Observability in
Dynamic and Distributed Environments
Alexander Schwartz, Principal IT Consultant
OOP Munich 2019-01-24

View Slide

Observability in Dynamic and Distributed Environments
2
© msg | January 2019 | Observability in Dynamic and Distributed Environments | Alexander Schwartz
Aspects of Observability
1
Health Status Information
2
Alerts and Insights with Metrics
3
Hunting Root Causes and Latencies with Traces
4
Logs as a Stream of Events
5
Putting it all together
6

View Slide

About me – Principal IT Consultant @ msg Travel & Logistics
© msg | January 2019 | Observability in Dynamic and Distributed Environments | Alexander Schwartz 3
15+ years Java
7 years PL/SQL 7 years
online loans
3,5 Online Banking
7 years IT Consulting
600+
Geocaches
@ahus1de

View Slide

4
1
2
3
4
5
6

View Slide

1. https://de.wikipedia.org/wiki/Fallacies_of_Distributed_Computing
Distributed and dynamic environments
• Services scale up and down to offer the
capacity needed
• Networks between services can (and will) fail
unexpectedly and are sometimes slow
• Topologies change
• Different administrators for different services
and infrastructure elements

View Slide

Overview Observability
Known
Knowns
Known
Unknowns
Unknown
Unknowns
Monitoring tells me something is broken (symptom). It‘s the source of alerting, if an immediate action
by a human is required.
Observability is everything else I need to find out why something is not working.
Situation known
at time of
development
Possible situation,
exact parameters
unclear
Unexpected situation,
analysis based on
context information
Unknown
Knowns
Situations that were
known to
3rd-party-developers

View Slide

Using the information for Monitoring and Root Cause Analysis
Known
Knowns
Known
Unknowns
Unknown
Unknowns
Status
Information
(Health Check)
Logs (Events)
of categories
ERROR/WARN
Tracing
(dependencies,
error causes,
latencies)
Metrics
(counters, gauges,
error rates,
execution times)
Logs (Events)
of categories
INFO/DEBUG
Monitoring & Alerting
?
Analysis of root causes
Unknown
Knowns
+

View Slide

8
1
2
3
4
5
6

View Slide

Health and other Status Information
Intention for Status Information
• Deliver information before requests are processed by the system
(to find misconfigurations early in distributed systems)
• Actionable for the receiver of the information
• Observe situations that can‘t be remedied by the service itself
• Category of „known knowns“ (when implemented by the team or well known 3rd party library)
or „unknown knowns“ (if it is a surprise feature in a 3rd party library)
Examples:
Status check Actions to remedy
Database reachable Check database, check application configuration, check network
Connectivity Check Check configuration, check Network
Circuit Breaker open Check Network, check if remote service is too slow, check for more requests
than usual

View Slide

Spring Boot Health Information
Type Question Action
Endpoint to deliver a
global health status
Is the application
degraded or in an error
state?
Depending on the failed sub-system a specific
action is required.
Observation:
• Service health depends on external services that might still be starting/recovering
• Restarts don’t help to remedy the situation
• Although the application is degraded, the application might have fallbacks
• Some Spring Boot health checks perform remote network calls and might take an unacceptable long
time to complete if network problem occur

View Slide

Kubernetes Liveness and Readiness Probes
Observation 1: Using the same probes for different actions in different situation is a bad idea
Observation 2: Spring Boot Health Information doesn’t match Kubernetes readiness/liveness concept,
therefore implement different endpoints to provide answers specific to Kubernetes’ questions
Type Question Action
Readiness Probe
(when starting)
Has the pod started
correctly?
After a timeout a non-ready pod will be killed and
restarted. Once it is ready it will be added to the
load balancer.
Readiness Probe
(when running)
Can the pod serve
requests?
Enable or disable the pod in the load balancer.
Liveness Probe Is the pod is in a
deterministic state?
Kill and restart the pod when this state persists.

View Slide

Best practices for Health Indicators
When collecting health indications:
• Implement health indicators for all remote systems and configurations
• Make the health indicators complete in a predetermined time (short timeouts)
• Archive the status indicator of each subsystem in your metrics/monitoring system
When triggering automatic actions:
• Ask specific questions
• Provide an answer as an aggregation of maybe several health indicators

View Slide

13
1
2
3
4
5
6

View Slide

Insights with Metrics
Micrometer
Micrometer [maɪˈkrɒm.ɪ.tər] is a facade (API) to collect metrics independent of the storage or your metrics
(“SLF4J, but for metrics”).
• Multidimensional metrics
• Integrations for libraries and backends
(Prometheus, Datadog, Ganglia, Graphite, JMX, New Relic, …)
• Ready to use with Spring Boot 1.x and 2.x
• Can be used stand-alone and together with other frameworks
• Version 1.0 released at the same time as Spring Boot 2.0
• Version 1.1 released at the same time as Spring Boot 2.1
Homepage: https://micrometer.io/
License: Apache 2.0

View Slide

Micrometer API
Base for all metrics: Name, optional: tags and description
Some Metrics Types:
• Counter: e. g. number of successful and not successful calls
• Gauge: e. g. number of currently active database connections
• Timer: e. g. duration of calls
Counter myOperationSuccess = Counter
.builder("myOperation")
.description("a description for humans")
.tags("result", "success")
.register(registry);
myOperationSuccess.increment();

View Slide

Micrometer API
Derived Metrics:
• Rate: e. g. calls per second
• Percentile: e. g. 90% of all calls faster than X ms
• Histogram: e. g. X calls in the interval of 50 ms to 100 ms
Histograms can be aggregated over instances, percentiles can‘t!

View Slide

Direction of the arrow: Data flow
Micrometer Architecture
Metrics
Backend
Meter
Registry
Micrometer
Core
3rd Party
Libraries
Adapter
Your Code
Application

View Slide

Direction of the arrow: Data flow
Example Infrastructure
Grafana Prometheus Application
Alert Manager
Metrics Backend
Application
Application

View Slide

Prometheus for distributed environments
Responsibilities:
• Collect and store metrics
• Handle inquiries for dashboards
• Alarms, Trend calculations
Well suited for:
• Discovering services via service discovery in dynamic environments
• Adding metadata to collected metrics (stage, datacenter, cluster,
node)
• Blending infrastructure metrics with application metrics
including business metrics
Homepage: https://prometheus.io
License: Apache 2.0

View Slide

Using Metrics to build Monitoring and Alerting
• Plain metric
http_server_requests_seconds_count
• Metric filtered by label
http_server_requests_seconds_count{status!='200'}
• Rate of calls in 5-minute interval (moving average)
rate (http_server_requests_seconds_count{status!='200'} [5m])
• Error Percentage per URI used for alerting
sum by (uri) (rate (http_server_requests_seconds_count {status!='200'} [5m]))
/
sum by (uri) (rate (http_server_requests_seconds_count [5m]))
> 0.01

View Slide

Best practices for Metrics
• Use the metrics your framework provides
• Setup the metrics environment already in testing stages
• When something is being logged, it is probably a good idea to create a metric for it
• Collecting metrics is more runtime-efficient than writing it into a log

View Slide

30
1
2
3
4
5
6

View Slide

Analyzing errors and latencies
The server
doesn’t respond!
Sometimes it is
so slow!

View Slide

1. https://twitter.com/rakyll/status/1045075510538035200
A better way to explain why tail latency matters
Jaana B. Dogan (@rakyll)

View Slide

Concept of Google’s Dapper
pass Trace-ID and
additionally a Span-ID
assign Trace-ID

View Slide

Zipkin Server receives information and provides a Web UI
For each Trace-/Span-ID:
• start-/end time client
• start-/end time server
• tags and logs

View Slide

Web UI Zipkin

View Slide

Sampling Traces
• In production only a percentage of requests is traced to save data and performance.
The percentage is enough to trace errors and latencies, but you won‘t be analyze all requests
• The first node decides what calls are being traced.
• You can force tracing by adding for example a special header to the incoming request
(don‘t allow that header to be sent from public Internet to prevent denial of service attack)

View Slide

Zipkin Browser-Plugin for Chrome
Add trace-ID
to HTTP Headers
at client
Direct link to traces view
in a new tab

View Slide

Best practices for Tracing
• Trace everything in development and testing
• Trace a small percentage or only on-demand in production
• Use tracing to investigate incidents and locate the relevant service (“unknown unknowns”)
• Use the generated dependency graph to verify and optimize dependencies

View Slide

40
1
2
3
4
5
6

View Slide

Welcome to Logging Hell!
Log:
Code:
for (Invoice i : invoiceRespository.findAll()) {
i.calculateTotal();
}
07:26:00.595 d.a.t.d.Invoice ERROR - can't load item ID 4711

View Slide

Logs with Context Information
for (Invoice i : respository.findAll()) {
ThreadContext.put(INVOICE_ID, Long.toString(i.getId()));
try {
i.calculateTotal();
} finally {
ThreadContext.remove(INVOICE_ID);
}
}

View Slide

Configuring the Logging Pattern
Configuration:
Log output:

08:39:42.969 {invoiceId=1} ... - can't load purchase ID 4711

View Slide

Log output for Web Applications
08:52:54.276 {http.method=GET,
http.url=http://localhost:8080/api/startBillingRun, invoiceId=1,
user=Theo Tester} ERROR d.a.t.d.Invoice - can't load purchase ID 4711
Further fields that might of of interest:
• Client-IP-Address
• Part of the Session-ID
• Browser name (User Agent)

View Slide

Adding correlation IDs to log entries
Additional Tracing HTTP Header:
GET /api/callback HTTP/1.1
Host: localhost:8080
...
X-B3-SpanId: 34e628fc44c0cff1
X-B3-TraceId: a72f03509a36daae
...
09:20:05.840 {
X-B3-SpanId=34e628fc44c0cff1,
X-B3-TraceId=a72f03509a36daae,
..., invoiceId=1} ERROR
d.a.t.d.Invoice - can't load
purchase ID 4711
Additional Information in the Log:

View Slide

Per-Request-Debugging-Logging
• Zipkin passes on the Header X-B3-Flags, that can encode additional information
• Zipkin-Chrome-Plugin passes the value “1” (debug=true)
• A Servlet-Filter can pick up this value and pass it to the Tread Context of Log4j2
(for example set X-B3-Flags-debug to true)
• The following log4j2-Configuration activates the trace level for requests that have this HTTP-Header
defaultThreshold="warn" onMismatch="NEUTRAL">

View Slide

Aggregate logs in a central, searchable store
Create a searchable store of
logs (rotate after fixed amount
of logs).
JSON log entries are the
simplest format that can be
parsed.
All nodes ship their logs
to a central store
(asynchronously)

View Slide

Best practices for Logging
• Use context information
• Have a central searchable storage for your logs
• Use JSON as a log format
• Enable log level configuration on request level
• Include correlation IDs in user’s error messages so can search the logs

View Slide

52
1
2
3
4
5
6

View Slide

Status Information
• Deliver actionable information even when no requests are processed
• Essential to handle „known knowns“ problems ahead of users reporting problems
• Implement health indicators for all remote systems and configurations
• Ask specific questions to trigger actions

View Slide

Metrics
• Look at response time percentiles and error rates to spot problems
• Essential to handle „known known“ and “known unknown” problems ahead of users reporting problems
• Frameworks already offer standard metrics
• Adding a custom metric to an application takes sometimes only one line of code
• Aggregate metrics over nodes and environments and calculating historical trends
• Treat your status information as metrics to use the same metrics and alerting pipeline

View Slide

Tracing
• Use it to find out root causes for latencies and errors
• Essential to handle „unknown unknowns“ during incident investigation
• Can draw automatic call trees from trace information
• It provides you free correlation IDs for your logs
• On top of tracing you can enable per-request debug logs

View Slide

Logging
• Use Levels error/warn to signal problems („known knowns“, „unknown knowns“)
• Use Levels info/debug to analyze incidents
• Aggregate the logs with context, starting with the correlation ID and request meta data
• Make them searchable by logging in JSON format and aggregating all logs in a central store (Graylog or
Kibana)

View Slide

Things that changed in distributed environments
Type Static Nodes Dynamic Multi-Node / Distributed
Correlation of
events
Session ID or thread ID Correlation ID passed between processes and
hosts

View Slide

Correlation of
events
hosts
Searching logs Log files and manually
configured log level
Central log server with searchable logs, dynamic
log level

View Slide

Correlation of
events
hosts
Central log server with searchable logs,
dynamic log levels
Metrics and
Monitoring
Manual monitoring configured
by operations
Linked to Service Discovery, metrics added by
application team autonomously

View Slide

Correlation of
events
hosts
dynamic log levels
Metrics and
Monitoring
by operations
Status Information Preflight check when starting
the application
Used for automated restarts and scaling, configure
load balancers, check remote connections

View Slide

Correlation of
events
hosts
dynamic log levels
Metrics and
Monitoring
by operations
the application
Tracing Root cause usually within the
edge node
Root cause for latency/fault usually not in edge
node, tracing will point to the problem/dependency

View Slide

Correlation of
events
hosts
dynamic log levels
Metrics and
Monitoring
by operations
the application
Tracing Root cause usually within the
edge node
Root cause for latency/fault usually not in edge
node, tracing will point to the problem/dependency
Some of the previous best practices turned to essential practices in a distributed environment.

View Slide

Links
Micrometer.io
https://micrometer.io
Prometheus:
https://prometheus.io
Grafana
https://grafana.com
Log4j
https://logging.apache.org/log4j
Graylog
https://www.graylog.org/ @ahus1de
Zipkin, Brave
https://github.com/openzipkin
Google SRE Book (Chapter “Monitoring Distributed Systems”)
https://landing.google.com/sre/
Additional Slides
https://www.ahus1.de/post/micrometer
https://www.ahus1.de/post/logging-and-tracing
https://www.ahus1.de/post/prometheus-and-grafana

View Slide

.consulting .solutions .partnership
Alexander Schwartz
Principal IT Consultant
+49 171 5625767
[email protected]
@ahus1de
msg systems ag (Headquarters)
Robert-Buerkle-Str. 1, 85737 Ismaning
Germany
www.msg.group

View Slide

Observability in dynamic and distributed Microservice Environments

Observability in dynamic and distributed Microservice Environments

Alexander Schwartz

More Decks by Alexander Schwartz

Other Decks in Programming

Featured

Transcript
