From Development to Deployment - Use Akamai to Facilitate Workflow Automation

Being able to Continually Integrate and Continually Deliver (CI/CD) application code and configurations is at the heart of DevOps within any organization. During this session, we will discuss how to leverage existing available Akamai tools and products such as PAPI, EAA, and Cloudlet to empower end-to-end workflow. We will learn how to spin up completely separate, fully-integrated development environments behind the firewall, where users can test development sites alongside their related Akamai dev configurations.

Transcript

1. © AKAMAI - EDGE 2017 From Development to Deployment: Use Akamai to Facilitate Workflow Automation By Eugene Zhang & Sabrina Burney
2. © AKAMAI - EDGE 2017 Legacy SDLC Plan & Code • Build • Unit test • Dev deployment Build & Test • Deploy to Test Envs • Functional and performance testing Release • Deploy to staging • Deploy to production • Update config • Deploy to Akamai staging • Deploy to Akamai production • Purge
3. © AKAMAI - EDGE 2017 Overview Plan & Code Build & Test Release Operate Monitor Provision & Deploy Fix/Enhance
4. © AKAMAI - EDGE 2017 Overview Plan & Code Build & Test Release Operate Monitor Provision & Deploy Fix/Enhance EAA Phase Release Fast Deployment Traffic Management PAPI/CPS
5. © AKAMAI - EDGE 2017 Development • Fast and Efficient • REST APIs for Everything • Akamai CLI • Build into Existing Infrastructure Plan & Code Build & Test Release
6. © AKAMAI - EDGE 2017 Development What components do we need to develop an environment? Edge SSL Certificates HTTP/s Delivery Data Center Routing How can we automate development of each component?
7. © AKAMAI - EDGE 2017 Development: Automation Manage Edge SSL Certificates • Certificate Provisioning System API (CPS) • Secure Provisioning Service API (SPS) Manage Traffic to Data Centers • Global Traffic Manager API (GTM) Manage Edge HTTP Delivery and Optimizations • Luna Property Manager API (PAPI)
8. © AKAMAI - EDGE 2017 Development: Standard Phases Create Update Deploy
9. © AKAMAI - EDGE 2017 Edge SSL Certificates Edge SSL Certificates • HTTPs adoption is growing • Guarantee secure delivery from Client to Edge • Quickly provision certificates from trusted Certificate Authorities (CA) HTTP/s Delivery Data Center Routing
10. © AKAMAI - EDGE 2017 Edge SSL Certificates: Life Cycle Create New Certificate Update Certificate: Edit or Renew Deploy Certificate
11. © AKAMAI - EDGE 2017 Edge SSL Certificates: Life Cycle with APIs Create New Certificate Update Certificate: Edit or Renew Deploy Certificate CPS & SPS API
12. © AKAMAI - EDGE 2017 CPS API: Certificate Management • JSON Format • Updates require 2- step process POST /cps/v2/enrollments?contractId=XXXXX { //Certificate type //Common Name & SAN //Organization Information } GET /cps/v2/enrollments/XXXXX { ... //Current SAN list ... } PUT /cps/v2/enrollments/XXXXX { ... //Updated SAN list ... } Create New Certificate Update Current Certificate Step1: Retrieve Update Current Certificate Step2: Submit
13. © AKAMAI - EDGE 2017 SPS API: Certificate Management • Form URL Encoded Format • Updates are 1- step process • Create Edge Hostnames Create New Certificate Update Current Certificate POST /config-secure-provisioning- service/v1/sps- requests/?contractId=XXXXX&groupId=XXXXX CnameHostname=XXXXX_&CertificateType=XXXXX_&CommonN ame=XXXXX_&SAN=XXXXX_&OrganizationInformation POST /config-secure-provisioning- service/v1/sps- requests/?contractId=XXXXX&groupId=XXXXX modifySAN=XXXXX POST /config-secure-provisioning- service/v1/secure-edge- hosts/?contractId=XXXXX&groupId=XXXXX CnameHostname=XXXXX Create New Edgekey Hostname
14. © AKAMAI - EDGE 2017 CPS vs SPS API
15. © AKAMAI - EDGE 2017 Traffic Management • Quickly onboard new data centers • Support successful and efficient migrations • Always maintain working QA & Production environments Data Center Routing Edge SSL Certificates HTTP/s Delivery
16. © AKAMAI - EDGE 2017 Traffic Management: Life Cycle Create New GTM Configuration Load Balancing Deploy GTM changes Failover Traffic Distribution IP Intelligence Update GTM Configuration
17. © AKAMAI - EDGE 2017 Traffic Management: Life Cycle with APIs Create New GTM Configuration Load Balancing Deploy GTM changes Failover Traffic Distribution IP Intelligence Update GTM Configuration GTM API
18. © AKAMAI - EDGE 2017 GTM API: Origin Routing Setup PUT /config-gtm/v1/domains/test-example.akadns.net HTTP/1.1 { //New Domain test-example.akadns.net } POST /config-gtm/v1/domains/test- example.akadns.net/datacenters { //Datacenters } PUT /config-gtm/v1/domains/test- example.akadns.net/properties/qa1 { //GTM Property for Traffic Distribution, Failover, Load balancing, and Liveness } Create New GTM Domain Assign DataCenters Create New GTM Property
19. © AKAMAI - EDGE 2017 Property Manager • Quickly spin up test configurations • Efficiently onboard new properties • Maintain working production environment while testing new logic Data Center Routing Edge SSL Certificates HTTP/s Delivery
20. © AKAMAI - EDGE 2017 Property Manager: Life Cycle Create Delivery Configuration Origin Rules Deploy changes Edge SSL Certs CPCode Update Configuration Traffic Routing Hostnames Cache/Compress Custom Rules Security Fast Activation
21. © AKAMAI - EDGE 2017 Property Manager: Life Cycle with APIs Create Delivery Configuration Origin Rules Deploy changes CPS API CPCode Update Configuration GTM API Hostnames Cache/Compress Custom Rules Security PAPI Fast Activation
22. © AKAMAI - EDGE 2017 Luna PAPI • Behaviors for (almost) everything • 1-step delivery configuration • Fast Deployment "behaviors": [ { "name": "origin" //Origin Rules - use GTM properties here //Origin SSL Pinning - Secure delivery between //Edge and Origin } { "name": "cpCode" //CpCode name and number } { "name": "caching" //Set TTL } { "name": "gzipResponse" //Switch to on/off } { "name": "subCustomer" //IP whitelisting } ]
23. © AKAMAI - EDGE 2017 Development: Code - Build - Release - Enhance CPS API Luna PAPI GTM API
24. © AKAMAI - EDGE 2017 Deployment: From Lab to Field Speed vs Control Availability and Redundancy No Impact to User Experience
25. © AKAMAI - EDGE 2017 Deployment: Phased Release Cloudlet • Service logic built into Edge • Gradually moving traffic over to newly deployed app • Safely expose customers to new experience, functionality, origin • Testing new application without affecting entire customer base • Activate in under one minute
26. © AKAMAI - EDGE 2017 Deployment: Cloudlet Policy PUT /cloudlets/api/v2/policies/<PolicyNumber>/versions/<VersionNumber> GET /cloudlets/api/v2/policies/<PolicyNumber>/properties POST /cloudlets/api/v2/policies/<PolicyNumber>/versions/<VersionNumber>/ activations Update Policy Retrieve Policy Activate Policy POST /cloudlets/api/v2/policies?gid=<groupid> Create Policy
27. © AKAMAI - EDGE 2017 Phased Release API
28. © AKAMAI - EDGE 2017 Phased Release API
29. © AKAMAI - EDGE 2017 Phased Release API
30. © AKAMAI - EDGE 2017 Phased Release API
31. © AKAMAI - EDGE 2017 Deployment: Fast Activation Speed • 10 minutes activation on production network • 3 minutes to activate on staging network Control • Network Safety Checks • Automatic Roll back if error increases • Easy roll back until property is 100% active Automation • Property Manager • PAPI
32. © AKAMAI - EDGE 2017 Fast Deployment Option to choose fast or regular (will go away eventually when all activations are fast) Automatically rolls back if unusual # of errors detected. (Not an option on Staging)
33. © AKAMAI - EDGE 2017 Deployment: Fast Purge KEY DIFFERENTIATORS BENEFITS Self-Service Management Luna Fast Purge App Open API Better Offload & Performance Longer TTL setting Consistent last mile performance Advantage of dynamic caching 5-second purge request speed Ability to purge by URL, CP code, and Cache Tag Instant Purge & Invalidation
34. © AKAMAI - EDGE 2017 Deployment: Fast Purge /ccu/v3/invalidate/url/network { "objects": [ "http://www.example.com/graphics/picture.gif", "http://www.site- example.com/graphics/picture.gif", "http://www.example1.com/documents/brochure. pdf" ]} { "hostname": "www.example.com", "objects": [ "/graphics/picture.gif", "/documents/brochure.pdf" ]} { "httpStatus": 201, "detail": "Request accepted.", "estimatedSeconds": 5, "purgeId": "043f-4af0-843f-aaf0043faaf0", "supportId": "17PY1321286429616716-211907680" } Request Body V3 format Response body
35. © AKAMAI - EDGE 2017 Continuous Testing Key Differentiator: Instant Secure Access ▪ Limited on-premise functional testing ▪ External exposure of internal application ▪ Complex testing workflow ▪ Limited APM tools Traditional Dev Environment Testing ▪ Testing during any development stages ▪ Instant access to dev env from anywhere ▪ End-to-end synthetic and real user testing ▪ Does not require network modification ▪ Strong security posture - Directory service integration - 2 factors authentication Continuous Testing with EAA
36. © AKAMAI - EDGE 2017 Continuous Testing
37. © AKAMAI - EDGE 2017
