Physical Computing with Python and Raspberry Pi - EuroPython 2017

Transcript

1. 1.

   Physical computing with Python and Raspberry Pi Ben Nuttall Raspberry

   Pi Foundation UK Charity 1129409
2. 2.

   Ben Nuttall • Raspberry Pi Community Manager • Based in

   Cambridge, UK • Creator of gpiozero python library • Columnist on opensource.com • github.com/bennuttall • twitter.com/ben_nuttall • ben@raspberrypi.org
3. 3.

   Over 14 million Raspberry Pis sold

4. 4.

   Raspberry Pi Foundation • Educational charity founded in 2009 •

   Incorporates: – Raspberry Pi Trading Ltd – Code Club – CoderDojo • Trading profits fund education programmes raspberrypi.org/about
5. 5.

   Our mission “Putting the power of digital making into the

   hands of people all over the world” So that people are: • Capable of understanding and shaping an increasingly digital world • Able to solve the problems that matter to them, both as makers and entrepreneurs • Equipped for the jobs of the future raspberrypi.org/about
6. 6.

   We do this by providing... • Low-cost, high-performance computers •

   Outreach and education programmes • Free resources and teacher training p
7. 7.

   Current models • Raspberry Pi 3 • 64-bit quad-core ARMv8

   @ 1.2GHz • 1GB RAM • $35 • Raspberry Pi Zero / Zero W • 32-bit single-core ARMv6 @ 1GHz • 512MB RAM • $5 / $10 raspberrypi.org/products
8. 8.

   Raspbian Jessie desktop raspberrypi.org/downloads

9. 9.

   Raspbian x86 rpf.io/x86

10. 10.

    Moving on from IDLE... • We have included a new

    IDE called Thonny • We are investing in developing Nicholas Tollervery’s Mu editor – watch this space! ntoll.org/article/mu-pi
11. 11.

    GPIO Pins – General Purpose Input/Output

12. 12.

    Physical computing • Flashy lights • Motors & robots •

    Photo & video • Sensors • Internet of Things • Home automation
13. 13.

    GPIO • 3V3, 5V • GPIO, SPI, I2C, UART •

    GPIO = variable 3V3 pinout.xyz
14. 14.

    GPIO components

15. 15.

    Add-on boards / HATs

16. 16.

    Python - RPi.GPIO import RPi.GPIO as GPIO from time import

    sleep GPIO.setmode(GPIO.BCM) GPIO.setwarnings(False) GPIO.setup(17, GPIO.OUT) while True: GPIO.output(17, GPIO.HIGH) sleep(1) GPIO.output(17, GPIO.LOW) sleep(1)
17. 17.

    Python - GPIO Zero from gpiozero import LED from time

    import sleep led = LED(17) while True: led.on() sleep(1) led.off() sleep(1)
18. 18.

    Python - GPIO Zero from gpiozero import LED led =

    LED(17) led.blink()
19. 19.

    GPIO Zero supports...

20. 20.

    GPIO Zero Device Hierarchy!

21. 21.

    Multi-paradigm: procedural from gpiozero import LED, Button led = LED(17)

    button = Button(4) while True: if button.is_pressed: led.on() else: led.off()
22. 22.

    Multi-paradigm: event-driven from gpiozero import LED, Button led = LED(17)

    button = Button(4) button.when_pressed = led.on button.when_released = led.off
23. 23.

    Multi-paradigm: declarative from gpiozero import LED, Button led = LED(17)

    button = Button(4) led.source = button.values
24. 24.

    .value >>> led = PWMLED(17) >>> led.value 0.0 >>> led.on()

    >>> led.value 1.0 >>> led.value = 0
25. 25.

    .value >>> led = PWMLED(17) >>> pot = MCP3008() >>>

    led.value = pot.value
26. 26.

    .value >>> led = PWMLED(17) >>> pot = MCP3008() >>>

    led.value = pot.value >>> while True: ... led.value = pot.value
27. 27.

    Source / Values Output Device .value .values .source Input Device

    .value .values
28. 28.

    Source / Values Output Device .value .values .source Input Device

    .value .values
29. 29.

    Source / Values from gpiozero import LED, Button led =

    LED(17) button = Button(2) led.source = button.values
30. 30.

    Processing values Output Device .value .values .source Input Device .value

    .values function
31. 31.

    Source tools from gpiozero import Button, LED from gpiozero.tools import

    negated led = LED(4) button = Button(17) led.source = negated(button.values)
32. 32.

    Combining values Output Device .value .values .source Input Device .value

    .values Source tool Input Device .value .values
33. 33.

    AND logic gate from gpiozero import Button, LED from gpiozero.tools

    import all_values button_a = Button(2) button_b = Button(3) led = LED(17) led.source = all_values(button_a.values, button_b.values)
34. 34.

    CPU Temperature from gpiozero import LEDBarGraph, CPUTemperature cpu = CPUTemperature(min_temp=50,

    max_temp=90) leds = LEDBarGraph(2, 3, 4, 5, 6, 7, 8, pwm=True) leds.source = cpu.values
35. 35.

    Is the internet working? from gpiozero import LED, PingServer from

    gpiozero.tools import negated green = LED(17) red = LED(18) google = PingServer('google.com') green.source = google.values green.source_delay = 60 red.source = negated(green.values)
36. 36.

    Energenie

37. 37.

    Energenie tortoise lamp from gpiozero import Energenie, TimeOfDay from datetime

    import time lamp = Energenie(1) daytime = TimeOfDay(time(8), time(20)) lamp.source = daytime.values
38. 38.

    Supporting multiple pin libraries • RPi.GPIO • Implemented in C,

    current default • Available in PyPI & apt repository (installed by default in Raspbian) • RPIO • Implemented in C, supports hardware PWM, supports Pi 1 only (dead project) • Available in PyPI • pigpio • Python wrapper for C library, supports lots of protocols, runs as daemon, supports remote connections • Available in PyPI & apt repository (installed by default in Raspbian) • Native • Pure Python, limited functionality, experimental • Included in gpiozero source • MockPin & MockPWMPin • Pure Python, used in test suite • Included in gpiozero source
39. 39.

    pigpio - remote GPIO from Pi or PC

40. 40.

    pigpio - remote GPIO from Pi or PC from gpiozero

    import LED from gpiozero.pins.pigpio import PiGPIOFactory from signal import pause factory = PiGPIOFactory('192.168.0.2') led = LED(22, pin_factory=factory) led.blink() pause()
41. 41.

    pigpio - remote GPIO from Pi or PC $ export

    GPIOZERO_PIN_FACTORY=pigpio $ export PIGPIO_ADDR=192.168.0.2 $ python3 led.py from gpiozero import LED from signal import pause led = LED(22) led.blink() pause()
42. 42.

    MockPin $ GPIOZERO_PIN_FACTORY=mock python3 >>> from gpiozero import LED >>>

    led = LED(22) >>> led.blink() >>> led.value True >>> led.value False
43. 43.

    MockPin >>> from gpiozero import LED >>> led = LED(22)

    >>> button = Button(23) >>> led.source = button.values >>> led.value False >>> button.pin.drive_low() >>> led.value True
44. 44.

    pinout command line tool

45. 45.

    Sense HAT • Special made for Tim Peake's Astro Pi

    mission • Sensors, LED display & joystick • Great for science, games and creativity • Works on any Pi model • Emulators also available raspberrypi.org/products/sense-hat
46. 46.

    Sense HAT

47. 47.

    Sense HAT >>> from sense_hat import SenseHat >>> sense =

    SenseHat() >>> sense.show_message(“Hello world”)
48. 48.

    Sense HAT >>> sense.temperature 25.0 >>> sense.humidity 45.0 >>> sense.accelerometer

    {'pitch': 0.0, 'roll': 0.0, 'yaw': 0.0} >>> sense.gyroscope {'pitch': 0.0, 'roll': 0.0, 'yaw': 0.0} >>> sense.orientation {'pitch': 0.0, 'roll': 0.0, 'yaw': 0.0}
49. 49.

    Sense HAT from sense_hat import SenseHat sense = SenseHat() while

    True: r = 255 * sense.humidity / 100 sense.clear(r, 0, 0) pythonhosted.org/sense-hat
50. 50.

    Astro Pi: Your code in space astro-pi.org

51. 51.

    Sense HAT Web Emulator trinket.io/sense-hat

52. 52.

    Sense HAT Desktop Emulator sense-emu.readthedocs.io

53. 53.

    Picamera • 8 megapixels (v2) – v1 was 5mpx •

    Visible light & infra-red versions available • 1080p30, 720p60 and VGA90 video • Command line interface and Python library raspberrypi.org/products/camera-module-v2
54. 54.

    Picamera - capture from picamera import PiCamera from time import

    sleep camera = PiCamera() camera.start_preview() sleep(3) camera.capture('/home/pi/Desktop/image.jpg') camera.stop_preview()
55. 55.

    Picamera – record video from picamera import PiCamera from time

    import sleep camera = PiCamera() camera.start_preview() camera.start_recording('/home/pi/video.h264') sleep(10) camera.stop_recording() camera.stop_preview()
56. 56.

    Picamera + GPIO push button from picamera import PiCamera from

    gpiozero import Button camera = PiCamera() button = Button(17) camera.start_preview() button.wait_for_press() camera.capture('/home/pi/Desktop/image.jpg') camera.stop_preview()
57. 57.

    Picamera image effects from picamera import PiCamera from time import

    sleep camera = PiCamera() camera.start_preview() for effect in camera.IMAGE_EFFECTS: camera.image_effect = effect camera.annotate_text = effect sleep(1) camera.stop_preview()
58. 58.

    Picamera image effects

59. 59.

    Web Streaming github.com/waveform80/pistreaming

60. 60.

    Picamera + OpenCV pyimagesearch.com

61. 61.

    Read the docs! • gpiozero.readthedocs.io • pythonhosted.org/sense-hat • sense-emu.readthedocs.io •

    picamera.readthedocs.io
62. 62.

    Google AIY Projects kit • Free with The MagPi #57

    • Google Voice HAT + speaker • Google assistant • Write code to process custom voice commands – “Lights on” – “Robot go forward” – “Take a picture” aiyprojects.withgoogle.com
63. 63.

    PyPI & ARM Wheels • PyPI doesn’t support uploading ARM

    wheels :( • I have a project called piwheels – I build all PyPI packages on a Raspberry Pi 3 – I host a Python package repository on the same Pi • Next gen PyPI (warehouse) now supports uploading ARM wheels :) • See my lightning talk slides at speakerdeck.com/bennuttall • See the project at github.com/bennuttall/piwheels github.com/bennuttall/piwheels
64. 64.

    How you can get involved...

65. 65.

    Python libraries • Play with, and contribute to: – gpiozero

    – picamera – sense hat – more! • Help maintainers upgrade modules to Python 3 • Create your own Python libraries for Raspberry Pi things
66. 66.

    The MagPi • Community magazine established in 2012 (as free

    PDF download) • Now the official Raspberry Pi magazine • Paper copies on sale in UK/US shops and online • Still a free PDF download • Occasionally comes with a free computer • Book series (also available for free) raspberrypi.org/magpi
67. 67.

    Raspberry Jam • Independently organised community events • Family-friendly •

    Mix of meetup / conference / workshop styles • Raspberry Jam Guidebook and more resources available • Contact me about setting one up! raspberrypi.org/jam
68. 68.

    Raspberry Jam near you? raspberrypi.org/jam

69. 69.

    Code Club • Free volunteer-led after school clubs for children

    • Projects provided using Scratch, HTML and Python • Training and support provided for volunteers • Help translating materials codeclubworld.org
70. 70.

    Physical computing with Python and Raspberry Pi Ben Nuttall Raspberry

    Pi Foundation UK Charity 1129409
