter(_.footSize > 38).collect()
     ds.rdd // IF YOU REALLY WANT


     View Slide

156. 156
     Training from Zinoviev Alexey
     Filter by
     Field
     case class User(email: String, footSize: Long, name: String)
     // DataFrame -> DataSet with Users
     val userDS =
     spark.read.json("/home/tmp/datasets/users.json").as[User]
     userDS.map(_.name).collect()
     userDS.filter(_.footSize > 38).collect()
     ds.rdd // IF YOU REALLY WANT


     View Slide

157. 157
     Training from Zinoviev Alexey
     DataSet API
     Demo


     View Slide

158. 158
     Training from Zinoviev Alexey
     Spark
     Family


     View Slide

159. 159
     Training from Zinoviev Alexey
     CATALYST OPTIMIZER


     View Slide

160. 160
     Training from Zinoviev Alexey
     Job Stages in Spark


     View Slide

161. 161
     Training from Zinoviev Alexey
     Scheduler Optimizations


     View Slide

162. 162
     Training from Zinoviev Alexey
     What’s faster: SQL or DataSet API?


     View Slide

163. 163
     Training from Zinoviev Alexey
     Unified Logical Plan


     View Slide

164. 164
     Training from Zinoviev Alexey
     SQL String -> Execution


     View Slide

165. 165
     Training from Zinoviev Alexey
     Catalyst Optimizer for DataFrames


     View Slide

166. 166
     Training from Zinoviev Alexey
     Bytecode


     View Slide

167. 167
     Training from Zinoviev Alexey
     How optimizer works


     View Slide

168. 168
     Training from Zinoviev Alexey
     DataSet.explain()
     == Physical Plan ==
     Project [avg(price)#43,carat#45]
     +- SortMergeJoin [color#21], [color#47]
     :- Sort [color#21 ASC], false, 0
     : +- TungstenExchange hashpartitioning(color#21,200), None
     : +- Project [avg(price)#43,color#21]
     : +- TungstenAggregate(key=[cut#20,color#21], functions=[(avg(cast(price#25 as
     bigint)),mode=Final,isDistinct=false)], output=[color#21,avg(price)#43])
     : +- TungstenExchange hashpartitioning(cut#20,color#21,200), None
     : +- TungstenAggregate(key=[cut#20,color#21],
     functions=[(avg(cast(price#25 as bigint)),mode=Partial,isDistinct=false)],
     output=[cut#20,color#21,sum#58,count#59L])
     : +- Scan CsvRelation(-----)
     +- Sort [color#47 ASC], false, 0
     +- TungstenExchange hashpartitioning(color#47,200), None
     +- ConvertToUnsafe
     +- Scan CsvRelation(----)


     View Slide

169. 169
     Training from Zinoviev Alexey
     Why does explain() show
     so many Tungsten things?


     View Slide

170. 170
     Training from Zinoviev Alexey
     Tungsten’s goal
     Push performance closer to the limits of modern
     hardware


     View Slide

171. 171
     Training from Zinoviev Alexey
     How to be effective with CPU
     • Runtime code generation (Whole Stage Code Generation)
     • Сache locality
     • Off-heap memory management


     View Slide

172. 172
     Training from Zinoviev Alexey
     Cache Locality


     View Slide

173. 173
     Training from Zinoviev Alexey
     Whole-Stage CodeGen


     View Slide

174. 174
     Training from Zinoviev Alexey
     Tungsten
     Power


     View Slide

175. 175
     Training from Zinoviev Alexey
     SERIALIZATION


     View Slide

176. 176
     Training from Zinoviev Alexey
     Issue: Spark uses Java serialization A LOT


     View Slide

177. 177
     Training from Zinoviev Alexey
     Two choices to distribute data across cluster
     • Java serialization
     By default with ObjectOutputStream
     • Kryo serialization
     Should register classes (no support of Serialazible)


     View Slide

178. 178
     Training from Zinoviev Alexey
     The main problem: overhead of serializing
     Each serialized object contains the class structure as
     well as the values


     View Slide

179. 179
     Training from Zinoviev Alexey
     The main problem: overhead of serializing
     Each serialized object contains the class structure as
     well as the values
     Don’t forget about GC


     View Slide

180. 180
     Training from Zinoviev Alexey
     Tungsten Compact Encoding


     View Slide

181. 181
     Training from Zinoviev Alexey
     Maybe something UNSAFE?


     View Slide

182. 182
     Training from Zinoviev Alexey
     UnsafeRowFormat
     • Bit set for tracking null values
     • Small values are inlined
     • For variable-length values are stored relative offset into the
     variable length data section
     • Rows are always 8-byte word aligned
     • Equality comparison and hashing can be performed on raw
     bytes without requiring additional interpretation


     View Slide

183. 183
     Training from Zinoviev Alexey
     Encoder’s concept
     Generate bytecode to interact with off-heap
     &
     Give access to attributes without ser/deser


     View Slide

184. 184
     Training from Zinoviev Alexey
     Encoders


     View Slide

185. 185
     Training from Zinoviev Alexey
     No custom encoders


     View Slide

186. 186
     Training from Zinoviev Alexey
     PERFORMANCE


     View Slide

187. 187
     Training from Zinoviev Alexey
     How to measure Spark performance?


     View Slide

188. 188
     Training from Zinoviev Alexey
     You'd measure performance!


     View Slide

189. 189
     Training from Zinoviev Alexey
     TPCDS
     99 Queries
     http://bit.ly/2dObMsH


     View Slide

190. 190
     Training from Zinoviev Alexey


     View Slide

191. 191
     Training from Zinoviev Alexey
     How to benchmark Spark


     View Slide

192. 192
     Training from Zinoviev Alexey
     Special Tool from Databricks
     Benchmark Tool for SparkSQL
     https://github.com/databricks/spark-sql-perf


     View Slide

193. 193
     Training from Zinoviev Alexey
     Spark 2 vs Spark 1.6


     View Slide

194. 194
     Training from Zinoviev Alexey
     MEMORY MANAGEMENT


     View Slide

195. 195
     Training from Zinoviev Alexey
     Can I influence
     on Memory Management in Spark?


     View Slide

196. 196
     Training from Zinoviev Alexey
     Should I tune generation’s stuff?


     View Slide

197. 197
     Training from Zinoviev Alexey
     Cached
     Data


     View Slide

198. 198
     Training from Zinoviev Alexey
     During
     operations


     View Slide

199. 199
     Training from Zinoviev Alexey
     For your
     needs


     View Slide

200. 200
     Training from Zinoviev Alexey
     For Dark
     Lord


     View Slide

201. 201
     Training from Zinoviev Alexey
     IN CONCLUSION


     View Slide

202. 202
     Training from Zinoviev Alexey
     Contacts
     E-mail : Alexey_Zinovyev@epam.com
     Twitter : @zaleslaw @BigDataRussia
     vk.com/big_data_russia Big Data Russia
     + Telegram @bigdatarussia
     vk.com/java_jvm Java & JVM langs
     + Telegram @javajvmlangs


     View Slide

203. 203
     Training from Zinoviev Alexey
     Github
     Spark Tutorial: Core, Streaming, Machine Learning
     https://github.com/zaleslaw/Spark-Tutorial


     View Slide

204. 204
     Training from Zinoviev Alexey
     Gitbook
     Обработка данных на Spark 2.2 и Kafka 0.10
     www.gitbook.com/book/zaleslaw/data-processing-book


     View Slide

205. 205
     Training from Zinoviev Alexey
     Any questions?


     View Slide
