Phil Meredith - Credit Suisse

Cassandra London Meetup - Sept 25th Meetup

Transcript

1. An overview of the Hippo project at Credit Suisse Phil Meredith – Equity Derivatives IT! phillip.meredith@credit-suisse.com
2. What is Hippo?
3. Equity Derivatives IT Hippo Risk System Trading UI Results Store
4. Equity Derivatives IT Refresh ! Data Make some decisions Tag data for calculations View calculation results Risk managing a portfolio
5. Equity Derivatives IT Technology Stack
6. Equity Derivatives IT “Gallerification”
7. Equity Derivatives IT Gallerification - example data { "equitySpotPrice/AAPL" : { "DateOfPrice" : "2014-08-26", "Id" : "AAPL", "Value" : 101.42, "Currency" : "USD" } } Source: Credit Suisse, 2014-08-26
8. Equity Derivatives IT “Tagging”
9. Equity Derivatives IT Tag – example data { "equitySpotPrice/AAPL": “{hippo path}", "fxSpotRate/GBP/USD": "{hippo path}" }
10. Challenges
11. Equity Derivatives IT The Challenges we faced High Availability Data Retention Scale
12. How can we make Hippo available all the time?
13. Equity Derivatives IT Unplanned downtime
14. Equity Derivatives IT Planned downtime
15. Equity Derivatives IT Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM HA Proxy Active! DC Passive! DC Topology DC1 DC2
16. Equity Derivatives IT Can we make it better?
17. Equity Derivatives IT Automatic DC switching
18. Equity Derivatives IT Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM HA Proxy Active! DC Passive! DC Detecting DC Failure – Normal Operation DC1 DC2
19. Equity Derivatives IT Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM HA Proxy Active! DC Passive! DC Detecting DC Failure – One node down DC1 DC2
20. Equity Derivatives IT Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM HA Proxy Active! DC Passive! DC Detecting DC Failure – Two nodes down DC1 DC2
21. Equity Derivatives IT Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM Hippo Hippo VM HA Proxy Passive! DC Active! DC Automatic Failover DC2 DC1
22. Equity Derivatives IT Can we make it better still?
23. Equity Derivatives IT Hippo Status Page Source: Credit Suisse, 2014-09-01
24. Equity Derivatives IT Hippo Status Page Source: Credit Suisse, 2014-09-01
25. Equity Derivatives IT How often do we actually flip the active DC? 6 times in the last three months! Source: Credit Suisse, 2014-09-01
26. How can we keep Data for longer?
27. Equity Derivatives IT Short term data
28. Equity Derivatives IT Long term data
29. Equity Derivatives IT Hippo could delete the data
30. Equity Derivatives IT Cassandra TTL ! to the rescue!
31. How can we scale?
32. Equity Derivatives IT Gallerify Create Tag Calculations 50sec 150sec 300sec Valuing a portfolio Takes 500 seconds 30% time spent building a tag!
33. Equity Derivatives IT Why is tag creation so slow?
34. Equity Derivatives IT Why are Tags occupying so much disk space?
35. Equity Derivatives IT Tag data overlap Tag 1 Tag 2 Tag 3 Tag 4
36. Equity Derivatives IT Gallery data overlap Gallery! Data Gallery! Data Gallery! Data Gallery! Data
37. Equity Derivatives IT It would be nice to create a tag based on an existing tag
38. Equity Derivatives IT tag! 123 equitySpotPrice/AAPL fxSpotRate/GBP/USD fxSpotRate/JPY/USD trade/tradeId123 /equitySpotPrice/AAPL/ v1 /fxSpotRate/GBP/USD/ v1 /fxSpotRate/JPY/USD/ v1 /trade/tradeId123/ v1 Tag CF: Tag! 456 equitySpotPrice/AAPL fxSpotRate/GBP/USD fxSpotRate/JPY/USD trade/tradeId123 /equitySpotPrice/AAPL/ v1 /fxSpotRate/GBP/USD/ v2 /fxSpotRate/JPY/USD/ v1 /trade/tradeId123/ v1
39. Equity Derivatives IT tag123 equitySpotPrice fxSpotRate trade equitySpotPrice123 fxSpotRate123 trade123 Tag CF: Taglet CF: equitySpotPrice123 equitySpotPrice/AAPL /equitySpotPrice/AAPL/v1 fxSpotRate123 fxSpotRate/GBP/USD fxSpotRate/JPY/USD /fxSpotRate/GBP/USD/v1 /fxSpotRate/JPY/USD/v1 trade123 trade/tradeId123 /trade/tradeId123/v1
40. Equity Derivatives IT DeltaTags! I want a new tag, which looks like tag123 but with a different fxSpotRate for GBP/ USD
41. Equity Derivatives IT tag123 equitySpotPrice fxSpotRate trade equitySpotPrice123 fxSpotRate123 trade123 tag456 equitySpotPrice trade equitySpotPrice123 trade123 Tag CF – New row Taglet CF equitySpotPrice123 equitySpotPrice/AAPL /equitySpotPrice/AAPL/v1 fxSpotRate123 fxSpotRate/GBP/USD fxSpotRate/JPY/USD /fxSpotRate/GBP/USD/v1 /fxSpotRate/JPY/USD/v1 trade123 trade/tradeId123 /trade/tradeId123/v1
42. Equity Derivatives IT tag123 equitySpotPrice fxSpotRate trade equitySpotPrice123 fxSpotRate123 trade123 tag456 equitySpotPrice trade equitySpotPrice123 trade123 Tag CF – New fxSpotRate column Taglet CF – New taglet equitySpotPrice123 equitySpotPrice/AAPL /equitySpotPrice/AAPL/v1 fxSpotRate123 fxSpotRate/GBP/USD fxSpotRate/JPY/USD /fxSpotRate/GBP/USD/v1 /fxSpotRate/JPY/USD/v1 trade123 trade/tradeId123 /trade/tradeId123/v1 fxSpotRate456 fxSpotRate/GBP/USD fxSpotRate/JPY/USD /fxSpotRate/GBP/USD/v2 /fxSpotRate/JPY/USD/v1
43. Equity Derivatives IT tag123 equitySpotPrice fxSpotRate trade equitySpotPrice123 fxSpotRate123 trade123 tag456 equitySpotPrice trade equitySpotPrice123 trade123 Tag CF – New fxSpotRate column Taglet CF – New taglet equitySpotPrice123 equitySpotPrice/AAPL /equitySpotPrice/AAPL/v1 fxSpotRate123 fxSpotRate/GBP/USD fxSpotRate/JPY/USD /fxSpotRate/GBP/USD/v1 /fxSpotRate/JPY/USD/v1 trade123 trade/tradeId123 /trade/tradeId123/v1 fxSpotRate456 fxSpotRate/GBP/USD fxSpotRate/JPY/USD /fxSpotRate/GBP/USD/v2 /fxSpotRate/JPY/USD/v1 fxSpotRate fxSpotRate456
44. Equity Derivatives IT DeltaTag - Valuing a portfolio Gallerify Create Tag Calculations 50sec 5sec 300sec Takes 355 seconds vs. 500 seconds 97%!
45. Equity Derivatives IT Tag data overlap Tag 1 Tag 2 Tag 3 Tag 4
46. Lessons Learned
47. Equity Derivatives IT Find a senior advocate
48. Equity Derivatives IT Measure all the things!
49. Equity Derivatives IT UAT everything
50. Equity Derivatives IT Take time to understand Cassandra
51. Equity Derivatives IT Questions?
