ROP Primer

A small presentation intended as an introduction to 32-bit return-oriented-program on Linux, with emphasis on CTF.

Transcript

1. BY @BARREBAS
   ROP PRIMER
   // CTF-TEAM.VULNHUB.COM


   View Slide

2. CONTENTS
   > THE NEED FOR ROP
   > ROP VS RET2LIBC
   > STRATEGIES
   > EXAMPLE: SHELLCODEME
   // CTF-TEAM.VULNHUB.COM


   View Slide

3. WHAT IS THIS ABOUT?
   > FOCUS ON BUFFER OVERFLOWS
   NOT ABOUT ALL KINDS OF VULNERABILITIES NOR AN
   INTRO INTO x86 ASSEMBLY
   RETURN-ORIENTED-PROGRAMMING IN CAPTURE THE
   FLAG CHALLENGES
   // CTF-TEAM.VULNHUB.COM


   View Slide

4. THE NEED FOR ROP
   CODE EXECUTION
   TO EXPLOIT, WE NEED
   > CONTROL OVER EIP


   View Slide

5. CODE EXECUTION
   OVERWRITE SAVED RETURN ADDRESS
   TO CONTROL EIP, WE CAN
   OVERWRITE GLOBAL OFFSET POINTER
   OR


   View Slide

6. CODE EXECUTION
   OVERFLOW A BUFFER ON THE STACK
   TO OVERWRITE SRA, WE MUST
   LET'S FOCUS ON BUFFER OVERFLOWS, THEY'RE
   EASIER TO EXPLAIN :)


   View Slide

7. EXECUTE SHELLCODE
   ON THE STACK
   HAVE TO STORE SHELLCODE
   SOME WRITABLE DATA SECTION
   OR


   View Slide

8. EXPLOIT MITIGATION
   SHELLCODE ON STACK
   SINCE NX/DEP: STACK = NON-EXECUTABLE
   BINARY WILL SEGFAULT AS SOON AS IT STARTS TO
   EXECUTE CODE FROM NON-EXECUTABLE MEMORY


   View Slide

9. WHAT IS ROP?
   > RETURN-ORIENTED-PROGRAMMING
   > RE-USE PIECES OF PROGRAM'S CODE SECTION
   >> CODE SECTION == EXECUTABLE
   // CTF-TEAM.VULNHUB.COM


   View Slide

10. ROP VS RET2LIBC
    > BOTH ROP AND RET2LIBC USE THE STACK TO
    CONTROL EXECUTION
    > TO EXECUTE CODE, WE'LL FAKE STACK FRAMES
    > FOR RET2LIBC, WE FAKE ONLY ONE STACK FRAME
    > ROP CAN USE THE SAME STACK FRAME
    LAYOUT TO FAKE CALLS!


    View Slide

11. LET'S LOOK AT RET2LIBC
    ASSUME LIBC ADDRESS IS STATIC (NO ASLR)
    OVERFLOW A FUNCTION POINTER OR SAVED RETURN
    ADDRESS WITH SYSTEM()
    SPAWN A SHELL
    CAT FLAG cat flag 2>&1
    /bin/sh


    View Slide

12. INTERMEZZO: BUFFER OVERFLOWS & RET2LIBC
    OBVIOUS VULNERABILITY


    View Slide

13. EXAMPLE
    ENABLE COREDUMPS ulimit -c unlimited
    CRASH THE BINARY & GENERATE CORE


    View Slide

14. GDB-PEDA IS OUR FRIEND
    BUT HOW?
    gdb ./vuln core
    START GDB
    USEFUL GDB-PEDA CMD: CHECKSEC
    WE HAVE OVERWRITTEN EIP WITH 'HHHH'


    View Slide

15. ANATOMY OF A BUFFER OVERFLOW
    objdump -d -M intel ./rop_example
    CALL: SUB ESP, 4
    MOV [ESP], EIP


    View Slide

16. THE STACK BEFORE THE CALL
    100
    CALL: SUB ESP, 4
    MOV [ESP], EIP
    112
    108
    104
    ESP
    < SOME VALUE
    < ARG1
    < ARG2
    < SOME VALUE


    View Slide

17. THE STACK AFTER THE CALL
    100
    CALL: SUB ESP, 4
    MOV [ESP], EIP
    112
    108
    104
    ESP < RETURN ADDR
    < ARG1
    < ARG2
    < SOME VALUE


    View Slide

18. MAIN() IS EXECUTED
    LEA: LOAD EFFECTIVE ADDRESS OF BUF
    BUF IS
    ON THE STACK!


    View Slide

19. THE STACK BEFORE READ()
    100
    132
    116
    BUF
    < RETURN ADDR
    ESP
    128


    View Slide

20. THE STACK AFTER READ()
    100
    132
    116
    BUF
    < HHHH
    ESP
    128
    < AAAABBBB....
    < EEEEFFFF....


    View Slide

21. MAIN() WANTS TO RETURN
    BUT WE HAVE
    OVERWRITTEN
    THE SAVED RETURN
    ADDRESS!


    View Slide

22. THE STACK BEFORE RET
    100
    132
    116
    BUF
    < HHHH
    ESP 128
    < AAAABBBB....
    < EEEEFFFF....
    RET: MOV EIP, [ESP]
    ADD ESP, 4


    View Slide

23. THE STACK AFTER RET
    100
    132
    116
    BUF
    < EIP = HHHH!
    ESP
    128
    < AAAABBBB....
    < EEEEFFFF....
    RET: MOV EIP, [ESP]
    ADD ESP, 4


    View Slide

24. EXECUTE OUR CODE
    BUT WE CAN RETURN-TO-LIBC
    echo 0 > /proc/sys/kernel/randomize_va_space
    DISABLE ASLR:
    STACK IS NOT EXECUTABLE


    View Slide

25. GRAB ADDR OF SYSTEM()
    > WE'RE GOING TO FAKE A CALL TO SYSTEM()
    > A ROP CHAIN LOOKS BASICALLY THE SAME
    HOW WOULD THE STACK LOOK?


    View Slide

26. THE STACK AFTER NORMAL CALL
    100
    112
    108
    104
    ESP < RETURN ADDR
    < ARG1
    < ARG2
    STACK LAYOUT AT TOP OF FUNCTION


    View Slide

27. RET2SYSTEM:THE STACK BEFORE RET
    100
    112
    108
    104
    ESP
    < FAKE RETURN ADDR
    < ARG1
    < SYSTEM()
    RET WILL TAKE VALUE FOR EIP OFF TOP OF STACK
    “/bin/sh”
    RET


    View Slide

28. 100
    112
    108
    104
    ESP < FAKE RETURN ADDR
    < ARG1
    < SYSTEM()
    IDENTICAL STACK LAYOUT AFTER 'NORMAL' CALL!
    “/bin/sh”
    RET2SYSTEM:THE STACK AFTER RET
    RET


    View Slide

29. STRATEGY
    > STORE ARGUMENT FOR SYSTEM() ON STACK
    > OVERWRITE SAVED RETURN ADDRESS
    > SETUP CORRECT STACK LAYOUT TO FAKE A CALL
    REMEMBER: ASLR IS OFF, STACK ADDR IS FIXED


    View Slide

30. EXPLOIT


    View Slide

31. #FAIL! DEBUG TIME
    USE THE COREDUMP, LUKE
    MAKE BINARY CRASH BEFORE SYSTEM() IS CALLED
    BY REPLACING THE ADDRESS WITH 'BBBB'


    View Slide

32. GDB'S STACK IS DIFFERENT
    LOCATION OF STACK IS DIFFERENT! UPDATE
    EXPLOIT WITH NEW POINTER


    View Slide

33. IT'S ALIVE!
    IMPORTANT: KEEP SHELL ALIVE WITH CAT
    (python exploit.py; cat) | ./vuln
    FAKE RETURN ADDR!
    BINARY STILL CRASHES:


    View Slide

34. ROP CHAINS CAN LOOK VERY SIMILAR TO THE
    STACK LAYOUT WE USED FOR RET2LIBC
    ROP >
    ^ RET2LIBC


    View Slide

35. RECYCLE CODE IN EXECUTABLE SECTIONS
    FUNCTIONS IN GLOBAL
    OFFSET TABLE
    CODE IN LIBRARIES
    (E.G. SYSTEM())
    GADGETS IN
    BINARY
    ASLR MIGHT BE A PROBLEM
    WE CAN RECYCLE ALL SORT OF CODE


    View Slide

36. ROP GADGETS: PUTTING THE R IN ROP
    ROP USES THE STACK EXTENSIVELY TO ACHIEVE
    > CONTROL OVER EIP VIA STATEMENTS
    > CONTROL OVER STACK
    RET
    CODE EXECUTION


    View Slide

37. A BINARY HAS MANY RETURN OPCODES
    > RETS ARE PRECEDED BY OTHER INSTRUCTIONS
    > GIVEN ENOUGH GADGETS, WE CAN DO ANYTHING...
    > PREFERABLY SOMETHING LIKE THIS
    cat flag # ;)


    View Slide

38. EXAMPLE GADGET FROM RANDOM BINARY
    > RETURN TO THIS GADGET TO SET SEVERAL REGISTERS
    > RET @ END MAKES SURE WE DON'T LOSE CONTROL
    > CORRESPONDING PYTHON CODE:


    View Slide

39. BUT THIS GADGET CONTAINS MORE GADGETS
    > WHAT IF WE RETURN TO 0x40196, IN THE MIDDLE OF
    THE STATEMENT?
    > WE END UP WITH A NEW GADGET:
    POP R12
    RECYCLING! =)


    View Slide

40. LOCATING GADGETS
    SEVERAL TOOLS EXIST
    ROPSHELL.COM
    GDB-PEDA
    MY OWN ROPGADGET.PY
    git clone https://github.com/longld/peda.git ~/peda
    echo "source ~/peda/peda.py" >> ~/.gdbinit


    View Slide

41. MANY STRATEGIES EXIST
    RE-USE OPEN/READ/WRITE TO GRAB THE FLAG
    MAKE MEMORY WRITEABLE & EXECUTABLE
    TWO EXAMPLES:


    View Slide

42. ROP EXAMPLE - SHELLCODEME
    WHAT ARE WE UP AGAINST?
    OBVIOUS VULNERABILITY =)


    View Slide

43. ROP EXAMPLE - SHELLCODEME
    # disassemble binary
    $ objdump -d -M intel ./shellcodeme > shellcodeme.out
    FIRST, DISASSEMBLE BINARY
    LAUNCH GDB & OVERFLOW THAT BUF!


    View Slide

44. TRICKY STACK LAYOUT
    RESTORE THE STACK SO THAT ESP POINTS TO INPUT
    INSPECT REGISTERS!
    EBP POINTS TO
    INPUT+16


    View Slide

45. MAKE ESP POINT TO INPUT
    USE THE LEAVE OPCODE
    LEAVE: MOV ESP, EBP; POP EBP
    I USUALLY AVOID GADGETS WITH LEAVE, BECAUSE IT
    MESSES UP ESP AND CAUSES LOSS OF CONTROL OVER EIP


    View Slide

46. FIRST ROP GADGET
    BOOM


    View Slide

47. TAKE A STEP BACK
    HOW ARE WE GOING TO EXPLOIT THIS WITH ROP?
    THE BINARY ALREADY HAS TWO USEFUL FUNCTIONS:
    MPROTECT & READ


    View Slide

48. MPROTECT CHANGES MEMORY
    PROTECTION FLAGS
    LET'S USE MPROTECT TO MAKE A
    SECTION OF MEMORY EXECUTABLE


    View Slide

49. HIGH-LEVEL EXPLOIT OVERVIEW
    WE'LL BUILD A ROP CHAIN TO 'CALL' MPROTECT
    TO MAKE A SECTION OF MEMORY RWX
    THEN, 'CALL' READ TO READ STANDARD SHELLCODE
    FROM STDIN
    FINALLY, WE'LL RETURN TO OUR NEWLY READ
    SHELLCODE & SPAWN A SHELL
    MPROTECT
    READ


    View Slide

50. LET'S START WITH MPROTECT
    THE ADDRESS OF MPROTECT WAS TAKEN FROM THE
    DISASSEMBLY OUTPUT


    View Slide

51. RUN IT LIVE IN GDB
    STORE OUTPUT OF ROP1.PY IN FILE
    $ python rop1.py > in
    RUN GDB-PEDA
    $ gdb ./shellcodeme
    START PROGRAM AND USE INPUT FROM FILE
    gdb-peda$ r

    View Slide

52. SUCCESS!
    EIP='FAKE'
    VMMAP >
    ^ 0x20000000 = RWX!


    View Slide

53. WHAT ABOUT THE NEXT STEP?
    STACK LOOKS LIKE THIS:
    SOLUTION: POP POP POP RET
    > EACH POP WILL ADD 4 TO ESP
    > FINAL RET WILL PICK UP THE ADDRESS
    OF THE NEXT GADGET FROM THE STACK


    View Slide

54. USING GDB-PEDA TO LOCATE PPPR
    gdb-peda$ ropgadget
    GDB LOCATED SEVERAL GADGETS
    WE'LL USE 0x804855D


    View Slide

55. UPDATE THE POC & RUN IT
    $ python rop1.py > in
    $ gdb ./shellcodeme
    gdb-peda$ r BOOM


    View Slide

56. ADD IN READ()
    SUPPLY “SHELLCODE” CONSISTING OF INT 3
    INT 3


    View Slide

57. MOMENT OF TRUTH
    & RUN THE EXPLOIT:
    GRAB SOME SHELLCODE TO SPAWN A SHELL


    View Slide

58. MOMENT OF TRUTH
    & RUN THE EXPLOIT:
    GRAB SOME SHELLCODE TO SPAWN A SHELL


    View Slide

59. SHELL HAS LANDED!


    View Slide

60. THANKS
    TEAM MEMBERS: NULLMODE, SUPERKOJIMAN, SWAPPAGE,
    BITVIJAYS, ET0X, HISTORYPEATS
    SHOUT-OUTS TO G0TMI1K, LEONJZA, RASTA_MOUSE &
    HIGHJACK FOR GOING THROUGH THIS PDF & GIVING FEEDBACK!
    IMAGES USED:
    ROPE: HiveHarbingerCOM // LINK
    SHELL: Chris 73 // LINK
    RECYCLING SIGN: JoseDLF // LINK


    View Slide

61. ROP PRIMER
    // CTF-TEAM.VULNHUB.COM
    BY @BARREBAS // BARREBAS.GITHUB.IO
