Akamai Connector for Varnish Webinar

Many organizations use Varnish at origin and Akamai at the Edge for scale, availability, and offload. This “dual-layer” of caching delivers a “best-of-both-worlds” approach for customers employing both solutions.

This approach has its challenges. Disparate caching layers mean Varnish users who want to take advantage of Akamai’s caching can endure operational inefficiencies.

To help overcome these challenges, Akamai and Varnish have collaborated to deliver the Akamai Connector for Varnish. The Connector allows Varnish administrators to use the VCL to integrate their Varnish instances at origin with Akamai at the Edge.

Join Davey Shafik, Akamai Developer Evangelist; Colin Bendell, Akamai CTO Office; and Dag Haavi Finstad, Varnish Software Engineer; for our webinar.

In this webinar, you’ll learn:

How to install and configure the Akamai Connector for Varnish
How the Connector works, and where to use it
Real-world examples of how it has proven effective

Transcript

1. Akamai Connector for Varnish akamaidev.io/varnish-connector
2. Colin Bendell Director, CTO Office Akamai Dag Finstad Software Developer Varnish Software Davey Shafik Developer Evangelist Akamai
3. Simplified Dev; Simplified Ops; Engineered for Performance Akamai Connector for Varnish Performance & Caching The Connector Advanced Uses
4. Configuration APIs Monitoring Integrations Client Libraries Edge Logic Akamai CLI Testing developer.akamai.com/devops Akamai for DevOps
5. Purge Synchronization Define Cache Rules Ensure Best Practices Defer ESI Processing Device Characteristics Control Refresh Traffic Akamai Connector for Varnish
6. Performance & Caching
7. The Mobile User Experience
8. Page Load Time: Seconds We Have Different Experiences on the Web
9. Page Load Time: Seconds Users Expect Web Pages in 2s (even on cellular) But Users Expect Fast
10. Performance Impacts Business Metrics
11. ▼ Wait ├ Caching ├ Protocol opt ├ Route opt. └ Sharding ├ webpack ├ sprites & inlining ├ lazyload └ PWA ▼ Reqs ├ Critical CSS ├ Service Workers ├ AMP └ 4:2:0 Chroma ▲ Render ▼ Bits ├ RWD ├ gzip / br ├ jp2 / webp └ HTTP/2 #WebPerf 101 Web Performance Strategies
12. Fixing Performance: Where do you start?
13. Performance & Caching
14. L1: 0.0005μs L2: 0.007μs L2: 0.030μs RAM: 0.1 μs SSD: 0.15 ms Seek: 10 ms Wifi: 25ms LTE: 75ms 3G: 150ms 1 bit of data accessed from CPU, Memory, Disk, Network Caching is Everywhere (200x L1) (20,000,000x L1) (300,000,000x L1) (1,000,000,000x L1) (10,000,000,000x L1)
16. First Deployment: No Caching 50ms 0ms 500ms TCP + HTTP + Server Think 400ms + 200ms + 500ms = 1,100ms
17. Real World 50ms 150ms 500ms TCP + HTTP + Server Think 800ms + 400ms + 500ms = 1,700ms 800ms + 800ms + 800ms = 2,400ms
18. Cache at Origin 50ms 150ms 500ms 800ms + 400ms + 1ms = 1,201ms
19. Cache at Origin = 800ms + 75 * (400ms + 1ms) TCP + HTTP + Server Think x 75 requests (httparchive.org) ( ) = 30.9 seconds!
20. Layers of Cache: Akamai + Origin 50ms 400ms + 100ms + 1ms = 101ms
21. Akamai's View of the Internet
22. Performance & Caching
23. CBC akamaidev.io/cbc-story
24. Varnish at Origin with Long Tail content Problem: low offload 80% Offload 30s TTL 90% Offload
25. 750 500 250 0 mbps 2 June 9 June 16 June 23 June 30 Jun Solution: Coordinated Caches 95+% Offload; Origin Traffic below 100mbps at peak
26. 3s Page Load Time After: faster page load time 1/3rd total page load time 2s 1s 5s 6s
27. The Connector
28. Purge Synchronization Define Cache Rules Ensure Best Practices Defer ESI Processing Device Characteristics Control Refresh Traffic Akamai Connector for Varnish
29. High Level Architecture Akamai Edge Varnish App Server CCU API
30. Installation
31. Getting Started (v4 or later) or
32. $ cp akamai_connector.repo /etc/yum.repos.d/ $ yum clean all $ yum install varnish-plus-akamai-connector [..] Installed: Varnish-plus-akamai-connector.x86_64 0:0.20170505-1.el7 Complete! $ Installation
33. $ akamai-connector-setup.sh
34. $ akamai-connector-setup.sh Akamai Connector for Varnish setup Usage: akamai-connector-setup.sh {install|force-*|remove-*|help} install Install the base Akamai VCLs and conf Does not overwrite if destination exists force-vcl Backup and force install the base Akamai VCLs force-conf Backup and force install the Akamai conf force-all Backup and force install the base Akamai VCLs and conf remove-vcl Remove the base Akamai VCLs remove-conf Remove the Akamai conf remove-all Remove the base Akamai VCLs and conf help This message Source: /usr/share/doc/akamai-connector VCL Destination: /etc/varnish Conf Destination: /etc/akamai-connector.conf
35. $ akamai-connector-setup.sh install $ Akamai Connector for Varnish setup Installing Source: /usr/share/doc/akamai-connector/akamai_auto.vcl Destination: /etc/varnish Arguments: --no-clobber Success Source: /usr/share/doc/akamai-connector/akamai.vcl Destination: /etc/varnish Arguments: --no-clobber Success Source: /usr/share/doc/akamai-connector/akamai-connector.conf.example Destination: /etc/akamai-connector.conf Arguments: --no-clobber Success
36. $ $ vim /etc/varnish/default.vcl /etc/varnish/default.vcl vcl 4.0; import std; backend default { .host = "127.0.0.1"; .port = "8080"; } sub vcl_backend_response { // usual stuff here set beresp.ttl = 5m; } import akamai; include "akamai_auto.vcl";
37. $ systemctl reload varnish $ Validating the configuration $
38. $ http \ http://localhost/akamai/testobject.html \ Via:"akamai.net(ghost) (AkamaiGHost)" HTTP/1.1 200 OK Content-Length: 20480 Date: Fri, 16 Jun 2017 12:49:54 GMT X-Varnish: 32770 3 Edge-Control: max-age=310, post-check=300 Via: 1.1 varnish-v4, Akamai Connector/1.0.2 Accept-Ranges: bytes Connection: keep-alive Validating the configuration $
39. $ $ vim /etc/varnish/default.vcl /etc/varnish/default.vcl vcl 4.0; import std; import akamai; include "akamai_auto.vcl"; backend default { .host = "127.0.0.1"; .port = "8080"; } sub vcl_recv { // usual stuff here } if (req.method == "PURGE") { return (purge); }
40. Setting up Purge akamaidev.io/api-credentials Ensure you have the API credentials for the CCU application host = akab-j4ut6lhxxxxk4zg-pfoqijsuxhntuabu.luna.akamaiapis.net client_secret = 6bbwkmp7xXXXX3srdgnwuhmmwgt6raln8uwd2njezo+8= access_token = akab-dzwylxxxxsx2s2fw-7ah4yypbk7bcii65 client_token = akab-cphsxxxxdyrym4-4drvje7rfbyvumfc
41. /etc/akamai-connector.conf $ $ vim /etc/akamai-connector.conf # Akamai Connector configuration settings # The purge host to connect to purge_host=<purge host> # The client token credential for purging purge_client_token=<client token> # The client secret credential for purging purge_client_secret=<client secret> # The access token credential for purging purge_access_token=<access token>
42. $ systemctl reload varnish $ Validating the configuration $
43. $ http PURGE http://localhost/article \ Host:example.com Validating purge configuration { "estimatedSeconds": 5, "purgeId": "01d62080-5295-11e7-af78", "supportId": "17PY1497618559250268-202654912", "httpStatus": 201, "detail": "Request accepted" }
44. Hold ‘Til Told
45. Example: Sports News Hold 'Til Told WPO Sports WPO Sports wposports.com
46. { "CHC": 0, "CLE": 0 } Cache forever; until it changes Hold 'Til Told
47. Scores change infrequently, but must be up-to-date What is the Right TTL? 8:02 8:04 (1-0) 8:48 (1-1) 9:12 (2-1) 9:56 (5-1) 10:08 (5-3) 10:09 (6-3) 10:30 (6-6) 12:24 (8-6) 12:42 (8-7) 12:56
48. Scores change infrequently, but must be up-to-date How do you keep scores fresh? 8:02 8:04 (1-0) 8:48 (1-1) 9:12 (2-1) 9:56 (5-1) 10:08 (5-3) 10:09 (6-3) 10:30 (6-6) 12:24 (8-6) 12:42 (8-7) 12:56
49. /etc/varnish/default.vcl vcl 4.0; import std; import akamai; include "akamai_auto.vcl"; sub vcl_backend_response { } // Edge TTL set beresp.ttl = 365d; // Downstream TTL set beresp.http.Cache-Control = "max-age=5";
50. $ http GET origin.example.com/score/CHC-CLE \ Via:"akamai.net(ghost) (AkamaiGHost)" Testing Hold 'Til Told (Origin) HTTP/1.1 200 OK Edge-Control: max-age=24h,downstream-ttl=5s { "CHC": 0, "CLE": 0 }
51. $ http GET example.com/score/CHC-CLE Testing Hold 'Til Told (Edge) HTTP/1.1 200 OK Cache-Control: max-age=5 { "CHC": 0, "CLE": 0 } $
52. Grace TTL / Prefresh
53. Cache Miss = Poor User Experience Edge Varnish Origin
54. Short TTL, but refresh asynchronously Async Refresh & Grace TTL Cache Hit Cache Miss Cache Hit 5min TTL 5min TTL Cache Miss
55. Short TTL, but refresh asynchronously Async Refresh & Grace TTL Cache Hit Cache Hit Cache Hit
56. /etc/varnish/default.vcl vcl 4.0; import std; import akamai; include "akamai_auto.vcl"; sub vcl_backend_response { set beresp.ttl = 5m; } // Grace TTL set beresp.grace = 30s;
57. Varnish Grace TTL to Akamai Prefresh Automatic Translation Cache Hit Grace TTL TTL Prefresh TTL
58. Purge Synchronization Define Cache Rules Ensure Best Practices Defer ESI Processing Device Characteristics Control Refresh Traffic Akamai Connector for Varnish
59. Optimize your website’s performance for web and mobile automatically Akamai Connector for Varnish Performance & Caching Installation Advanced Uses
60. Akamai Connector for Varnish v1 The Beginning of the Journey
61. Call To Action • Register and download the Connector today; its free! • Download: https://www.varnish-software.com/products/akamai-connector-for-varnish/ • Documentation: https://akamai-connector.varnish-software.com/akamai-connector- guide.pdf • Support: email to akamai-connector@varnish-software.com • Akamai Developer site: http://akamaidev.io/varnish-connector Reformat: Austin
62. Akamai Connector for Varnish Take Action! akamaidev.io/varnish-connector
63. Akamai Connector for Varnish akamaidev.io/varnish-connector @ColinBendell @DShafik Dag Finstad
